GreenWorks G24LM33 User manual

LMG301
G24LM33
EN OPERATOR MANUALMOWER

1 Description......................................... 2
1.1 Purpose.............................................................. 2
1.2 Overview........................................................... 2
2 General safety rules...........................2
2.1 Training..............................................................2
2.2 Preparation.........................................................2
2.3 Operation........................................................... 3
2.4 Maintenance.......................................................4
3 Symbol................................................4
4 Risk levels...........................................5
5 Recycle................................................5
6 Installation......................................... 5
6.1 Unpack the machine.......................................... 5
6.2 Install the lower handle......................................5
6.3 Install the upper handle .....................................5
6.4 Install the grass catcher......................................5
6.5 Set the blade height............................................6
6.6 Install the battery pack.......................................6
6.7 Remove the battery pack................................... 6
7 Operation........................................... 6
7.1 Start the machine............................................... 6
7.2 Stop the machine............................................... 6
7.3 Empty the grass catcher.....................................6
7.4 Operate on slopes...............................................6
7.5 Operation tips.................................................... 7
8 Maintenance.......................................7
8.1 General maintenance......................................... 7
8.2 Replace the blade...............................................7
8.3 Store the machine.............................................. 7
9 Troubleshooting................................. 7
10 Technical data....................................8
11 Warranty............................................8
12 EC Declaration of conformity.......... 8
1
English EN

1 DESCRIPTION
1.1 PURPOSE
This machine is used for domestic lawn mowing. The cutting
blade must be approximately parallel to the ground. All four
wheels must touch the ground while you mow.
1.2 OVERVIEW
Figure 1-9.
1Switch box handle
2Start button
3Upper handle
4Lower handle
5Rear discharge door
6Battery door
7Grass catcher
8Screw
9Bolt
10 Grass catcher handle
11 Bracket
12 Spacer
13 Screw
14 Battery pack
15 Battery release button
16 Safety key
17 Blade
18 Spacer
19 Mounting nut
20 Height adjustment axle
21 Positioner
22 Handle knob
2 GENERAL SAFETY RULES
WARNING
Read carefully before use. Save this manual for future
reference.
2.1 TRAINING
• Read the instructions carefully.
Be familiar with the controls
and the correct use of the
machine.
• Never allow children, persons
with reduced physical, sensory
or mental capabilities or lack
of experience and knowledge
or people unfamiliar with these
instructions to use the
machine. Local regulations can
restrict the age of the operator.
• Keep in mind that the operator
or user is responsible for
accidents or hazards occurring
to other people or their
property.
2.2 PREPARATION
• While operating the machine
always wear substantial
footwear and long trousers. Do
not operate the machine when
barefoot or wearing open
sandals. Avoid wearing
clothing that is loose fitting or
that has hanging cords or ties.
• Thoroughly inspect the area
where the machine is to be
used and remove all objects
which can be thrown by the
machine.
• Before using, always visually
inspect to see that the blade,
blade bolt and the blade
assembly are not worn or
damaged. Replace worn or
damaged components in sets to
2
English
EN

preserve balance. Replace
damaged or unreadable labels.
2.3 OPERATION
• Use the machine only in
daylight or good artificial
light.
• Avoid operating the machine
in wet grass.
• Always be sure of your footing
on slopes.
• Walk, never run.
• Work across the face of slopes,
never up and down.
• Exercise extreme caution when
changing direction on slopes.
• Do not work excessively steep
slopes.
• Use extreme caution when
reversing or pulling the
machine towards you.
• Stop the blade(s) if the
machine has to be tilted for
transportation when crossing
surfaces other than grass, and
when transporting the machine
to and from the area to be
used.
• Never operate the machine
with damaged guards or
shields or without guards or
shields in place.
• Switch on the motor carefully
according to instructions and
with feet well away from the
blade(s).
• Do not tilt the machine when
switching on the motor, except
if the machine has to be tilted
for starting. In this case, do not
tilt it more than absolutely
necessary and lift only the
part, which is away from the
operator.
• Do not start the machine when
standing in front of the
discharge opening.
• Do not put hands or feet near
or under rotating parts. Keep
clear of the discharge opening
at all times.
• Do not transport the machine
while the power source is
running.
• Stop the machine, remove the
disabling device and battery
pack. Make sure that all
moving parts have come to a
complete stop
• whenever you leave the
machine;
3
English EN

• before clearing blockages or
unclogging chute;
• before checking, cleaning or
working on the machine;
• after striking a foreign
object. Inspect the machine
for damage and make repairs
before restarting and
operating the machine;
• if the machine starts to
vibrate abnormally (check
immediately);
• inspect for damage;
• replace or repair any
damaged parts;
• check for and tighten any
loose parts.
2.4 MAINTENANCE
• Keep all nuts, bolts and screws
tight to be sure the machine is
in safe working condition.
• Check the grass collector
frequently for wear or
deterioration.
• On machines with multi blade,
take care as rotating one blade
can cause other blades to
rotate.
• Be careful during adjustment
of the machine to prevent
entrapment of the fingers
between moving blades and
fixed parts of the machine.
• Always allow the machine to
cool down before storing.
• When servicing the blades be
aware that, even though the
power source is switched off,
the blades can still be moved.
• Replace worn or damaged
parts for safety. Use only
genuine replacement parts and
accessories.
3 SYMBOL
Some of the following symbols may be used on this product.
Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the
product better and safer.
Symbol Explanation
Read operator's manual.
Keep bystanders away.
Do not expose machine to rain or wet
conditions.
Beware of sharp blades. Blades con-
tinue to rotate after the motor is
switched off. Remove disabling de-
vice before maintenance.
Do not operate on inclines greater
than 15º. Mow across the face of
slopes, never up and down.
4
English
EN

Symbol Explanation
Beware of electric shock hazard.
Wait for all components of machine
to have completely stopped before
touching them.
4 RISK LEVELS
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
SYM-
BOL
SIGNAL MEANING
DANGER Indicates an imminently haz-
ardous situation,which, if not
avoided, will result in death
or serious injury.
WARNING Indicates a potentially hazard-
ous situation,which, if not
avoided, could result in death
or serious injury.
CAUTION Indicates a potentially hazard-
ous situation, which, if not
avoided, may result in minor
or moderate injury.
CAUTION (Without Safety Alert Sym-
bol) Indicates a situation that
may result in property dam-
age.
5 RECYCLE
Separate collection. You must not discard
with usual household waste. If it is necessa-
ry to replace the machine, or if it is no more
use to you, do not discard it with household
waste. Make this machine available for sepa-
rate collection.
Separate collection of used machine and
packaging let you recycle materials and use
them again. Use of the recycled materials
helps prevent environmental pollution and
decreases the requirements for raw materi-
als.
At the end of their useful life, discard batter-
ies with a precaution for our environment.
The battery contains material that is danger-
ous to you and the environment. You must
remove and discard these materials separate-
ly at a equipment that accepts lithium-ion
batteries.
6 INSTALLATION
WARNING
Do not change or make accessories that are not
recommended by the manufacturer.
WARNING
Do not put in the safety key or the battery pack until you
assemble all the parts.
6.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
• If the parts are damaged, do not use the machine.
•If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the service
center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with local
regulations.
6.2 INSTALL THE LOWER HANDLE
Figure 2
1. Insert the lower handle into the frame holes.
2. Put the bolts through the holes and tighten with a
screwdriver.
WARNING
Do not make damage to the cables when you install the
handle.
6.3 INSTALL THE UPPER HANDLE
Figure 3
1. Align the holes in the upper handle and the lower handle.
2. Put the bolts through the holes.
3. Tighten the knobs onto the bolts.
4. Do the same operation on the other side.
6.4 INSTALL THE GRASS CATCHER
Figure 4 & 5
1. Put the four screws into the washers to attach the bracket.
5
English EN

2. Move the bracket into the groove.
3. Align the latches and the slots of the top and lower halves
of the grass catcher and push the two halves together to
interlock.
4. Push the latch of the handle into the grass catcher.
5. Open the rear discharge door and hold it.
6. Hold the the grass catcher by its handle and put the hooks
over the slots.
7. Close the rear discharge door.
6.5 SET THE BLADE HEIGHT
The machine can be set to different blade heights.
WARNING
Remove the battery pack and safety key before turning over
the machine to adjust the cutting height.
Figure 6
1. Turn the machine over to access the front and rear cutting
height adjustment.
2. Push the axle forward to unlock the cutting height
adjustment.
3. Move the axle into one of the three positions. Make sure
that the two sides of the axle are in the same height.
4. Make sure that the four wheels are assembled in the same
cutting height and scroll smoothly and unclogged.
6.6 INSTALL THE BATTERY PACK
Figure 7
WARNING
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the engine stops before
you install or remove the battery pack.
• Read, know, and follow the instructions in the battery
and charger manual.
1. Open the battery door.
2. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
3. Push the battery pack into the battery compartment until
the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery door.
NOTE
The engine starts only when you put in the safety key.
6.7 REMOVE THE BATTERY PACK
Figure 7
1. Open the battery door.
2. Remove the safety key.
3. Push and hold the battery release button.
4. Remove the battery pack from the machine.
7 OPERATION
WARNING
Wear eye protection during operation.
7.1 START THE MACHINE
Figure 8
NOTE
Install the grass catcher before mowing.
1. Put in the safety key.
2. Push and hold the start button.
3. While you hold the start button, pull the switch box
handle in the direction of the handle bar.
4. Release the start button to start the machine.
7.2 STOP THE MACHINE
Figure 8
1. Release the switch box handle to stop the machine.
WARNING
Wait until the blade fully stops before you start the machine
again. Do not quickly turn the machine off and on.
WARNING
Always remove the safety key and battery pack after you
complete the work.
7.3 EMPTY THE GRASS CATCHER
1. Stop the machine.
2. Remove the safety key.
3. Remove the battery pack.
4. Open the rear discharge door and hold it.
5. Hold the grass catcher by its handle and unhook it from
the slots.
6. Close the rear discharge door.
7. Empty the grass catcher.
7.4 OPERATE ON SLOPES
WARNING
Do not mow on the slopes with incline more than 15°. If
you are not comfortable, do not mow on a slope.
6
English
EN

• Do not go up and down on a slope, mow across the face
of the slope. Be careful when you change the direction on
a slope.
•Monitor the holes, ruts, rocks, and other hidden objects
that can cause you to fall. Remove all obstacles such as
rocks and tree limbs.
• Make sure that your footing is stable. If you are out of
balance, release the switch box handle immediately.
• Do not mow near drop-offs, ditches, or embankments.
7.5 OPERATION TIPS
• Do not try to override the operation of the start button or
switch box handle.
•Do not tilt the machine when you start it.
• Do not put hands or feet near or below the turning parts.
• Keep the discharge chute clean.
• Do not cut wet grass.
• Higher blade height is necessary for new or thick grass.
• Clean the bottom of the mower deck after each use.
Remove grass clippings, leaves, dirt, and other debris.
8 MAINTENANCE
WARNING
Remove the safety key and battery pack from the machine
before maintenance.
WARNING
Keep the motor and battery pack free from grass, leaves or
too much grease.
CAUTION
Use only approved replacement parts.
CAUTION
Do not let brake fluids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can cause damage to the
plastic, and make the plastic unserviceable.
CAUTION
Do not use strong solvents or detergents on the plastic
housing or components.
NOTE
Recommended tightening torque (blade): 33-37 Nm.
8.1 GENERAL MAINTENANCE
• Before each use, examine the machine for damaged,
missing, or loose parts such as screws, nuts, bolts and
caps.
•Tighten correctly all the fasteners and caps.
• Clean the machine with a dry cloth. Do not use water.
8.2 REPLACE THE BLADE
Figure 9.
WARNING
Use only approved replacement blades.
WARNING
Wear heavy gloves or wind cloth around the blade when
you touch the blade.
1. Stop the machine.
2. Make sure that the blade fully stops.
3. Remove the safety key and battery pack.
4. Turn the machine to its side.
5. Use a piece of wood to prevent the movement of the
blade.
6. Remove the mounting nut and spacer with a wrench or
socket.
7. Remove the blade.
8. Install the new blade. Make sure that the raised points
engage the hole(s) in the blade.
9. Put in the mounting nut and spacer and tighten them.
8.3 STORE THE MACHINE
• Clean the machine before storage.
•Make sure that the motor is not hot when you store the
machine.
• Make sure that the machine does not have loose or
damaged parts. If it is necessary, do these steps/
instructions:
• Replace the damaged parts.
• Tighten the bolts.
• Speak to a person of an approved service center.
• Store the machine in a dry area.
• Make sure that children cannot come near the machine.
9 TROUBLESHOOTING
Problem Possible cause Solution
The handle is not
in position.
The bolts are not
engaged correctly.
Adjust the height
of the handle and
make sure that the
knobs and bolts
are aligned cor-
rectly.
7
English EN

Problem Possible cause Solution
The machine does
not start.
The battery ca-
pacity is low.
Charge the battery
pack.
The handle switch
is defective.
Replace the handle
switch.
The battery key is
not put in.
Put in the battery
key.
The machine cuts
grass unevenly.
The lawn is rough. Examine the mow-
ing area.
The blade height is
not set correctly.
Move the wheels
to a higher posi-
tion.
The machine is
hard to push.
The grass is too
tall, or the blade
height is too low.
Increase the blade
height.
The grass catcher
and the blade
drags in thick
grass.
Empty the grass
clippings from the
grass catcher.
There is a high vi-
bration in the ma-
chine.
The blade is un-
balanced and
worn.
Replace the blade.
The engine shaft is
bent.
1. Stop the en-
gine.
2. Remove the
safety key and
battery pack.
3. Disconnect the
power source.
4. Inspect for
damage.
5. Repair the ma-
chine before
you start it
again.
The machine stops
during mowing.
The blade height is
too low.
Increase the blade
height.
The battery pack is
out of power.
Charge the battery
pack.
The grass clip-
pings attach to the
deck or the blade.
Remove the bat-
tery pack and
check the deck.
Operation temper-
ature of the ma-
chine is too high.
Cool the machine.
* If you cannot find the solution to these problems, go to the
service center.
10 TECHNICAL DATA
Voltage 24 V
No load speed 4200 / min
Cut width 330 mm
Cut height 20 - 60 mm
Grass catcher capacity 30 L
Weight (without battery
pack)
7.9 Kg
Measured sound pressure
level
LPA = 78 dB(A) , K = 3
dB(A)
Guaranteed sound power lev-
el
LWA.d = 92 dB(A)
Vibration ＜2.5 m/s2 , K = 1,5 m/s2
Battery model G24B2 / G24B4 and other
BAG series
Charger model 29817 / 29827 / 2913907/
2903507/ 2904407 and other
CAG series
11 WARRANTY
(The full warranty terms and conditions can be found on
Greenworks webpage)
The Greenworks warranty is 3 years on the product, and 2
years on batteries (consumer/private usage) from the date of
purchase. This warranty covers manufacturing faults. A faulty
product under warranty might be either repaired or replaced.
A unit that has been misused or used in other ways then
described in the owner’s manual might be rejected for
warranty. Normal wear, and wear parts are not considered as
warranty. The original manufacturer warranty is not affected
by any additional warranty offered by a dealer or retailer.
A faulty product must be returned to the point of purchase in
order to claim for warranty, together with the proof of
purchase (receipt).
12 EC DECLARATION OF
CONFORMITY
Name and address of the manufacturer:
Name: GLOBGRO AB
Globe Group Europe
Address: Propellergatan 1, 211 15 Malmö, Sweden
Name and address of the person authorised to compile the
technical file:
Name: Peter Söderström
Address: Propellergatan 1, 211 15 Malmö, Sweden
8
English
EN

Herewith we declare that the product
Category: Lawn Mower
Model: G24LM33
Serial number: See product rating label
Year of Construction: See product rating label
• is in conformity with the relevant provisions of the
Machinery Directive 2006/42/EC.
•is in conformity with the provisions of the following
other EC-Directives:
• 2014/30/EU
• 2000/14/EC & 2005/88/EC
• 2011/65/EU & (EU)2015/863
Furthermore, we declare that the following parts, clauses of
harmonised standards have been used:
• EN 60335-1, EN 60335-2-77, EN 62233, EN ISO 3744,
EN 55014-1, EN 55014-2, ISO 11094, IEC 62321-3-1,
IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC
62321-7-1, IEC 62321-7-2. IEC 62321-8
Conformity assessment method to Annex VI Directive
2000/14/EC.
Measured sound power level LWA: 90.4 dB(A)
Guaranteed sound power level LWA.d : 92 dB(A)
Place, date: Malmö,
20.05.2019
Signature: Ted Qu, Quality Director
9
English EN
