GreenMachine 26CS GM22000 User manual

26CS
GM22000
26SS
GM23000
OPERATOR’S MANUAL
MANUEL D’UTILISATION / MANUAL DEL OPERADOR
26cc STRING TRIMMERS
TAILLE-BORDURES À LIGNE 26 cc
RECORTADORAS DE HILO 26 cc
ALL VERSIONS
TOUTES LES VERSIONS / TODAS LAS VERSIONES
To register your Green Machine product, please visit:
http://register.greenmachinetools.com/
Pour enregistrer votre produit de Green Machine, s’il vous
plaît la visite: http://register.greenmachinetools.com/
Para registrar su producto de Green Machine por favor
visita: http://register.greenmachinetools.com/
NOTICE: Do not use E15 or E85 fuel (or fuel containing greater than 10% ethanol) in this product. It is a violation
of federal law and will damage the unit and void your warranty.
AVIS : Ne pas utiliser d’essence E15 ou E85 (ou un carburant contenant plus de 10 % d’éthanol) dans ce produit. Une telle
utilisation représente une violation de la loi fédérale et endommagera l’appareil et annulera la garantie.
AVISO: No utilice combustibles E15 o E85 (ni combustibles que contengan más de 10 % de etanol) con este producto.
Esto constituye una violación a la ley federal, dañará la unidad y anulará la garantía.
Your string trimmers has been engineered and manufactured to high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Ce taille-bordures à ligne a été conçue et fabriquée conformément
aux strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation. Correctement entretenue, elle vous donnera des
années de fonctionnement robuste et sans problème.
AVERTISSEMENT : Pour réduire les risques de
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Su recortadoras de hilo ha sido diseñada y fabricada de conformidad
con las estrictas normas para brindar fiabilidad, facilidad de uso
y seguridad para el operador. Con el debido cuidado, le brindará
muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones, el
usuario debe leer y comprender el manual del operador antes
de usar este producto.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS

ii
See this fold-out section for all of the figures
referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner
toutes les figures mentionnées dans le manuel
d’utilisation.
Consulte esta sección desplegable para ver todas
las figuras a las que se hace referencia en el
manual del operador.

iii
A - Dual line string head (tête de cordon à ligne
double, cabezal del hilo doble)
B - Drive shaft housing (logement d’arbre
moteur, alojamiento del eje de impulsión)
C - Front handle (poignée avant, mango
delantero)
D - Stop switch (commutateur d’arrêt,
interruptor del apagado)
E - Rear handle (poignée arrière, mango
trasero)
F - Starter grip and rope (poignée du lanceur et
corde, mango del arrancador y cuerda)
G - Muffler (silencieux, silenciador)
Fig. 1
Fig. 3
A- Drive shaft (arbre moteur, eje de impulsión)
B - Spool retainer (retenue de bobine, retén del
carrete)
C - Plastic seal (étanchéité en plastique, sello de
plástico)
D -Spool (bobine, carrete)
E - String head assembly (ensemble de tête de
couple, conjunto del cabezal de hilo)
B
D
A
A
BC
A
A - Pull lines (tirer vers l’extérieur, tira del hilo)
Fig. 4
A
M
B
C
D
E
GH
I
J
26SS
F
K
26CS
A
B
C
D
E
G
H
I
J
L
F
K
E
H - Primer bulb (poire d’amorçage, bomba de
cebado)
I - Fuel cap (bouchon de carburant, tapa del
tanque)
J - Start lever (levier de volet de départ, palanca
de arranque)
K - Throttle trigger (gâchette d’accélérateur,
gatillo del acelerador)
L - Curved shaft grass deflector (déflecteur
d’herbe d’arbre courbe, deflector de pasto
del eje curvo)
M- Straight shaft grass deflector (déflecteur
d’herbe d’arbre droit, deflector de pasto para
eje recto)
Fig. 2
A - Front handle (poignée avant, mango
delantero)
B - Washer (rondelle, arandela)
C - Bolt (boulon, perno)
D - Wing nut (écrou à oreilles, tuerca de
mariposa)
A
B
CD

iv
Fig. 8
Fig. 9
A
C
B
C
Fig. 6
AB
C
D
E
F
G
H
IJ
B
Fig. 7
A
A
C
DB
26CS
Fig. 10
26SS
A
B
C
A
BC
26CS
26SS
Fig. 5
A
B
C
D
F
E
A - Wing nut (écrou à oreilles, tuerca de
mariposa)
B - Washer (rondelle, arandela)
C - Bolt (boulon, perno)
D - Curved shaft grass deflector (déflecteur
d’herbe d’arbre courbée, deflector de pasto
del eje curvo)
E - Bracket (support, soporte)
F - Line cut-off blade (lame de sectionnement
de ligne, cuchilla de corte)
A - Gear head (carter d’engrenages, cabezal de
engranajes)
B - Slot (fente, ranura)
C - Square tab (languette carrée, orejeta
cuadrada)
D - Wing nut (écrou à oreilles, tuerca de
mariposa)
E - Mounting bracket (support de montage,
soporte de montaje)
F - Drive shaft housing (logement d’arbre
moteur, alojamiento del eje de impulsión)
G - Screw (vis, tornillo)
H - Pin (axe, pasador)
I - Straight shaft grass deflector (déflecteur
d’herbe d’arbre droit, deflector de pasto para
eje recto)
J - Line cut-off blade (lame de sectionnement
de ligne, cuchilla de corte)
A - Stop switch (commutateur d’arrêt, interruptor
del apagado)
B - Primer bulb (poire d’amorçage, bomba de
cebado)
C - Throttle trigger (gâchette d’accélérateur,
gatillo del acelerador)
D - Starter grip and rope (poignée du lanceur et
corde, mango del arrancador y cuerda)
A - Full choke position (position de volet de
départ ouvert, posición de arranque)
B - Run position (position de marche, posición
de marcha)
C - Choke lever (levier de volet de départ,
palanca de arranque)
PROPER OPERATING
POSITION
BONNE POSITION DE
TRAVAIL
POSICIÓN CORRECTA
PARA EL MANEJO DE LA
HERRAMIENTA
A - Dangerous cutting area (zone de coupe
dangereuse, área peligrosa de corte)
B - Direction of rotation (sens de rotation,
sentido de rotación)
C - Best cutting area (zone d’efficacité
maximum, mejor área de corte)

v
Fig. 13
A - Spool (bobine, carrete)
B - Eyelets (œillets, ojillos)
A
BB
Fig. 17
Fig. 15
A - Latch (loquet, pestillo)
B - Pull cover to open (tirer sur le couvercle
pour l’ouvrir, tire de la tapa para abrirla)
C - Air filter cover (couvercle du filtre à air, tapa
del filtro de aire)
A
B
C
A A
A - Pull lines (tirer vers l’extérieur, tira del hilo)
Fig. 14
Fig. 11
Fig. 12
A
B
A
A - Spool retainer (retenue de bobine, retén del
carrete)
A - Eyelet (œillets, ojillo)
B - Arrow on spool (flèche sur la bobine, flecha
en el carrete)
A - Idle speed screw (vis de ralenti, tornillo de
ajuste de la velocidad en vacío)
A
Fig. 16
A
B
C
A - Latch (loquet, pestillo)
B - Filter screen (filtre écran, filtro pantalla)
C - Air filter cover (couvercle du filtre à air, tapa
del filtro de aire)

2
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
General Safety Rules........................................................................................................................................................ 3
Règles de sécurité générales / Reglas de seguridad generales
Specific Safety Rules........................................................................................................................................................ 3
Règles de sécurité particulières / Reglas de seguridad específicas
Symbols............................................................................................................................................................................ 4
Symboles / Símbolos
Features............................................................................................................................................................................ 5
Caractéristiques / Características
Assembly.......................................................................................................................................................................5-6
Assemblage / Armado
Operation.......................................................................................................................................................................6-8
Utilisation / Funcionamiento
Maintenance................................................................................................................................................................9-11
Entretien / Mantenimiento
Troubleshooting.........................................................................................................................................................12-13
Dépannage / Solución de problemas
Warranty ....................................................................................................................................................................14-15
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN

3 — English
WARNING:
Read and understand all instructions. Failure to follow
all instructions listed below may result in electric shock,
fire and/or carbon monoxide poisoning which will cause
death or serious personal injury.
READ ALL INSTRUCTIONS
For safe operation, read and understand all instructions
before using this product. Follow all safety instructions.
Failure to follow all safety instructions listed below, can
result in serious personal injury.
Do not allow children or untrained individuals to use this
unit.
Neverstartor run the engine inaclosed or poorly ventilated
area; breathing exhaust fumes can kill.
Clear the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or line which
can be thrown or become entangled in the cutting line
or blade.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
Wear heavy, long pants, long sleeves, boots, and gloves.
Do not wear loose fitting clothing, short pants, sandals,
or go barefoot. Do not wear jewelry of any kind.
ProductusersonUnited States ForestServiceland,and in
somestates,must comply withfirepreventionregulations.
This product is equipped with a spark arrestor; however,
other user requirements may apply. Check with your
federal, state, or local authorities.
Never operate this unit on the operator’s left side.
Secure long hair above shoulder level to prevent
entanglement in moving parts.
Keep all bystanders, children, and pets at least 50 ft.
away. Bystanders should be encouraged to wear eye
protection.
Do not operate this unit when you are tired, ill, or under
the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure
to hot surfaces. Keep cutting attachment below waist.
To avoid hot surfaces, never operate the unit with the
bottom of the engine above waist level.
Keep all parts of your body away from any moving part.
Do not touch area around the muffler or cylinder of the
unit; these parts get hot from operation.
Always stop the engine and remove the spark plug wire
before making any adjustments or repairs except for
carburetor adjustments.
Inspect the unit before each use for loose fasteners, fuel
leaks, etc. Replace any damaged parts before use.
The string head will rotate during carburetor adjustments.
It has been reported that vibrations from hand-held tools
maycontribute to a condition calledRaynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness, and blanching of the fingers, usually apparent
upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking, and work practices
are all thought to contribute to the development of these
symptoms. It is presently unknown what, if any, vibrations
or extent of exposure may contribute to the condition.
There are measures that can be taken by the operator to
possibly reduce the effects of vibration:
a) Keep your body warm in cold weather. When operating
the unit wear gloves to keep your hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
b) After each period of operation, exercise to
increase blood circulation.
c) Take frequent work breaks. Limit the amount of
exposure per day.
d) Keep the product well maintained, fasteners tightened
and worn parts replaced.
If you experience any of the symptoms of this condition,
immediatelydiscontinueuse and see yourphysician about
these symptoms.
Mix and store fuel in a container approved for gasoline.
Do not smoke while fueling or mixing fuel.
GENERAL SAFETY RULES

4 — English
SPECIFIC SAFETY RULES
Replace string head if cracked, chipped, or damaged
in any way. Be sure the string head is properly installed
and securely fastened. Failure to do so can cause serious
injury.
Make sure all guards, straps, deflectors, and handles are
properly and securely attached.
Never use blades, flailing devices, wire, or rope. Use only
the manufacturer’s replacement line in the cutting head.
Do not use any other cutting attachment. To install any
other brand of cutting head to this string trimmer can
result in serious personal injury.
Never operate unit without the grass deflector in place
and in good condition.
Maintain a firm grip on both handles while trimming. Keep
string head below waist level. Never cut with the string
head located over 30 in. or more above the ground.
This product is intended for infrequent use by homeown-
ers and other occasional users for such general applica-
tions as trimming light and heavy vegetation, etc. It is not
intended for prolonged use. Prolonged periods of opera-
tion can cause circulatory problems in the user’s hands
due to vibration. For such use, it may be appropriate to
use a product having an anti-vibration feature.
GENERAL SAFETY RULES
Mix fuel outdoors where there are no sparks or flames.
Wipe up any fuel spillage. Move 30 ft. away from refueling
site before starting engine.
Stop the engine and allow to cool before refueling or
storing the unit.
Allow the engine to cool; empty the fuel tank into a
container approved for gasoline and secure the unit from
moving before transporting in a vehicle.

5 — English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME EXPLANATION
Safety Alert Symbol Indicates a potential personal injury hazard.
Read Operator’s Manual To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye and Hearing Protection Always wear eye protection with side shields marked to com-
ply with ANSI Z87.1, along with hearing protection.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Ricochet Thrown objects can ricochet and result in personal injury or
property damage.
No Blade Do not install or use any type of blade on a product display-
ing this symbol.
Gasoline and Lubricant
Use unleaded gasoline intended for motor vehicle use with
an octane rating of 87 [(R + M) / 2] or higher. This product is
powered by a 2-cycle engine and requires pre-mixing gasoline
and 2-cycle lubricant.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.

6 — English
PRODUCT SPECIFICATIONS
Weight (dry)
26CS .....................................................................................................................................................................9.3 lbs.
26SS ......................................................................................................................................................................10 lbs.
Line cutting width...........................................................................................................................................................17 in.
Engine displacement.......................................................................................................................................................26cc
Line diameter.............................................................................................................................................................. .080 in.
KNOW YOUR STRING TRIMMER
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
GRASS DEFLECTOR
The trimmer includes a grass deflector that helps protect
you from flying debris.
STRING HEAD TAP ADVANCE SYSTEM
The String Head Tap Advance System allows easy line
advance during trimmer operation.
TOP-MOUNTED MOTOR
The top-mounted motor improves balance and is located
away from the dust and debris of the cutting area.
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Donotdiscardthepackingmaterial until you havecarefully
inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-332-1631 for assistance.
PACKING LIST
Trimmer Assembly
Front Handle
String Head Assembly
Spool Retainer
Curved Shaft Grass Deflector – 26CS
PACKING LIST (continued)
Straight Shaft Grass Deflector – 26SS
Bottle of 2-Cycle Lubricant
Operator’s Manual
WARNING:
If any parts are damaged or missing, do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING:
Do not attempt to modify this product or create acces-
sories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark plug
wire from the spark plug when assembling parts.
FEATURES
ASSEMBLY

7 — English
FRONT HANDLE
See Figure 2.
Loosen and remove the wing nut, lock washer, washer,
and bolt from the handle.
Install the handle on the drive shaft housing at the loca-
tion indicated by the label on the shaft.
Adjust handle up or down, if necessary, to desired operat-
ing position.
Reinstall the bolt, washer, lock washer, and wing nut.
Tighten wing nut to secure.
NOTE: On units with curved shafts, for shipping purposes
only,thehandleis located underneath thedrive shaft housing.
The handle must be rotated before operating the trimmer.
Slightly loosen the wing nut on the handle.
Rotate the handle on the drive shaft housing at the loca-
tion indicated by the label on the shaft.
Retighten the wing nut to secure the handle in place.
STRING HEAD ASSEMBLY
See Figures 3 - 4.
Place the string head assembly on the end of the drive
shaft. Make sure the hex-shaped opening on the string
head assembly seats completely on the drive shaft. Install
the spool retainer to secure.
Install the spool retainer:
Turn the spool retainer clockwise for 26CS.
Turn the spool retainer counterclockwise for 26SS.
Remove the plastic seal from the string head assembly.
Pull outward on the lines to rotate the spool into the cut-
ting position.
Push the spool retainer down while pulling on line(s) to
manually advance the line and to check for proper as-
sembly of the string head.
CURVED SHAFT GRASS DEFLECTOR – 26CS
See Figure 5.
WARNING:
The line cut-off blade on the grass deflector is sharp.
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
Removethebolt,washer,andwingnutfromgrass deflector.
Press the grass deflector onto the bottom of the curved
shaft as shown.
Insert the bolt through the grass deflector and the bracket
on the curved shaft.
Place the washer on the bolt.
Place the wing nut on the bolt and tighten securely.
STRAIGHT SHAFT GRASS DEFLECTOR –
26SS
See Figure 6.
Removethe wing nut and mounting bracket fromthegrass
deflector.
Assemble straight shaft grass deflector to drive shaft so
that the pin in the grass deflector fits in the locator hole
in the lower side of the drive shaft near the gear head.
Place the mounting bracket over the drive shaft so the
square tab on the mounting bracket fits into the slot in
the straight shaft grass deflector.
Rotate the mounting bracket so the screw on the grass
deflector goes into the slot on the mounting bracket.
Reinstall the wing nut and tighten securely.
ASSEMBLY
WARNING:
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING:
Never use blades, flailing devices, wire, or rope on this
product. Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
OPERATION

8 — English
OPERATION
WARNING:
Operation of this equipment could create sparks that
can start fires around dry vegetation. A spark arrestor
may be required. The operator should contact local fire
agencies for laws or regulations relating to fire prevention
requirements.
WARNING:
Gasoline and its vapors are highly flammable and ex-
plosive. To prevent serious personal injury and property
damage, handle it with care. Keep away from ignition
sources and open flames, handle outdoors only, do not
smoke and wipe up spills immediately.
FUELING AND REFUELING THE TOOL
FUEL MIXTURE
This product is powered by a 2-cycle engine and requires
pre-mixing gasoline and 2-cycle lubricant. Pre-mix unleaded
gasoline and 2-cycle engine lubricant in a clean container
approved for gasoline. DO NOT mix quantities larger than
usable in a 30-day period.
Recommended fuel: This engine is certified to operate on
unleaded gasoline intended for automotive use.
NOTE: We recommend you use high-quality synthetic
2-cycle lubricant in this product. Mix at 2.6 oz. per gallon
(US).
Do not use automotive lubricant or 2-cycle outboard
lubricant.
HIGH QUALITY 2-CYCLE ENGINE LUBRICANT
GASOLINE LUBRICANT
1.0 gal. (US) (3.8 liter) 2.6 oz. (76 ml)
2.5 gal. (US) (9.5 liter) 6.4 oz. (189 ml)
FILLING TANK
Clean surface around fuel cap to prevent
contamination.
Loosen fuel cap slowly, by turning it counterclockwise.
Rest the cap on a clean surface.
Carefully pour fuel into the tank. Avoid spillage.
Prior to replacing the fuel cap, clean and inspect the
gasket.
Immediately replace fuel cap and hand tighten by turning
it clockwise. Wipe up any fuel spillage.
Moveatleast 30 ft.away fromrefuelingareabeforestarting
the product.
NOTE: It is normal for smoke to be emitted from a new
engine after first use.
WARNING:
Always shut off engine before fueling. Never add fuel to a
machine with a running or hot engine. Move at least 30 ft.
from refueling site before starting engine. Do not smoke
and stay away from open flames and sparks. Failure to
safely handle fuel could result in serious personal injury.
OXYGENATED FUELS
NOTICE: DO NOT USE E15 OR E85 FUEL (OR FUEL
CONTAINING GREATER THAN 10% ETHANOL) IN THIS
PRODUCT. IT IS A VIOLATION OF FEDERAL LAW AND
WILL DAMAGE THE UNIT AND VOID YOUR WARRANTY.
NOTE: Fuel system damage or performance problems
resulting from the use of an oxygenated fuel containing more
than the percentages of oxygenates stated below are not
covered under warranty.
Ethanol. Gasoline containing up to 10% ethanol by volume
(commonly referred to as E10) is acceptable. E15 and E85
are not.
STARTING AND STOPPING
See Figures 7 - 8.
Trimmer should be on a flat, bare surface for starting.
To start a cold engine:
Slowly press the primer bulb 10 times.
NOTE: After the 7th press, fuel should be visible in the
primer bulb. If it is not, continue to press the primer until
you see fuel in the bulb.
Set the choke lever to the FULL CHOKE position.
Squeeze the throttle trigger fully and pull starter grip and
rope sharply until engine attempts to run. Do not pull the
starter grip and rope more than four (4) times.
NOTE: Keep throttle trigger squeezed fully.
Set the choke lever to the HALF CHOKE position.
Pull the starter grip and rope until the engine runs. Do not
pull the starter grip and rope more than six (6) times.
NOTE: If the engine does not start, return to the FULL
CHOKE position and repeat the steps that follow.
Allow the engine to run for 10 seconds, then set the choke
lever to the RUN position.
To restart a warm engine:
Slowly press the primer bulb 10 times.
Set the choke lever to the RUN position.
Squeeze the throttle trigger fully and pull the starter grip
and rope until the engine runs.
To stop the engine:
To stop the engine, releasethe throttletriggerand depress
the STOP switch to the stop position “ ”.

9 — English
IF ASSISTANCE IS REQUIRED FOR THIS PRODUCT:
Do not return this product to the retail store where it was
purchased. Please call our Customer Service Department
for any issues you may have.
For Help Call: 1-800-332-1631.
OPERATING THE STRING TRIMMER
See Figure 9.
WARNING:
Engine housing can become hot during trimmer opera-
tion. Do not rest or place your arm, hand, or any body
part against the engine housing during trimmer operation.
Only hold the trimmer as shown in Figure 9 with all body
parts clear of engine housing. Extended contact with
the engine housing may result in burns or other injuries.
WARNING:
Always position the unit on the operator’s right side. The
use of the unit on the operator’s left side will expose the op-
erator to hot surfaces and can result in possible burn injury.
WARNING:
To avoid burns from hot surfaces, never operate unit with
the bottom of the engine above waist level.
Hold the trimmer with your right hand on the rear handle
and your left hand on the front handle. Keep a firm grip with
both hands while in operation. Trimmer should be held at a
comfortable position with the rear handle about hip height.
Always operate trimmer at full throttle. Cut tall grass from the
top down. This will prevent grass from wrapping around the
shaft housing and string head which may cause damage from
overheating. If grass becomes wrapped around the string
head, STOP THE ENGINE, disconnect the spark plug wire,
and remove the grass. Prolonged cutting at partial throttle
will result in lubricant dripping from the muffler.
WARNING:
Always hold the string trimmer away from your body,
keeping clearance between your body and the product.
Any contact with the housing or string trimmer cutting
head can result in burns and/or other serious personal
injury.
CUTTING TIPS
See Figure 9 - 10.
Avoid hot surfaces by always keeping the tool away from
your body. (Proper operating position shown in figure 9.)
Keep the trimmer tilted toward the area being cut; this is
the best cutting area.
The curved shaft trimmer cuts when passing the unit from
right to left. The straight shaft trimmer cuts when passing
the unit from left to right. This will avoid throwing debris at
the operator. Avoid cutting in the dangerous area shown
in figure 10.
Use the tip of line to do the cutting; do not force string
head into uncut grass.
Wire and picket fences cause extra line wear, even break-
age. Stone and brick walls, curbs, and wood may wear
line rapidly.
Avoid trees and shrubs. Tree bark, wood moldings, siding,
and fence posts can easily be damaged by the line.
ADVANCING LINE USING THE STRING HEAD
TAP ADVANCE SYSTEM
Line advance is controlled by tapping string head on grass
while running engine at full throttle.
Run engine at full throttle.
Tap string head on ground to advance line. Line advances
each time the head is tapped.
Several taps may be required until line strikes the cut off
blade.
Resume trimming.
NOTE: If the line is worn too short you may not be able to
advance the line by tapping it on the ground. If so, STOP
THE ENGINE, disconnect the spark plug wire, and manually
advance the line.
ADVANCING THE LINE MANUALLY
With the engine off and the spark plug wire disconnected,
push the spool retainer down while pulling on line(s) to manu-
ally advance the line.
CUT-OFF BLADE
This trimmer is equipped with a cut-off blade on the grass
deflector. For best cutting, advance line by tapping the string
head until the line is trimmed to length by the cut-off blade.
Advance line whenever you hear the engine running faster
than normal, or when trimming efficiency diminishes. This
will maintain best performance and keep line long enough
to advance properly.
OPERATION

10 — English
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts could create a hazard or cause
product damage.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
WARNING:
Before inspecting, cleaning, or servicing the machine,
shut off engine, wait for all moving parts to stop, and
disconnect spark plug wire and move it away from spark
plug. Failure to follow these instructions can result in
serious personal injury or property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, lubricant, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating lubricants, etc., come in con-
tact with plastic parts. Chemicals can damage, weaken or
destroy plastic which can result in serious personal injury.
You can often make adjustments and repairs described here.
For other repairs, have the trimmer serviced by an authorized
service dealer.
SPOOL REPLACEMENT STRING HEAD TAP
ADVANCE SYSTEM
See Figures 11 - 12.
If replacing line only, refer to Line Replacement later in
this manual.
Use only .080 in. trimmer line.
Stop the engine and disconnect the spark plug wire. Hold
the string head and unscrew the spool retainer.
To remove the spool retainer:
Turn the spool retainer counterclockwise for 26CS.
Turn the spool retainer clockwise for 26SS.
Remove the empty spool from the string head.
NOTE: It is not necessary to remove the string head
housing from the drive shaft.
Insert the new spool into the string head.
NOTE: Make sure the arrows on the spool are aligned
with the eyelets in the string head housing. Push down
and hold the spool and housing together while complet-
ing the installation.
Reinstall the spool retainer to secure.
To install the spool retainer:
Turn the spool retainer clockwise for 26CS.
Turn the spool retainer counterclockwise for 26SS.
Install line as described in Line replacement.
LINE REPLACEMENT
See Figures 12 - 14.
Stop the engine and disconnect the spark plug wire.
Rotate the spool clockwise as necessary to align the
arrows on the spool with the eyelets in the string head
housing.
Cut one piece of trimmer line 15 ft. long. Insert the line
into the eyelet on the string trimmer housing. Push until
the end of the line comes out the other side of the string
head. Pull the line from the other side until equal amounts
of line appear on both sides of the spool.
Rotate the spool clockwise to wind the line on the spool
until approximately 6 in. of line is showing on each side.
Push the spool retainer down while pulling on line(s) to
manually advance the line and to check for proper as-
sembly of the string head.
CLEANING THE EXHAUST PORT, MUFFLER,
AND SPARK ARRESTOR
NOTE: Depending on the type of fuel used, the type and
amount of lubricant used, and/or your operating condi-
tions, the exhaust port, muffler, and/or spark arrestor screen
may become blocked with carbon deposits. If you notice a
power loss with your gas powered tool, you may need to
remove these deposits to restore performance. We highly
recommend that only qualified service technicians perform
this service.
The spark arrestor must be cleaned or replaced every 50
hours or yearly to ensure proper performance of your prod-
uct. Spark arrestors may be in different locations depending
on the model purchased. Please contact your nearest service
dealer for the location of the spark arrestor for your model.
CLEANING THE AIR FILTER SCREEN
See Figures 15 - 16.
For proper performance and long life, keep air filter screen
clean.
Remove the air filter cover by pushing down on the latch
with your thumb while gently pulling on the cover.
Brush the air filter screen lightly to clean.
Replace the air filter cover by inserting the tabs on the
bottom of the cover into the slots on the air filter base;
push the cover up until it latches securely in place.
MAINTENANCE

11 — English
FUEL CAP
WARNING:
Check for fuel leaks. A leaking fuel cap is a fire hazard and
must be replaced immediately. If you find any leaks, cor-
rect the problem before using the product. Failure to do so
could result in a fire that could cause serious personal injury.
The fuel cap contains a non-serviceable filter and a check
valve. A clogged fuel filter will cause poor engine perfor-
mance. If performance improves when the fuel cap is loos-
ened, check valve may be faulty or filter clogged. Replace
fuel cap if required.
IDLE SPEED ADJUSTMENT
See Figure 17.
WARNING:
The cutting head will move when adjusting the idle speed.
Wear all protective clothing and keep all bystanders,
children, and pets at least 50 ft. away. Make adjustments
with the unit supported by hand so that the cutting head
does not contact the ground or any object. Keep all parts
of your body away from the cutting head and muffler.
Failure to follow these instructions could result in serious
personal injury.
If the cutting attachment turns at idle, the idle speed screw
needs adjusting on the engine. Turn the idle speed screw
counterclockwise to reduce the idle RPM and stop the cut-
ting attachment movement. If the cutting attachment still
moves at idle speed, contact a service dealer for adjustment
and discontinue use until the repair is made.
WARNING:
The cutting attachment should never turn at idle. Turn
the idle speed screw counterclockwise to reduce the
idle RPM and stop the cutting attachment, or contact a
service dealer for adjustment and discontinue use until
the repair is made. Serious personal injury could result
from the cutting attachment turning at idle.
SPARK PLUG
This engine uses a Champion RCJ6Y or equivalent spark
plug with .025 in. electrode gap. Use an exact replacement
and replace annually, or more frequently if necessary.
STORING THE PRODUCT
Clean all foreign material from the product. Store idle unit
indoors in a dry, well-ventilated area that is inaccessible
to children. Keep away from corrosive agents such as
garden chemicals and de-icing salts.
Abide by all ISO and local regulations for the safe storage
and handling of gasoline.
When storing 1 month or longer:
Drain all fuel from tank into a container approved for
gasoline. Run engine until it stops.
HIGH ALTITUDE ENGINE OPERATION
Please have an authorized service center adjust this engine
if it is to be run above 2000 feet. Failure to do so may result
in poor engine performance and increased emissions. An
engine adjusted for high altitudes can not be run at 2000
feet or lower. In doing so, the engine will overheat and cause
serious engine damage. Please have an authorized service
center restore high altitude modified engines to the original
factory specification before operating below 2000 feet.
MAINTENANCE

12 — English
CALL
www.greenmachinetools.com
1-800-332-1631
CALL US FIRST
For any questions about operating or maintaining your product,
call the GREEN MACHINE™Help Line!
Your product has been fully tested prior to shipment to ensure
your complete satisfaction.
MAINTENANCE
THIS PRODUCT WAS MANUFACTURED WITH A CATALYST MUFFLER
Congratulations! You have made an investment toward protecting the environment. In order to maintain this product’s
original emission level, please refer to the maintenance section below.
MAINTENANCE SCHEDULE
Inspect Clean Replace Replace
Maintenance Before Every Every 25 Hours Every
Part Each Use 5 Hours or Yearly 50 Hours
*CATALYTIC MUFFLER ASSEMBLY..................................................................................................................X
SPARK SCREEN ...............................................................................................................................................X
*AIR FILTER ASSY
includes:
Filter Screen ........................................................................ X
*CARBURETOR ASSY
includes:
Gaskets ........................................ X
*FUEL TANK ASSY
includes:
Fuel Lines..................................... X
Fuel Cap....................................... X
Fuel Filter................................................................................................................... X
*IGNITION ASSY
includes:
Spark Plug................................................................................................................. X
* NOTICE: THE USE OF EMISSION CONTROL COMPONENTS OTHER THAN THOSE DESIGNED FOR THIS UNIT
IS A VIOLATION OF FEDERAL LAW.

13 — English
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM CONTACT YOUR AUTHORIZED SERVICE DEALER.
TROUBLESHOOTING
Problem Possible Cause Solution
Engine will not start. No spark.
No fuel.
Engine is flooded.
Starter rope pulls harder now than
when new.
Check spark. Remove spark plug. Re-
attach the spark plug cap and lay spark
plug on metal cylinder. Pull the starter
rope and watch for spark at spark plug
tip. If there is no spark, repeat test with
a new spark plug.
Push primer bulb until bulb is full of
fuel. If bulb does not fill, primary fuel
delivery system is blocked. Contact
a servicing dealer. If primer bulb fills,
engine may be flooded, proceed to
next item.
Remove spark plug, turn trimmer so
spark plug hole is aimed at the ground.
Rotate the choke dial to “RUN” posi-
tion and pull starter cord 10 to 15
times. This will clear excess fuel from
engine. Clean and reinstall spark plug.
Pull starter three times with choke dial
at “RUN”. If engine does not start, ro-
tate choke dial to “FULL CHOKE” posi-
tion and repeat normal starting proce-
dure. If engine still fails to start, repeat
procedure with a new spark plug.
Contact an authorized servicing dealer.
Engine does not reach full speed and
emits excessive smoke.
Check lubricant fuel mixture.
Air filter is dirty.
Carburetor out of adjustment.
Use fresh fuel and the correct 2-cycle
lubricant mix.
Clean air filter. Refer to Cleaning the
Air Filter Screen earlier in this manual.
Contact an authorized servicing dealer.
Engine starts, runs, and accelerates
but will not idle.
Idle speed screw on carburetor needs
adjustment.
Turn idle speed screw clockwise to
increase idle speed. See figure 17.

14 — English
TROUBLESHOOTING
Problem Possible Cause Solution
Line will not advance. Line is welded to itself.
Not enough line on spool.
Line is worn too short.
Line is tangled on spool.
Engine speed is too slow.
Lubricate with silicone spray.
Install more line. Refer to Line
Replacement earlier in this manual.
Pull lines while alternately pressing
down on and releasing spool retainer.
Remove line from spool and rewind.
Refer to Line Replacement earlier in
this manual.
Advance line at full throttle.
Spool retainer hard to turn. Screw threads are dirty or damaged. Clean threads and lubricate with
grease – if no improvement, replace
the spool retainer.
Grass wraps around drive shaft hous-
ing and string head.
Cutting tall grass at ground level.
Operating trimmer at part throttle.
Cut tall grass from the top down to
prevent wrapping.
Operate trimmer at full throttle.
Lubricant drips from muffler. Operating trimmer at part throttle.
Check lubricant/fuel mixture.
Air filter screen dirty.
Operate trimmer at full throttle.
Use fresh fuel and the correct 2-cycle
lubricant mix.
Clean air filter. Refer to Cleaning the
Air Filter Screen earlier in this manual.

15 — English
LIMITED WARRANTY STATEMENT
OWTIndustries,Inc.,warrantstothe original retailpurchaser
that this GREEN MACHINE™brand outdoor product is free
from defect in material and workmanship and agrees to
repair or replace, at OWT Industries, Inc.’s, discretion, any
defective product free of charge within two years from the
date of purchase.
This warranty extends to the original retail purchaser only
and commences on the date of the original retail purchase.
Any part of this product found in the reasonable judgment
of OWT Industries, Inc. to be defective in material or
workmanship will be repaired or replaced without charge
for parts and labor by an authorized service center for
GREEN MACHINE™brand outdoor products (Authorized
Green Machine Service Center).
Theproduct,includingany defective part, mustbe returned
to an authorized Green Machine service center within the
warranty period. The expense of delivering the product to
the service center for warranty work and the expense of
returningit back tothe owner afterrepairorreplacementwill
be paid by the owner. OWT Industries, Inc.’s, responsibility
in respect to claims is limited to making the required repairs
orreplacementsand no claim of breachofwarranty shall be
cause for cancellation or rescission of the contract of sale
of any GREEN MACHINE™brand outdoor product. Proof
of purchase will be required by the dealer to substantiate
any warranty claim. All warranty work must be performed
by an authorized service dealer.
This warranty is limited to thirty (30) days from the date of
original retail purchase for any GREEN MACHINE™brand
outdoor product that is used for rental or commercial
purposes, or any other income-producing purpose.
This warranty does not cover any product that has been
subject to misuse, neglect, negligence, or accident, or that
has been operated in any way contrary to the operating
instructions as specified in this operator’s manual. This
warranty does not apply to any damage to the product that
is the result of improper maintenance or to any product
that has been altered or modified. The warranty does not
extend to repairs made necessary by normal wear or by the
use of parts or accessories which are either incompatible
with the GREEN MACHINE™brand outdoor product or
adversely affect its operation, performance, or durability.
In addition, this warranty does not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting
Lines, Inner Reels, Starter Pulleys, Starter Ropes, Drive
Belts, Tines, Felt Washers, Hitch Pins, Mulching Blades,
Blower Fans, Blower and Vacuum Tubes, Vacuum Bag
and Straps, Guide Bars, Saw Chains, Blades
OWTIndustries,Inc., reservestherightto change or improve
thedesignofanyGREENMACHINE™brandoutdoorproduct
without assuming any obligation to modify any product
previously manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED IN
THEIR ENTIRETY AFTER THE EXPIRATION OF THE
TWO-YEAR WARRANTY PERIOD. OWT INDUSTRIES,
INC.’S, OBLIGATION UNDER THIS WARRANTY IS
STRICTLY AND EXCLUSIVELY LIMITED TO THE
REPAIR OR REPLACEMENT OF DEFECTIVE PARTS
AND OWT INDUSTRIES, INC., DOES NOT ASSUME OR
AUTHORIZE ANYONE TO ASSUME FOR THEM ANY
OTHER OBLIGATION. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU. OWT INDUSTRIES, INC., ASSUMES NO
RESPONSIBILITY FOR INCIDENTAL, CONSEQUENTIAL,
OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO, EXPENSE OF RETURNING THE PRODUCT TO AN
AUTHORIZED GREEN MACHINE SERVICE CENTER AND
EXPENSE OF DELIVERING IT BACK TO THE OWNER,
MECHANIC’STRAVEL TIME, TELEPHONE ORTELEGRAM
CHARGES, RENTAL OF A LIKE PRODUCT DURING THE
TIME WARRANTY SERVICE IS BEING PERFORMED,
TRAVEL, LOSS OR DAMAGE TO PERSONAL PROPERTY,
LOSS OF REVENUE, LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, OR INCONVENIENCE. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all GREEN MACHINE™brand
outdoor products manufactured by or for OWT Industries,
Inc., and sold in the United States and Canada.
To locate your nearest Authorized Green Machine Service
Center, dial 1-800-332-1631.
WARRANTY

16 — English
THE FOLLOWING CALIFORNIA AIR RESOURCES BOARD (CARB) STATEMENT ONLY APPLIES TO MODEL NUMBERS
REQUIRED TO MEET THE CARB REQUIREMENTS.
The U.S. Environmental Protection Agency (EPA), the California Air Resources Board
(CARB), and OWT Industries, Inc., are pleased to explain the Emissions Control
System Warranty on your 2012 model year non-road or small off-road engine. In
California, new equipment that uses small off-road engines must be designed, built,
and equipped to meet the state’s stringent anti-smog standards. In other states, new
2012 model year non-road engines must be designed, built, and equipped at the time
of sale to meet the U.S. EPA regulations for small non-road engines. The non-road
engine must be free from defects in materials and workmanship which cause it to
fail to conform with U.S. EPA standards for the first two years of engine use from the
date of sale to the ultimate purchaser. OWT Industries, Inc., must warrant the emis-
sion control system on your non-road or small off-road engine for the period of time
listed above provided there has been no abuse, neglect, or improper maintenance
of your non-road or small off-road engine.
Your emission control system may include parts such as the carburetor or fuel injection
system, the ignition system, catalytic converters, fuel tanks, valves, filters, clamps,
connectors, and other associated components. Also included may be hoses, belts
and connectors, and other emission-related assemblies.
Where a warrantable condition exists, OWT Industries, Inc., will repair your non-road or
small off-road engine at no cost to you, including diagnosis, parts, and labor performed
at an authorized service center for GREEN MACHINE™brand outdoor products.
MANUFACTURER’S WARRANTY COVERAGE:
This product’s emissions control system is warranted for two years. If any
emission-related part on your engine is defective, the part will be repaired or replaced
by OWT Industries, Inc., free of charge.
OWNER’S WARRANTY RESPONSIBILITIES
(a) As the non-road or small off-road engine owner, you are responsible for the perfor-
mance of the required maintenance listed in your operator’s manual. OWT Industries,
Inc., recommends that you retain all receipts covering maintenance on your non-road or
small off-road engine, but OWT Industries, Inc., cannot deny warranty solely for the lack
of receipts or for your failure to ensure the performance of all scheduled maintenance.
(b) As the non-road or small off-road engine owner, you should be aware, however,
that OWT Industries, Inc., may deny you warranty coverage if your non-road or small
off-road engine or a part has failed due to abuse, neglect, improper maintenance,
or unapproved modifications.
(c) You are responsible for presenting your non-road or small off-road engine to an
authorized service dealer as soon as a problem exists. The warranty repairs should
be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities, you
should contact a OWT Industries, Inc., Customer Representative at 1-800-332-1631.
DEFECT WARRANTY COVERAGE REQUIREMENTS:
(a) The warranty period begins on the date the engine or equipment is delivered to
an ultimate purchaser.
(b) General Emissions Warranty Coverage. OWT Industries, Inc., warrants to the
ultimate purchaser and each subsequent purchaser that your non-road or small off-
road engine is designed, built, and equipped at the time of sale to conform with all
applicable regulations adopted by the California Air Resources Board or the United
States Environmental Protection Agency; and that it is free from defects in materials
and workmanship which cause the engine to fail to conform with applicable regula-
tions for a period of two years from the date the non-road or small off-road engine is
purchased by the initial purchaser. Any replacement part or service that is equivalent
in performance and durability may be used in non-warranty maintenance or repairs,
and shall not reduce the warranty obligations of OWT Industries, Inc.
(c) The warranty on emissions-related parts will be interpreted as follows: Any war-
ranted part that is not scheduled for replacement as required in the Maintenance
Schedule is warranted for two years. If any such part (including any part that is
scheduled only for regular inspection) fails during the period of warranty coverage,
it will be repaired or replaced at any GREEN MACHINE™Authorized Service Center
at no charge. Any such part repaired or replaced under warranty will be warranted
for the remaining warranty period. A statement to the effect of “repair or replace
as necessary” would not reduce the period of warranty coverage. Any warranted
part that is scheduled for replacement as required maintenance in the Maintenance
Schedule is warranted for the period of time prior to the first scheduled replacement
point for that part. Any such part repaired or replaced under warranty is warranted
for the remainder of the period prior to the first scheduled replacement point, and
will be repaired or replaced at any GREEN MACHINE™Authorized Service Center
for no charge until that replacement point is reached.
OWT Industries, Inc., shall remedy warranty defects at any authorized GREEN MA-
CHINE™Authorized Service Center, including any distribution center that may be
franchised to service the subject engines. Any diagnostic work done at a GREEN
MACHINE™Authorized Service Center shall be free of charge to the owner if such
work determines that a warranted part is defective. Any manufacturer-approved or
equivalent replacement part may be used for any warranty maintenance or repairs
on emission-related parts, and must be provided free of charge to the owner if the
part is still under warranty. OWT Industries, Inc., is liable for damages to other engine
components caused by the failure of a warranted part still under warranty.
Add-on or modified parts that are not exempted by the California Air Resource
Board may not be used. The use of any non-exempted add-on or modified parts
will be grounds for disallowing a warranty claim. OWT Industries, Inc., will not be
liable to warrant failures of warranted parts caused by the use of a non-exempted
add-on or modified part.
The Emission Parts List specifically defines the emission-related warranted parts.
OWT Industries, Inc., will provide any documents that describe its warranty proce-
dures or policies within five days upon request by the California Air Resources Board.
EMISSIONS PARTS LIST
Emissions parts vary from product to product. Your emissions control system warranty
applies to any of the following components that may be included on your product:
(1) Fuel Metering System
(i) Carburetor and internal parts (and/or pressure regulator or fuel injection
system).
(ii) Air/fuel ratio feedback and control system.
(iii) Cold start enrichment system.
(iv) Fuel Tank.
(v) Fuel Hose.
(2) Air Induction System
(i) Controlled hot air intake system.
(ii) Intake manifold.
(iii) Air filter.
(3) Ignition System
(i) Spark plugs.
(ii) Magneto or electronic ignition system.
(iii) Spark advance/retard system.
(4) Exhaust Gas Recirculation (EGR) System
(i) EGR valve body and carburetor spacer, if applicable.
(ii) EGR rate feedback and control system.
(5) Air Injection System
(i) Air pump or pulse valve.
(ii) Valves affecting distribution of flow.
(iii) Distribution manifold.
(6) Catalyst or Thermal Reactor System
(i) Catalytic converter.
(ii) Thermal reactor.
(iii) Exhaust manifold.
(7) Particulate Controls
(i) Traps, filters, precipitators, and any other device used to capture particulate
emissions.
(8) Miscellaneous Items Used in Above Systems
(i) Electronic controls.
(ii) Vacuum, temperature, and time sensitive valves and switches.
(iii) Hoses, belts, connectors, and assemblies.
OWT Industries, Inc., will furnish with each new engine written instructions for its
maintenance and use by the owner.
OWT INDUSTRIES, INC., LIMITED WARRANTY STATEMENT FOR FEDERAL AND CALIFORNIA
EMISSION CONTROL SYSTEMS NON-ROAD AND SMALL OFF-ROAD ENGINES
YOUR WARRANTY RIGHTS AND OBLIGATIONS
WARRANTY
