GRAPHTEC LABELROBO LCX603 User guide

LCX603-UM-651-01-9370
603
SETUP MANUAL
(Installing manual for service person）
MANUAL NO. LCX603-UM-651
LABELROBO

LCX603-UM-651-9370 iii
HISTORY OF REVISIONS
No. Dateissued Descriptionofrevision Page Edition
1 12.3.27 FirstPrinting All 01
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

LCX603-UM-651-9370 iv
CONTENTS
1 Preparation before the setup .........1-1
1.1 Conrming the Installing Space for the LCX603 .........1-1
1.2 Preparation items before the setup ..............................1-2
1.3 Preparation knowledge before the setup .....................1-3
2 Setup ................................................2-1
2.1 How to take out the LCX603 from the Packing Box ....2-1
2.2 Installing the LCX603 on the Table .............................. 2-5
2.3 Removing the Packing Materials ................................. 2-6
2.4 Conrming the Standard Accessories .........................2-9
2.5 Conrming the power supply and the LAN cable .....2-10
2.6 Parts Names and Functions ........................................2-11
2.7 The Flowchart of Setup ................................................2-15
2.8 Connecting the AC power cable .................................2-16
2.9 Installing the Cutter Pen ..............................................2-17
2.9.1 Preparing the Cutter Pen ........................................................ 2-17
2.9.2 Installing the cutter pen to the LCX603 .................................2-19
2.9.3 How to use the control panel .................................................2-20
2.10 Turning on the power ...................................................2-22
2.11 Installing the media to the media stocker ..................2-23
2.12 Loading media to the LCX603 .....................................2-26
2.13 Installing the Ink Ribbon ..............................................2-39
2.13.1 How to install the ink ribbon stocker to the LCX603 ...........2-39
2.13.2 Regarding the Ink Ribbon Stocker ....................................... 2-40

LCX603-UM-651-9370 v
2.13.3 Installing the Ink ribbon to the Ink Ribbon Cassette ...........2-41
2.14 Adjusting the density .................................................. 2-46
2.15 Test Printing and Density Adjustment ...................... 2-50
2.16 Adjusting the blade length and the tool condition ... 2-55
2.17 Adjusting printing and cutting position .................... 2-59
2.18 Distance Adjustment ................................................... 2-63
2.19 Adjusting the print head position .............................. 2-68
2.20 Installing the Separator ...............................................2-75
2.21 Cross cutter setting .................................................... 2-80
2.22 Installing the laminate ................................................. 2-82
2.23 Setting the Anti-Wrinkle Line ......................................2-87
2.24 Setting the Registration Mark Type ........................... 2-89
2.25 Setting the Unit Length ................................................2-91
2.26 Setting the Frame Cut ..................................................2-92
3 Installing the Printer Driver ............3-1
3.1 When send the print data via the USB .........................3-1
3.2 When send the print data via the LAN ........................ 3-6
3.3 Printer Driver Operation ..............................................3-15

LCX603-UM-651-9370 1-1
1 Preparation before the setup
1 Preparation before the setup
1.1 Conrming the Installing Space for the LCX603
ConrmtheinstallationspaceasshowninthepicturebelowbeforeinstallingtheLCX603.
PleasediscusswithyourenduserbeforeinstallingtheLCX603toyourcustomers’ssite.
WheninstallingtheLCX603onatable,pleaseuseadurable,solidtablewithasurfacelargerthan1000
mm×400mm.
 Leavesufcientspaceforoperationsinfrontofandbehindtheprinter.
500mm
50mm
1000mm
500mm
Notes for installation of the LCX603
 Whensettinguponadeskorworktable,makesuretherearetwopeopletocarryoutthe
task.
DonotusethehandleinthemediastockersectionwhenliftuptheLCX603,otherwisethe
LCX603willbreak.
Handle

LCX603-UM-651-9370 1-2
1 Preparation before the setup
1.2 Preparation items before the setup
TheprintingtestandthecuttingtestwillbeperformedwhentheLCX603isinstalling,preparethefollowing
itemstosetupfortheLCX603.
Items Usage Q’ty
PC Toprintoutthetestpattern. 1
USBcable Toprintoutthetestpattern. 1
Media:FNSMatN50-1310B Mediaforprintingtest 1roll
Inkribbon:RP120-B-R4A,Resin Resininkribbonprintingtestforthehead1,(Blackribbon) 1roll
Inkribbon:RP120-BL-R4A,Resin Resininkribbonprintingtestforthehead2,(Blueribbon) 1roll
Inkribbon:RP120-R-R4A,Resin Resininkribbonprintingtestforthehead3,(Redribbon) 1roll
Inkribbon:WD120-B-R4A,Semi-Resin Semi-Resininkribbonprintingtestforthehead1,(Blackribbon) 1roll
Inkribbon:WD120-BL-R4A,Semi-Resin Semi-Resininkribbonprintingtestforthehead2,(Blueribbon) 1roll
Inkribbon:WD120-R-R4A,Semi-Resin Semi-Resininkribbonprintingtestforthehead3,(Redribbon) 1roll
Laminate:PET16-1110R4A Laminatingtest 1roll
Bobbin Torewindthelaminateandtheseparatedmedia. 2
Blade:CB09UA Tocuttingtest 1
Bladeholder:PHP32-CB09N-HS Tocuttingtest 1
CleaningKit Tocleantheprinthead. 1set

LCX603-UM-651-9370 1-3
1 Preparation before the setup
1.3 Preparation knowledge before the setup
ThesettingpersonmustunderstandthefollowingknowledgebeforesetupfortheLCX603.
PleasereadtheChapter2tohavetheknowledgefortheLCX603beforesettingtheLCX603.
(1) LabelPrinterPartNames
(2) Thefunctionsofthecontrolpanellampsandkeys
(3) Howtoinstallthecuttingtool
(4) Howtoadjustthebladelength
(5) Howtoinstalltheinkribbons
(6) Howtoinstallthemedia
(7) Howtoinstallthelaminate
(8) Aboutcompatibilityofinkribbonandthematerial
(9) Howtoadjusttheprintingdensity
(10)Howtoadjustthecuttingcondition
(11) Howtosetthecrosscuttingfunction

LCX603-UM-651-9370 2-1
2 Setup
2 Setup
2.1 How to take out the LCX603 from the Packing Box
TheLCX603ispackedbythewoodyboxasshowninthepicturebelow.
FollowtheproceduretotakeouttheLCX603fromthepackingbox.
 WhenunpackingtheLCX603fromwoodybox,makesuretherearetwopeopletocarryout
thetask.
How to take out the LCX603 from the packing box
(1) Removetheselftappingscrewswhicharemarkingbytheredcircleholdingthetoppanel.
Removetheselftappingscrews
whicharemarkingbytheredcircle.
Selftappingscrew Selftappingscrew

LCX603-UM-651-9370 2-2
2 Setup
(2) Detachthetoppanelfromthebox.
(3) TakeouttheaccessoryboxfromthepackingboxofLCX603.
Accessorybox

LCX603-UM-651-9370 2-3
2 Setup
(4) Removetheselftappingscrewswhicharemarkingbytheredcircleholdingthebottompartofouter
panels.
Selftappingscrew
Selftappingscrew
Selftappingscrew
Selftappingscrew
(5) Liftuptheouterpanels,andthendetachtheouterpanelsfromthebottomofpackingbox.

LCX603-UM-651-9370 2-4
2 Setup
(6) TakeouttheLCX603fromthebottomofpackingbox.
 WhencarryingtheLCX603,makesuretherearetwopeopletocarryoutthetask.
WhencarryingtheLCX603,havethebottompartoftheLCX603.
DonotusethehandleinthemediastockersectionwhenliftuptheLCX603,otherwisethe
LCX603willbreak.
Handle

LCX603-UM-651-9370 2-5
2 Setup
2.2 Installing the LCX603 on the Table
(1) ConrmtheinstallationspaceasshowninthepicturebelowbeforeinstallingtheLCX603.
 Leavesufcientspaceforoperationsinfrontofandbehindtheprinter.
500mm
50mm
1000mm
500mm
(2) WheninstallingtheLCX603onatable,pleaseuseadurable,solidtablewithasurfacelargerthan
1000mm×400mm.
(3) Installinaatlocation.
(4) TheweightofLCX603isabout80kg,thetablemustbestrongenoughtoputtheLCX603.
(5) HavethebottompartoftheLCX603andthenputtheLCX603onthetable.
Notes for installation of the LCX603
 Whensettinguponadeskorworktable,makesuretherearetwopeopletocarryoutthe
task.
WhencarryingtheLCX603,havethebottompartoftheLCX603.
DonotusethehandleinthemediastockersectionwhenliftuptheLCX603,otherwisethe
LCX603willbreak.
Handle
(6) Adjustthefourlevelers(adjusters)sothattheLCX603isat.

LCX603-UM-651-9370 2-6
2 Setup
2.3 Removing the Packing Materials
RemoveallpackingmaterialsfromtheLCX603beforeturningonthepowerofLCX603.
(1) RemovethePPbandholdingtheseparatorarm.
(2) Removethelamenttapesholdingthepenblock.
(3) Removethelamenttapesholdingthepressleverandthecamlever.
(4) Removethepackingmaterialsfromthebottomofthepenblock.

LCX603-UM-651-9370 2-7
2 Setup
(5) Removethepackingmaterialsfromunderthepushroller.
(6) Removethelamenttapeholdingthemediastocker.
(7) Removethelamenttapeholdingthelabeltray.
(8) Removethelamenttapeholdingthefrontribbonstockerdoor.

LCX603-UM-651-9370 2-8
2 Setup
(9) Openthefrontdoor,andthenremovelamenttapesholdingthethreeribbonleversandtheribbon
stockerlever.
(10)Opentheribbonstockerdoor,andthenremovelamenttapesholdingthethreeprintheads.

LCX603-UM-651-9370 2-9
2 Setup
2.4 Conrming the Standard Accessories
Checktoconrmthatalloftheitemsshownbelowarepresent.
Item Q'ty Check Item Q'ty Check
Powercable 1ps. User'sManual(ThisManual),
AdditionalUser’sManual
1Set
CD(Driver) 1ps. Cutterblade(CB09UA-1) 1pc.
Cutterplunger(PHP32-
CB09N-HS)
1ps. Dancerroller(1,2) 2pcs.
Inkribbonange 12pcs. Inkribbon
(Black:Semi-RESIN)
1Set
Windingupformtube
(Usesforaseparatorandlaminatewinderbobbins)
4pcs. Cleaningstick 1Set
Mediastockerange
(Longshaft)
1Set Laminatestockerange
(Shortshaft)
1Set
Separatorwinderbobbin,Separatorangecollar
(Largewhitegear)
1Set Laminatestockerange
(Smallblackgear)
1Set
Mediaassistance 1Set Ribbonstocker
(3ribboncassettesareset)
1Set
USBcable 1pc.

LCX603-UM-651-9370 2-10
2 Setup
2.5 Conrming the power supply and the LAN cable
(1) ConrmthespeciedACpowerissuppliedontheACpoweroutlet.
DonotconnecttheACpowercableyet.
(2) PreparetheLANcableiftheLCX603connectbytheLANcable.

LCX603-UM-651-9370 2-11
2 Setup
2.6 Parts Names and Functions
Part Names 1
Control panel
Label tray
Outlet
Cross cutter unit
Laminate stocker
Separator
winder bobbin
Separator
Dancer roller 1
Press roller
Feed roller
Laminate bar
Cutter unit
Press lever
Laminate winder bobbin
Dancer roller 2
Control panel................................Carryoutoperationsandvarioussettings.
Separator......................................Setwhenunnecessarymediaisdetached.
Separator winder bobbin............Rollsupdetachedunnecessarymedia.
Press lever....................................Opensandclosesthepressrollerwhenthemediaisset.
Laminate bar.................................Usedwhenlaminateisset.
Laminate winder bobbin.............Rollsupthelaminatebackingsheet.
Laminate stocker.........................Setsthelaminate.
Feed roller.....................................Feedsthemedia.
Press roller...................................Thruststhemediaintothefeedroller.
Dancer roller (1, 2)........................Usedwhensetting/feedingmedia.
Cutter unit.....................................Cuts(stenciling,frame-cutting)media.
Label tray......................................Traythatreceivescompletedlabels.
Cross cutter unit..........................Cutterusedforcross-cutting(horizontalcutting)media.
Outlet.............................................Sectionthatoutputsmedia.

LCX603-UM-651-9370 2-12
2 Setup
Part Names 2
Media stocker
Ribbon stocker
Ribbon cassette
AC line inlet
Power switch
Network interface
USB interface
Emergency Stop Switch
Ribbon cassette...........................Usedwhensettingtheribbon.
Ribbon stocker.............................Unitthatsetstheribboncassette.
Media stocker...............................Unitthatsetsthemedia.
USB interface...............................ConnectorusedwhenconnectingthisdeviceviaUSBI/F.
Network interface.........................ConnectorusedwhenconnectingthisdevicevianetworkI/F.
Power switch................................Switchforturningthepoweron/off.
AC line inlet...................................Connectorthatconnectsthepowercord.
Emergency Stop Switch..............Presstostoptheunit.Pleaseusethisincaseofemergency.
