Graco LazerVac 25R090 Use and care manual

www.graco.com/techsupport
?? ??
3A5577D
EN
Operation, Repair, Parts
LazerVac™and Cyclone
Vacuum for collection of dry concrete and asphalt dust. For professional use only.
Vacuum
Model 25M860 - LazerVac 550 (gasoline)
Separator
Model 25M862 - Cyclone 32 (32 gallon)
Model 25R090 - Cyclone LP
Important Safety Instructions
Read all warnings and instructions in this manual before using the
equipment. Be familiar with the controls and the proper usage of the
equipment. Save these instructions.
LazerVac 550 Cyclone 32 Cyclone LP

Contents
23A5577D
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Component Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
LazerVac 550 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Cyclone 32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Cyclone LP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Emptying Collection Tanks and Bags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Shutdown and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Maintenance and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Recycling and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Rechargeable Battery Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
End of Product Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Main Assembly Diagram (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Main Assembly Parts (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Accessories Diagram (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Accessories Parts List (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Lid and Vacuum Release Assembly Diagram (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Lid and Vacuum Release Assembly Parts List (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Filter Bag Assembly Diagram (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Filter Bag Assembly Parts List (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Air Filter Assembly Diagram (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Air Filter Assembly Parts List (LazerVac 550) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Cyclone 32 Assembly and Accessories Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Cyclone 32 Assembly and Accessories Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Cyclone LP Assembly and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Cyclone LP Assembly and Accessories Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
California Proposition 65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Warnings
3A5577D 3
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation
point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these
symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard
symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
WARNING
DUST HAZARD
Grinding concrete and other surfaces can create dust that contains hazardous substances.
To reduce the risk of serious injury:
• Control the dust to meet all applicable workplace regulations.
• Wear a properly fit-tested and government approved respirator suitable for the dust conditions when
emptying collection tank or performing maintenance.
• Do not use without dust bag and filters in place.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not leave the work area while equipment is energized. Turn off all equipment when equipment
is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
• Maintain a safe operating distance from other people in the work area.
ENTANGLEMENT HAZARD
Rotating parts can cut or amputate fingers and other body parts.
• Keep clear of rotating parts.
• Do not operate equipment with protective guards or covers removed.
• Do not wear loose clothing, jewelry or long hair while operating equipment.
• Disconnect battery before checking, moving, or servicing the equipment.
BURN HAZARD
Blower, diffuser and engine can become very hot during operation. To avoid severe burns, do not
touch hot equipment.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in the operating
area of the equipment to help protect you from serious injury, inhalation of dust or chemicals, and
hearing loss. This equipment includes but is not limited to:
• Protective eye wear.
• Hearing protection.
• Properly fit-tested and government approved respirator suitable for the dust conditions.

Warnings
43A5577D
FIRE AND EXPLOSION HAZARD
Flammable fumes in work area can ignite or explode. To help prevent fire and explosion:
• Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they
may be present.
• Use equipment only in well ventilated area.
• Do not fill fuel tank while engine is running or hot; shut off engine and let it cool. Fuel is flammable
and can ignite or explode if spilled on hot surface.
• Keep work area free of debris, including solvent, rags and gasoline.
• Keep a fire extinguisher in work area.
CARBON MONOXIDE HAZARD
Exhaust contains poisonous carbon monoxide, which is colorless and odorless. Breathing carbon
monoxide can cause death.
• Do not operate in an enclosed area.
BATTERY HAZARD
Lead-acid batteries produce explosive gases and contain sulfuric acid that can cause severe burns. To
avoid sparks and injury when handling or working with a lead-acid battery:
• Read and follow the battery manufacturer’s warnings.
• Exercise caution when working with metallic tools or conductors to prevent short circuits and sparks.
• Keep all sparks, flames, and cigarettes away from batteries.
• Always wear protective eyewear and protective equipment for face, hands, and body.
• If you have direct contact with battery fluid, flush with water and consult a physician immediately.
• Installation and maintenance must be performed by knowledgeable personnel only.
WARNING

Component Identification
3A5577D 5
Component Identification
LazerVac 550 Cyclone 32 Cyclone LP
Component
A Air Filter Housing
B Diffuser
C Engine Choke, Fuel Valve, and Throttle Control
DEngine
E Electric Start Key
F Vacuum Dust Collection Bag
G Battery
HVelcro®Belt (to secure Vacuum Dust Collection
Bag)
J Vacuum Hookup
K Vacuum Inlet
L Vacuum Outlet
M Main Housing (contains Filter Bags)
N Separator Lid
O Long Hose (to connect the LazerVac or Cyclone
to the GrindLazer)
P Short Hose (to connect the LazerVac to the
Cyclone)
R Blower
S Vacuum Release Handle
T Dust Collection Tank (Dust Bag Holder is inside
tank, not shown)
U Bag Adapter
V Relief Valve (protects air filters from damage)
W GrindLazer Hookup
X Separator Mid Body
Y Separator Lower Body
Z 10” Wheel
AA 4” Wheel
BB Tool Box
CC Tool Bag
DD Drum Latch
Component

Setup
63A5577D
Setup
1. Install dust collection bags onto vacuum and into
separator.
a. Slide the Vacuum Dust Collection Bag onto the
Continuous Dust Bag Adapter. Install the bag
assembly onto the bottom of the Main Housing
of the LazerVac. Wrap the Velcro Belt around
the top of the bag to ensure an air tight seal.
Pull enough bag down to rest on the bottom of
the vacuum cart, then tie a cable tie around the
bottom of the bag.
b. If using a Cyclone separator, remove the
Separator Lid and insert the Dust Bag into the
tank. Insert the Dust Bag Holder into the bag.
Wrap the bag around the lip of the tank and
reinstall the Separator Lid onto the tank.
2. Connect hoses.
If using a Cyclone separator:
• Connect one end of the Short Vacuum Hose to the
inlet of the LazerVac. Connect the other end of the
Short Vacuum Hose to the outlet of the Cyclone
separator.
• Connect one end of the Long Vacuum Hose to the
inlet of the Cyclone separator. Connect the other
end of the Long Vacuum Hose to the vacuum
hookup on the GrindLazer.
If not using a Cyclone separator:
• Connect one end of the Long Vacuum Hose to the
inlet of the LazerVac. Connect the other end of the
Long Vacuum Hose to the vacuum hookup on the
GrindLazer.
NOTE: Use the Y-Connector to connect 2 hoses to the
vacuum or separator, if desired.

Operation
3A5577D 7
Operation
1. Slide the Fuel Valve on the engine to ON.
2. Slide the Engine Choke to closed.
3. Adjust the Throttle Control to 1/3 speed setting.
4. Turn the Electric Start Key to START.
5. After the engine warms up, move Engine Choke to
open and adjust the Throttle Control to the desired
speed.
6. LazerVac is now ready for dust collection from the
GrindLazer.
7. To help ensure proper dust collection, momentarily
pull down on the Vacuum Release Handle every 10
minutes of operation while the LazerVac engine is
running. This helps clean the Filter Bags from
accumulated dust and debris, and transfers them to
the Vacuum Dust Collection Bag.

Operation
83A5577D
Emptying Collection Tanks and
Bags
Cyclone Separator
1. When Dust Collection Tank is full, turn off vacuum.
Put on respirator. Remove the Separator Lid and
the Dust Bag Holder from the tank.
2. Gather and secure the top of the collection bag. Lift
and remove the collection bag, tie up and then
dispose. Follow local ordinances and regulations for
disposal.
3. Insert new bag into collection tank and reinstall the
Dust Bag Holder and Separator Lid onto the tank.
LazerVac and Cyclone LP
1. When Vacuum Collection Bag has collected
approximately 45 lbs (20 kg) of dust, the bag should
be replaced. Momentarily pull down on the Vacuum
Release Handle, then turn the LazerVac off.
2. Pull down on the continuous bag to expose 6 - 12”
(15 - 30 cm) of new, unused bag.
3. Use a cable tie to tie off the top of the bag. Fasten
another cable tie 2” (5 cm) cable tie above the first
cable tie.
4. Put on respirator. Cut the bag between the two
cable ties.
5. Dispose of the dust bag. Follow local ordinances
and regulations for disposal.
6. Pull down on the new bag attached to the vacuum
until the bottom of the bag rests on the bottom of the
vacuum cart. Ensure the bottom of the bag is tied off
firmly with the cable tie.
DUST HAZARD
Grinding concrete and other surfaces can create dust
that contains hazardous substances. To reduce the
risk of serious injury:
• Respirator must be worn when emptying or
cleaning Dust Collection Tanks or bags.
• Follow local ordinances and regulations for
disposal.

Shutdown and Storage
3A5577D 9
Shutdown and Storage
Shutdown
1. While the engine is running, momentarily pull down
on the Vacuum Release Handle.
2. Move Throttle Control to the minimum setting.
3. Turn the Electric Start Key to OFF.
Storage
Slide Fuel Valve on the engine to OFF. Store indoors.
NOTICE
Do not store in a location with high temperatures or
excessive humidity, in order to prevent damage to
your LazerVac components.

Maintenance and Repair
10 3A5577D
Maintenance and Repair
Maintenance
The following steps should be performed to help
maintain proper operation and sustain the life of the
LazerVac.
Daily
• Prior to use, inspect all hoses for holes. Repair or
replace damaged hoses.
• To help maintain performance and dust control,
replace bag filters and/or air filters when:
- Filters have tears or are clogged.
- Airborne dust is visible when using the
LazerVac.
- Airborne dust exits the Diffuser when using the
LazerVac.
• Check belt tension for slipping and/or excessive
wear. Tighten or replace belt if needed.
• Verify that the Relief Valve does not open when the
engine is running. If the Relief Valve opens, clean or
replace the air filters.
Weekly
Inspect seals for damage. If damaged, replace seal.
Ensure seals are installed correctly and properly sealed.
Repair
Filter Bag Replacement
1. Unlatch the Drum Latches from the Main Housing in
order to access the Filter Bags. Lift off the Housing
Lid.
To reduce the risk of serious injury:
• Respirator must be worn during all maintenance
and repair.
• Follow local ordinances and regulations for
disposal of dust.
• Disconnect spark plug wire and black cable from
battery before maintenance.
DUST HAZARD
Vacuum performance will deteriorate if the drive belt
has excessive wear or is not properly tensioned.

Maintenance and Repair
3A5577D 11
2. Untie knots from the top of the Filter Bags.
3. Press wire form at the bottom of the Filter Bag.
4. Separate filter from hole by lifting up on the Filter
Bag.
5. Remove old Filter Bag from the vacuum.
6. Insert new Filter Bag and tie a knot from the new
Filter Bag onto the top wire rack.
7. Press wire and insert new Filter Bag into hole.
8. Ensure seals are installed correctly and properly
sealed when reassembling the Main Housing.
V-Belt Replacement and Tensioning
Follow these instructions to install a new V-Belt, or to
re-tension current belts.

Maintenance and Repair
12 3A5577D
1. Loosen the four bolts (labeled “A”) that secure the
Blower to the mounting plate.
2. Loosen the two bolts (labeled “B”) and remove Belt
Guard.
3. To install a new V-Belt, use a 3/4” hex wrench on
“C” to move the Blower Pulley closer to the Engine
Pulley. Replace the belt.
4. To tension the belt, use a 3/4” hex wrench on “C” to
move the Blower Pulley away from the Engine
Pulley. Keep tightening the belt until the belt deflects
approximately 1/8” (3mm) when squeezed by hand.
5. Ensure pulleys are aligned after tensioning. If they
are not aligned, release the belt tension, loosen the
Engine Pulley set screws and align the pulleys.
Check alignment after tensioning the V-Belt.
6. When the V-Belt is properly aligned and tensioned,
tighten the four bolts (labeled “A”) to secure the
Blower to the mounting plate. Reassemble the Belt
Guard with the two bolts (labeled “B” in step 2).

Recycling and Disposal
3A5577D 13
Recycling and Disposal
Rechargeable Battery Disposal
Do not place batteries in the trash. Recycle batteries
according to local regulations. In the USA and Canada,
call 1-800-822-8837 to find recycling locations or go to
www.call2recycle.org.
Do not place batteries in the trash. Recycle batteries
according to local regulations.
End of Product Life
At the end of a product’s useful life, recycle it in a
responsible manner.

Parts
14 3A5577D
Parts
Main Assembly Diagram (LazerVac 550)

Parts
3A5577D 15
Main Assembly Parts (LazerVac 550)
Ref Part Number Description Qty
1 see page 17 Lid and Vacuum Release Plunger 1
2 17X196 Main Body Seal 1
3 17X197 Main Body Seal Ring 1
4 17X198 Filter Housing/Main Body 1
5 see page 18 Filter Bag Assembly 1
6 17X199 Coupler Hose 1
7 see page 19 Filter Housing Assembly 1
8 17X200 Main Frame 1
9* 17X154 Velcro Belt 1
10* 17W295 Vacuum Dust Collection Bag (Continuous, 20 meters) 1
11 17X925 Blower Pulley, 3” 1
17X927 Bushing, Blower Pulley 1
12 17X202 Belt Guard 1
13 17X924 V-Belt 1
14 17W966 Engine Pulley, 5” 1
17X926 Bushing, Engine Pulley 1
15 17W422 13 hp Honda Engine 1
16 17X204 Vacuum Gauge 1
17 17X205 Drum Latch 7
1817W132 Warning Label, Multiple, Icons 1
19194126 Warning, Fire and Explosion 1
2016D646 Warning, Hot Surface 3
2116C394 Warning, Entanglement 2
22 17X930 Continuous Dust Bag Adapter 1
24 N/A Cable Ties (to tie off bag) N/A
25 17X928 Blower 1
26 17Y255 Exhaust Diffuser 1
27 115753 33 Amp-Hour Sealed Battery (not shown) 1
Replacement warning, safety labels, tags, and cards are available at no cost.
* LazerVac 550 is shipped with one spare each of items 9 and 10.

Parts
16 3A5577D
Accessories Diagram (LazerVac 550)
Accessories Parts List (LazerVac 550)
Part Number Description Qty
917X156 Long Vacuum Hose, Standard, 2” (includes item 19) 1
17X704 Long Vacuum Hose, Heavy Duty, High Temp, 2” 1
10 17X158 Vacuum Extension (set of 2) 1
11 17X162 Vacuum Large Brush 1
12 17X161 Vacuum Small Brush 1
13 17X160 Vacuum Floor Nozzle 1
14 17X159 Vacuum Elbow 1
18 17X163 Y-Connector 1
19 17X164 2” Hose Connector for Standard Hose (LazerVac is shipped with 2 extra connectors) 4
20 17X693 Short Vacuum Hose, Standard, 2” (includes item 19) 1
17W154 Short Vacuum Hose, Heavy Duty, High Temp, 2” 1

Parts
3A5577D 17
Lid and Vacuum Release Assembly Diagram (LazerVac 550)
Lid and Vacuum Release Assembly Parts List (LazerVac 550)
Part Number Description Qty
1 17X220 Vacuum Release Handle Assembly 1
8 17X227 Lower Lid 1
9 17X168 1/4-20 Acorn Nut 4
10 17W228 1/4” Lock Washer 4
11 17X174 1/4-20 Coupling Nut 4
12 17W259 1/4-20 Hex Nut 4
13 17X233 1/4-20x1 1/4 Hex Head Bolt 4

Parts
18 3A5577D
Filter Bag Assembly Diagram (LazerVac 550)
Filter Bag Assembly Parts List (LazerVac 550)
Part Number Description Qty
1 17X235 Filter Funnel Base 1
2 17X236 Filter Seal 1
3 17X237 Filter Base Plate 1
4 17X238 Filter Bag (set of 7) 1
10 17X244 Wire Net and Spring Kit 1

Parts
3A5577D 19
Air Filter Assembly Diagram (LazerVac 550)
Air Filter Assembly Parts List (LazerVac 550)
Part Number Description Qty
1 17X245 Filter Main Casing 1
2 17X246 Filter Casing Lid 1
3* 17X247 Air Filter, set of 2 1
4 17X248 Relief Valve 1
*HEPA Filter Set available (17Y254)

Parts
20 3A5577D
Cyclone 32 Assembly and Accessories Diagram
