grandfire CLASSIC Series User manual
1
GRANDFIRECLASSIC&
DELUXESERIESUSER
MANUAL
08/17
2
AMESSAGETOOURCUSTOMERS
ThankyouforselectingGRANDFIREProfessionalGrill.
Yourgrillhasbeendesignedandbuiltwithmeticulousattentionsanditoffersuniqueandpowerfulfeatures.We
havedevelopedthisUsers’Manualtoassistyouonuseandmaintenances.Itcontainsvaluableinformationon
howtoproperlyinstall,operateandmaintainyournewapplianceforsafetyandbestperformances.
Thanksagainforyourchoice.Enjoy!
3
TABLEOFCONTENTS
SafetyPractices&Precautions‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4
InstallingYourBarbecue‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8
Gasconnections‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐14
FinalChecks‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐15
ElectricalConnections‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐17
UsingYourNewBarbecue‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐17
Cleaning&Maintenance‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐22
TroubleshootingGuide‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐23
WarrantyService‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐24
LimitedWarrantyInformation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐25
ExplodedPartsViews&lists‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐26
WiringDiagrams‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐40
NOTETOINSTALLER
Thismanualmustremainwithgrill.Aninstaller‐suppliedgasshut‐offvalvemustbeinstalledinaneasilyaccessible
location.Outdoorinstallations mustcomplywithAS/NZS5601.1andlocalstatutorycodesaswellastherequirements
ofanylocalcouncil,gas,electricityauthorityorotherstatutoryregulation.Spannertightensallgasfittingsasper
instructions.
4
SAFETYPRACTICES&PRECAUTIONS
Belowisasummaryofimportantsafetywarnings.Itisnotacompletelist.ReadthisEntireinstructionbookletbefore
installationoroperationofyourbarbecue.
INSTALLATIONSAFETY
Warning:Contactyourlocalmunicipalityforanybuildingcodesregulatingtheinstallationofoutdoorbarbecue
appliances.Outdoorinstallations mustcomplywithAS/NZS5601.1andlocalstatutorycodesaswellasthe
requirementsofanylocalcouncil,gas,electricityauthorityorotherstatutoryregulation.Spannertightensallgas
fittingsasperinstructions.
SAFELOCATION
Donotusebarbecueindoors.Thisisanoutdoorcookingappliance.Itmustonlybeusedoutdoors,andmustnot
beusedinabuilding,garageoranyotherenclosedarea.
Donotstorecombustiblematerials,gasolineorflammableliquidsorvaporswithin45cmofbarbecue.
Thisbarbecueisnotdesignedformarineuse,andshallnotbeinstalledonaboatoranymarinecraft.
Keepthebarbecueandcylinderwellventilated.Donotobstructtheflowofairaroundthebarbecue,asthisis
requiredforpropercombustion.
Forbuilt‐insituations,allowadequateventilationforthebarbecueandcylinder,andadequateprotectionfrom
adverseweather.
Allowclearaccesstotheentiregassupplyhoseandregulator.
Useyourbarbecueonlyonalevelsurface.
GASCYLINDERSAFETY
Donotinstallthegascylinderbeneaththebarbecueunlessinconjunctionwithanapprovedtrolley.
DANGER!!!
WhattoDoIfYouSmellGas
Shutoffgastotheappliance.
Extinguishanyopenflame.
Openlid.
Ifodorcontinues,keepawayfromthe
applianceandimmediatelycallyourgas
supplieroryourfiredepartment.
ForYourSafety
Donotstoreorusegasolineorotherflammable
vapoursorliquidsinthevicinityofthisorany
otherappliance.
AnLPGcylindernotconnectedforuseshallnot
bestoredinthevicinityofthisoranyother
appliance.
DONOTOPERATETHISAPPLIANCEBEFOREREADINGTHEINSTRUCTION
BOOKLET
DONOTPLACEARTICLESONORAGAINSTTHISAPPLIANCE
DONOTSTORECHEMICLESORFLAMMABLEMATERIALS,ORSPRAY
AEROSOLESNEARTHISAPPLIANCE
DONOTOPERATETHEAPPLIANCEINDOORS
DONOTOPERATEINANENCLOSEDAREA
DONOTOPERATETHISAPPLIANCEBEFORELEAKCHECKINGHOSES
ANDGASCYLINDERCONNECTION
OUTDOORUSEONLY
DONOTSTORESPAREGASCYLINDERINTHIS
COMPARTMENTORNEARTHISAPPLIANCE;USE
ONLYTHECYLINDERSTORAGEFACILITYPROVIDED.
IFTHISWARNINGISNOTFOLLOWED,AFIRE
CAUSINGINJURYORDAMAGEMAYOCCUR.
WARNING
5
Keepthecylinderprotectedfromheat.
Onlyonegascylindermaybeattachedtotheapplianceatanyonetime.
WhenusinganLPGsupplysystem(e.g.portableLPGcylinder)inanenclosure,ventilationmustbeprovided.Keep
ventilationopeningofanycylinderenclosureclearandfreeofanydebris.Gasvaporishighlyexplosiveandcan
causeseriousbodilyinjuryordamagetopropertyifallowedtoaccumulateinaconfinedspaceandignited.
HavethegascylinderfilledbyanauthorizedLPGsupplier.
Closethegascylindervalveaftereachuse.
Donotsmokeoruseanakedflamenearthegascylinderwhiledisconnectingthegaslinebetweentheappliance
andgascylinder.
Donotusearustyordentedgascylinderorcylinderwithadamagedgasvalve.
Donotfillthegascylinderbeyond80%capacity.
Donotstoregascylinderindoors,orinanyenclosedarea.
Donotlaythegascylinderdown.
SAFEOPERATION
Thisbarbecuebecomesveryhotduringuse,so:
Keepyoungchildrenaway.
Whenhandlinghotcomponents,theuseofprotectiveglovesisrecommended.
Donotallowtheflexiblegassupplyhoseoranyelectricalcordtocomeincontactwithanyheatedsurfaceofthe
appliance.
DONOTwearloosegarmentsorsleeveswhenusingthebarbecue.
Donotleaveyourbarbecueunattendedwhilstinuse.Donotuseplasticorglassutensilsonthebarbecue.Donot
operatebarbecueinstrongwinds.
Donotmovetheapplianceduringuse.
Donotallowchildrentooperatethisappliance.
Donotoperatewindowroastinghoodsintherain.
Donotdisconnectanygasfittingswhiletheapplianceisoperating.
SAFELIGHTING
Alwaysleak‐testwithasolutionofsoapywater.Donottestforgasleakswithanakedflame.
Alwaysfullyopentheroastinghoodorremovethemetallidoftheappliancebeforelighting.
Visuallycheckburnerflamestoconfirmlighting.Donotleanoverbarbecuewhenlighting.
Donotusecharcoaloranyothersolidfuelinthisappliance.
SAFECAREANDMAINTENANCE
Alwayskeepyourbarbecueclean:
Whenyouhavefinishedcookingturnthegrillburnerstohighforupto10minutestoburnoffanyexcessgrease.Make
sureyourgreasepaniscleantoavoidagreasefire.
Letthebarbecuecoolbeforereplacinganylidorcover.
Emptyandcleangreasetray.
Cleanthebarbecueatleasttwiceannually.
6
Checkmainopening,throatandventtoeachburnerandpilotflametuberegularlyforinsectnests(e.g.wasp,ants
orspiders).Nestsaredangerousandmustbecleanedoutthoroughly.
Donotusecausticbasedcleaningagentsonthebarbecue.
Checkallgashosesandlineconnectionsfordamage,cutsorcrackseachtimetheapplianceistobeused.
Donotattempttomodifytheappliance.Anymodificationtothisappliancemaybedangerousandmayvoidthe
warranty.
Donotattempttodismantleoradjustcontrolvalvesorregulator.
IFTHEREISAFIRE
Mostfiresarecausedbyabuildupofgrease,orbyanimpropergasconnection.
Ensureallpeopleandpetsarekeptasfarawayaspossible.
Ifpossible,turnthegasoffatthecylinderorforpipedinstallations,ontheon/offvalve.
Useafireextinguisherifpossible.Ifwateristheonlyfireretardantavailable,thoroughlysoaktheareaaroundthe
appliance.Whensprayingwateronthebarbecueitself,donotuseastrongjetofwater,asthismaycause
splashingofburninggrease,resultinginafurtherspreadingofthefire.Ratherspraylightlyovertheframecooking
surfacestocooltheappliancebelowignitiontemperature.
IMPORTANT!GRILLINGINWINDYCONDITIONS
Usingyourgrillinwindyconditionsmaydisruptthefront‐to‐backairflow.Whilegrillingwithallburnersonhighandthe
hoodclosed,younoticethatthetemperaturegaugefailstorise…becareful.Highwindmaykeephotgasesfromexiting
therearofthegrill,thecontrolpanelandknobsmayhavebecomeextremelyhot.
Onbreezydays,becarefulnottoleavethefronthooddownformorethan15minuteswhentheburnersareon
high.(Neverleavethegrillunattendedwheninoperation)
Ifyoususpectthegrillisoverheating,usinganovenmitttoopenthefronthood.Thenadjusttheburnercontrol
knobtoalowersetting.
Repositionthegrillsoprevailingwindsarenotblowingintotherearofthegrill.
Note:Anydamagecausedfromuseinwindyconditions,suchasmeltedknobsorigniterwire,orcontrolpanel
discolorationfromheatbuildup,isexcludedfromwarrantycoverage.
INSTALLINGYOURBARBECUE
BEFOREYOUSTART
Ifyourdealerhashadyourgrilldelivered,pleasecheckforvisibledamagetotheoutercartonimmediately.Please
makethedeliverypersonawareofthedamagerightawayandpleasecallyourdealer.Ifthedamageisnotnoticed
untilthemerchandiseisunpackedyoushouldnotifyyourdealerwithin7daysofthedeliverydate.
ImportantNotes:
Thisisanoutdoorappliance.Ensureyourbarbecueispositionedsafelyawayfromanythingthatcancatchfire.
IndoorUse:Undernocircumstancesthisbarbecuecanbeusedindoors.Thisincludesgaragesoranyotherenclosed
areas.
ClearancefromCombustibles:Ensureyourbarbecueremainsatadistanceofatleast45cm(18”)fromany
combustiblematerialsuchaswood,gyprock,paperandplants.Donotstorecombustiblematerials,gasolineor
7
flammableliquidsorvapourswithin45cm(18”)ofthebarbecue.
AdequateVentilation:Ensurethereisadequateventilationforboththebarbecueandcylinder.Thisisrequirednotonly
forpropercombustion,butalsotopreventgasbuildup.
FirmLevelSurface:Useyourbarbecueonlyonafirmlevelsurface.Thisbarbecueisnotdesignedforrecreational
vehicles,andshallnotbeinstalledonaboatoranymarinecraft.
ProtectionFromWeather:Keepthebarbecueprotectedfromadverseweather,includingrainandhighwinds.Polyvinyl
coversareavailablethathavebeenspeciallydesignedforthisrangeofbarbecues.
MaintenanceAccess:Whenyourbarbecueisinstalled,youshouldbeabletoaccessthegassupplylineincludingthe
gaspipingorhose,gasregulator,gascylinderandanyshutoffvalves.
PartialEnclosures:Ifyourbackyardhasareasthatarepartiallyclosedoff,suchasbalconiesandpergolas.Insomecases,
itishardtodecidewhetherthesepartiallyenclosedareasshouldbeclassifiedasindoorareas,particularlyintermsof
permanent(non‐closable)ventilation.Thegassafetyauthoritieshaveagreedonthedefinitionofpartialenclosures
below.
PARTIALENCLOSURES
Thisapplianceshallonlybeusedinanaboveground,openair
situationwithnaturalventilation,withoutstagnantareas,wheregas
leakageandproductsofcombustionarerapidlydispersedbywind
andnaturalconvection.Anyenclosureinwhichtheapplianceis
usedshallcomplywithoneofthefollowing:
Withinapartialenclosurethatincludesanoverheadcoverandno
morethantwowalls.Acommonexampleisanoutdoorgazebo.
Anenclosurewithwallsonallsides,butatleastonepermanent
openatgroundlevel,andnooverheadcover.
Acommonexampleisanenclosedbackyard.Typically,thewallsarelessthan3mhigh.Iftheyarehigher,thereisa
dangerofgasbuildup.
Thebarbecuemaybewithinapartialenclosurethatincludesanoverheadcoverand
morethantwowalls,thefollowingshallapply:
Atleast25%ofthewallareiscompletelyopen;and
Atleast30%oftheremainingwallareaisopenandunrestricted.
Inthecaseofbalconies,atleast20%ofthetotaloftheside,backandfrontwallareas
shallbeandremainopenandunrestricted.
REMOVINGPACKINGMATERIALS
Thoughourproductisfullyassembledbeforeshippingtoallourcustomers,therearesomeminorinstallationsmustbe
donebeforetheproductbeingused.Pleaseunpackthegrillandremoveallsecurepackingmaterialininsidethegrill.
Thewarmingrackisfastenedinpositionwithzip‐tie.Pleasecutoffthetiesonbothendtoreleaseit.TheLPGregulator
istiedonthebackpanel.Pleasecutoffthetieforregulator.
