GreenWorks 2200102 User manual

Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757)
22" 4.0A ELECTRIC HEDGE TRIMMER
2200102

2 3
Contents .............................................................................................................................. 2
Specications ...................................................................................................................... 2
Important Safety Instructions............................................................................................3-4
Specic Safety Rules........................................................................................................... 5
Symbols ............................................................................................................................6-7
Electrical...........................................................................................................................8-9
Know your hedge trimmer .................................................................................................. 10
Assembly ............................................................................................................................11
Operation.......................................................................................................................12-14
Maintenance ................................................................................................................. 15-16
Troubleshooting ................................................................................................................. 17
Warranty ............................................................................................................................ 18
Exploded View ................................................................................................................... 19
Parts List............................................................................................................................ 20
SPECIFICATIONS
22" 4.0A ELECTRIC HEDGE TRIMMER
Motor ...........................................................................................120 V AC, 60 Hz, 4.0 A
Reciprocating Speed ........................................................................................ 3,200 SPM
Blade Length ..............................................................................................22in. (55.9 cm)
Unit Weight ............................................................................................... 5.72 Ibs (2.6Kg)
Cutting Capacity..........................................................................................9/16in. (14mm)
CONTENTS IMPORTANT SAFETY INSTRUCTIONS
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions
may result in electric shock, re, and/or serious injurys.
Save all warnings and instructions for future reference.
The term “power tool” in all of the warnings listed below refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1. Work area safety
A. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
B. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
C. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
A. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
B. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
C. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
D. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
E. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
F. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
A. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
B. Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
C. Avoid accidental starting. Ensure the switch is in the off-position before plugging in. Carrying
power tools with your nger on the switch or plugging in power tools that have the switch on invites
accidents.

4 5
IMPORTANT SAFETY INSTRUCTIONS SPECIFIC SAFETY RULES
SAVE THESE INSTRUCTIONS
D. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
E. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
F. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
G. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust-related hazards.
4. Power tool use and care
A. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
B. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
C. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
D. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
E. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tools operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
F. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
G. Use the power tool, accessories and tool bits etc., in accordance with these instructions and in
the manner intended for the particular type of power tool, taking into account the working conditions
and the work to be performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
5. Service
A. Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
HEDGE TRIMMER SAFETY WARNINGS
• Use both hands when operating the hedge trimmer. Using one hand could cause loss of
control and result in serious personal injury.
• Keep all parts of the body away from the cutter blade. Do not remove cut material or hold
material to be cut when blades are moving. Make sure the switch is off when clearing jammed
material. Blades coast after turn off. A moment of inattention while operating the hedge
trimmer may result in serious personal injury.
• Carry the hedge trimmer by the handle with the cutter blade stopped. When transporting or
storing the hedge trimmer always t the cutting device cover. Proper handling of the hedge
trimmer will reduce possible personal injury from the cutter blades.
• Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact
hidden wiring or its own cord. Cutter blades contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an electric shock.
• Keep cable away from cutting area. During operation the cable may be hidden in shrubs and
can be accidentally cut by the blade.
• DANGER – Keep hands away from blade. Contact with blade will result in serious personal
injury.
W A R N I N G (PROPOSITION 65)
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of
work. To reduce your exposure to these chemicals, work in a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.

6 7
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
Class II Construction Double-insulated construction
Wet Conditions Alert Do not expose to rain or use in damp locations
Read The Operator’s Manual To reduce the risk of injury user must read and
understand operator’s manual before using this
product.
Safety Alert Precautions that involve your safety.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Eye Protection Always wear safety goggles or safety glasses
with side shields and, as necessary, a full face
shield when operating this product.
Ricochet Thrown objects can ricochet and result in
personal injury or property damage.
Sharp Blade Do not install or use any type of blade on a
product displaying this symbol.
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper inter-pretation of these symbols will allow you to operate the product better and safer.
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualied
service technician. For service we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTER for repair. When servicing, use only identical replacement parts.
WARNING
To avoid serious personal injury, do not attempt to use this product until you read thoroughly
and understand completely the operator’s manual. If you do not understand the warnings and
instructions in the operator’s manual, do not use this product. Call GREENWORKS customer
service for assistance.
WARNING
The operation of any power tool can result in foreign objects being thrown into your
eyes, which can result in severe eye damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with side shields and, when needed, a
full face shield. We recommend Wide Vision Safety Mask for use over eyeglasses or
standard safety glasses with side shields. Always use eye protection which is marked to
comply with ANSI Z87.1.
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SYMBOLS

98
ELECTRICAL
CAUTION
ALWAYS MAKE SURE THAT YOUR OUTLET IS PROPERLY GROUNDED. IF UNCERTAIN,
HAVE IT CHECKED BY A CERTIFIED ELECTRICIAN.
WARNING
THIS HEDGE TRIMMER IS FOR OUTDOOR USE ONLY. DO NOT EXPOSE TO RAIN OR USE
IN DAMP LOCATIONS.
GUIDELINES FOR USING EXTENSION CORDS
USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one of heavy enough gauge to carry the current
your product will draw. An undersized cord will cause overheating. The table below shows the
correct size to use depending on cord length and nameplate ampere rating. If in doubt, use
the next heavier gauge.The smaller the gauge number, the heavier the cord. Make sure your
extension cord is properly wired and in good electrical condition. Always replace a damaged
extension cord or have it repaired by a qualied person before using it. Keep your extension
cords away from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This circuit should not be less than #12 wire and
should be protected with a 15A time delayed fuse. Before connecting the motor to the power
line, make sure the switch is in the OFF position and the electric current is rated the same as the
current stamped on the motor nameplate. Running at a lower voltage will damage the motor.
WARNING
ALTHOUGH THIS TOOL IS DOUBLE INSULATED, THE EXTENSION CORD AND RECEPTACLE
MUST STILL BE GROUNDED WHILE IN USE TO PROTECT THE OPERATOR FROM
ELECTRICAL SHOCK.
ELECTRICAL
MINIMUM GAUGE FOR EXTENSION CORDS (AWG)
(WHEN USING 120 V ONLY)
Amp Rating Total Length of Cord in Feet (meters)
More Than Not More Than 25' (7.6 m) 50' (15 m) 100' (30.4 m) 150' (45.7 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
GROUNDING INSTRUCTIONS
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least
resistance for electric current and reduces the risk of electric shock. This tool is equipped with
an electric cord that has a POLARIZED plug.The power cord MUST be plugged into a matching
outlet that is properly installed and grounded in accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not t the outlet, have the proper outlet
installed by a qualied electrician.
WARNING
USE ONLY IDENTICAL REPLACEMENT PARTS WHEN SERVICING THE HEDGE TRIMMER,
TO AVOID INJURY.
WARNING
DOUBLE INSULATION DOES NOT TAKE THE PLACE OF NORMAL SAFETY PRECAUTIONS
WHEN OPERATING THIS TOOL.
WARNING
TO AVOID ELECTRIC SHOCK:
• Use only identical replacement parts when servicing a tool with double insulation.
Servicing should be performed by a qualied technician.
• Do not use in wet or damp areas or expose to rain.
WARNING
TO AVOID ELECTRICAL HAZARDS, FIRE HAZARDS, OR DAMAGE TO THE TOOL, USE
PROPER CIRCUIT PROTECTION. YOUR HEDGE TRIMMER IS WIRED AT THE FACTORY
FOR 120V OPERATION. CONNECT TO A 120V, 15A CIRCUIT AND USE A 15A TIME-
DELAYED FUSE OR CIRCUIT BREAKER. TO AVOID SHOCK OR FIRE IF THE POWER CORD
IS WORN, CUT OR DAMAGED IN ANY WAY, REPLACE IT IMMEDIATELY.
DOUBLE INSULATED (See Figure 1.)
This hedge trimmer has a plug that looks like the one shown in Fig. 1. The hedge trimmer is
double insulated to provide a double thickness of insulation between you and the tool’s electrical
system. All exposed metal parts are isolated from the internal metal motor components with
protective insulation.
1) 2-prong plug
2) Properly grounded
extension cord
12Fig. 1

10 11
KNOW YOUR HEDGE TRIMMER
The safe use of this product requires an understanding of the information on the product and in
this operator’s manual as well as a knowledge of the project you are attempting. Before use of
this product, familiarize yourself with all operating features and safety rules. (See Figure 2.)
CORD RETAINER
A convenient cord retainer helps keep the extension cord connection secure during trimmer
operation.
GUARD
The guard helps to deect chips or other debris away from the operator’s hands.
TRIGGER SWITCH AND LOCK OFF BUTTON
The trigger switch, located beneath the rear handle, and the lock-off button, located behind the
front handle, must be depressed simultaneously to allow blade rotation. Lock-off switch may be
released once hedge trimmer is running.
Blade
Blade support rod
Guard
Auxiliary handle Lock off button
Trigger switch
Cord retainer
UNPACKING
• This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the packing list are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.
• If any parts are damaged or missing, please call 1-888- 909-6757 for assistance.
PACKING LIST
• Electric hedge trimmer
• Operator’s manual
WARNING
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Failure to heed this warning could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
A SS EM B LY
Fig. 2

12 13
OPERATION
WARNING
Do not allow familiarity with this product to make you careless. Remember that a careless
fraction of a second is sufcient to inict serious injury.
WARNING
Always wear safety goggles or safety glasses with side shields when operating power tools.
Failure to do so could result in objects being thrown into your eyes, resulting in possible serious
injury.
WARNING
Do not use any attachments or accessories not recommended by the manufacturer of this
product. The use of attachments or accessories not recommended can result in serious personal
injury.
CONNECTING TO POWER SUPPLY
This product is designed with a cord retainer that prevents the extension cord from being pulled
loose while using.
• Form a loop with the end of the extension cord.
• Insert loop portion of extension cord through opening in the bottom of the rear handle and place
over cord retainer.
• Slowly pull loop against cord retainer until the slack is removed. (Fig.3)
• Plug product into extension cord.
NOTE: Failure to remove all excess cord slack from extension cord retainer could result in plug loosening from
receptacle.
OPERATION
STARTING THE HEDGE TRIMMER (See Figure 3.)
1. Attach an extension cord to your hedger.
2. Place one hand on the trigger handle (1). Place the other hand on the auxiliary handle (2).
3. Slide the lock switch (4) backwards you then squeeze the trigger switch (3) to turn ON the
hedge trimmer. The trimmer will stay on as long as the trigger switch is squeezed. Lock-off
switch may be released once hedge trimmer is running.
STOPPING THE HEDGE TRIMMER
1. Release the trigger switch (3).
2. Allow at least 5 seconds for the cutting blade to stop moving.
CUTTING TIPS
WARNING
Always keep both hands on the hedge trimmer handles. Never hold shrubs with one hand and
operate hedge trimmer with the other. Failure to heed this warning can result in serious injury.
WARNING
Clear the area to be cut before each use. Remove all objects such as cords, lights, wire, or loose
string which can become entangled in the cutting blade and create a risk of serious personal
injury.
• When operating the hedge trimmer, keep the extension cord behind the trimmer. Never drape it
over the hedge being trimmed.
• Do not force the hedge trimmer through heavy shrubbery. This can cause the blades to bind
and slow down. If the blades slow down, reduce the pace.
• Do not attempt to cut stems or twigs that are larger than 3/8 in., or those obviously too large to
feed into the cutting blade. Use a non-powered hand saw or pruning saw to trim large stems.
• If blades do become jammed, stop the motor, allow the blades to stop, and disconnect the plug
from the power source before attempting to remove the obstruction.
• If desired, you can use a string to help cut your hedge level. Decide how high you want the
hedge. Stretch a piece of string along the hedge at the desired height. Trim the hedge just
above the guide line of string. Trim the side of a hedge so that it will be slightly narrower at the
top. More of the hedge will be exposed when shaped this way, and it will be more uniform.
• Wear gloves when trimming thorny or prickly growth. When trimming new growth, use a wide
sweeping action, so that the stems are fed directly into the cutting blade. Older growth will have
thicker stems and will be trimmed easiest by using a sawing movement.
1
4
3
2
Cord retainer Extension cord
Fig.3

14 15
OPERATION
OPERATING THE HEDGE TRIMMER
WARNING
Read the safety information for safe operation using the blade. Extreme care must be taken
when using blades to ensure safe operation. Refer to Important Safety Instructions and Specic
Safety Rules (See pages 3 - 5)
The unit is used for cutting in either direction in a slow, sweeping action from side to side.
• Stand so that you are stable and balanced on both feet. Do not overreach.
• Inspect and clear the area of any hidden objects.
• Never use the hedge trimmer near power lines, fencing, posts, buildings, or other immovable
objects.
• Never use a blade after hitting a hard object without rst inspecting it for damage. Do not use if
any damage is detected.
• Never touch blades or service unit with the power supply connected.
MAINTENANCE
WARNING
WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS. USE OF ANY OTHER
PARTS MAY CREATE A HAZARD OR CAUSE PRODUCT DAMAGE.
WARNING
ALWAYS WEAR SAFETY GOGGLES OR SAFETY GLASSES WITH SIDE SHIELDS DURING
PRODUCT OPERATION. IF OPERATION IS DUSTY, ALSO WEAR A DUST MASK.
WARNING
BEFORE INSPECTING, CLEANING, OR SERVICING THE MACHINE, DISCONNECT THE
PLUG FROM POWER SOURCE AND WAIT FOR ALL MOVING PARTS TO STOP. FAILURE
TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SERIOUS PERSONAL INJURY OR
PROPERTY DAMAGE.
WARNING
DO NOT AT ANY TIME LET BRAKE FLUIDS, GASOLINE, PETROLEUM-BASED PRODUCTS,
PENETRATING OILS, ETC., COME IN CONTACT WITH PLASTIC PARTS. CHEMICALS CAN
DAMAGE, WEAKEN, OR DESTROY PLASTIC WHICH MAY RESULT IN SERIOUS PERSONAL
INJURY. ONLY THE PARTS SHOWN ON THE PARTS LIST ARE INTENDED TO BE REPAIRED
OR REPLACED BY THE CUSTOMER. ALL OTHER PARTS SHOULD BE REPLACED AT AN
AUTHORIZED SERVICE CENTER.
WARNING
BLADES ARE SHARP. WHEN HANDLING THE BLADE ASSEMBLY, WEAR NON-SLIP, HEAVY-
DUTY PROTECTIVE GLOVES. DO NOT PLACE YOUR HAND OR FINGERS BETWEEN
BLADES OR IN ANY POSITION WHERE THEY COULD GET PINCHED OR CUT. NEVER
TOUCH BLADES OR SERVICE UNIT WITH THE POWER SUPPLY CONNECTED.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.

16 17
MAINTENANCE
CLEANING THE HEDGE TRIMMER
• Stop the motor and disconnect from power supply.
• Clean dirt and debris from the body of the hedge trimmer, using a damp cloth with a mild
detergent.
NOTE: Do not use any strong detergents on the plastic housing or the handle. They can be damaged by
certain aromatic oils such as pine and lemon, and by solvents such as kerosene.
STORING THE TRIMMER
• Clean all foreign material from the product.
• Store it in a well-ventilated place that is inaccessible to children.
• Keep away from corrosive agents such as garden chemicals and de-icing salts.
TROUBLESHOOTING
Unit will not start.
Motor runs, but cutting
blades do not move.
Hedge trimmer smokes
during operation.
1. Cord not plugged in.
2. Cord or switch is dam-
aged.
Hedge trimmer damaged.
Do not use hedge trimmer.
Hedge trimmer damaged.
Do not use hedge trimmer.
1. Plug in cord.
2. Have cord or switch
replaced.
Call for technical service.
Call for technical service.
PROBLEM POSSIBLE CAUSE SOLUTION

18 19
GREENWORKS™ hereby warranties this product, to the original purchaser with proof of
purchase, for a period of four (4) years against defects in materials, parts or workmanship.
GREENWORKS™, at its own discretion will repair or replace any and all parts found to be
defective, through normal use, free of charge to the customer. This warranty is valid only for
units which have been used for personal use that have not been hired or rented for industrial/
commercial use, and that have been maintained in accordance with the instructions in the
owners’ manual supplied with the product from new.
Battery carries a one (1) year warranty against defects in workmanship and materials. Batteries
must be charged in accordance with the operator’s manuals directions and regulations in order
to be valid.
ITEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to misuse, commercial use, abuse, neglect,
accident, improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or maintained in accordance with the owner's
manual; or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, blade sharpening;
5. Normal deterioration of the exterior nish due to use or exposure.
GREENWORKS HELPLINE (1 888 90WORKS):
Warranty service is available by calling our toll-free helpline, 9am to 5pm EST. Monday – Friday
at 1-888-909-6757 (1-888-90WORKS).
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power equipment unit or attachment are the
responsibility of the purchaser. It is the purchaser’s responsibility to pay transportation charges
for any part submitted for replacement under this warranty unless such return is requested in
writing by GREENWORKS.
LIMITED FOUR-YEAR WARRANTY EXPLODED VIEW

20
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 31301443-2 Housing assy 1
2 34101443 Silver cap 1
3 3220735 Screw 2
4 3220186 Screw 2
5 3290706 Spring washer 2
6 3290186 Flat washer 2
7 31302162-4 Auxiliary handle 1
8 3410711-3 Guard 1
9 3220187 Screw 2
10 3220313 Screw 10
11 36101443B Motor and blade assembly 1
12 34102443-2 Self-lock outo 1
13 33402161 Switch spring 1
14 3630129 Switch 1
15 3411386-5 Switch board 1
16 31901443 Inner plug 1
17 36504161 Wire connecter 1
Printed in China on 100% Recycled PaperRev: 00 (01-07-14)
TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757)
