Graco 15V963 User manual

312785B
ENG
Instructions-Parts
Gateway Network
Communication Kits
Installation and program setup instructions for use with ProMix®2KS Electronic
Proportioners. For professional use only.
Not approved for use in European explosive atmosphere locations.
See page 3 for kit information.
Important Safety Instructions
Read all warnings and instructions in this manual
and in your proportioning system manual. Save
these instructions.
TI12933a

2312785B
Contents
Graco Gateway Kits . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Graco Gateway Overview . . . . . . . . . . . . . . . . . . . . 5
Install the Gateway Module Hardware . . . . . . . . . . 5
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connect the Module to the EasyKey . . . . . . . . . . 7
Cabling Connections . . . . . . . . . . . . . . . . . . . . . . 7
Mount the Control on DIN Rail . . . . . . . . . . . . . 11
Install CompactFlash®Card . . . . . . . . . . . . . . . 11
Install the GracoConfig Software . . . . . . . . . . . . . 12
System Requirements . . . . . . . . . . . . . . . . . . . . 12
Load the Software . . . . . . . . . . . . . . . . . . . . . . . 13
Software Updates . . . . . . . . . . . . . . . . . . . . . . . 13
Download the Preconfigured Database to the
Gateway Module . . . . . . . . . . . . . . . . . . . . . 14
Graco Gateway Network Communications
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 15
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
GracoConfig Main Page . . . . . . . . . . . . . . . . . . 15
Setup the Database . . . . . . . . . . . . . . . . . . . . . 16
Map Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Modbus and I/O Data . . . . . . . . . . . . . . . . . . . . . . . 21
Start Mix Process . . . . . . . . . . . . . . . . . . . . . . . 21
Stop Mix Process . . . . . . . . . . . . . . . . . . . . . . . 21
Color Change Process . . . . . . . . . . . . . . . . . . . 21
Purge Process . . . . . . . . . . . . . . . . . . . . . . . . . 21
ProMix 2KS Active Alarms (Modbus Register
40010) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
ProMix 2KS Modbus/TCP Variable Map . . . . . . 30
ProMix 2KS Recipe Bits . . . . . . . . . . . . . . . . . . 31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
General Troubleshooting . . . . . . . . . . . . . . . . . . 32
Graco Gateway Messages Troubleshooting . . . 35
Serial Communication Troubleshooting . . . . . . . 36
Ethernet Communication Troubleshooting . . . . 37
LED Functions . . . . . . . . . . . . . . . . . . . . . . . . . 38
System Electrical Schematic . . . . . . . . . . . . . . . . 39
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
15V331 Gateway Ethernet Kit (shown) . . . . . . . 40
15V963 Gateway DeviceNet Kit . . . . . . . . . . . . 40
15V964 Gateway Profibus Kit . . . . . . . . . . . . . . 40
Appendix A: DeviceNet™Slave Communication 42
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
DeviceNet Port Protocols . . . . . . . . . . . . . . . . . 42
About DeviceNet . . . . . . . . . . . . . . . . . . . . . . . . 44
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Automatic Update of the EDS File . . . . . . . . . . . 51
Configure the RSNetWorx for
DeviceNet Software . . . . . . . . . . . . . . . . . . 52
Configure the Allen Bradley ControlLogix PLC . 55
Wire the DeviceNet Network . . . . . . . . . . . . . . . 56
Appendix B: Profibus™DP Slave
Communication . . . . . . . . . . . . . . . . . . . . . . . . 57
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Profibus Port Protocols . . . . . . . . . . . . . . . . . . . 57
About Profibus DP . . . . . . . . . . . . . . . . . . . . . . . 58
Setup the PLC . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Graco Gateway Setup . . . . . . . . . . . . . . . . . . . . 66
Appendix C: Graco Gateway to ControlLogix
via Ethernet IP . . . . . . . . . . . . . . . . . . . . . . . . . 72
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
ControlLogix Configuration . . . . . . . . . . . . . . . . 73
Graco Gateway Configuration . . . . . . . . . . . . . 77
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 82
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 82

Graco Gateway Kits
312785B 3
Graco Gateway Kits
15V331 Gateway Ethernet Kit
Allows communication between ProMix 2KS and a PLC
over an ethernet. Enables process equipment to read
variables while operating, as well as control the ProMix
2KS and change setup. It does not provide access to job
and alarm logs.
15V963 Gateway DeviceNet Kit
Allows communication between ProMix 2KS and a PLC,
using DeviceNet process control. Enables process
equipment to read variables while operating, as well as
control the ProMix 2KS and change setup. It does not
provide access to job and alarm logs.
15V964 Gateway Profibus Kit
Allows communication between ProMix 2KS and a PLC,
using Profibus process control. Enables process equip-
ment to read variables while operating, as well as con-
trol the ProMix 2KS and change setup. It does not
provide access to job and alarm logs.
Related Manuals
Component Manuals in English
Manual Description
312778 ProMix 2KS Automatic System
Installation
312779 ProMix 2KS Automatic System
Operation
312780 ProMix 2KS Automatic System
Repair-Parts
313386 Basic Web Interface/Advanced Web
Interface

Warnings
4312785B
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual, refer back to these Warnings. Product-specific hazard symbols and
warnings not covered in this section may appear throughout the body of this manual where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent
fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail.
• If there is static sparking or you feel a shock, stop operation immediately. Do not use equipment
until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can cause
electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS forms from distributor or retailer.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-
facturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.

Graco Gateway Overview
312785B 5
Graco Gateway Overview
The Graco Gateway enables the ProMix 2KS to network
with a programmable logic controller (PLC). Kits are
available for Ethernet, DeviceNet, or Profibus protocols.
The Graco Gateway will support many other protocols;
contact Graco Technical Assistance for information to
support your desired protocol.
NOTE: Only persons very familiar with their PLC com-
munication architecture should use this hardware and
software. This manual assumes that the person using
the Graco Gateway has full understanding of the PLC
equipment and related software.
NOTE: Network communications essentially operate
with the same rules as Discrete I/O. However, network
communications require placing correct values or
adjusting appropriate bits within various Modbus regis-
ters (for example, see Table 4). These changes should
only be made by qualified persons familiar with this type
of communication.
The module allows for most PLCs to communicate with
the ProMix 2KS via Modbus RTU protocol by bridging
the gap between the desired communication protocol
and RS485 Modbus RTU. As a result, the PLC has full
access to all the registers for monitoring and controlling
the ProMix 2KS. It is the responsibility of the integrator
or user to ensure proper configuration of the communi-
cation hardware on the PLC side.
Install the Gateway
Module Hardware
Location
Install the Gateway module near the EasyKey™, in a
non-hazardous area.
Mounting
1. See Dimensions, page 79.
2. Ensure that the wall and mounting hardware are
strong enough to support the weight of the equip-
ment, cables, and stress caused during operation.
3. Using the equipment as a template, mark the
mounting holes on the wall at a convenient height
for the operator and so equipment is easily accessi-
ble for maintenance.
4. Drill mounting holes in the wall. Install anchors as
needed.
5. Bolt equipment securely.
Grounding
The Gateway module is grounded through its connec-
tion to the EasyKey, which must be connected to a true
earth ground. See the system installation manual. A
ground wire and clamp, part no. 223547, is available
from Graco.
This equipment is not for use in explosive atmo-
spheres. Do not install equipment approved only for
non-hazardous location in a hazardous area.
Your system must be grounded. Read Warnings,
page 4.

Install the Gateway Module Hardware
6312785B
FIG. 1: Graco Gateway Typical Installation
TI13939a
Computer (PC)
Programmable Logic Controller (PLC)
Graco Gateway
Module
EasyKey
USB Cable
(included), for initial
setup only
2-wire twisted
pair cable, with
shield wire
PLC Communication
Wire/Cable
(protocol dependent)
NON-HAZARDOUS AREA

Install the Gateway Module Hardware
312785B 7
Connect the Module to the
EasyKey
FIG. 1 is only a guide showing installation of the Graco
Gateway in a ProMix 2KS System; it is not a complete
system design, Contact your Graco distributor for assis-
tance in designing a system to suit your particular
needs.
1. Shut off ProMix 2KS power (0 position). FIG. 2. Also
shut off power at main circuit breaker.
2. Connect a 2-wire twisted pair cable with shield wire
from the EasyKey connector to the connector on the
Gateway module. Connect a communications
wire/cable (protocol dependent) from the Gateway
module to the PLC. See FIG. 3.
NOTE: Graco provides expansion cards for DeviceNet
and Profibus protocols. DeviceNet setup procedures are
on page 42. Profibus setup procedures are on page 57.
See page 40 for Parts.
NOTE: If using the Graco Gateway in your system, dis-
connect its cable from the EasyKey before updating the
ProMix 2KS software.
Cabling Connections
See FIG. 4 and FIG. 5 for typical cable connections in a
ProMix 2KS system.
FIG. 6 through FIG. 9 show other possible cable connec-
tions.
FIG. 2: Power Off
0 = OFF
TI12657a

Install the Gateway Module Hardware
8312785B
FIG. 3: EasyKey and Module Cable Connection Points
TI12930a
TI12638a
2-wire twisted pair cable, with
shield wire (to Gateway Module)
2-wire twisted pair cable, with
shield wire (to EasyKey). See
Wiring Diagrams on page 41
for pin connections.
EasyKey (Bottom View)
Gateway Module
Communication Wire/Cable (to PLC).
This connection is protocol dependent.
USB Port

Install the Gateway Module Hardware
312785B 9
FIG. 4: Graco Gateway Port Pin Outs
TI13974a
Green/ Amber LED
RS232/PG
USB/PG
ETHERNET (NIC)
Yel l ow LED
COMMS
COMMS
Expansion
Port
Power Connector
24 Vdc +/- 10%
Common
N/C
Pin 6 Pin 1
Pin 6 Pin 1
Pin 8
Pin 1
FIG. 5: RS485 Communication Port (Typical ProMix 2KS Connection)
TI13972a

Install the Gateway Module Hardware
10 312785B
FIG. 6: Programming Ports
TI13969a
Green/Amber LED
RS232/PG
USB/PG
ETHERNET
OR
OR
Yellow LED
FIG. 7: RS232/PG Communication Ports
TI13970a
RS232/PG
OR
FIG. 8: RS232 Communication Ports
TI13971a
RS232

Install the Gateway Module Hardware
312785B 11
Mount the Control on DIN Rail
The Gateway control mounts on a DIN rail. Tilt the con-
trol and push down onto the DIN rail, then push in. See
FIG. 10. A minimum clearance of 1 in. (25 mm) above
and below the control is required to ensure adequate
ventilation.
Install CompactFlash®Card
The CompactFlash socket accepts either Type I or Type
II cards. These cards are available at most computer
and office supply retailers. Use cards with a minimum of
4 Mbytes and a maximum of 2 Gbytes. Use the Com-
pactFlash card for optional database storage only. See
FIG. 11.
FIG. 9: Ethernet Connection
TI13973a
Green/Amber
LED
ETHERNET
Yel l ow L E D
Standard Ethernet Cable
FIG. 10: Mount the Control on a DIN Rail
TI13965a
1 in. (25 mm)
minimum
clearance top
and bottom
TI13966a
FIG. 11: Install a CompactFlash Card
Insert card with top side
on the left. Do not insert
or remove card while
power is applied. TI13967a

Install the GracoConfig Software
12 312785B
Install the GracoConfig Software
GracoConfig software provides access to the Graco
Gateway module hardware. The CD provided contains
the GracoConfig software (GracoConfigXXX.exe, where
the XXX represents the version control number). It also
includes a preconfigured database which is essentially a
setup file for the Gateway. The database file has a .gg2
extension.
The Graco Gateway provides conversions for many pro-
tocols, including the following:
• All Allen-Bradley protocols
• DeviceNet
• Ethernet TCP/IP
• Ethernet IP
• Mitsubishi
• Modbus (ASCII, RTU)
•Profibus
•Siemens
NOTE: Graco provides expansion cards for DeviceNet
and Profibus protocols. DeviceNet setup procedures are
on page 42. Profibus setup procedures are on page 57.
See page 40 for Parts.
NOTE: Contact your Graco distributor or Graco Techni-
cal Assistance for information regarding additional sup-
ported protocols.
System Requirements
GracoConfig software will run on PCs with the following
specifications:
• A Pentium class processor as required by the cho-
sen operating system.
NOTE: GracoConfig software will operate with all
versions of Microsoft®Windows 98 and above. Win-
dows 2000 or above is recommended for more
robust operation.
• RAM and free disk space as required by the chosen
operating system.
• An additional 50MB of disk space for software
installation.
• A display of at least 800 by 600 pixels, with 256 or
more colors.
• USB port for downloading a configured database to
the Gateway module.

Install the GracoConfig Software
312785B 13
Load the Software
1. Connect the USB cable (23, supplied) between the
USB port on the Gateway module and a USB port
on your PC. See FIG. 12.
2. FIG. 13 will appear. Select “Yes, this time only”, then
click Next.
3. FIG. 14 will appear. Insert the CD in your PC’s
CDROM drive. Select “Install the software from a list
or specific location”, then click Next. The program
location is C:\Program Files\Graco\GracoCon-
fig\Device.
NOTE: The name of the driver may be different. Just
accept the name and proceed by following the
instructions on the screen.
Software Updates
Contact your distributor or Graco Technical Assistance
for software updates.
FIG. 12: Gateway Module USB Port
FIG. 13: Found New Hardware Screen
TI12930a
USB Port
USB Cable Strain Relief
FIG. 14: Load Software from a Specific Location

Install the GracoConfig Software
14 312785B
Download the Preconfigured
Database to the Gateway Module
Graco supplies a preconfigured database as a setup file
for the Gateway, containing parameters which communi-
cate between the Gateway and the ProMix 2KS. The file
name has a .gg2 extension.
GracoConfig files are downloaded to the Gateway mod-
ule using the Link menu. The programming link between
the PC and the Gateway module uses the USB cable.
Before downloading, check that the Communications
Port is set to USB, as follows.
NOTE: During programming the Gateway module may
ask for an updated driver. Follow the instructions on the
screen to automatically find and select the drivers.
1. Go to Start>Programs>Graco>GracoConfig and run
the program. The GracoConfig main page will
appear.
2. Using the Link pulldown menu, select Options to
open the Link Options window. Check that the Com-
munications Port is set to USB, and click OK.
3. Go to File>Open and select the file with the xx.gg2
extension. The file name should appear at the top of
the window (FIG. 15) once loaded.
4. Download the database using the Link>Update
command. As a shortcut, use the Update
symbol on the toolbar. See FIG. 15.
NOTE: Downloading typically takes only a few sec-
onds but may take longer if the software has to
update firmware on the Gateway module.
FIG. 15: GracoConfig Main Page
Link Pulldown Menu Update Symbol
FIG. 16: Set Communications Port to USB

Graco Gateway Network Communications Configuration
312785B 15
Graco Gateway Network Communications
Configuration
Startup
To run GracoConfig, select the icon from the
Graco folder on the Programs section of your Start
Menu. The main page will appear, showing the Commu-
nications button.
GracoConfig Main Page
Communications Button
The Communications button provides access to screens
used to configure your system and setup parameters,
allowing you to:
• Specify which protocols are to be used on the Gate-
way serial ports and on the Ethernet port.
• If using master protocols (ie., protocols by which the
Gateway initiates data transfer to and from a remote
device), you can specify one or more devices to be
accessed.
• If using slave protocols (i.e., protocols by which the
Gateway receives and responds to requests from
remote devices or computer systems), you can set
read or write access for specific data items.
• Move data between one remote device and another.
Balloon Help
The Balloon Help feature allows you to see help infor-
mation for each icon in the main menu, or for each field
in a dialog box or window. It is controlled via the
icon at the right-hand edge of the toolbar. Balloon Help
has three user-selectable modes:
•Do Not Display disables balloon help
•When Mouse Over displays help when the mouse
pointer is held over a particular field for a certain
period of time
•When Selected displays help constantly for the cur-
rently selected field.
FIG. 17: Communications Button
Communications Button

Graco Gateway Network Communications Configuration
16 312785B
Setup the Database
1. Double-click on the Communications button to open
the preconfigured database (.gg2). The file is
already setup for ProMix 2KS. See FIG. 18.
2. See FIG. 19. Highlight Protocol 1. Click the Edit but-
ton on the right side of the window to open the
Driver Picker window. Choose a protocol from the
lists provided, in this example Modbus and TCP/IP
Slave. The system will create device PLC1.
FIG. 18: Preconfigured Database
FIG. 19: Select Protocol

Graco Gateway Network Communications Configuration
312785B 17
3. See FIG. 20. Right click on device PLC1 to rename it
to something meaningful for your system.
4. See FIG. 21. Add as many Gateway blocks as
desired under each device.
FIG. 20: Rename PLC1
FIG. 21: Add Gateway Blocks

Graco Gateway Network Communications Configuration
18 312785B
Map Data
1. See FIG. 22. Select the block for data mapping. Click
the Edit button next to the Start Address field on the
right side of the window. The Select Address win-
dow will open.
2. Refer to Table 4 on page 30 for a Modbus map.
Select the desired Modbus register address as a
starting point (in this case 40002). Enter the appro-
priate values in the Select Address window and click
OK. The desired register address will populate the
Start Address field.
FIG. 22: Mapping Gateway Blocks

Graco Gateway Network Communications Configuration
312785B 19
3. See FIG. 23. Click the Edit button next to the Block
Size field on the right side of the window. The Edit
Value window will open. Enter the number of Mod-
bus register addresses in the range from the start-
ing address entered in step 2 to the desired ending
address, inclusive. In this example, 7. The
addresses must be contiguous. This means that
each address must be available and addressable
from the ProMix 2KS. If one of the 7 addresses does
not exist within the ProMix 2KS Modbus structure,
the complete block will not communicate.
FIG. 23: Setting Block Size

Graco Gateway Network Communications Configuration
20 312785B
4. See FIG. 24. Click OK. The range of addresses will
appear under the appropriate Block on the left side
of the window.
NOTE: In this example, a Modbus device master
communicating via TCP/IP will have direct access to
Modbus registers 40002 through 40008 of the Pro-
Mix 2KS.
For example, see Block 1 address line 1:
5. The Direction field typically should remain set to
Device to G3.
Modbus address (command)
from TCP/IP master
connected to Gateway.
Modbus address
of ProMix 2KS.
FIG. 24: Block Mapping Data
