GREAT PLAINS Verti-Till VT5300 User manual

Assembly Instructions for the Ridge Splitter
Verti-Till
9/23/03
Your initial action is to bolt the angled drop stubs [(3) 589-147H] to the back 4x4 tube on the
Verti-Till using 5/8x4x5 ½ U-Bolts [(63) 806-184C] 5/8” hex nuts [(25) 803-021C] and 5/8” lock
washers [(26) 804-022C]. Be sure to place them as shown on the overhead layout. Do not tighten these
bolts at this time. Your next step is to U-Bolt the splitter shank tube(s) [(1) 589-077D or 589-081D] to
the drop stubs. Be sure everything is placed with the correct dimensions and tighten everything down at
this time.
Your spring shank should come to you pre-assembled, so installation of these should be fairly
straightforward. Take the shank mount plate off of the assembly and bolt the spring shank assembly to
the splitter shank tube. Space the spring shank assemblies out as shown on the overhead layout and
tighten bolts.

4/21/2004
REF # DESCRIPTION PART NO. VT5300 VT7300
1 72" SPLITTER SHANK TUBE 589-077D 2
102" SPLITTER SHANK TUBE 589-081D 1
2 SPRING SHANK ASSEMBLY 589-136S 4 6
3 ANGLED DROP STUB 589-147H 4 4
4 PLOW 1/2-10X2 1/2 GR5 802-590C 8 12
5 NUT HEX 3/4-10 PLT 803-027C 32 32
6 NUT HEX TOP LOCK 1/2-13 PLT 803-342C 8 12
7 WASHER FLAT 1/2 USS PLT 804-017C 4 6
8 WASHER LOCK SPRING 3/4 PLT 804-023C 32 32
9 U-BOLT 3/4-10X4 1/32X5 3/8 806-012C 16 16
10 CHISEL POINT 5/8X2X15 820-032C 4 6
11 MAX MULCHER SHANK MC0013 1 1
12 CUP WASHER 589-065D 1 1
13 SHANK BOLT SPACER 589-070D 2 2
14 SHANK MOUNT PLATE 589-071D 1 1
15 SHANK PIVOT BUSHING 589-072D 1 1
16 SHANK SPRING BOLT 589-131H 1 1
17 SHANK SPRING BOLT TIGHTENER 589-132H 1 1
18 SHANK CRADLE RH 589-133H 1 1
19 SHANK CRADLE LH 589-134H 1 1
20 SHANK UPRIGHT 589-135H 1 1
21 HHCS 1/2-13X3 GR5 802-039C 1 1
22 HHCS 5/8-11X2 GR5 802-055C 2 2
23 HHCS 5/8-11X4 GR5 802-060C 1 1
24 HHCS 5/8-11X6 GR5 802-116C 2 2
25 HHCS 3/4-10X5 1/2 GR5 802-594C 1 1
26 NUT HEX 5/8-11 PLT 803-021C 4 4
27 NUT LOCK 5/8-11 PLT 803-024C 1 1
28 NUT LOCK 3/4-10 PLT 803-026C 1 1
29 NUT HEX JAM 1-8 PLT 803-030C 1 1
30 NUT HEX TOP LOCK 1/2-13 PLT 803-342C 1 1
31 WASHER FLAT 1/2 USS PLT 804-017C 2 2
32 WASHER LOCK SPRING 5/8 PLT 804-022C 4 4
33 SPRING COMP 3.13OD .63W 14.0LG 807-217C 1 1
(INDIVIDUAL PARTS INCLUDED IN (589-136S) SPRING SHANK ASSEMBLY)
VERTI-TILL FINISHING ATTACHMENTS
RIDGE SPLITTER
RIDGE SPLITTER PARTS LIST
Verti-Till Ridge Splitter.xls
