Graco InSite 24T280 User manual

333276A
EN
Instructions - Parts
Graco InSite™
Remote Reporting Installation Kit
For remote reporting of actual temperature, temperature setpoint, actual pressure,
pressure setpoint, cycles, and GPS location from a Reactor
®
2 E-30 or E-XP2 proportioner.
For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
Model 24T280
Important Safety Instructions
Read all warnings and instructions in this manual
and in your Reactor 2 system manual. Save all
instructions.
WLD

Related Manuals
2333276A
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Reactor Compatibility . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . 8
Related Manuals
Manuals are available at www.graco.com. Component
manuals in English:
Reactor 2 Compatibility
The Graco InSite is compatible with the following Reac-
tor models:
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
Manual Description
333023 Reactor 2 E-30 and E-XP2Operation
333024 Reactor 2 E-30 and E-XP2 Repair
Reactor
Model Part Numbers
E-30 272010
272011
E-XP2 272012
WARNING
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can cause electric
shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.

Installation
333276A 3
Installation
1. Shutdown Reactor system. See system manual for
instructions.
Install Cellular Module
1. Use two bolts (A) to secure cellular module (1) to
bracket. See F
IG . 1.
2. Connect 4-pin end of cable (2) to cellular module (1)
connector.
3. Route cellular module cable (2) through wire tie (3)
to MCM (B). Secure with wire ties (4) as needed.
4. Connect other end of cellular module cable (2) to
MCM (B) connector 14.
NOTICE
To prevent damage to the Graco InSite, do not
expose to rain.
NOTICE
To prevent cracking the plastic shell of the cellular
module (1), do not overtighten bolts (A) when install-
ing onto bracket (2).
F IG . 1: Install Cellular Module
WLD



B
A

Operation
4333276A
Operation
Registering and Activating the
Graco InSite
To register and activate the Graco InSite, go to
www.GracoInSite.com, click on “InSite Login”, then fol-
low the instructions on the screen.
Find and record the 15 digit serial number from the cel-
lular module below:
Verify Module Status
To check the status of the cellular module, locate the
status LEDs on the module then refer to the following
chart.
LED Status Description
Green flashing Finding GPS location
Green solid GPS location identified
Orange flashing Cellular connection in process
Orange solid Cellular connection established
Green and orange off Reactor power is OFF
WLD
Module Status LEDs
Orange
Green

Troubleshooting
333276A 5
Troubleshooting
Problem Cause Solution
No module status LEDs are illumi-
nated.
No power to cellular module. Turn Reactor ON.
Ensure unit is properly installed.
See Installation on page 3.
Make sure the M8, 4-pin to M12,
8-pin cable is installed between cel-
lular module and control box.
Has not identified GPS location
(green module status LED flashing).
Still identifying location. Wait a few minutes for the unit to
identify the location.
Unable to identify location. In a
location where GPS lock cannot
occur. Buildings and warehouses
often prevent GPS locks.
Move system to a location with a
clear view of the sky.
Has not established a cellular con-
nection (orange module status
flashing).
Still establishing cellular connection. Wait a few minutes for unit to estab-
lish the connection.
Unable to establish cellular connec-
tion.
Move system to a location with cel-
lular service to establish cellular
connection.
Cannot view data for my unit(s) on
website.
Graco InSite unit has not been acti-
vated.
Activate unit. See Registering and
Activating the Graco InSite on
page 4.
Temperature data not displayed on
website.
Reactor temperature measurement
is not working.
See Reactor repair manual.
Hose zone temperature data not
displayed on website.
The RTD is not correctly installed
on the hose or is broken.
See Reactor repair manual.
Pressure data not displayed on
website.
Reactor pressure measurement is
not working.
See Reactor repair manual.

Parts
6333276A
Parts
Ref Part Description Qty
1 16X118 MODULE, cellular and GPS 1
2 16V801 CABLE, M8 4 pin female to M12
8-pin male, 9.8 ft (3 m)
1
3 127377 TIE, cable, 6 in. 1
125871 TIE, cable, 7.5 in. 3
F IG . 2
WLD
1
2

Technical Data
333276A 7
Technical Data
Graco InSite Remote Reporting Installation Kit
US Metric
Operating Temperature -22 to 167°F -30 to 75°C
Storage Temperature -40 to 185°F -40 to 85°C
Ambient Temperature during Battery Charging 41 to 104°F 5 to 40°C
FCC ID FCC (XPYLEONG100),
IC-Industry Canada (8595A-LEONG100)
