LITESHEET BriteCor AC BWB User manual

BWB BriteCor AC Direct
Wet Location Brik
Installation Manual

BWB BriteCor Wet Brik Installation Manual
Page 2of 7
NOTES
•WARNING –Risk of fire or electric shock.
•WARNING - It is recommended that installation be
performed by a certified electrician.
•All electrical connections must be in compliance with
local codes, ordinances or the national electrical code
(NEC). Contact your municipal building department to
learn about your local codes, permits and/or
inspections.
•Do not connect this Luminaire to an electrical system
that does not provide means for equipment grounding.
Never use a fixture in a two-wire system that is not
grounded.
•If dimming functionality is included, use only with
Litesheet approved dimmers.
•This unit is not approved for use in ducted ceilings.
•Do not use excessive force when manipulating cables
and wires.
•WARNING –To prevent wiring damage or abrasion, do
not pinch wires between surfaces.
•WARNING –Only connect Luminaire to the voltage
indicated by the Luminaire label. It is intended for
direct connection to this voltage. DO NOT connect to a
different or unknown voltage.
•Enclosure is rated for Wet Location and IP66. When
installing incoming connections, all wire ports must be
sealed using similar rated hardware to maintain Wet
Location and IP66 rating.
Document #: 11-00030
Rev: B
Date: 4/27/2022

LiteSheet Solutions
Page 3of 7
CONTENTS OF KIT
•BWB Wet Brik
•(Optional) Mounting Brackets
TOOLS AND ADDITIONAL PARTS REQUIRED
•P2 Philips Head Screwdriver / Drill
•Flat Head Screwdriver
•3/8” Drive
Preparation
1. Turn off power source.
2. Drill and attach mounting screws to
mounting surface.
Installation (Flip Bracket)
1. Mount the luminaire to the mounting
surface using the provided brackets.

BWB BriteCor Wet Brik Installation Manual
Page 4of 7
2. Lock the bracket in place using the #8-32
side screw.
Installation (Adjustable Bracket)
1. Mount the luminaire to the mounting
surface using the attached brackets.
2. Adjust the angle of the luminaire to the
desired position. Tighten the 3/8” bolts of
the bracket to lock the luminaire in place.

LiteSheet Solutions
Page 5of 7
Wiring Guide
1. Temporarily remove the (3) screws from
the front of the luminaire. Loosen the 3
screws in the back luminaire.
2. Remove the PG 13.5 end cap from the
fixture. Insert incoming power wires/
cable. Reseal the wire port with IP66 or
Wet Location rated hardware (not
included.)

BWB BriteCor Wet Brik Installation Manual
Page 6of 7
3. Connect the incoming ground connection
to the green ground wire provided.
Connect the incoming line power to the
luminaire disconnect provided.
•Black –Line Power (Hot)
•White –Neutral
•Green –Safety Ground
4. Close the luminaire lid and reinsert the
machine screws. Tighten the screws fully
to ensure a tight seal.
5. Apply power to luminaire.

LiteSheet Solutions
Page 7of 7
For warranty information and
technical support, contact us at:
434-446-1460
Find more great products at:
www.litesheet.com
