GreenMachine GM09000 User manual

NOTICE: Do not use E15 or E85 fuel (or fuel containing greater than 10% ethanol) in this product. It is a violation
of federal law and will damage the unit and void your warranty.
AVIS : Ne pas utiliser d’essence E15 ou E85 (ou un carburant contenant plus de 10 % d’éthanol) dans ce produit. Une telle
utilisation représente une violation de la loi fédérale et endommagera l’appareil et annulera la garantie.
AVISO: No utilice combustibles E15 o E85 (ni combustibles que contengan más de 10 % de etanol) con este producto. Esto
constituye una violación a la ley federal, dañará la unidad y anulará la garantía.
OPERATOR’S MANUAL
MANUEL D’UTILISATION / MANUAL DEL OPERADOR
BLOWER / VACUUM
SOUFFLANTE / ASPIRATEUR
SOPLADORA / ASPIRADORA
GM09000
ALL VERSIONS
TOUTES LES VERSIONS / TODAS LAS VERSIONES
To register your Green Machine product, please visit:
http://register.greenmachinetools.com/
Pour enregistrer votre produit de Green Machine, s’il vous
plaît la visite: http://register.greenmachinetools.com/
Para registrar su producto de Green Machine por favor
visita: http://register.greenmachinetools.com/
Your blower/vacuum has been engineered and manufactured to high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Cette soufflante / aspirateura été conçue et fabriquée conformément
aux strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation. Correctement entretenue, elle vous donnera des
années de fonctionnement robuste et sans problème.
AVERTISSEMENT : Pour réduire les risques de
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Su sopladora / aspiradora ha sido diseñada y fabricada de
conformidad con las estrictas normas para brindar fiabilidad,
facilidad de uso y seguridad para el operador. Con el debido cuidado,
le brindará muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones, el
usuario debe leer y comprender el manual del operador antes
de usar este producto.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS

i
Fig. 1
Fig. 3
Fig. 2
Fig. 4
Fig. 6
Fig. 7
Fig. 5
A
B
A
A
A
C
A
B
B
B
B
C
N
F
D
M
EL
J
K
C
H
G
O
I
P
See this fold-out section for all the figures referenced in the operator’s manual.
Voir que cette section d’encart pour toutes les figures a adressé dans le manuel d’utilisation.
Vea esta sección de la página desplegable para todas las figuras
mencionó en el manual del operador.
C
Q
B
A
A- Lower vacuum tube (tube d’aspiration inférieur, tubo inferior de la
aspiradora)
B- Shoulder strap (bandoulière, correa para el hombro)
C- Cruise control lever/throttle lock (levier de régulateur de vitesse /
verrouillage d’accélération, palanca de control de crucero / seguro del
acelerador)
D- Upper vacuum tube (tube d’aspiration supérieur, tubo superior de la
aspiradora)
E- Vacuum tube screw (vis de tube d’aspiration, tornillos de los tubos de la
aspiradora)
F- Vacuum bag (sac à débris, saco de la aspiradora)
G - Throttle trigger (gâchette d’accélérateur, gatillo del acelerador)
H- Stop switch (commutateur d’arrêt, interruptor del apagado)
I - Vacuum handle (poignée d’aspirateur, mango de la aspiradora )
J- Fuel cap (bouchon du réservoir, tapa del tanque de combustible)
K- Starter grip and rope (poignée du lanceur et corde, mango del
arrancador y cuerda)
L- Primer bulb (poire d’amorçage, bomba de cebado)
M- Choke lever (levier de volet de départ, palanca del anegador)
N- Upper handle (poignée supérieure, mango superior)
O- Vacuum bag adaptor (adaptateur de sac à débris, adaptador del
saco de la aspiradora)
P - Muffler (silencieux, silenciador)
Q- Raised slot (fente en saillie, ranura realzada)
A - Flat head screwdriver (tournevis à lame
plate, destornillador de punta plana)
A - Upper blower tube (tube de soufflante
supérieur, tubo superior de la sopladora)
B - Sweeper nozzle (embout éventail, boquilla
para barrer)
A- Sweeper nozzle (embout éventail, boquilla
para barrer )
B - Upper blower tube (tube de soufflante
supérieur, tubo superior de la sopladora)
C - Blower housing outlet (sortie du logement
de la soufflante, salida del armazón de la
sopladora)
A - Vacuum bag adaptor (adaptateur de sac à
débris, adaptador del saco de la aspiradora)
B - Vacuum bag (sac à débris, saco de la
aspiradora)
A - Adaptor installed in vacuum bag (adaptateur
installé dans le sac à débris, adaptador
instalado en el saco de la aspiradora)
B - Raised slot (fente en saillie, ranura realzada)
C - Raised locking tab (languette de
verrouillage en saillie, orejeta realzada de
aseguramiento)
A- Vacuum bag assembly (ensemble de sac à
débris, conjunto del saco de la aspiradora)
B- Vacuum inlet door (volet d’entrée d’air,
puerta de la entrada de la aspiradora)
C- Door tab (languette du volet, orejeta de la
puerta)

ii
Fig. 8 Fig. 10 Fig. 13
Fig. 14
Fig. 15
Fig. 11
Fig. 12
Fig. 9
A
B
C
A
C
E
D
B
A
A
B
A
AB
B
D
E
A- Vacuum tube assembly (ensemble de tubes
d’aspiration, conjunto de los tubos de la
aspiradora)
B- Vacuum inlet door (volet d’entrée d’air,
puerta de la entrada de la aspiradora)
C- Screw (vis, tornillo)
D - Vacuum opening (ouverture d’aspiration,
abertura de aspiración)
E - Screw mount (trous de vis, agujeros de
tornillos)
A - Stop switch (commutateur d’arrêt,
interruptor del apagado)
B- Throttle trigger (gâchette d’accélérateur,
gatillo del acelerador)
C - Cruise control lever/throttle lock (levier
de régulateur de vitesse / verrouillage
d’accélération, palanca de control de
crucero / seguro del acelerador)
D- Primer bulb (poire d’amorçage, bomba de
cebado)
E - Starter grip and rope (poignée du lanceur et
corde, mango del arrancador y cuerda)
PROPER BLOWER OPERATING POSITION
POSITION D’UTILISATION ADÉQUATE
DE LA SOUFFLANTE
POSICIÓN DE FUNCIONAMIENTO
CORRECTA DE LA SOPLADORA
A - Sweeper nozzle (embout éventail, boquilla
para barrer)
A- Cruise control lever (levier de régulateur de
vitesse, palanca de control de crucero)
B- Throttle trigger (gâchette d’accélérateur,
gatillo del acelerador)
PROPER VACUUM OPERATING POSITION
POSITION D’UTILISATION ADÉQUATE
DE L’ASPIRATEUR
POSICIÓN DE FUNCIONAMIENTO
CORRECTA DE LA ASPIRADORA
Keep muffler away from the body (garder
l’échappement à l’écart de du corps, mantenga
el silenciador alejado del cuerpo)
A- Turn the dial to open and close (tourner
le cadran pour ouvrir et fermeture, gire el
selector para abrirla y cerrar )
B- Air filter cover (couvercle du filtre à air, tapa
de la cámara de ventilación)
A- Air filter cover (couvercle du filtre à air, tapa
de la cámara de ventilación)
B - Air filter (filtre à air, filtro de aire)

2 - English
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
General Safety Rules........................................................................................................................................................ 3
Règles de sécurité générales / Reglas de seguridad generales
Specific Safety Rules........................................................................................................................................................ 4
Règles de sécurité particulières / Reglas de seguridad específicas
Symbols............................................................................................................................................................................ 5
Symboles / Símbolos
Features............................................................................................................................................................................ 6
Caractéristiques / Características
Tools Needed.................................................................................................................................................................... 6
Outils nécessaires / Herramientas necesarias
Assembly.......................................................................................................................................................................6-7
Assemblage / Armado
Operation.....................................................................................................................................................................8-10
Utilisation / Funcionamiento
Maintenance..............................................................................................................................................................10-11
Entretien / Mantenimiento
Troubleshooting.............................................................................................................................................................. 12
Dépannage / Solución de problemas
Warranty ....................................................................................................................................................................13-14
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior

3 - English
WARNING:
READ AND UNDERSTAND ALL INSTRUCTIONS. Fail-
ure to follow all instructions listed below may result in
electric shock, fire and/or serious personal injury.
READ ALL INSTRUCTIONS
Do not allow children or untrained individuals to use this
unit.
Never start or run the engine inside a closed area;
breathing exhaust fumes can kill.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1 along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
Keep all bystanders, children, and pets at least 50 ft.
away.
Wear heavy long pants, long sleeves, boots, and gloves.
Do not wear loose fitting clothing, short pants, sandals,
jewelry of any kind, or go barefoot.
To reduce the risk of injury associated with objects being
drawn into rotating parts, do not wear loose clothing,
scarves, neck chains, and the like.
Secure long hair so it is above shoulder level to prevent
entanglement in any rotating parts.
Do not operate this unit when you are tired, ill, upset, or
under the influence of alcohol, drugs, or medication.
Do not start or operate the engine in a confined space,
building, or other unventilated space where dangerous
carbon monoxide fumes can collect. Carbon monoxide,
a colorless, odorless, and extremely dangerous gas, can
cause unconsciousness or death.
Do not operate in poor lighting.
Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
Wear a face filter mask in dusty conditions to reduce the
risk of injury associated with the inhalation of dust.
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure
to hot surfaces.
Never operate the unit without a spark arrestor screen;
this screen is located inside the muffler.
Product users on United States Forest Service land, and in
some states, must comply with fire prevention regulations.
This product is equipped with a spark arrestor; however,
other user requirements may apply. Check with the
federal, state, or local authorities in your area.
Before storing, allow the engine to cool.
Empty fuel tank into a container approved for gasoline
and restrain the unit from moving before transporting in
a vehicle.
To reduce the risk of fire and burn injury, handle fuel with
care. It is highly flammable.
Do not smoke while handling fuel.
Mix and store fuel in a container approved for gasoline.
Mix fuel outdoors where there are no sparks or flames.
Select bare ground, stop engine, and allow to cool before
refueling.
Loosen fuel cap slowly to release pressure and to keep
fuel from escaping around the cap.
Tighten the fuel cap securely after refueling.
Wipe spilled fuel from the unit. Move 30 ft. away from
refueling site before starting engine.
Never attempt to burn off spilled fuel under any
circumstances.
Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.
Maintain the unit per maintenance instructions in this
Operator’s Manual.
Inspect the unit before each use for loose fasteners, fuel
leaks, etc. Replace damaged parts.
Do not use on a ladder, rooftop, tree, or other unstable
support. Stable footing on a solid surface enables better
control of the blower in unexpected situations.
Before cleaning, repairing, or inspecting, shut off the
engine and make certain all moving parts have stopped.
Disconnect the spark plug wire, and keep the wire away
from the plug to prevent starting.
Service on the blower/vacuum must be performed by
qualified repair personnel only. Service or maintenance
performed by unqualified personnel could result in injury
to the user or damage to the product.
GENERAL SAFETY RULES

4 - English
Always hold the blower/vacuum in your right hand during
blower operation. Refer to the Operation instructions later
in this manual for proper position during vacuum opera-
tion and additional information.
Never place objects inside the blower tubes.
Use only as directed in this operator’s manual.
Do not operate vacuum without vacuum bag installed;
flying debris could cause serious injury. Always close
vacuum bag completely before operating.
Rotating impeller blades can cause severe injury. Stop
the engine and ensure impeller blades have stopped
rotating before opening the vacuum door or installing/
changing tubes. Do not put hands or any other object
into the vacuum tubes while they are installed on the unit.
Never run the unit without the proper equipment attached.
When used as a blower, always install the blower tubes.
When used as a vacuum, always install the vacuum
tubes and vacuum bag. Make sure the vacuum bag is
completely zipped when the unit is running to avoid flying
debris.
Avoid situations that could catch the vacuum bag on
fire. Do not operate near an open flame. Do not vacuum
warm ash from fireplaces, barbecue pits, brush piles, etc.
Do not vacuum discarded cigars or cigarettes unless the
cinders are completely cool.
Never place blower on any surface, except a hard, clean
surface when engine is running. Gravel, sand, and other
debris can be picked up by the air inlet and thrown at the
operator or bystanders, causing possible serious injuries.
To reduce the risk of hearing loss associated with sound
level(s), hearing protection is required.
To reduce the risk of injury associated with contacting
rotating parts, stop the engine before installing or
removing attachments. Always disconnect the spark plug
before performing maintenance or accessing any movable
parts.
Never use blower near fires, fireplaces, hot ashes,
barbecue pits, etc., which may cause fire to spread.
Do not point the blower nozzle in the direction of people
or pets.
Never run the unit without the proper equipment attached.
Always ensure the blower tubes are installed.
This product is intended for infrequent use by homeown-
ers and other occasional users for such general applica-
tions as blowing leaves and lawn clippings, etc. It is not
intended for prolonged use. Prolonged periods of opera-
tion can cause circulatory problems in the user’s hands
due to vibration. For such use, it may be appropriate to
use a product having an anti-vibration feature.
FUELING
Fuel is highly flammable. Take precautions when using
to reduce the chance of serious personal injury.
Store fuel in a cool, well-ventilated area, safely away from
spark and/or flame-producing equipment.
Store fuel in containers specifically designed for this
purpose.
Only refuel outdoors and do not smoke while refueling.
Add fuel before starting the engine. Never remove the cap
of the fuel tank or add fuel while the engine is running or
when the engine is hot.
Do not smoke while handling fuel.
Mix and store fuel in a container approved for gasoline.
Mix fuel outdoors where there are no sparks or flames.
Loosen fuel cap slowly to release pressure and to keep
fuel from escaping around the cap.
Tighten the fuel cap securely after refueling.
Wipe spilled fuel from the unit. Move 30 feet away from
refueling site before starting engine.
Never attempt to burn off spilled fuel under any circum-
stances.
To reduce the risk of fire and burn injury, handle fuel with
care. It is highly flammable.
If fuel is spilled, do not attempt to start the engine but
move the machine away from the area of spillage and
avoid creating any source of ignition until fuel vapors
have dissipated.
Replace all fuel tank and container caps securely.
Empty fuel tank into a container approved for gasoline
and restrain the unit from moving before transporting in
a vehicle.
When draining the fuel tank, use an approved fuel storage
container in a well-ventilated area.
Select bare ground, stop engine, and allow to cool before
refueling.
Save these instructions. Refer to them frequently and use
them to instruct others who may use this tool. If you loan
someone this tool, loan them these instructions also.
SPECIFIC SAFETY RULES

5 - English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME EXPLANATION
Safety Alert Symbol Indicates a potential personal injury hazard.
Read Operator’s Manual To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye and Hearing Protection
Always wear eye protection with side shields marked to
comply with ANSI Z87.1 as well as hearing protection when
operating this equipment.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Ricochet Thrown objects can ricochet and result in personal injury or
property damage.
Vacuum Door Do not run unit while vacuum door is unsecured.
Long Hair Risk of long hair being drawn into air inlet.
Blower Tubes Do not run unit without tubes in place.
Loose Clothing Risk of loose clothing being drawn into air intake.
Gasoline and Lubricant
Use unleaded gasoline intended for motor vehicle use with
an octane rating of 87 [(R + M) / 2] or higher. This product is
powered by a 2-cycle engine and requires pre-mixing gasoline
and 2-cycle lubricant.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SYMBOLS

6 - English
PRODUCT SPECIFICATIONS
Engine Displacement.......................................................................................................................................................26cc
Air Velocity:
*MPH...........................................................................................................................................................................150
*CFM...........................................................................................................................................................................400
Sound Pressure............................................................................................................................................................ 70dBa
Weight .........................................................................................................................................................................9.5 lbs.
*Rated per ANSI B175.2
KNOW YOUR BLOWER/VACUUM
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
BLOWER TUBE AND NOZZLES
The blower tube and nozzles can be assembled and installed
on the blower without using any tools.
CRUISE CONTROL LEVER/THROTTLE LOCK
The cruise control lever/throttle lock feature allows the user
to operate the blower without holding the throttle trigger.
To slow the engine, simply push the cruise control lever/
throttle lock forward.
ENGINE
The blower has a powerful 26cc engine with sufficient power
to handle tough blowing and vacuuming jobs.
SWEEPER NOZZLE
The sweeper nozzle allows for more area to be covered
during blower operation.
THROTTLE TRIGGER
The blower can be operated at any speed between idle and
full throttle.
VACUUM/MULCHER
Converting the blower to a vacuum/mulcher is simple and
can be done using a flat head screwdriver.
VACUUM BAG
The vacuum bag attaches to the blower easily by using the
vacuum bag adaptor.
VACUUM HANDLE
This feature allows user to perform vacuuming duties
comfortably.
VACUUM TUBES
The vacuum tubes can be installed on the blower using a
flat head screwdriver.
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
The following tool (not included or drawn to scale) is needed for assembly:
See Figure 2.
Flat Head Screwdriver
FEATURES
TOOLS NEEDED
ASSEMBLY
FEATURES

7 - English
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-332-1631 for assistance.
PACKING LIST
Blower
Upper Blower Tube
Sweeper Nozzle
Upper and Lower Vacuum Tubes
Vacuum Tube Screws (2)
Vacuum Bag
Vacuum Bag Adaptor
2-Cycle Engine Lubricant
Operator’s Manual
NOTE: Read and remove all hang tags and store with your
Operator’s Manual.
WARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of the product
with damaged or missing parts could result in possible
serious personal injury.
WARNING:
Do not attempt to modify this product or create acces-
sories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark plug
wire from the spark plug when assembling parts.
ASSEMBLING THE BLOWER TUBES
See Figures 3 - 4.
Align raised tabs on blower housing outlet to the slots on
upper blower tube; slide together and tighten securely by
twisting. Check tightness after initial use and retighten if
needed.
Attach sweeper nozzle to upper blower tube by aligning
raised tabs on upper blower tube; slide together and
tighten securely by twisting. Check tightness after initial
use and retighten if needed.
To remove the tubes, rotate the tubes to unlock them and
remove from the blower housing outlet.
INSTALLING THE VACUUM BAG
See Figures 5 - 6.
Remove the nozzle and upper blower tube from the
blower by twisting and removing from blower housing
outlet.
Unzip the vacuum bag and push the vacuum bag adaptor
through the opening opposite the zipper as shown. The
wider end of the adaptor will remain on the inside of the
vacuum bag when installed properly.
Align the raised slots on the vacuum bag adaptor with the
raised locking tabs on the blower housing outlet. Push
the vacuum bag adaptor onto the housing and twist to
lock into place.
 Rotate the vacuum bag until the shoulder strap is upright.
Make sure the vacuum bag is zipped and closed before
starting the unit.
INSTALLING THE VACUUM TUBES
See Figures 7 - 8.
WARNING:
Contact with rotating impeller blades could result in seri-
ous personal injury. Always stop the engine and ensure
impeller blades have stopped rotating before opening
the vacuum door or installing/changing tubes. Do not put
hands or any other object into the vacuum tubes while
they are installed on the unit.
To install the vacuum tubes:
Secure the upper and lower vacuum tubes together by
aligning the raised locking tabs with the raised slots.
Tap tube assembly on ground until the screw holes in
lower tube are in the raised slot of the upper tube. Secure
with supplied screws.
Depress door tab using a flathead screwdriver and open
vacuum inlet door.
Align screw mounts on vacuum opening with screws on
vacuum tube assembly.
Turning clockwise, tighten screws on upper vacuum tube
to secure to blower housing.
To remove the vacuum tubes:
Loosen screws of the upper vacuum tube by turning
counterclockwise.
Remove the vacuum tube assembly from the blower
housing.
Close the vacuum inlet cover door securely.
ASSEMBLY

8 - English
WARNING:
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING:
Operation of this equipment may create sparks that
can start fires around dry vegetation. A spark arrestor
may be required. The operator should contact local fire
agencies for laws or regulations relating to fire prevention
requirements.
APPLICATIONS
You may use this product for the purposes listed below:
Clearing leaves and other debris from your lawn
Keeping decks and driveways free from leaves and other
forms of debris
Vacuuming leaves from your lawn
FUELING AND REFUELING
FUEL MIXTURE
This product is powered by a 2-cycle engine and requires
pre-mixing gasoline and 2-cycle lubricant. Pre-mix unleaded
gasoline and 2-cycle engine lubricant in a clean container
approved for gasoline. DO NOT mix quantities larger than
usable in a 30-day period.
Recommended fuel: This engine is certified to operate on
unleaded gasoline intended for automotive use.
NOTE: We recommend you use premium 2-cycle lubri-
cant, PowerCare 2-cycle lubricant (6.4 oz. or 16 oz.), or
an equivalent high-quality synthetic 2-cycle lubricant in this
product. Mix at 2.6 oz. per gallon (US).
Do not use automotive lubricant or 2-cycle outboard
lubricant.
HIGH QUALITY 2-CYCLE ENGINE LUBRICANT
GASOLINE LUBRICANT
1.0 gal. (US) (3.8 liter) 2.6 oz. (76 ml)
2.5 gal. (US) (9.5 liter) 6.4 oz. (189 ml)
FILLING THE TANK
Clean the surface around the fuel cap to prevent con-
tamination.
Loosen the fuel cap slowly by turning counterclockwise.
Pour the fuel mixture carefully into the tank.
Clean and inspect the fuel cap gasket before replacing
the fuel cap.
Replace the fuel cap and tighten it by turning it clockwise.
Wipe spilled fuel from the product.
Move at least 30 ft. away from refueling area before start-
ing the product.
NOTE: It is normal for smoke to be emitted from a new
engine during first use.
WARNING:
Always shut off engine before fueling. Never add fuel to a
machine with a running or hot engine. Move at least 30 ft.
from refueling site before starting engine. Do not smoke
and stay away from open flames and sparks. Failure to
safely handle fuel could result in serious personal injury.
OXYGENATED FUELS
NOTICE:DO NOT USE E15 OR E85 FUEL (OR FUEL
CONTAINING GREATER THAN 10% ETHANOL) IN THIS
PRODUCT. IT IS A VIOLATION OF FEDERAL LAW AND
WILL DAMAGE THE UNIT AND VOID YOUR WARRANTY.
NOTE: Fuel system damage or performance problems
resulting from the use of an oxygenated fuel containing more
than the percentages of oxygenates stated below are not
covered under warranty.
Ethanol. Gasoline containing up to 10% ethanol by volume
(commonly referred to as E10) is acceptable. E15 and E85
are not.
STARTING AND STOPPING
See Figure 9.
Blower should be on a flat, bare surface for starting.
Slowly press the primer bulb 10 times.
NOTE: After the 10th press, fuel should be visible in the
primer bulb. If it is not, continue to press the primer until
you see fuel in the bulb.
Set the choke lever to the FULL CHOKE position.
Lock cruise control lever/throttle lock.
Pull starter grip and rope sharply until engine attempts to
run. Do not pull the starter grip more than four (4) times.
Set the choke lever to the HALF CHOKE position.
Pull the starter grip and rope until the engine runs.
NOTE: If the engine does not start, return to the FULL
CHOKE position and repeat the steps that follow.
Allow the engine to run for 15 seconds, then set the choke
lever to the RUN position.
OPERATION

9 - English
TO STOP THE ENGINE:
To stop the engine, depress and hold the STOP switch
to the stop position “ ”.
HOT RESTART OF THE ENGINE:
Set the choke lever to the RUN position.
Lock cruise control lever/throttle lock.
Pull the starter grip and rope until the engine runs.
IF ASSISTANCE IS REQUIRED STARTING THIS
PRODUCT:
Do not return this product to the retail store where it was
purchased. Please call our Customer Service Department
for any issues you may have.
For Help Call: 1-800-332-1631
OPERATING THE BLOWER
See Figures 10 - 11.
WARNING:
Never run the unit without the blower tubes installed or
the vacuum door securely closed. Use of an improperly
assembled unit could result in serious personal injury.
Start the blower. Refer to Starting and Stopping earlier
in this manual. Hold the blower with the upper handle in
your right hand.
WARNING:
Always hold the blower away from your body with the
handle in your right hand when operating as a blower,
keeping clearance between your body and the product.
The muffler side of the blower should be away from your
body. Any contact with the housing can result in burns
and/or other serious personal injury.
WARNING:
Do not place blower on top of or near loose debris or
gravel. Debris may be sucked into blower intake vent
resulting in possible damage to the unit and could result
in serious personal injury.
To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the center
of a pile.
Operate power equipment at reasonable hours only - not
early in the morning or late at night when people might be
disturbed. Comply with the times listed in local ordinances.
To reduce sound levels, limit the number of pieces of
equipment used at any one time.
Conserve water by using power blowers instead of hoses
for many lawn and garden applications, including areas
such as gutters, screens, patios, grills, porches, and
gardens.
Operate blower at the lowest possible throttle speed to
do the job.
Check your equipment before operation, especially the
muffler, air intakes, and air filters.
Use rakes and brooms to loosen debris before blowing.
In dusty conditions, slightly dampen surfaces when water
is available.
Watch out for children, pets, open windows, or freshly
washed cars, and blow debris safely away.
Hold blower, as shown in Figure 10, so the air stream can
work close to the ground.
After using blowers or other equipment, CLEAN UP!
Dispose of debris properly.
Use the sweeper nozzle for the everyday blowing opera-
tion. This nozzle allows for more area to be covered during
the blowing operation.
CRUISE CONTROL LEVER/THROTTLE LOCK
See Figure 12.
The cruise control lever/throttle lock can be used to operate
the blower without holding the throttle trigger.
To engage, pull cruise control lever/throttle lock back
towards user, and stop at the desired throttle setting.
To release, push cruise control lever/throttle lock all the
way towards the front of unit.
VACUUM OPERATION
See Figure 13.
WARNING:
Never run the unit without the vacuum tubes and vacuum
bag installed. Use of an improperly assembled unit could
result in serious personal injury.
WARNING:
Keep the muffler and all hot surfaces of the blower/
vacuum away from your body. Failure to do so could
result in possible serious personal injury.
Install the vacuum tubes and the bag. Refer to the
Assembly section earlier in this manual.
Start the blower. Refer to Starting and Stopping earlier
in this manual.
Place the vacuum bag strap over your right shoulder.
Hold the upper handle in your left hand and the vacuum
handle in your right hand.
Move the blower/vacuum from side to side along outer
edge of the debris. To avoid clogging, do not place the
vacuum tube directly into the debris pile.
Hold the engine higher than the inlet end of the vacuum
tube.
OPERATION

10 - English
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts could create a hazard or cause
product damage.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING:
Before inspecting, cleaning, or servicing the machine,
shut off engine, wait for all moving parts to stop, and
disconnect spark plug wire and move it away from spark
plug. Failure to follow these instructions can result in
serious personal injury or property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, lubricant, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating lubricants, etc., come in con-
tact with plastic parts. Chemicals can damage, weaken or
destroy plastic which could result in serious personal
injury.
You can often make adjustments and repairs described here.
For other repairs, have the blower/vacuum serviced by an
authorized service dealer.
Always point vacuum tube downhill when working on a
hillside.
To avoid serious injury to the operator or damage to the
unit, do not pick up rocks, metal, broken glass, bottles,
or other similar objects.
If the vacuum tubes should clog, stop the engine , ensure
impeller blades have stopped spinning, and disconnect
the spark plug wire before cleaning out the obstruction.
Remove the vacuum tubes and clear the debris from the
blower fan housing. Remove the bag and clear the tube.
A small rod or stick may be required to clear the entire
tube length. Ensure that all debris has been cleared before
reassembling the vacuum tubes.
CLEANING THE AIR FILTER
See Figure 14 - 15.
For proper performance and long life, keep air filter clean.
Remove the air filter cover by turning the dial counter-
clockwise while gently pulling on the cover.
Rinse filter with clean water.
Gently squeeze filter until excess water is removed.
Replace filter.
Place the air filter cover back on the unit. Turn dial clock-
wise until cover is secure.
CLEANING THE EXHAUST PORT, MUFFLER
AND SPARK ARRESTOR
NOTE: Depending on the type of fuel used, the type and
amount of lubricant used, and/or your operating conditions, the
exhaust port, muffler, and/or spark arrestor screen may be-
come blocked with carbon deposits. If you notice a power
loss with your gas powered tool, you may need to remove
these deposits to restore performance. We highly recom-
mend that only qualified service technicians perform this
service.
The spark arrestor must be cleaned or replaced every 50
hours or yearly to ensure proper performance of your prod-
uct. Spark arrestors may be in different locations depending
on the model purchased. Please contact your nearest service
dealer for the location of the spark arrestor for your model.
WARNING:
Never run the blower without the spark arrestor in place.
Failure to do so could result in a fire that could cause
serious personal injury.
VACUUM BAG
A dirty bag will reduce performance. To clean the bag, turn it
inside out and shake. Wash the bag in soapy water at least
once a year. To obtain a replacement bag, see Repair Parts
on the back page of this manual.
OPERATION
MAINTENANCE

11 - English
FUEL CAP
WARNING:
Check for fuel leaks. A leaking fuel cap is a fire hazard
and must be replaced immediately. If you find any leaks,
correct the problem before using the product. Failure
to do so could result in a fire that could cause serious
personal injury.
The fuel cap contains a non-serviceable filter and a
check valve. A clogged fuel filter will cause poor engine
performance. If performance improves when the fuel cap
is loosened, check valve may be faulty or filter clogged.
Replace fuel cap if required.
SPARK PLUG REPLACEMENT
This engine uses a Champion RCJ-6Y spark plug with .025
in. electrode gap. Use an exact replacement and replace
annually.
STORING THE PRODUCT
Clean all foreign material from the product. Store idle unit
indoors in a dry, well-ventilated area that is inaccessible
to children. Keep away from corrosive agents such as
garden chemicals and de-icing salts.
Abide by all ISO and local regulations for the safe storage
and handling of gasoline.
When storing 1 month or longer:
Drain all fuel from tank into a container approved for
gasoline. Run engine until it stops.
HIGH ALTITUDE ENGINE OPERATION
Please have an authorized service center adjust this engine
if it is to be run above 2000 feet. Failure to do so may result
in poor engine performance and increased emissions. An
engine adjusted for high altitudes can not be run at 2000
feet or lower. In doing so, the engine will overheat and cause
serious engine damage. Please have an authorized service
center restore high altitude modified engines to the original
factory specification before operating below 2000 feet.
MAINTENANCE SCHEDULE
Inspect Clean Replace Replace
Maintenance Before Every Every 25 Hours Every
Part Each Use 5 Hours or Yearly 50 Hours
*CATALYTIC MUFFLER ASSEMBLY..................................................................................................................X
SPARK SCREEN ...............................................................................................................................................X
*AIR FILTER ASSY
includes:
Filter .................................................................................... X
*CARBURETOR ASSY
includes:
Gaskets ........................................ X
*FUEL TANK ASSY
includes:
Fuel Lines..................................... X
Fuel Cap....................................... X
Fuel Filter................................................................................................................... X
*IGNITION ASSY
includes:
Spark Plug................................................................................................................. X
* NOTICE: THE USE OF EMISSION CONTROL COMPONENTS OTHER THAN THOSE DESIGNED FOR THIS UNIT
IS A VIOLATION OF FEDERAL LAW.
THIS PRODUCT WAS MANUFACTURED WITH A CATALYST MUFFLER
Congratulations! You have made an investment toward protecting the environment. In order to maintain this product’s
original emission level, please refer to the maintenance section below.
MAINTENANCE

12 - English
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM, CONTACT YOUR AUTHORIZED SERVICING DEALER.
PROBLEM CAUSE REMEDY
Engine fails to start. No fuel in tank.
Spark plug shorted or fouled.
Spark plug is broken. (cracked
porcelain or electrodes broken)
Ignition lead wire shorted, broken, or
disconnected from spark plug.
Ignition inoperative.
Fill tank.
Replace spark plug.
Replace spark plug.
Replace lead wire or attach to spark
plug.
Contact authorized service center.
Engine hard to start. Water in gasoline or stale fuel mixture.
Too much lubricant in fuel mixture.
Engine is under or over choked.
Weak spark at spark plug.
Drain entire system and refill with fresh
fuel.
Drain and refill with correct mixture.
Adjust choke as necessary.
Contact authorized service center.
Engine lacks power. Air filter clogged. Clean air filter. Refer to Cleaning the
Air Filter earlier in this manual.
Engine overheats. Insufficient lubricant in fuel mixture. Mix fuel as described in starting
instructions.
TROUBLESHOOTING

13 - English
WARRANTY
LIMITED WARRANTY STATEMENT
OWTIndustries, Inc., warrantsto the originalretailpurchaser
that this GREEN MACHINE™brand outdoor product is free
from defect in material and workmanship and agrees to
repair or replace, at OWT Industries, Inc.’s, discretion, any
defective product free of charge within two years from the
date of purchase.
This warranty extends to the original retail purchaser only
and commences on the date of the original retail purchase.
Any part of this product found in the reasonable judgment
of OWT Industries, Inc. to be defective in material or
workmanship will be repaired or replaced without charge
for parts and labor by an authorized service center for
GREEN MACHINE™brand outdoor products (Authorized
Green Machine Service Center).
Theproduct,including anydefective part,must bereturned
to an authorized Green Machine service center within the
warranty period. The expense of delivering the product to
the service center for warranty work and the expense of
returningit backto theowner afterrepairor replacementwill
be paid by the owner. OWT Industries, Inc.’s, responsibility
in respect to claims is limited to making the required repairs
orreplacements and no claimof breachof warranty shall be
cause for cancellation or rescission of the contract of sale
of any GREEN MACHINE™brand outdoor product. Proof
of purchase will be required by the dealer to substantiate
any warranty claim. All warranty work must be performed
by an authorized service dealer.
This warranty is limited to thirty (30) days from the date of
original retail purchase for any GREEN MACHINE™brand
outdoor product that is used for rental or commercial
purposes, or any other income-producing purpose.
This warranty does not cover any product that has been
subject to misuse, neglect, negligence, or accident, or that
has been operated in any way contrary to the operating
instructions as specified in this operator’s manual. This
warranty does not apply to any damage to the product that
is the result of improper maintenance or to any product
that has been altered or modified. The warranty does not
extend to repairs made necessary by normal wear or by the
use of parts or accessories which are either incompatible
with the GREEN MACHINE™brand outdoor product or
adversely affect its operation, performance, or durability.
In addition, this warranty does not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting
Lines, Inner Reels, Starter Pulleys, Starter Ropes, Drive
Belts, Tines, Felt Washers, Hitch Pins, Mulching Blades,
Blower Fans, Blower and Vacuum Tubes, Vacuum Bag
and Straps, Guide Bars, Saw Chains, Blades
OWTIndustries, Inc.,reservestheright tochangeor improve
thedesignof any GREENMACHINE™brandoutdoorproduct
without assuming any obligation to modify any product
previously manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED IN
THEIR ENTIRETY AFTER THE EXPIRATION OF THE
TWO-YEAR WARRANTY PERIOD. OWT INDUSTRIES,
INC.’S, OBLIGATION UNDER THIS WARRANTY IS
STRICTLY AND EXCLUSIVELY LIMITED TO THE
REPAIR OR REPLACEMENT OF DEFECTIVE PARTS
AND OWT INDUSTRIES, INC., DOES NOT ASSUME OR
AUTHORIZE ANYONE TO ASSUME FOR THEM ANY
OTHER OBLIGATION. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU. OWT INDUSTRIES, INC., ASSUMES NO
RESPONSIBILITY FOR INCIDENTAL, CONSEQUENTIAL,
OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO, EXPENSE OF RETURNING THE PRODUCT TO AN
AUTHORIZED GREEN MACHINE SERVICE CENTER AND
EXPENSE OF DELIVERING IT BACK TO THE OWNER,
MECHANIC’STRAVELTIME,TELEPHONE ORTELEGRAM
CHARGES, RENTAL OF A LIKE PRODUCT DURING THE
TIME WARRANTY SERVICE IS BEING PERFORMED,
TRAVEL, LOSS OR DAMAGE TO PERSONAL PROPERTY,
LOSS OF REVENUE, LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, OR INCONVENIENCE. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all GREEN MACHINE™brand
outdoor products manufactured by or for OWT Industries,
Inc., and sold in the United States and Canada.
To locate your nearest Authorized Green Machine Service
Center, dial 1-800-332-1631.

14 - English
WARRANTY
THE FOLLOWING CALIFORNIA AIR RESOURCES BOARD (CARB) STATEMENT ONLY APPLIES TO MODEL
NUMBERS REQUIRED TO MEET THE CARB REQUIREMENTS.
The U.S. Environmental Protection Agency (EPA), the California Air Resources Board
(CARB), and OWT Industries, Inc., are pleased to explain the Emissions Control
System Warranty on your 2012 model year non-road or small off-road engine. In
California, new equipment that uses small off-road engines must be designed, built,
and equipped to meet the state’s stringent anti-smog standards. In other states, new
2012 model year non-road engines must be designed, built, and equipped at the time
of sale to meet the U.S. EPA regulations for small non-road engines. The non-road
engine must be free from defects in materials and workmanship which cause it to
fail to conform with U.S. EPA standards for the first two years of engine use from the
date of sale to the ultimate purchaser. OWT Industries, Inc., must warrant the emis-
sion control system on your non-road or small off-road engine for the period of time
listed above provided there has been no abuse, neglect, or improper maintenance
of your non-road or small off-road engine.
Your emission control system may include parts such as the carburetor or fuel injection
system, the ignition system, catalytic converters, fuel tanks, valves, filters, clamps,
connectors, and other associated components. Also included may be hoses, belts
and connectors, and other emission-related assemblies.
Where a warrantable condition exists, OWT Industries, Inc., will repair your non-road or
small off-road engine at no cost to you, including diagnosis, parts, and labor performed
at an authorized service center for GREEN MACHINE™brand outdoor products.
MANUFACTURER’S WARRANTY COVERAGE:
This product’s emissions control system is warranted for two years. If any
emission-related part on your engine is defective, the part will be repaired or replaced
by OWT Industries, Inc., free of charge.
OWNER’S WARRANTY RESPONSIBILITIES
(a) As the non-road or small off-road engine owner, you are responsible for the perfor-
mance of the required maintenance listed in your operator’s manual. OWT Industries,
Inc., recommends that you retain all receipts covering maintenance on your non-road or
small off-road engine, but OWT Industries, Inc., cannot deny warranty solely for the lack
of receipts or for your failure to ensure the performance of all scheduled maintenance.
(b) As the non-road or small off-road engine owner, you should be aware, however,
that OWT Industries, Inc., may deny you warranty coverage if your non-road or small
off-road engine or a part has failed due to abuse, neglect, improper maintenance,
or unapproved modifications.
(c) You are responsible for presenting your non-road or small off-road engine to an
authorized service dealer as soon as a problem exists. The warranty repairs should
be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities,
you should contact a OWT Industries, Inc., Customer Representative at 1-800-
332-1631.
DEFECT WARRANTY COVERAGE REQUIREMENTS:
(a) The warranty period begins on the date the engine or equipment is delivered to
an ultimate purchaser.
(b) General Emissions Warranty Coverage. OWT Industries, Inc., warrants to the
ultimate purchaser and each subsequent purchaser that your non-road or small off-
road engine is designed, built, and equipped at the time of sale to conform with all
applicable regulations adopted by the California Air Resources Board or the United
States Environmental Protection Agency; and that it is free from defects in materials
and workmanship which cause the engine to fail to conform with applicable regula-
tions for a period of two years from the date the non-road or small off-road engine is
purchased by the initial purchaser. Any replacement part or service that is equivalent
in performance and durability may be used in non-warranty maintenance or repairs,
and shall not reduce the warranty obligations of OWT Industries, Inc.
(c) The warranty on emissions-related parts will be interpreted as follows: Any war-
ranted part that is not scheduled for replacement as required in the Maintenance
Schedule is warranted for two years. If any such part (including any part that is
scheduled only for regular inspection) fails during the period of warranty coverage,
it will be repaired or replaced at any GREEN MACHINE™Authorized Service Center
at no charge. Any such part repaired or replaced under warranty will be warranted
for the remaining warranty period. A statement to the effect of “repair or replace
as necessary” would not reduce the period of warranty coverage. Any warranted
part that is scheduled for replacement as required maintenance in the Maintenance
Schedule is warranted for the period of time prior to the first scheduled replacement
point for that part. Any such part repaired or replaced under warranty is warranted
for the remainder of the period prior to the first scheduled replacement point, and
will be repaired or replaced at any GREEN MACHINE™Authorized Service Center
for no charge until that replacement point is reached.
OWT Industries, Inc., shall remedy warranty defects at any authorized GREEN MA-
CHINE™Authorized Service Center, including any distribution center that may be
franchised to service the subject engines. Any diagnostic work done at a GREEN
MACHINE™Authorized Service Center shall be free of charge to the owner if such
work determines that a warranted part is defective. Any manufacturer-approved or
equivalent replacement part may be used for any warranty maintenance or repairs
on emission-related parts, and must be provided free of charge to the owner if the
part is still under warranty. OWT Industries, Inc., is liable for damages to other engine
components caused by the failure of a warranted part still under warranty.
Add-on or modified parts that are not exempted by the California Air Resource
Board may not be used. The use of any non-exempted add-on or modified parts
will be grounds for disallowing a warranty claim. OWT Industries, Inc., will not be
liable to warrant failures of warranted parts caused by the use of a non-exempted
add-on or modified part.
The Emission Parts List specifically defines the emission-related warranted parts.
OWT Industries, Inc., will provide any documents that describe its warranty proce-
dures or policies within five days upon request by the California Air Resources Board.
EMISSIONS PARTS LIST
Emissions parts vary from product to product. Your emissions control system warranty
applies to any of the following components that may be included on your product:
(1) Fuel Metering System
(i) Carburetor and internal parts (and/or pressure regulator or fuel injection
system).
(ii) Air/fuel ratio feedback and control system.
(iii) Cold start enrichment system.
(iv) Fuel Tank.
(v) Fuel Hose.
(2) Air Induction System
(i) Controlled hot air intake system.
(ii) Intake manifold.
(iii) Air filter.
(3) Ignition System
(i) Spark plugs.
(ii) Magneto or electronic ignition system.
(iii) Spark advance/retard system.
(4) Exhaust Gas Recirculation (EGR) System
(i) EGR valve body and carburetor spacer, if applicable.
(ii) EGR rate feedback and control system.
(5) Air Injection System
(i) Air pump or pulse valve.
(ii) Valves affecting distribution of flow.
(iii) Distribution manifold.
(6) Catalyst or Thermal Reactor System
(i) Catalytic converter.
(ii) Thermal reactor.
(iii) Exhaust manifold.
(7) Particulate Controls
(i) Traps, filters, precipitators, and any other device used to capture particulate
emissions.
(8) Miscellaneous Items Used in Above Systems
(i) Electronic controls.
(ii) Vacuum, temperature, and time sensitive valves and switches.
(iii) Hoses, belts, connectors, and assemblies.
OWT Industries, Inc., will furnish with each new engine written instructions for its
maintenance and use by the owner.
OWT INDUSTRIES, INC., LIMITED WARRANTY STATEMENT FOR FEDERAL AND CALIFORNIA
EMISSION CONTROL SYSTEMS NON-ROAD AND SMALL OFF-ROAD ENGINES
YOUR WARRANTY RIGHTS AND OBLIGATIONS

15
NOTES / NOTAS

3 - Français
AVERTISSEMENT :
LIRE ET VEILLER À BIEN COMPRENDRE TOUTES
LES INSTRUCTIONS. Le non respect de toutes les
instructions ci-dessous peut entraîner un choc électrique,
un incendie et / ou des blessures graves.
CONSERVER CES INSTRUCTIONS
Ne pas laisser des enfants ou personnes n’ayant pas reçu
une formation adéquate utiliser cet outil.
Ne jamais lancer ou faire tourner le moteur dans un endroit
clos. Les gaz d’échappement peuvent être mortels.
Toujours porter une protection oculaire avec écrans
latéraux certifiée conforme à la norme ANSI Z87.1, avec
protection auditive. Si cette précaution n’est pas prise,
des objets peuvent être projetés dans les yeux et d’autres
lésions graves.
Garder tous les badauds, enfants et animaux domestiques
à une distance d’au moins 15 m (50 pi).
Porter des pantalons longs, manches longues, des
chaussures de travail et des gants épais. Ne pas porter
de vêtements amples, shorts, sandales, bijoux quels qu’ils
soient et ne pas travailler pieds nus.
Pour réduire les risques de happement par les pièces en
mouvement, ne pas porter de vêtements amples, foulards,
colliers, etc.
Attacher les cheveux longs pour les maintenir au-dessus
des épaules, afin qu’ils ne se prennent pas dans les pièces
en rotation.
Ne pas utiliser cet appareil en cas de fatigue, si l’on est
souffrant ou préoccupé, ou sous l’influence de l’alcool,
de drogues ou de médicaments.
Ne pas démarre ou faire tourner le moteur dans un espace
confine, un bâtiment ou un autre zone sans ventilation
où des vapeurs toxiques de monoxyde de carbone
peuvent s’accumuler. Le monoxyde de carbone, un gaz
incolore, inodore et extrêmement toxique peut causer
l’inconscience voire la mort.
Ne pas travailler sous un éclairage insuffisant.
Garder toutes les parties du corps à l’écart des pièces
en mouvement et des paries brûlantes de l’outil.
Porter un masque facial filtrant dans les milieux
poussiéreux afin de réduire le risque de lésions lié à
l’inhalation de poussière.
Examiner la zone de travail avant chaque utilisation. La
débarrasser de tous les objets tels que cailloux, verre
brisé, clous, fils métalliques, cordes, etc. risquant d’être
projetés ou de se prendre dans la machine.
Se tenir bien campé et en équilibre. Ne pas travailler
hors de portée. Le travail hors de portée risque de faire
perdre l’équilibre ou de causer un contact avec les
pièces brûlantes.
Ne jamais utiliser l’outil sans le pare-étincelles, qui se
trouve dans le silencieux.
Les produits utilisés sur les territoires des services
forestiers des États-Unis et de certains états doivent être
conformes aux réglementations de lutte contre l’incendie.
Cet outil est doté d’un pare-étincelles, toutefois, d’autres
dispositifs peuvent être requis. Consulter les autorités
locales et gouvernementales.
Laisser le moteur refroidir avant de remiser l’outil.
Vider le réservoir de carburant dans un contenant
approuvé pour l’essence et immobiliser l’unité avant de
la transporter dans un véhicule.
Manipuler le carburant avec précaution pour éviter les
risques d’incendies et de brûlures. Le carburant est
extrêmement inflammable.
Ne pas fumer pendant la manipulation du carburant.
Mélanger et conserver le carburant dans un bidon ou
jerrican approuvé pour l’essence.
Mélanger le carburant à l’extérieur, loin de toute flamme
ou source d’étincelles.
Poser la machine sur un sol nu, arrêter le moteur et le
laisser refroidir avant de faire le plein.
Desserrer le bouchon du réservoir lentement pour relâcher
la pression et éviter que le carburant s’échappe.
Une fois le réservoir plein, remettre le bouchon en place
et le serrer fermement.
Essuyer tout le carburant éventuellement répandu.
S’éloigner de 9 m (30 pi) du point d’approvisionnement
avant de lancer le moteur.
N’essayer en aucun cas de brûler le carburant répandu.
Utiliser exclusivement des pièces de rechange et
accessoire d’origine. L’usage de toute autre pièce pourrait
créer une situation dangereuse ou endommager l’outil.
Entretenir l’outil conformément aux instructions de ce
manuel d’utilisation.
Inspecter l’outil avant chaque utilisation pour s’assurer
qu’il n’y a pas de pièces desserrées, de fuites ce
carburant, etc. Remplacer les pièces endommagées.
Ne pas utiliser l’unité sur une échelle, un toit, un arbre ou
un autre support instable. Le fait de se tenir bien campé
sur une surface solide permet de mieux contrôler la
soufflante dans des situations inattendues.
Avant de nettoyer, réparer ou inspecter, arrêter le moteur
et vérifier que toutes les pièces en mouvement sont
immobilisées. Déconnecter le fil de bougie et le garder
à l’écart de la bougie afin d’empêcher un démarrage
accidentel.
Le dépannage de la soufflante / aspirateur doit
exclusivement être confié à un personnel qualifié.
Les réparations ou entretiens par des personnes non
qualifiées peuvent entraîner des blessures ou dommages
à l’outil.
RÈGLES DE SÉCURITÉ GÉNÉRALES

4 - Français
Toujours tenir la soufflante/aspirateur avec la main droite
pendant le soufflage. Consulter les instructions d’Utilisation
présentées ultérieurement dans ce manuel afin de
connaître la position adéquate pour utiliser l’aspirateur, et
obtenir des renseignements supplémentaires.
Ne jamais rien insérer dans les tubes.
Utiliser exclusivement selon les instructions de ce manuel.
Ne pas utiliser l’aspirateur sans le sac, car des débris
pourraient être projetés et infliger des blessures graves.
Toujours fermer le sac complètement avant d’utiliser
l’aspirateur.
L’aubage de la roue en rotation peut entraîner des
blessures graves. Arrêter le moteur et s’assurer que
l’aubage de la roue a cessé de tourner avant d’ouvrir la
porte de l’aspirateur ou d’installer ou de changer les tuyaux.
Ne pas mettre les mains ou quelque objet que ce soit dans
les tubes installés sur la machine.
Ne jamais utiliser la soufflante sans les accessoires
appropriés installés. Les tubes de soufflante doivent
toujours être installés lorsque la machine est utilisée en
soufflante. Lorsque la machine est utilisée pour aspirer,
les tubes d’aspiration et le sac doivent toujours être
installés. Pour éviter la projection de débris, s’assurer que
la fermeture à glissière de sac est complètement fermée
lorsque le moteur tourne.
Éviter les situations pouvant mettre le feu au sac. Ne pas
utiliser la machine à proximité de flammes vives. Ne pas
aspirer les cendres chaudes de cheminées, barbecues,
feux de bois, etc. Ne pas aspirer de mégots de cigares
ou cigarettes dont les cendres ne sont pas complètement
froides.
Ne jamais placer la soufflante en marche sur une surface,
sauf si celle-ci est dure et propre. Le gravier, le sable et
les autres débris peuvent être aspirés dans l’entrée d’air
et projetés en direction de l’utilisateur ou des personnes
à proximité, ce qui peut entraîner des blessures graves.
Pour réduire les risques de perte de l’ouïe causée par le
niveau sonore, porter une protection auditive.
Pour réduire les risques de blessures infligées par des
pièces en rotation, arrêter le moteur avant d’installer ou
de retirer des accessoires. Toujours débrancher le fil de
bougie avant de procéder à un entretien ou d’accéder à
des pièces en mouvement.
Ne jamais utiliser la soufflante à proximité d’un feu, d’un
poêle, de cendres chaudes, d’un barbecue, etc., sans quoi
le feu risque de se propager.
Ne pas diriger la soufflante vers des personnes ou un
animaux.
Ne jamais utiliser la soufflante sans les accessoires
appropriés installés. Les tubes doivent toujours être en
place.
Ce produit est conçu pour les personnes qui prévoient
l’utiliser de manière peu fréquente pour des applications
générales par exemple, souffler les feuilles et les brins
d’herbe, etc.; l’outil peut également convenir à d’autres
utilisateurs occasionnels. Elle n’est pas conçue pour un
usage prolongé. Les périodes d’utilisation prolongée
peuvent entraîner des problèmes circulatoires dans les
mains de l’opérateur, causés par les vibrations. Pour ce type
d’application, il peut être bon d’utiliser une scie équipée
d’un dispositif anti-vibrations.
APPROVISIONNEMENT EN CARBURANT
Le carburant est extrêmement inflammable. Lors de
l’utilisation, prendre les précautions nécessaires pour
réduire le risque de blessures graves.
Conserver le carburant dans une zone froide bien ventilée
à l’écart d’étincelles et / ou de matériels produisant des
flammes.
Conserver le carburant dans des jerrycans spécialement
conçus à cet effet.
Toujours faire le plein à l’extérieur et ne pas fumer pendant
cette opération.
Faire l’appoint de carburant avant de lancer le moteur. Ne
jamais retirer le bouchon du réservoir de carburant ni faire
l’appoint pendant que le moteur tourne ou est chaud.
Ne pas fumer pendant la manipulation du carburant.
Mélanger et conserver le carburant dans un bidon ou
jerrycan approuvé pour l’essence.
Mélanger le carburant à l’extérieur, loin de toute flamme
ou source d’étincelles.
Desserrer le bouchon du réservoir lentement pour relâcher
la pression et éviter que le carburant s’échappe.
Une fois le réservoir plein, remettre le bouchon en place
et le serrer fermement.
Essuyer tout le carburant éventuellement répandu.
S’éloigner de 9 m (30 pi) du point d’approvisionnement
avant de lancer le moteur.
N’essayer en aucun cas de brûler le carburant répandu.
Manipuler le carburant avec précaution pour éviter les
risques d’incendies et de brûlures. Le carburant est
extrêmement inflammable.
Si du carburant est répandu, ne pas essayer de lancer le
moteur, mais éloigner la machine et éviter de créer une
source d’inflammation jusqu’à ce que les vapeurs de
carburant se soient dissipées.
Remettre en place les bouchons de jerrycan et de réservoir
de carburant et les serrer fermement.
Vider le réservoir de carburant dans un contenant approuvé
pour l’essence et empêcher l’unité de bouger avant de le
transporter dans un véhicule.
Lors de la vidange du réservoir de carburant, utiliser
un bidon ou jerrycan approuvé pour la conservation de
carburant et procéder dans un endroit bien aéré.
Poser la machine sur un sol nu, arrêter le moteur et le laisser
refroidir avant de faire le plein.
Conserver ces instructions. Les consulter fréquemment et
les utiliser pour instruire les autres utilisateurs éventuels.
Si cet outil est prêté, il doit être accompagné de ces
instructions.
RÈGLES DE SÉCURITÉ PARTICULIÈRES

5 - Français
Certains des symboles ci-dessous peuvent être présents sur la produit. Veiller à les étudier et à apprendre leur
signification. Une interprétation correcte de ces symboles permettra d’utiliser la produit plus efficacement et de
réduire les risques.
SYMBOLE NOM EXPLICATION
Symbole d’alerte de sécurité Indique un risque de blessure potentiel.
Lire le manuel d’utilisation
Pour réduire les risques de blessures, l’utilisateur doit lire
et veiller à bien comprendre le manuel d’utilisation avant
d’utiliser ce produit.
Protection oculaire et auditive
Toujours porter une protection oculaire munie d’écrans
latérauxcertifiée conformeà lanorme ANSIZ87.1, ainsiqu’une
protectionauditiveet respirationlorsde l’utilisationde cetoutil.
Ne laisser personne s’approcher Garder les badauds à une distance de 15 m (50 pi) minimum.
Ricochet Les objets projetés peuvent ricocher et infliger des blessures
ou causer des dommages matériels.
Volet d’aspiration Ne pas actionner lorsque le volet d’aspiration n’est pas
verrouillé.
Cheveux longs Risque d’aspiration des cheveux longs dans l’entrée d’air.
Tubes de soufflante Ne pas utiliser sans les tubes en place.
Vêtements amples Risque d’aspiration des vêtements amples dans l’entrée d’air.
Essence et lubrifiant
Utiliser de l’essence sans plomb pour automobiles, avec un
indice d’octane de 87 [(R + M) / 2] ou plus. Cet outil utilise
un moteur deux temps qui nécessite le mélange d’essence
et d’lubrifiant 2 temps.
Les termes de mise en garde suivants et leur signification ont pour but d’expliquer le degré de risques associé à l’utilisation
de ce produit.
SYMBOLE SIGNAL SIGNIFICATION
DANGER : Indique une situation extrêmement dangereuse qui, si elle n’est pas évitée,
aura pour conséquences des blessures graves ou mortelles.
AVERTISSEMENT : Indique une situation potentiellement dangereuse qui, si elle n’est pas évitée,
pourrait entraîner des blessures graves ou mortelles.
ATTENTION : Indique une situation potentiellement dangereuse qui, si elle n’est pas évitée,
pourraît entraîner des blessures légères ou de gravité modérée.
ATTENTION : (Sans symbole d’alerte de sécurité) Indique une situation pouvant entraîner
des dommages matériels.
SYMBOLES
