Graco 24A537 Manual

Kit Instructions/Parts
Air Valve
Repair Kits 406747C
EN
Kit 24A537 - For Graco Air Valve Models 24A351 and 24A353.
Kit 24A538 - For Graco Air Valve Models 24A352, 24A354, and 262608.
Parts
Important Safety Instructions
Read all warnings and instructions in this manual
and in your air motor or pump manual. Save all
instructions.
Ref. Description Qty.
1 AIR VALVE PISTON 1
2 DETENT PISTON 1
3 PLATE, air valve 1
4 SCREW, M3, thread forming 2
5 ROLLER, detent 1
6 SPRING, detent 1
7 CUP, for Kit 24A537 1
7a
7b
7c
TWO-PIECE CUP ASSEMBLY,
with o-ring, for Kit 24A538
1
8 PIN, detent 1
9 CAM, detent 1
10 O-RING 2
11 U-CUP 2
12 O-RING (for models compatible
with DataTrak with Runaway
Protection)
1
13 AIR VALVE GASKET 1
ti13628a
For Models
compatible with
DataTrak with
Runaway
Protection
10
12
7
11
11
10
3
Lips face down.
Lips face up.
magnet
1
1
1
1
1
1
2
413
69
1
1
10
1
Apply lubricant.
1
Always install a new gasket (13)
when installing a new air valve.
2
2
Two-Piece Cup for
Kit 24A538
7c
1
7b
1
7a

All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Original instructions. This manual contains English. MM 406747
