INSTRUCTION MANUAL
FOR REFRIGERATOR-
FREEZER

2
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at temperatures above 0°C.
The freezer is intended for freezing fresh food and for long-term storage of
frozen food (up to one year, depending on the type of food).
Please visit our website where you can enter your appliance model number,
indicated on the rating plate or the warranty sheet, to find detailed description
of your appliance, tips on use, troubleshooting, service information, instructions
for use etc.
http://www.gorenje.com
Important safety warning
!

3
CONTENTS
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 SAFETY AND WARNING INFORMATION
11 INSTALLING YOUR NEW APPLIANCE
13 APPLIANCE DESCRIPTION
15 CHANGING THE DOOR OPENING DIRECTION
21 OPERATING THE APPLIANCE
25 USING YOUR APPLIANCE
29 HELPFUL HINTS AND TIPS
31 CLEANING AND CARE
32 TROUBLESHOOTING
34 DISPOSAL OF THE APPLIANCE
MISCELLANEOUS

4
IMPORTANT NOTES AND
PRECAUTIONS
For your safety and correct usage, before installing and
first using the appliance, read this user manual carefully,
including its hints and warnings. To avoid unnecessary
mistakes and accidents, it is important to make sure that all
people using the appliance are thoroughly familiar with its
operation and safety features. Save these instructions and
be sure that they remain with the appliance if it is moved
or sold, so that anyone using it throughout its life, will be
properly informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
SAFETY AND WARNING
INFORMATION
!

5
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Keep all packaging away from children as there is risk of
suffocation.
• If you are discarding the appliance, pull the plug out of
the socket, cut the connection cable (as close to the
appliance as you can) and remove the door to prevent
children playing from suffering an electric shock or from
closing themselves inside it. I
• f this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on
the door or lid, be sure to make the spring lock unusable
before you discard the old appliance. This will prevent it
from becoming a death trap for a child.
General safety
• WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
!

6
• WARNING — Do not store explosive substances such
as aerosol cans with a flammable propellant in this
appliance.
• WARNING — If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• WARNING — Do not damage the refrigerant circuit.
• WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
• WARNING — The refrigerant and insulation blowing
gas are flammable. When disposing of the appliance,
do so only at an authorized waste disposal centre. Do
not expose to flame. WARNING —When positioning
the appliance, ensure the supply cord is not trapped or
damaged.
• WARNING —Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
Replacing the LED
• WARNING—The LED light must not be replaced by the
user! If the LED light is damaged, contact the customer
helpline for assistance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless

7
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
• WARNING — Refrigerators contain refrigerant andgases
in the insulation. Refrigerant and gases must be disposed
of professionally as they may cause eye injuries or
ignition. Ensure that tubing of the refrigerant circuit is
not damage prior to proper disposal.
WARNING! Risk of fire/flammable materials.
If the refrigerant circuit should be damaged:
• Avoid opening flames and sources of ignition.
• Thoroughly ventilate the room in which the appliance is
situated.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire, and/
or electric shock.
!Electrical safety
• The power cord must not be lengthened.
• Make sure that the power plug is not crushed or
damaged. A crushed or damaged power plug may
overheat and cause a fire.
• Make sure that you can access the main plug of the
appliance.
• Do not pull the main cable.
• If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.

8
• You must not operate the appliance without the interior
lighting lamp cover.
• The fridge is only applied with power supply of single
phase alternating current of 220~240V/50Hz. If
fluctuation of voltage in the district of user is so large
that the voltage exceeds the above scope, for safety
sake, be sure to apply A.C. Automatic voltage regulator
of more than 350W to the fridge. The fridge must
employ a special power socket instead of common one
with other electric appliances. Its plug must match the
socket with ground wire.
Daily use
• Do not store flammable gass or liquids in the appliance,
There is a risk of an explosion.
• Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
• When unplugging always pull the plug from the mains
socket,do not pull on the cable.
• Do not place hot items near the plastic components of
this appliance.
• Do not place food products directly against the air outlet
on the rear wall.
• Store pre-packed frozen food in accordance with the
frozen food manufacture’s instructions.
• The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant
instructions for storage.
• Do not place carbonated or fizzy drinks in the
freeze compartment as it creates pressure on the
container,which may cause it to explode,resulting in
damage to the appliance.
• Frozen food can cause frost burns if consumed straight
from the freezer compartment.
• Do not place the appliance in direct sunlight.

9
• Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
• The appliance is intended for keeping food stuff and/
or beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should
be taken when moving it.
• Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could
cause skin abrasions or frost/freezer burns.
• Never use the base,drawers, doors etc. to stand on or as
supports.
• Frozen food must not be refrozen once it has been
thawed out.
• Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
• To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
• WARNING - Food needs to be packed into bags before
it is put into the refrigerator. Liquids need to be stored in
bottles or capped containers in order to avoid a spill, as
the design structure of the product is not easy to clean.
caution!
Care and cleaning
• Before maintenance, switch off the appliance and
disconnect the mains plug from the mains socket.
• Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
• Do not use sharp objects to remove frost from the
appliance. Use a plastic scraper.

10
Installation Important!
• For electrical connection carefully, follow the instructions
given in this manual.
• Unpack the appliance and check if there are damages on
it. Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought
it. In this case retain packing.
• It is advisable to wait at least four hours before
connecting the appliance to allow the oil to flow back in
the compressor.
• Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be
too close to a wall to avoid touching or catching warm
parts (compressor, condenser) to prevent the risk of a
fire, follow the instructions relevant to installation.
• The appliance must not be locate close to radiators or
cookers.
• Make sure that the mains plug is accessible after the
installation of the appliance
Service
• Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
• This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1) If the appliance is Frost Free.
2) If the appliance contains freezer compartment.

11
INSTALLING YOUR NEW
APPLIANCE
• Before using the appliance for the first time, you should review the following tips.
Ventilation of appliance
In order to improve eciency of the cooling system and save energy, it is
necessary to maintain good ventilation around the appliance for the dissipation
of heat. For this reason, sucient clear space should be available around the
refrigerator.
Suggest: It is advisable for there to be 50-70 mm of space form the back to the
wall, at least 100 mm from its top, at least 100 mm from its side to the
wall and a clear space upfront to allow the doors to open 115°.
Please see the following diagrams
B
≥100
C
≥100
A
50-70mm
115°
1150
A B C
Without handle 660 880 1210
With handle 708 925 1220
Technical characteristics
A Depth (door clsoed)
B Width
C Depth (door opened)

12
Note:
• This appliance performs well within the climate class showed in the table
below. It may not work properly if being left at a temperature above or below
the indicated range for a long period.
Class Temperature
SN from +10 °C to +32 °C
N from +16 °C to +32 °C
ST from +16 °C to +38 °C
• Stand you appliance in a dry place to avoid damage moisure.
• Keep the appliance out of direct sunlight, rain or frost. Stand the appliance
away from heat sources such as stoves, fires or heaters.
Leveling of appliance
• For sucient leveling and air circulating in the lower rear section of the
appliance, the bottom feet may need to be adjusted, You can adjust them by
your fingers or a suitable spanner.
• To allow the doors to self-close, tilt back the top backwards for abaut 10 mm.
İ
İ
1
1
0
0
m
m
m
m

13
APPLIANCE DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1. LED light
2. Door switch
3. Glass shelf
4. Fridge wind channel
5. Control panel
6. Crisper cover
7. Crisper
8. Upper freezer drawer
9. Middle freezer drawer
10.Lower freezer drawer
11. Adjustable bottom foot
12.Upper rack
13.Lower rack
14.Fridge gasket
15.Fridge door
16.Freezer wind channel
17.Freezer gasket
18.Freezer door
Note: Due to unceasing modification of our products, your refrigerator may
be slightly dierent from this instruction manual, but its functions and using
methods remain the same.
View of the appliance (control panel)

14
1
2
3
4
5
6
7
8
9
10
13
14
15
11
12
16
17
1. Display panel
2. Door switch
3. Glass shelf
4. Crisper cover
5. Crisper
6. Upper freezer drawer
(Serving tray optional)
7. Middle freezer drawer
8. Lower freezer drawer
9. Adjustable bottom foot
10.Upper rack
11. Fridge wind channel
12.Fridge gasket
13.Lower rack
14.Fridge door
15.Freezer door
16.Freezer gasket
17.Freezer wind channel
Note: Due to unceasing modification of our products, your refrigerator may
be slightly dierent from this instruction manual, but its functions and using
methods remain the same.
View of the appliance (display panel)

15
CHANGING THE DOOR OPENING
DIRECTION
The side at which the door opens can be changed, from the right side (as
supplied) to the left side, if the installation site requires.
Warning! When reversing the door, the appliance must not be connected to the
mains. Ensure that the plug is removed from the mains socket
Tools you will need.
8mm socket wrench Thin-blade
screwdriver Putty knife
Cross-shaped
screwdriver Monkey
wrench 8mm wrench
Additional parts (in the plastic bag)
Door stopper-left
Note: If required you may lay the refrigerator on its back in order to gain access
to the base, you should rest it on soft foam packaging or similar material to
avoid damaging the backboard of the refrigerator. To reverse the door, the
following steps are generally recommended.

16
1. Stand the refrigerator upright. Open the upper door to take out all door racks
(to avoid damage) and then close the door.
2. Remove part (1), then take down part (2) from the top right side of
refrigerator. Unscrew screws (3) by a 8 mm socket driver or a spanner, and
remove hinge (4). Please hold upper door by hand when installing. Use a putty
knife or thin-blade screwdriver to lever part (5) which is at the top left corner
of the refrigerator.
③
①
②
④
⑤
3.Remove the upper door from the middle hinge by carefully lifting the door
straight up. Then place the upper door on a smooth surface with its upper
cover upwards.

17
4.Loose screw (3) and take down part (2) and part (1), Install replacement door
stopper-left (4) (provided in the plastic bag) and part (2) (stop block) to the
left side with screw (3). Keep part (1) with the appliance for future reference.
①②③
④
1 Door stopper
2 Stop block
3 Self tapping
screw
4 Door stopper-
left
5.Unscrew the two special flange self-tapping screws which are used for fixing
the middle hinge part, then remove the middle hinge part that hold the lower
door in place.
NOTE: When removing the door, watch for washer(s) between the lower hinge
and the bottom of the lower door that may stick to the door. Do not lose.
6.Place the lower door on a smooth surface with its panel upwards. Loose
screw (3) and take down part (1) and part (2), then Install door stopperleft (4)
(provided in the plastic bag) and left part (2) and screw (3) to the left side and
tighten them securely.Keep part (1) with the appliance for future reference.
①
②
③
④
1 Door stopper
2 Stop block
3 Self tapping
screw

18
7. Change screw hole covers on middle cover plate from left to right (as shown in
figure below).
screw hole covers screw hole covers
8.Lay the refrigerator on soft foam packaging or similar material. Remove both
adjustable bottom feet parts, and the lower hinge part by unscrewing the
special flange self-tapping screws.
①
②
③
1 Adjustable bottom feet part
2 Lower hinge part (right)
3 Self tapping screws
9.Remove part (1) from the lower hinge part(right), loose out the lower hinge
pin, change it to the reverse hole site, and then tighten into position, then
install part (1) on the lower hinge pin.
①
10.Change screw hole covers on lower cover plate from left to right (as shown in
figure below).
screw hole covers screw hole covers

19
11.Replace the lower hinge part to the left side and fixing it with the special
flange self-tapping screws. Replace the adjustable bottom feet parts to
another side and fixing it.
12.Transfer the lower door to the property position, adjust the lower hinge part,
make the hinge axis into the lower hole of the lower door, then tight the bolts.
13.Slot the lower door onto the bottom hinge pin and hold in position. Turn the
middle hinge by 180°, change the washer on the axis to the lower side, adjust
the middle hinge to the appropriate position and then install it ensuring the
lower door in secured in place.
middle hinge part
self-tapping screw
Note: washer may
stick to lower door washer

20
14.Transfer the upper door to the appropriate position. Secure the door`s level,
make the middle hinge axis into the lower hole of the upper door.
15.Move the upper door to an appropriate position, and then fix part (4) by
screws (3).(Please hold the upper door by hand when installing).Install the
upper hinge cover (2) on the left corner by screw (1). Install the screw hole
cover (5) on the top right corner of the refrigerator.
③
①
②
④
⑤
1 Self-tapping screw
2 Upper hinge cover
3 Special flange screw
4 Upper hinge
5 Screw hole cover
16.Open the upper door and install the door racks and then close it.
Note: If your appliance has handle, you have to reverse handle by follow
instructions below. Remove the upper door and place it on a smooth surface
with its panel upwards. Lever part (1) and part (4), then loose screws (2).
Change handle (3) to the right side, then install screws (2), part (1) and part
(4) in turn.
1 Handle covers
2 Special screws
3 Handle
4 Screw hole cover
Warning! When changing the side at which the door opens, the appliance
must not be connected to the mains. Remove plug from the mains beforehand.
