GPX MOTO GPX 450R FSE User guide

GPX MOTO
- 1 -
www.GPXMOTO.com + www.GPXMOTOUK.com
GPX MOTO
GPX 450R FSE
Owners Handbook
WWW.GPXMOTO.COM
WWW.GPXMOTOUK.COM

GPX MOTO
www.GPXMOTO.com + www.GPXMOTOUK.com
- 2 -
ADVICE
Motorcycles are very dangerous. Check your motorcycle carefully before every ride to ensure
everything is working correctly. Do not ride if you are under the influence. If you cannot ride a
motorcycles , do not ride a motorcycle. Its your life and wellbeing so be careful with it.
Most of off-road motorcycle fatalities are caused by head injuries. Without helmets, the chances of
serious injury or death caused by head injuries are much higher. Always wear an approved
motorcycle helmet and protective apparel such as goggles, gloves , knee and elbow protectors and
boots while riding, which will save your life at the critical moment.
This motorcycle was designed for off road racing , therefore there is no capacity to carry a
passenger .Please therefore do not use this motorcycle to carry any passengers. Ignoring this or order
rules could lead to serious injury or a fatality.
Always go riding with another person so you can help each other.
Do not use non-original parts to modify this motorcycle. If you need to replace any parts, please use
spare parts and accessory products that are approved and / or recommended by GPX and have them
installed by an authorized GPX workshop. GPX accepts no liability for any personal modification,
other products and any resulting damage or loss.
Our GPX series products are specially designed for off-road racing and riding.
Please take care of your vehicle and avoid any problem caused by improper use.
Please check your motorcycle carefully before riding and do the maintenance accordingly after use.
If you crash the motorcycle, check the condition of the motorcycle before you resume your journey.
Ignoring this advice could easily lead to an accident and endanger your own safety as well as others ,
as you may be riding a broken or faulting motorcycle .
When using this motorcycle, the temperature of the engine and exhaust pipe is very high, so it needs
to a period to cool down after parking. During this period, do not touch the engine or exhaust pipe as
you will scold yourself.
Do not wear shorts while riding, otherwise leg injuries may happen.
APPEARANCE
GPX 450R FSE COMPONENTS AND POSITIONS

GPX MOTO
www.GPXMOTO.com + www.GPXMOTOUK.com
- 3 -
No.
Name
No.
Name
1
Front mudguard
11
Front brake hose
2
Clutch lever
12
Engine sump shield
3
Coolant overflow tank
13
Electric starter motor
4
Petrol cap and tank vent hose
14
Front sprocket
5
Seat
15
Side stand
6
Rear mudguard
16
Air box cover
7
Rear light and no plate mount
17
Drive chain
8
Front brake cover
18
Rear sprocket
9
Front suspension compression adjustment
10
Front brake caliper

GPX MOTO
www.GPXMOTO.com + www.GPXMOTOUK.com
- 4 -
No.
Name
No.
Name
19
Rear brake disc and caliper
30
Rear suspension rebound adjustment
20
Exhaust silencer
31
Oil level window
21
Rear suspension compression adj
32
Rear brake lever
22
Radiator cap
33
Oil filter access
23
Front suspension rebound adjustment
34
Oil strainer access
24
Throttle
35
Sump shield
25
Front brake lever
36
Front fork protector
26
Front LED light
37
Front suspension compression adjuster
27
Rear wheel spindle
38
Front wheel spindle
28
Chain adjustment
39
Front exhaust
29
Rear suspension height adjustment
Tips and Tricks and keep your GPX 450R FSE FSE in tip top condition.
Following these tips will help to serve you with a reliable and long lasting motorcycle

GPX MOTO
www.GPXMOTO.com + www.GPXMOTOUK.com
- 5 -
1. Read this handbook !
2. So you don’t forget and over run ,keep your own dated and mileage recorded list of when you carried
out this maintenance. Showing this record and keeping oil and parts receipts to a buyer in the future
will help to prove you have looked after your GPX.
3. Clean the air filter and lubricate this with air filter oil after each 4 hours of riding or each competition.
4. Check and adjust your engine oil level before each ride.
5. Use good quality fully synthetic 10W/40 motorcycle oil (full specification beneath)
6. Change your engine oil , paper filter and clean the oil strainers every 10 hours of riding or after each
competition.
7. Check / adjust and lubricate your chain before each and every ride.
8. Wash your bike propertly and carefully. Avoid the air box, carburetor ,fuel tank vent hose, bearings
and electrical connector and components.
9. Dry your motorcycle after you wash. Use an air line , paper or cotton towels or a leaf blower if you
have one. Start at the top and down downwards towards the floor, drying the wheels last.
10. If you are not confident or don’t know how to maintain a motorcycle speak to your dealer, or seasoned
motorcycle mechanics , not your neighbour .
11. Lightweight dirtbikes are not like cars.They need adjusting , tweaking and maintaining regularly. Its
just part of the fun. Speak to your dealer if you want reliable advice.
12. Check you brakes , throttle and clutch before each ride. Be safe.
13. If your unsure about anything …STOP and get good advice.
VIN CODE
Vin code of the GPX 450R FSE ,is located on the head
stock.
CHASSIS NUMBER
