Great Stage Light GLM007-280 User manual

Moving Head Light
BEAM WASH SPOT 280W 10R
USER MANUAL
GLM007-280
Attention: This manual includes the important information of how to
installation and use the machine safely. Please operate as the
requirements after read the manual carefully. At the same time please
keep it carefully in case one day you needed.
！！First please unlock the X-, Y-axis locking ！！

Notice
WARN: This Lamp brightness is too high, don’t close range illuminate
people or flammable objects for a long time, otherwise, who will be burned or
cause a fire.
Firstly thank you for your appreciation of our professional lighting product.
This manual includes the important information of how to installation and use
this light safely. Please operate as the requirements after read the manual carefully. At
the same time please keep it carefully in case one day you needed.
This kind of moving head light is the perfect combination of humanity and
industrial design with beautiful modeling. The body of the light use aluminum alloy
and high temperature durable engineering plastic material with wonderful cooling
effect. Transmission mechanism adopts electronic positioning technology. This
product fully meets the CE standard using the international standard control signal
DMX512.It is widely used in television, disco, dance hall, night club and other indoor
outdoor performance.
This product is performance and packed well when they are sale.
All users should strictly follow the stated warning and instructions. Any damage
caused by misuse not related with us. It’s not our responsibility that the fault and
problem for ignore the operation manual.

Note: Please connect ground safely when use this equipment.
It provides 13 different colors, 22 gobos, quickly change the shape of beam
and shows a spectacular half empty effect., With light weight, low power, fashion
design, powerful function, high brightness, it can easily installed in any place. Such
as moving stage, TV activities, exhibition hall or meeting room.
Technical parameters:
Voltage:110-240v 50/60Hz
Power ：450w
Lamp can be choose：Osram 280w
Color temperature: 8000K
Luminous flux : 7950 lm
Channel mode: 16/24Channels
Color Wheel: 13 colors with white
Gobo Wheel: 2 gobos wheel ,one fixed gobo wheel,with 15gobos,rotation gobo
wheel with 10gobos.
Shut: up to 13 times per second with automatic pulse effect.
Dimmer: 0-100% linear dimmer
Prism:3D 6-facet prism and 8-facet prism
Lens: High brightness optical lens
Focus: electronic focus
Control mode: DMX 512
Frost: 0% - 100% linear frost
Control bulb on/off and reset delay function

Display: Touch screen
Carton size:47.5*44*71.5cm G.W:26kg
Signal connection:
The connection of lights and the connection of light and controller must used
two core shielding wire with its diameter not less than 0.5 mm. We should pay
special attention that the connection of three core of XLR plugs and socket cannot
contact with inner shell and between core and core also cannot contact.
When use XLR-XLR control line, connect the DMX outlet of controller with the
DMX input of the first machine, and connect the DMX outlet of the first machine
with DMX input the second machine. Repeating the process until all machines
connected. At last connect the loop plug with the last lamp’s signal output the
connection of controller mode is completed.
This menu of control display board specifically designs for the various types of
moving light equipped with various function control mode, operate easy. For some
operation that some type of light without it is invalid corresponding menu options
setting.
Menu Operation of Moving Head Light:
There are several features are offered in the base of control panel. Such as
setting the DMX address, switch on or off the bulb, run the program and the selection
of work mode.
Menu operation:
It provides various functions on the base of the control panel. Such as setting DMX

address, switch the bulb, test program running, work mode selection and so on.
Display board, control board.
DMX channel:
一、16/24 channel mode.
Standard
Mode
Simple Mode
DMX
value
Channel function
1
1
0－255
X
2
*
0－255
X fine
3
2
0－255
Y
4
*
0－255
Y fine
5
3
0－255
X Y speed
6
4
Macro function
0－19
Empty
20－24
Save model (230w)
25－129
Empty
130－139
Controller turn on lamp
140－149
X Y axis reset
150－159
Empty
160－169
Effect reset
170－199
Empty
200－209
Light reset
210－229
Empty
230－239
Controller turn off lamp
240－255
Empty
7
5
Color wheel
0
White
1-9
White- Crimson
10-18
Crimson -Light yellow
19-27
Light yellow -Blue
28-36
Blue -Purple red
37-45
Purple red –Deep yellow
46-54
Deep yellow –Blue green
55-63
Blue green-green
64-72
Green-yellow
73-81
yellow –rose red
82-90
rose red -brown
91-99
brown –cool color
100-108
cool color -fluorescence
109-117
fluorescence -Brown

118-126
Brown -white
130－134
Crimson + light yellow
135－138
Light Yellow + Blue
139－143
Blue + purple
144－147
Purple + dark yellow
148－152
Deep yellow + blue green
153－157
Blue green + green
158－161
Green + Yellow
162－166
Yellow + Rose red
167－171
Rose red + brown
172－176
Brown + Cool
177－180
Cool + fluorescence
181－185
Fluorescent + Brown
186－189
Brown + White
190－215
From fast to slow flowing water
218－243
From slow to fast flowing water
244－255
Color film by random variation voice
8
*
Empty
9
6
Empty
10
7
Fixed gobo
0－3
Empty
4－9
Gobo 1
10－15
Gobo 2
16－21
Gobo 3
22－27
Gobo 4
28－33
Gobo 5
34－39
Gobo 6
40－45
Gobo 7
46－51
Gobo 8
52－57
Gobo 9
58－63
Gobo 10
64－69
Beam 1
70－75
Beam 2
76－87
Beam 3
Pattern jitter from slow to fast
88－95
Gobo 1
96－103
Gobo 2
104－111
Gobo 3
112－119
Gobo 4
120－127
Gobo 5
128－135
Gobo 6
136－143
Gobo 7
144－151
Gobo 8
152－159
Gobo 9

160－165
Gobo 10
168－175
Beam 1
176－183
Beam 2
184－199
Beam 3
200－255
Fixed pattern of water from slow to fast
11
8
Rotation Gobo
0
Empty
1-4
Soft light
Index effects
5-7
Gobo 1
8-10
Gobo 2
11－13
Gobo 3
14－16
Gobo 4
17－19
Gobo 5
20－22
Gobo 6
23－25
Gobo 7
26-28
Gobo8
29－31
Gobo 9
Rotation effect
32-34
Gobo 1
35－37
Gobo 2
38－40
Gobo 3
41－43
Gobo 4
44-46
Gobo 5
47－49
Gobo 6
50-52
Gobo 7
53－55
Gobo 8
56－59
Gobo 9
Shake effect
60-67
Gobo 1
68－75
Gobo 2
76－83
Gobo 3
84－91
Gobo 4
92-99
Gobo 5
100－107
Gobo 6
108-115
Gobo 7
116-123
Gobo 8
124－129
Gobo 9
Rotation shake effect
130-137
Gobo 1
138－145
Gobo 2
146－153
Gobo 3
154－161
Gobo 4
162－169
Gobo 5
169-176
Gobo 6

194－255
Counterclockwise from slow to fast flowing water
16
12
Frost
0－64
Empty
65－255
Linear frost
17
13
Zoom
0－255
Linear zoom
18
*
0－255
Zoom fine
19
14
0－255
Focus
20
*
0－255
zoom fine
21
*
0－255
Empty
22
15
Strobe
177－184
Gobo 7
185－192
Gobo 8
193-199
Gobo 9
200－201
Soft light
202－221
Flow reversal from fast to slow
222－223
Stop
224－243
Water from slow to fast forward
244－255
Color film by random variation voice
12
9
Gobo rotation
0－127
Index
128－177
Counterclockwise from slow to fast flowing water
178－203
Stop
204-255
Clockwise from fast to slow flowing water
13
*
0－255
Empty
Prism
14
10
0－19
Empty
20－75
Six linear prism
76－255
Eight round prism
15
11
Prism rotation
0－127
Index
128-191
Clockwise from fast to slow flowing water
192-193
Empty

0－31
Strobe off
32－63
Strobe on
64－95
Strobe from fast to slow
96－127
Strobe on
128－143
From fast to slow,faster start off slowly
144－159
From slow to fast,fast start off slowly
160－191
Strobe on
192－223
Random strobe from slow to fast
224－255
Strobe on
23
16
Dimmer
0－255
Linear dimmer
24
*
Empty
Light Protection and Maintenance:
You should exchange the lens timely when you find the damage. You should
also instant replacement the bulb when you find the deformation damage. The aging
bulb has a danger of blowout. Please check the power fuse of light when the light
unable to start. Install the corresponding specification fuse 6.35X32 T15A/250V
when burning. Light has overheating protection device, Protection device will
automatically cut off power supply when overheating. Please check the fan’s
operation, dirt jam between fan and fan nets when the situation happened. Find the
reason and repair then restarting light. Attention only qualified technical personnel
can repair it.
Light cleaning:
It is necessary to keep the light cleaning to ensure its reliable use. The fan
should clean every 15 days. It needed to clean periodically of the internal and
external optical lens, mirror and coating color filter in order to optimize the efficacy
output. Do not use any chemical solvents containing to clean color filter. The
frequency of cleaning is according to the operation of light and the environment of
operation. With soft cloth and general glass clean products clean the light. Suggest

clean outside optical system every 20 days. Clean internal optical system at least
every 30/60 days. Don’t use alcohol and organic solvent wipe to clean the shell of
light lest cause damage.
