GreenWorks GE 080 User manual

82V Edger
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-855-470-4267
www.greenworkstools.com/82v-Commercial/
GE 080
(2700102)

2
CONTENTS
Contents .............................................................................................................................. 2
Product Specications ........................................................................................................ 2
Important Safety Instructions............................................................................................... 3
Symbols............................................................................................................................... 5
Know Your Edger ................................................................................................................. 7
Assembly ............................................................................................................................. 9
Operation........................................................................................................................... 12
Maintenance........................................................................................................................... 15
Environmentally Safe Battery Disposal .................................................................................16
Troubleshooting..................................................................................................................17
Warranty..................................................................................................................................18
Exploded View .......................................................................................................................20
Parts List ......................................................... ....... ..............................................................21
PRODUCT SPECIFICATIONS
82V LITHIUM-ION EDGER
Type ............................................................................................. Cordless, battery powered
Motor ..................................................................................................................... Brushless
Blade Length ......................................................................................................8 in. (203 mm)
No load speed .................................................................................................7000 ±10% RPM
Weight (without battery) ..................................................................................10.37 lbs (4.7 kg)

3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Read and understand all instructions before using this product. Failure to follow all
instructions listed below may result in electric shock, re, and/or serious personal injury.
• Use only identical manufacturer’s replacement parts and accessories. Use of any other parts
may create a hazard or cause product damage.
• Always wear safety glasses with side shields marked to comply with ANSI Z87.1. Everyday
glasses have only impact resistant lenses. They are NOT safety glasses. Following this rule
will reduce the risk of eye injury. Use face mask if operating in dusty work spaces.
• Avoid Dangerous Environments — Don’t expose power tools to damp or wet conditions. Water
entering a power tool will increase the risk of electric shock.
• Don’t use in rain.
• Keep all bystanders, children, and pets at least 50 ft. away.
• Do not use the power tools for any job except for which it is intended.
• Avoid Unintentional Starting – Do not carry the edger with ngers on the switch. Be sure the
battery is removed while transporting.
• Do not operate the equipment while barefoot or when wearing sandals or similar lightweight
footwear. Wear footwear that will protect your feet and improve your footing on slippery
surfaces.
• Don’t overreach - Keep proper footing and balance at all times.
• Stay alert - Watch what you are doing. Use common sense. Do not operate this unit when you
are tired, ill or under the inuence of alcohol, drugs or medication.
• Always store idle power tools indoors - When not in use, power tools should be stored indoors
in a dry place, out of reach of children.
• Power tool maintenance – Replace blade if cracked, chipped, or damaged in any way. Be
sure the blade is properly installed and securely fastened. Keep cutting edge sharp and clean
for best performance and to reduce the risk of injury. Follow instructions for lubricating and
changing accessories. Keep handles dry, clean, and free from oil and grease. Failure to do so
can cause serious injury.
• Check Damaged Parts – Before further use of the power tool, a guard or other damaged
parts should be carefully checked to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts, binding of moving parts, breakage of
parts, damaged mountings, and any other condition that may affect its operation. A guard or
other damaged parts should be properly repaired or replaced by an authorized service center
unless indicated elsewhere in this manual.
• Do not charge or operate cordless tools in damp or wet locations or in the rain. Following this
rule will reduce the risk of electric shock.
• Remove or disconnect battery before servicing, cleaning or removing material from the power
tool.
• Do not dispose of the batteries in a re. The cells may explode. Check with local codes for
specic disposal instructions.

4
IMPORTANT SAFETY INSTRUCTIONS
• Do not open or mutilate the batteries. Released electrolytes are corrosive and may cause
damage to the eyes or skin. It may be toxic if swallowed.
• Exercise care not to short the battery with conducting materials such as rings, bracelets, and
keys. The battery or conductor may overheat and cause burns.
• Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts.
Use of rubber gloves and substantial footwear is recommended when working outdoors. Wear
protective hair covering to contain long hair.
• Do not add unnecessary force to your power tool – It will do the job better and with less
likelihood of a risk of injury at the rate for which it was designed.
• Recharge only with the charger specied by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re when used with another battery pack.
• For use only with (GL 200, GL 250, GL 300, GL 400, GL 500, GL 900) battery. For use only
with GC 400 charger.
• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal
to another. Shorting the battery terminals together may cause a re.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid contacts eyes, seek medical help immediately.
Liquid ejected from the battery may cause irritation or burns.
• Do not use a battery pack or power tool that is damaged or modied. Damaged or modied
batteries may exhibit unpredictable behavior resulting in re, explosion or risk of injury.
• Keep guards in place and in working order.
• Keep blades sharp.
• Keep hands and feet away from cutting area.
W A R N I N G (PROPOSITION 65)
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of
work. To reduce your exposure to these chemicals, work in a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.
SAVE THESE INSTRUCTIONS

5
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
min Minutes Time
/min Per Minute Revolutions, strokes, surface speed, orbits
etc., per minute.
Direct Current Type or a characteristic of current
Read The Operator’s Manual
To reduce the risk of injury user must read and
understand operator’s manual before using
this product.
Eye Protection
Always wear eye protection with side shields
marked to comply with ANSI Z87.1 when
operating this equipment.
Safety Alert Precautions that involve your safety.
Ricochet Thrown objects can ricochet and result in
personal injury or property damage.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Sharp Blade Danger - Keep hands and feet away from
blade.
Wet Conditions Alert Do not expose to rain or use in damp locations.
SYMBOLS

The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualified
service technician. For service we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTER for repair. Use only identical manufacturer’s replacement parts and
accessories.
WARNING
To avoid serious personal injury, do not attempt to use this product until you have read this Owner's
Manual thoroughly and understand it completely. If you do not understand the warnings and
instructions in this Owner's Manual, do not use this product. Call the Toll-free Helpline (1-855-470-
4267) for assistance. The operation of any power tool can result in foreign objects being thrown
into your eyes, which can result in severe damage to your eyes. Before operating a power tool,
always wear safety goggles, safety glasses with side shields, or a full face shield when needed. We
recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with
side shields. Always use eye protection that is marked to comply with ANSI Z87.1.
WARNING
The operation of any power tool can result in foreign objects being thrown into your
eyes, which can result in severe eye damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with side shields or a full face shield.
We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety
glasses with side shields. Always use eye protection which is marked to comply with
ANSI Z87.1.
DANGER Indicates an imminently hazardous situation, which if not
avoided will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which if not avoided
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which if not avoided
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SYMBOLS
SAVE THESE INSTRUCTIONS
6
SYMBOL SIGNAL MEANING

7
KNOW YOUR EDGER
Fig. 1
1
2
3
4
5
6
7
8

8
KNOW YOUR EDGER (See Figure 1.)
The safe use of this product requires an understanding of the information on the product and in
this operator’s manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
1. REAR HANDLE
Ergonomic handle with overmold improves comfort and grip.
2. AUXILIARY HANDLE
The edger is equipped with an auxiliary handle for added control and ease of operation.
3. SOLID TRIMMER SHAFT
The solid trimmer shaft encloses and protects the cables between the motor and trimmer head.
4. GUARD
The edger includes a guard that helps protect from ying debris.
5. EDGER WHEEL
The edger wheel allows for more stable cutting performance while edging.
6. SAFETY LOCK BUTTON
The safety lock button prevents accidental starting.
7. VARIABLE SPEED TRIGGER
Provides added control and precision.
8. DEPTH ADJUSTMENT KNOB (WING NUT)
The depth adjustment knob allows user to control depth of cut.
KNOW YOUR EDGER

9
ASSEMBLY
WARNING
Do not use this product if any parts on the packing list are already assembled to your product when
you unpack it. Parts on this list are not assembled to the product by the manufacturer and require
customer installation. Use of a product that may have been improperly assembled could result in
serious personal injury.
PACKING LIST
Part Name Figure Qty
Edger 1
Auxiliary Handle 1
Wheel Assembly 1
Metal Rod 1
Wrench 1
Operator's Manual 1
UNPACKING
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the packing list are included.
• Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the tool.
• If any parts are damaged or missing, please call 1-855-470 - 426 7.

ASSEMBLY
10
WARNING
If any parts are damaged or missing, do not operate this product until the parts are replaced. Use
of this product with damaged or missing parts could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
edger. Any such alteration or modification is misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
To prevent accidental starting that could cause serious personal injury, always remove the battery
pack from the product when assembling parts.
ATTACHING THE WHEEL (See Figure 2.)
1. Remove the wing nut (1), washer (2), axle sleeve (3), wheel (4), axle sleeve (3), rubber
washer (5) and wheel axle (6) orderly from the wheel assembly.
2. Insert the wheel axle(6) into the slot (7) downward, then put the rubber washer (5), axle
sleeve (3), wheel (4), axle sleeve (3), washer (2) and wing nut (1) orderly through the wheel
axle (6).
1
2
3
4
3
5
7
6
3. Tighten the wing nut (1).
1
2
3
4
6
3
5
Fig. 2.1
Fig. 2.2

11
ASSEMBLY
Fig. 3.1
Fig. 3.2
Fig. 3.3
1
2
3
ATTACHING THE AUXILIARY HANDLE (See Figure 3.)
1. Loosen the four screws (1) in the handle with a philips screwdriver (not included) and
remove the screws from the handle.
2. Attach the auxiliary handle (2) and lower clamp (3) on the shaft.
3. Adjust handle up or down to desired operating position.
4. Insert and tighten the four screws so that the handle cannot be rotated on the shaft.

12
OPERATION
WARNING
Read and understand entire Operator's Manual for each optional attachment used on this power
head and follow all warnings and instructions. Failure to follow all instructions may result in electric
shock, re and/or serious personal injury.
WARNING
Do not allow familiarity with this product to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING
Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
APPLICATIONS
You may use this product for the purpose listed below:
• Edging around walkways, curbs, ower beds and other similar areas.
INSTALLING THE BATTERY PACK (See Figure 4.)
• Insert battery pack into tool until an audible click is heard, and the battery is set securely
within the tool.
REMOVING THE BATTERY PACK (See Figure 4.)
• Depress the battery release button (1) on the tool and pull the battery pack out.
1
Fig. 4

13
STARTING AND STOPPING THE EDGER (See Figure 5.)
• Ensure a fully charged battery is installed into the edger.
• To start the edger, press and hold the safety lock button (1) and squeeze the trigger (2).
• To stop the edger, release trigger.
1
2
ADJUSTING DEPTH OF CUT (See Figure 6.)
• Remove the battery pack.
• Loosen the depth adjustment knob to increase or decrease the depth.
• Adjust the depth so that the blade barely touches the ground when the machine is held in a normal
operating posture.
• Tighten the depth adjustment knob.
• Standing in a normal working position, check the depth of cut again and correct if necessary.
• Replace the battery pack once all adjustments are complete.
OPERATION
Fig. 5
Depth Adjustment Knob
Fig. 6

14
REPLACING THE BLADE (See Figure 7.)
If the blade worn out, replace it with a new one (not provided) produced by Greenworks.
• Remove the battery pack.
• Use a metal rod (1) (provided) to x the blade.
• Remove the screw (2) clockwise with the wrench provided.
• Remove the washer (3).
• Remove the old blade and replace it with a new one.
• Place the washer (3) on the blade.
• Place the screw on the washer and tighten it unclockwise with the wrench provided.
Fig. 7
LOOSEN
TIGHTEN
OPERATING THE EDGER
WARNING
Always hold the edger away from the body keeping clearance between your body and the edger.
Any contact with the edger cutting head while operating can result in serious personal injury.
• Hold the edger with your right hand on the rear handle and your left hand on the front handle.
• Keep a rm grip with both hands while in operation.
• Edger should be held at a comfortable position with the rear handle about hip height.
• The edger will edge along sidewalks, driveways, ower beds, curbs, and similar areas.
• Cut at a steady pace. If the blade begins to bog down, you are edging too fast; slow your pace. Do
not force the blade into ground.
• Light contact of the blade against the sidewalk edge, curb, etc., is acceptable and will not damage
the edger.
• Best appearance is obtained when grass is dry. Avoid edging in wet soil or wet grass areas or the
blade guard might clog and result in an uneven edge. If the blade guard becomes clogged, stop
the edger, remove the battery, and remove debris from the blade guard.
OPERATION
23
1

15
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, lubricant, grease, etc.
Always store the machine clean and in a dry enclosure with the battery charged.
MAINTENANCE
Maintenance task Each time
the machine
is used
Every two
hours
Each week After use Every year
or when
required
Visual check of the tool's
safety systems (distancing
device, carrying eye, safety
casing)
X X
Check the trigger safety
system functions X
Check the sharpness of
blades and sharpen if
necessary
X X X
Visual check of the tool (no
cracks or deformation) X X X
Check the battery level X
Inspection of the tool by an
approved Greenworks dealer X

16
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
The following toxic and corrosive materials are in the batteries used in this edger battery pack:
Lithium-Ion, a toxic material.
WARNING
All toxic materials must be disposed of in a specified manner to prevent contamination of the
environment. Before disposing of damaged or worn out Lithium-Ion battery packs, contact your
local waste disposal agency, or the local Environmental Protection Agency for information and
specific instructions. Take the batteries to a local recycling and/or disposal centre, certified for
lithium-ion disposal.
WARNING
If the battery pack cracks or breaks, with or without leaks, do not recharge it and do not use.
Dispose of it and replace with a new battery pack. DO NOT ATTEMPT TO REPAIR IT!
To avoid injury and risk of re, explosion, or electric shock, and to avoid damage to the
environment:
• Cover the battery's terminals with heavy-duty adhesive tape.
• DO NOT attempt to remove or destroy any of the battery pack components.
• DO NOT attempt to open the battery pack.
• If a leak develops, the released electrolytes are corrosive and toxic. DO NOT get the
solution in the eyes or on skin, and do not swallow it.
• DO NOT place these batteries in your regular household trash.
• DO NOT incinerate.
• DO NOT place them where they will become part of any waste landll or municipal solid
waste stream.
• Take them to a certied recycling or disposal centre.

17
TROUBLESHOOTING
Problem Cause Solution
Motor fails to
start when
switch trigger is
depressed.
1. Battery is not secure. 1. To secure the battery pack, make sure the
latch (or latches) snap into place.
2. Battery is not charged. 2. Charge the battery pack according to the
instructions included with your model.

18
LIMITED WARRANTY
GREENWORKS™ hereby warranties this product, to the original purchaser with proof of
purchase, 2 year commercial power train warranty, 2 year commercial battery warranty against
defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair
or replace any and all parts found to be defective, through normal use, free of charge to the
customer. This warranty is valid only for units which have been used for personal use that have
not been hired or rented and that have been maintained in accordance with the instructions in
the owners’ manual supplied with the product from new.
2 Year Limited Power Train Warranty Coverage:
– Motor
– Gear Box
– 2 years from the date of purchase (non transferable)
2 Year Limited Battery Warranty Coverage:
– Greenworks Commercial Battery Packs (GL 200, GL 250, GL 300, GL 400, GL 500,
GL 900)
– 2 year from the date of purchase (non transferable)
60 Day Limited Wearable Parts Warranty Coverage:
– Blades
– Guards
– 60 Days from date of purchase (non transferable)
Warranty Exclusions, Limitations and Rights:
1. All warranties may not be transferred by the consumer to any subsequent
purchaser.
2. Parts or components not supplied by the warrantor, or parts or components that
have been modied.
3. Any failure resulting from the use of improper tools or improper repair procedures.
4. Any failure or part that has become inoperative due to accident, impact, abuse,
misuse, neglect, mishandling, dulling of cutting edges, or failure to operate the
product in accordance with the information provided in the instruction manual
supplied with the product.
5. Normal deterioration of the exterior due to use or exposure, and any repairs made

19
LIMITED WARRANTY
necessary by normal wear, improper maintenance, improper lubrication, improper
storage, dirt, abrasives, impact, moisture, water, rain, snow, rust, corrosion,
varnish, or other similar conditions.
6. Routine maintenance items such as lubricants, blade sharpening.
7. The unit, if it has not been operated and/or maintained in accordance with the
owner's manual.
8. Improper voltage for electric products and batteries that have been exposed to
temperatures beyond those specied in the product’s instruction manual, batteries
that have not been properly charged or batteries that have reached their useful life.
GREENWORKS HELPLINE:
Warranty service is available by calling our toll-free helpline, at 1-855-470-4267.
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power equipment unit or attachment are the
responsibility of the purchaser. It is the purchaser’s responsibility to pay transportation charges
for any part submitted for replacement under this warranty unless such return is requested in
writing by GREENWORKS.

20
EXPLODED VIEW
1
2
3
4
5
6
7
8
9
