Greenpacket OX-350I User manual

Page 1 of 91
User Manual
OX-350I
WiMAX Outdoor CPE
Version: 1.3
Date: Oct. 26, 2011

OX-350I User Manual Rev1.3
Page 2 of 91
Previous History
Revision
Date of Issue
Scope
Author
1.0 2011/08/31 Initial document Alpha C.
1.1 2011/09/21 Add FCC Warning Wording Tony Kao
1.2 2011/10/04 Modify Important Notice content in page 4 Tony Kao
1.3 2011/10/26 Add a note for Max. Antenna Gain limitation
in page 4 Tony Kao

OX-350I User Manual Rev1.3
Page 3 of 91
Federal Communication Commission Interference Statement :
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

OX-350I User Manual Rev1.3
Page 4 of 91
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 60cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Due to the essential high output power natural of WiMAX device, use of this
device with other transmitter at the same time may exceed the FCC RF exposure
limit and such usage must be prohibited (unless such co-transmission has been
approved by FCC in the future).
IMPORTANT NOTE:
1. According to FCC regulation (FCC 05-56), in order for the device to
safely operate in the 3.675~3.700 GHz range, the device shall be connected
to a Base station which supports "listen mode" and can instruct this device
accordingly.
2. The max. gain of antenna used in this product is limited to be under 17.04dBi.
