Green Brook Aquila SLLLED3 User manual

IMPORTANT
This product should be installed by a competent person
and in accordance with the current IET Wiring Regulations.
If in doubt,consult a qualified electrician.
GENERAL INFORMATION
IMPORTANT
• Never look directly into the LED light source.
• Do not place in water or other liquids
• Never operate with wet hands
• Never cover the fitting
• Never operate when the casing is open, or when the
wiring casing is missing or damaged, or when the diffuser
is defective
• Never attempt to repair this unit yourself, there are no user
serviceable parts
• Never remove the diffuser
Installation Instructions
for Aquila Range - LED Link Lights
Part Nos: Cool hite - SLLLED3, SLLLED4, SLLLED7, SLLLED14,
SLLLED18 & SLLLED22
Part Nos: arm hite - SLLLED3 , SLLLED4 ,
SLLLED7 , SLLLED14 , SLLLED18
& SLLLED22
INSTALLATION
1. Fixing holes must be clear of any obstruction (eg.cables)
between the mounting surface and fitting. The minimum
distance between the fitting and any adjacent
flammable surface is 10mm (as shown In Dia.1).
Dia.1
2. Select the type of brackets you need to use and mark off
the fixing points. If fixing to a shelf or under a cupboard
check the screw size required and screw into place.
(see Dia.2).
Dia.2
Dia.3
SLLLED T5 Ins Feb17. xp_Layout 1 06/03/2017 13:19 Page 1

Issue no: 704739
3. Fittings may be butted (see Dia.3) together or with the
optional link lead (codes: SLLL250NJ -250mm,
SLLL500NJ - 500mm or SLLL1000NJ -1000mm)
Please note the TOTAL linked fittings limit:
SLLLED3/WW = ax 30 connections
SLLLED4/WW = ax 30 connections
SLLLED7/WW = ax 18 connections
SLLLED14/WW = ax 15 connections
SLLLED18/WW = ax 10 connections
SLLLED22/WW = ax 8 connections
4. Connect the mains cable to a fixed socket or spur
incorporating a 3 amp fuse.
Disposal Information for the Product user:
1. Please note the requirement to dispose of Waste Electrical
& Electronic Equipment separately from household waste
(WEEE marked with crossed out wheelie bin symbol).
2. This equipment may contain substances that are
hazardous to health and the environment if disposed of
carelessly. It is important that it is separated from normal
household waste and recycled in the WEEE chain.
3. Please consider your role in contributing to re-use and
re-cycling by taking this product at end of life to a
collection centre for waste electrical equipment at your
local Civic Amenity site.
Part No Colour
Temperature
LED Power
Consumption
LED’s
Array Dimensions
Cool hite
SLLLED3 4000K 3W - 87 lm/W 18 L268 x W22 x H44mm
SLLLED4 4000K 4W - 85 lm/W 24 L343 x W22 x H44mm
SLLLED7 4000K 7W - 86 lm/W 40 L571 x W22 x H44mm
SLLLED14 4000K 14W - 84 lm/W 62 L904 x W22 x H44mm
SLLLED18 4000K 18W - 85 lm/W 84 L1204 x W22 x H44mm
SLLLED22 4000K 22W - 86 lm/W 102 L1504 x W22 x H44mm
arm hite
SLLLED3WW 3000K 3W - 83 lm/W 18 L268 x W22 x H44mm
SLLLED4WW 3000K 4W - 83 lm/W 24 L343 x W22 x H44mm
SLLLED7WW 3000K 7W - 83 lm/W 40 L571 x W22 x H44mm
SLLLED14WW 3000K 14W - 82 lm/W 62 L904 x W22 x H44mm
SLLLED18WW 3000K 18W - 81 lm/W 84 L1204 x W22 x H44mm
SLLLED22WW 3000K 22W - 83 lm/W 102 L1504 x W22 x H44mm
GUARANTEE
Your GreenBrook LED Link Lights
are guaranteed for 3 year from
the date of urchase.
This is in addition to your statutory rights.
PLEASE KEEP THESE INSTRUCTIONS
SAFE FOR FUTURE REFERENCE
EST ROAD . HARLO
ESSEX . CM20 2BG . UK
[e-mail]
www.greenbrook.co.uk
TECHNICAL INFORMATION
Rated Voltage: 230V AC 50Hz
Beam Angle: 120º
Temp Range: -20 to 40ºC
Switching Cycle: 8000
Life expectance
of fitting: 20,000 hours
Conforms to: EN 60598-1, EN 60598-2-1
EN 61347-1, EN 61347-2-13
