Graco SERIES F User manual

306–788
Rev. G
Supersedes Rev. F
First choice when
quality counts. 
INSTRUCTIONS-PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
DIRECTIONAL
Spray Nozzle Adapters
3000 psi (21.0 MPa) (210 bar) Maximum Working Pressure
Fits Automatic and Hand-held Hydra-Spray

, Airless Spray Guns
* Spray tip not included. Order separately .
Model 206–235, Series F
Single Nozzle*
Model 206–236 , Series F
Dual Nozzle*
06415
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1997, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001

 
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Numbers 12. . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury .

This equipment is for professional use only .

Read all instruction manuals, tags, and labels before operating the equipment.
 Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor .

Do not alter or modify this equipment.
 Check equipment daily . Repair or replace worn or damaged parts immediately .
 Do not exceed the maximum working pressure stated for your equipment. Do not exceed the
maximum working pressure of the lowest rated component in your system.
 Handle hoses carefully . Do not pull on hoses to move equipment.
 Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 66  C (150  F) or below –40  C (–40 F).
W
ear hearing protection when operating this equipment.
 Comply with all applicable local, state, and national fire, electrical, and safety regulations.


WARNING
INJECTION HAZARD
Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely
serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also
cause serious injury .

Fluid injected into the skin is a serious injury . The injury may look like just a cut, but it is a serious
injury . Get immediate medical attention.
 Do not point the gun at anyone or at any part of the body .
 Do not put your hand or fingers over the spray tip.
 Do not stop or deflect leaks with your hand, body , glove or rag.
 Always have the tip guard and the trigger guard on the gun when spraying.
 Be sure the gun trigger safety operates before spraying.
 Lock the gun trigger safety when you stop spraying.
 Follow the Pressure Relief Procedure on page 6 if the spray tip clogs and before cleaning,
checking or servicing the equipment.
T ighten all fluid connections before operating the equipment.
 Check the hoses, tubes, and couplings daily . Replace worn, damaged, or loose parts immediately .

4 306-788
WARNING
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and re -
sult in a fire or explosion and serious injury .
 Ground the equipment and the object being sprayed. Refer to Grounding in your separate equip -
ment manuals.
 If there is any static sparking or you feel an electric shock while using this equipment, stop spray-
ing immediately . Do not use the equipment until you identify and correct the problem.
 Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
 Keep the spray area free of debris, including solvent, rags, and gasoline.
 Before operating this equipment, electrically disconnect all equipment in the spray area.
 Before operating this equipment, extinguish all open flames or pilot lights in the spray area.
 Do not smoke in the spray area.
 Do not turn on or of f any light switch in the spray area while spraying or while operating if fumes
are present.
 Do not operate a gasoline engine in the spray area.
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
 Know the specific hazards of the fluid you are using.
 Store hazardous fluid in an approved container . Dispose of hazardous fluid according to all local,
state and national guidelines.
 Always wear protective eyewear , gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer .

5306-788
Installation
General Information
WARNING
To reduce the risk of serious injury , always follow
the Pressure Relief Procedure on page 6 when -
ever you are instructed to relieve the pressure.
NOTE: Always use Genuine Graco Parts and Acces -
sories, available from your Graco distributor .
WARNING
Be sure your system has a bleed-type master air
valve and a fluid drain drain valve. These two
accessories help reduce the risk of serious bodily
injury , including fluid injection, splashing in the eyes
or on the skin, or injury from moving parts, if you
are adjusting or repairing the pump or gun.
 The bleed-type master air valve relieves air
trapped between this valve and the pump after
the air regulator is shut of f. T rapped air can
cause the pump to cycle unexpectedly .

The fluid drain valve Assists in relieving fluid
pressure in the displacement pump, hose, and
gun; triggering the gun to relieve pressure may
not be suf ficient.
1. Install the gasket (7) and then screw the swivel
body (1 1 or 13) firmly onto the gun. Don’t install
the spray tip yet. See Fig. 1.
2. Flush and then prime the pump or sprayer accord -
ing to the instructions supplied with it.
3. Relieve the Pressure.
4. Install an appropriate spray tip (A) in the tip
guard (12). Be sure the tip filter (9) is in place, and
then screw on the tip guard tightly . See Fig. 1.
CAUTION
Failure to install the tip filter (9) and the gasket (7)
will result in leaking at the nozzle.
5. Adjust the nozzle for the desired spray pattern
angle. Loosen the pivot screw (8) and move the
swivel nozzle (5) as needed. T ighten the pivot
screw . Refer to Fig. 2 for examples of dif ferent
angles.
Fig. 1
Fig. 2
06417
06419
12 A9
58
7
11
Directs pattern 100 
to either side of center .
100100
Overlaps patterns for
wider coverage in one pass.
Directs patterns up to
200 in different directions.
200

 
Operation
Pressure Relief Procedure
WARNING
INJECTION HAZARD
T o reduce the risk of serious injury ,
including fluid injection, splashing in the
eyes or on the skin, or injury from mov -
ing parts or electric shock, always follow this proce -
dure whenever you:
 are instructed to relieve the pressure,
 stop spraying,
 check or service any of the system equipment,
 install or clean the spray tips,
 or shut off the pump.
1. Shut of f the pump and unplug it.
2. Hold a metal part of the gun firmly to the side of a
grounded metal pail, and trigger the gun into the
paint pail to relieve pressure.
3. Engage the gun safety device.
4. Open your pump’ s or sprayer ’ s pressure relief
valve or drain valve.
If you suspect that the spray tip or hose is completely
clogged, or that pressure has not been fully relieved
after following the steps above, very slowly loosen the
tip guard retaining nut or hose end coupling and relieve
pressure gradually , then loosen completely . Now clear
the tip or hose.


Operation
WARNING
T o reduce the risk of a fluid injection injury , never
operate the gun with the tip guard(s) removed.
WARNING
T o reduce the risk of serious injury , always follow
the Pressure Relief Procedure on page 6 when -
ever you are instructed to relieve the pressure.
Whenever you stop spraying for a moment, engage
the gun safety latch.
Adjust the Spray Pattern
1. Relieve the Pressure.
2. T o adjust the spray pattern direction, engage the
safety knob and loosen the tip guard retaining nut.
T urn the spray tip so that the groove is horizontal
for a horizontal spray pattern, and vertical for a
vertical spray pattern.
3. The spray tip orifice size and spray angle deter -
mines the coverage and size of the pattern. When
more coverage is needed, use a larger spray tip
rather than increasing the fluid pressure.
4. If adjusting the pressure does not give a good
spray pattern, try another tip size. Be sure to
Relieve the Pressure completely before changing
tips.
CAUTION
Openings in the tip guard are designed to reduce
paint buildup on the guard while spraying. Any
damage to the sharp edges of the openings causes
paint to collect in that area. T o reduce the risk of
damage, never hang the gun by the tip guard.
Cleaning and Clearing the Spray Tip
WARNING
To reduce the risk of fluid injection or splashing in
the eyes or on the skin, do not hold your hand,
body , or a rag in front of the spray tip when clean -
ing or checking a clogged tip. Always point the gun
toward the ground or into a waste container when
checking to see if the spray tip is cleared.
Do not try to “blow back” paint; this is not an air
spray gun.
Do not wipe fluid buildup of f the gun or spray tip
until pressure is relieved. See the Pressure Relief
Procedure on page 6.
Clean of f the front of the tip frequently during the day’ s
operation and at the end of the work day . Remove and
clean the tip and filter (9) at least twice daily . See
Fig. 6. Always follow the Pressure Relief Procedure
on page 6. Use a solvent soaked brush to clean the
spray tip and to keep fluid buildup from drying and
clogging the spray tip.
If the spray tip clogs while spraying, release the spray
gun trigger , engage the trigger safety , shut of f the
pump and Relieve the Pressure. Remove the spray
tip and tip filter (9) and blow out the obstruction with air
from the front of the spray tip, or let the spray tip and
gun nozzle soak long enough to dissolve the obstruc -
tion. If the obstruction will not dissolve, jar it out by
tapping the back of the spray tip against a flat surface.
CAUTION
Never soak the entire gun in solvent. Prolonged
exposure to solvent can ruin the packings.
When not in use, keep the nozzles immersed in clean,
compatible solvent.

 
Maintenance
WARNING
T o reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 6.
1. Relieve the Pressure
2. Disconnect the hose from the gun. Remove the tip
guards, tips and filters, and soak in a clean, com
-
patible solvent.
3. If the fluid leaks around the swivel, check the
tightness of the access plug (4). See Fig. 3.
4. If leakage continues, remove the nozzle adapter
from the gun. Unscrew the access plug (4). Re -
move the spring (1), washer (3), seal (6), and
gasket. See Fig 3.
5. Clean and inspect all parts. Replace damaged or
worn parts as necessary and reassemble.
Fig. 3 06418
6
1
4
3
2

9306-788
Notes

10 306-788
Parts
NOZZLE ADAPTER; single
Includes items 1–12
Model 206–235, Series F
NOZZLE ADAPTER; dual
Includes items 1–13
Model 206–236, Series F
06416
1
12
*10
14
5
13 8
7*
6*
3
1
2*
4
12
*10
9
5
6*
3
1
2*
4
7*
8
11
1
1
Torque to 22–23 ft-lb (30–31 N m)

11306-788
Parts
Model 206–235, Series F
NOZZLE ADAPTER; single
Model 206–236, Series F
NOZZLE ADAPTER; dual
Ref.
No. Part No. Description Qty.
1 150–081 SPRING, compression 1
2* 150–451 GASKET
, copper 1
3 151–395 WASHER 1
4 162–617 PLUG, seal access 1
5 162–618 NOZZLE, swivel 1
6* 176–238
SEAL, T eflon cup 1
7* 166–969 GASKET
, Delrin
1
8 205–032 SCREW
, nozzle pivot 1
9 205–265
TIP FIL TER Assy , edge type; 0.009”
(0.23mm) spacing; includes
replaceable part Ref. No. 10 1
10* 164–075
. HEAD, filter 1
11 206–304 BODY
, swivel; single nozzle 1
12 220–218 GUARD, tip 1
14 724–195 ELEMENT 1
* Recommended “tool box” spare parts. Keep these parts on
hand to reduce down time.
Ref.
No. Part No. Description Qty.
1 150–081 SPRING, compression 2
2* 150–451 GASKET
, copper 2
3 151–395 WASHER 2
4 162–617 PLUG, seal access 2
5 162–618 NOZZLE, swivel 2
6* 176–238
SEAL, T eflon cup 2
7* 166–969 GASKET
, Delrin
1
8 205–032 SCREW
, nozzle pivot 2
9 205–265
TIP FIL TER Assy , edge type; 0.009”
(0.23mm) spacing; includes
replaceable part Ref. No. 10 2
10* 164–075
. HEAD, filter 2
12 220–218 GUARD, tip 2
13 206–305 BODY
, swivel; double nozzle
14 724–195 ELEMENT 1
* Recommended “tool box” spare parts. Keep these parts on
hand to reduce down time.
Manual Change Summary
This manual has been updated electronically .

12 306-788
The Graco Warranty and Disclaimers
WARRANTY
Graco warrants all equipment listed in this manual which is manufactured by Graco and bearing its name to be free from defects
in material and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. Graco will,
for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defec -
tive. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’ s written rec-
ommendations.
This warranty does not cover , and Graco shall not be liable for general wear and tear , or any malfunction, damage or wear
caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident,
tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by
the incompatibility of Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the im -
proper design, manufacture, installation, operation or maintenance of structures, accessories, equipment or materials not sup -
plied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor
for verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective
parts. The equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not
disclose any defect in material or workmanship, repairs will be made at a reasonable charge, which charges may include the
costs of parts, labor , and transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PUR-
POSE.
Graco’
s sole obligation and buyer ’ s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no
other remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or prop -
erty
, or any other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two
(2) years of the date of sale.
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE IN CONNECTION WITH
ACCESSORIES, EQUIPMENT , MA TERIALS, OR COMPONENTS
SOLD BUT NOT MANUFACTURED BY GRACO.
These items sold, but not manufactured by Graco (such as electric motors,
switches, hose, etc.) are subject to the warranty , if any , of their manufacturer . Graco will provide purchaser with reasonable assis -
tance in making any claim for breach of these warranties.
For Sales to Canadian Customers:
Except as expressly stated herein, Graco makers no representations, warranties or conditions, express, implied or collateral, con -
cerning
any goods or services sold, and GRACO SHALL NOT BE LIABLE IN ANY MANNER FOR any other representation,
warranty or condition of any kind, whether arising by operation of law or otherwise, including but not limited to, WARRANTIES OF
MERCHANTABLE QUALITY OR FITNESS FOR A PARTICULAR PURPOSE.
LIMITATION OF LIABILITY
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equip -
ment hereunder , or for the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of
contract, breach of warranty , the negligence of Graco, or otherwise.
Graco Phone Number
TO PLACE AN ORDER , contact your Graco distributor , or call this number to identify the distributor closest to you:
1–800–367–4023 T oll Free.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Sales Offices: Minneapolis, Detroit, Los Angeles
Foreign Offices: Belgium, Canada, England, Korea, France, Germany , Hong Kong, Japan
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
PRINTED IN U.S.A. 306–788 March 1965, Revised March 1997
