Grill-Max Express X30 User manual

¨
GRILL-MAX EXPRESS
¨
GRILL-MAX EXPRESS
ROLLER GRILLS
X30, X45, X50, X75
Innite Controls
BUN WARMERS
XBW-30, XBW-50
Installation and
Operation
Instructions
2M-Z13702 Rev. C 10/17/2014
is a registerd trademark of Star International Holdings Company Inc, All rights reserved.
IL2072

2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it ready when
you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
[email protected]
W[email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

TABLE OF CONTENTS
PAGE NUMBER
GENERAL SAFTEY INFORMATION 3
GENERAL INSTALLATION INFORMATION 4
 ConnectionLoad&Sepecications 4
GENERAL OPERATING INSTRUCTIONS 5
Cleaning 5
ROLLERGRILL EXPLODED VIEW 6
PARTS LIST
30 MODEL SERIES 7
45 MODEL SERIES 8
50 MODEL SERIES 9
75 MODEL SERIES 10
WIRING DIAGRAM 11
BUN WARMER EXPLODED VIEW 12
PARTS LIST
XBW-30 & XBW-50 MODEL 13
WARRANTY 14
GENERAL SAFETY INFORMATION
Thisequipmentisdesignedandsoldforcommercialuseonlybypersonneltrainedandexperiencedin
itsoperationandisnotsoldforconsumeruseinandaroundthehomenorforusedirectlybythegeneral
publicinfoodservicelocations.
Beforeusingyournewequipment,readandunderstandalltheinstructions&labelsassociatedwiththe
unitpriortoputtingitintooperation.Makesureallpeopleassociatedwithitsuseunderstandtheunits
operation&safetybeforetheyusetheunit.
Allshippingcontainersshouldbecheckedforfreightdamagebothvisibleandconcealed.Thisunithas
beentestedandcarefullypackagedtoinsuredeliveryofyourunitinperfectcondition.Ifequipmentis
receivedindamagedcondition,eitherapparentorconcealed,aclaimmustbemadewiththedelivering
carrier.
Concealeddamageorloss-ifdamageorlossisnotapparentuntilafterequipmentisunpacked,a
requestforinspectionofconcealeddamagemustbemadewithcarrierwithin15days.Becertainto
retainallcontentsplusexternalandinternalpackagingmaterialsforinspection.Thecarrierwillmake
aninspectionandwillsupplynecessaryclaimforms.
3
CAUTION

GENERAL INSTALLATION INFORMATION
Thegrillshouldbeconnectedtoawalltypereceptacle,adirectlineorindividualbranchcircuit.
Anindividualbranchcircuitispreferred.Ifconnectedtoanoverloadedcircuitthegrillwillnot
operateproperly.Theunitshouldbelevelwheninstalled.Adjustable1-inchlegsarestandard
onallmodels.
BunWarmersmustbelevelforselfclosingfeature.
Thisgrillisequippedforthevoltageshownonthenameplate.
Itwilloperateonalternatingcurrentonly,however,thespeciedvoltagemustbeapplied.
CONNECTION LOAD:
DO NOT CONNECT TO DIRECT CURRENT (DC).
IMPORTANT
UNLEVEL UNITS COULD RESULT IN HAVING PRODUCT TRAVEL FROM
ONE SIDE TO THE NEXT, OVER A PERIOD OF TIME.
4
WARNING
Nameplate
H
DW
IL2071
Value Roller Grill
Model No (W) Width (D) Depth (H) Height Voltage Wattage Amps Plug
X30 23-3/4” 20-5/8”
10” 120
1150 9.6
5-15PX45 28-1/2” 1650 13.8
X50
35-3/4”
20-5/8” 1535 12.8
X75 28-1/2” 1730 14.4 5-20P
240 2400 10 6-15P
Value Bun Box
XBW30 23-3/4”
20-5/8” 6-1/4”
120 35 0.3 5-15P
230 50 0.22 CEE-7/VII
XBW50 35-3/4” 120 50 0.4 5-15P
230 70 0.3 CEE-7/VII

GENERAL OPERATING PROCEDURES
Themainswitchlocatedonthecontrolpanelcontrolsallthepowertotheunit.Withthemainswitchon,the
rollerswillturn,butnoheatwillbesuppliedunlesstheheatcontrolsareturnedon.Forexibilitytheheating
sectionofthegrillisdividedintotwoindividuallycontrolledheatsections.Therightcontrolregulatestheheatto
therearsection(greyrollerseals)andtheleftcontrolregulatestheheattothefrontsection(blackrollerseals).
Theswitchislightedtoindicatewhentheunitisturnedon.Asignallightisprovidedforeachheatcontroland
indicateswhentheheatedsectionison.
COOKING
Theheatcontrolsprovideaninniterangeofsettingsforawidevarietyoffoodproductsandinstallation
conditions.Thesize,contentandshapeoftheproductandtheinstallationofanysanitaryfoodshields
orsneezeguardswilldeterminetheproperheatsetting.TheNationalSanitationFoundationrequires
thatperishablefoodsbekeptat140°Foraboveduringservingperiods.Donotkeepthefoodproduct
onalowsettingformorethantwohours.Theproductshouldbekeptrefrigerateduntilreadyforuse.
Cookingtimewillvarydependingonthestartingtemperatureandthequalitiesoftheproduct.Forbest
resultswhencookinghotdogsuseahotdogmadeforgrilling.
USE ONLY PLASTIC OR COATED UTENSILS FOR HANDLING THE FOOD
PRODUCT. METAL COULD SCRATCH THE ROLLER COATING AND AFFECT
THE CLEAN ABILITY OF THE ROLLERS.
DO NOT USE STEEL WOOL OR ABRASIVE CLEANERS ON THE ROLLERS.
SCRAPES WILL VOID THE WARRANTY. USE CAUTION WHEN CLEANING
A HOT GRILL TO PREVENT BURNS OR BODILY INJURY.
CLEANING
Beforecookingforthersttime,washtherollerswithmildsoapandwaterusingasoftcloth.Donot
use metal utensils when cooking. Scratches and scrapes will hamper the ability to easily clean the
rollers.Neverusesteelwoolorabrasivecleanersontherollers.Thiswilldamagethenishandthe
rollerbearings.Therollerscleanmosteasilywhenhot.Usecautionwhencleaningtopreventburns
andbodilyinjury.Cleantherollerswithacleanwetcloth.Wipefromtheendstothecentertoprevent
forcingdebrisintotherollerseals.Donotallowthefoodproducttobuildupandbakeontotheroller
surface.Theexterioroftheunitshouldbecleanedusingamilddetergentornon-abrasivecleaner.Clean
theentireunitdailytoinsurelonglifeandsatisfactoryperformanceaswellastomaintainanattractive
appearance.Donotcleanwithwaterjetequipment.
MAINTENANCE AND REPAIRS
Contactthefactory,aservicerepresentativeoralocalservicecompanyforserviceorrequiredmaintenance.
ReplacementcordsetsmustbepurchasedfromStarInternationalHoldingsInc.,Company.
5
CAUTION
CAUTION

¨
GRILL-MAX EXPRESS
VALUE ROLLER GRILL: MODEL X30, X45, X50, X75
SK2473 REV. B 7/20/2011
1
2
3
9
56
8
11
10
12
30
16
17
18
21
22
23
24
25
26
29
27
28
13
19
15
20
14
7
4
Nameplate

PARTS LIST October17,2014,Rev.C
VALUE ROLLER GRILL MODEL X30, X30S, X30SG, X30F, X30SF, X30SGF
FigNo. PartNumber Description Quantity Applications
1A5-Z2185 DRIP TRAY 30 1
2
A5-RG3001 ROLLER ASSY CHROME
11
X30, X30F
PS-RG3078 ROLLER ASSY POLY WELDED X30S, X30SF
A5-RG4565 ROLLER ASY HIGRIP 30S/45S X30SG, X30SGF
32N-Z2178 ELEMENT 120V 30/45 11
2N-Z2194 ELEMENT 230V 30/45 11 230V ONLY
42A-Z8017 BUSHING IDLER 4
52P-Z8392 IDLER SPROCKET ASSEMBLY 4
62C-1810 WASHER 3/16 BURR STL NP 10
7A5-Z13684 CHAIN GUIDE-11 COUNT 1
82C-Z0498 NUT 10-24 NYLK HEX STL ZP 4
92C-6349 SCREW #8X3/8 B THP STL NP 27
10 2I-Z13659 INNER SEAL-BLACK 12 FRONT ROLLERS
2I-Z13660 INNER SEAL-LIGHT GRAY 10 BACK ROLLERS
11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 22
12 A5-RG30153 ASY,CHN TENSIONER W/SPKT 1
13 2P-Z8074 EXTENSION SPRING 1
14 2P-Z13743 #25 ROLLER CHAIN,188TEETH 1X30, X30S, X30SG
2P-Z13744 #25 ROLLER CHAIN,184TEETH X30F, X30SF, X30SFG
15 A5-Z13666 COVER,END PANEL,SLT,11CT 2X30, X30S, X30SG
A5-Z13669 COVER-END PANEL-FLAT-11CT X30F, X30SF, X30SFG
16 2P-Z11853 MOTOR SPROCKET 1
17 2C-1506 SCREW 10-32X1/2 RHP STL 4
2C-200121 WASHER #10 SPLIT SS 4
18 2U-Z11854 MOTOR GEAR, 120V 1
2U-Z11855 MOTOR GEAR, 230V 230V / 60HZ
19 2K-Y3240 BUSHING HEYCO SR 17-2 1
20 A5-Z13677 COVER,BODY PANEL, X30 1
21 2K-Y8571 BUSHING SNAP 2 1/8 2
22 2A-Z11501 FOOT 1” SOLID RUBBER 4
23 2J-Z14323 INFINITE CTL, 120V 2
2J-Z14324 INFINITE CONTROL, 230V 230V ONLY
25 2M-Z13657 OVERLAY, MODEL X30, X45 1
26 2E-Z1858 SWITCH-LIGHTED 1
27 2R-Z1854 KNOB-CONTROL 2
28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2
2J-Z13655 PILOT LIGHT RECT-RED-230V 230V ONLY
29 A5-Z13685 ELEMENT RETAINER,LWR-11CT 1
30 2C-Z14533 WASHER, SHOULDER IDLER ARM 2
NI 2P-Z0584 TONGS-PLASTIC 9” 1
NI D5-HWP006 CORD ASSEMBLY 14-3 120V 1
2E-Z0512 CORD SET, CONT, EUR 10A 230V ONLY
NI A5-RG2006 WIRE ASSEMBLY #5 1

PARTS LIST October17,2014,Rev.C
VALUE ROLLER GRILL MODEL X45, X45S, X45SG, X45F, X45SF, X45SGF
FigNo. PartNumber Description Quantity Applications
1A5-Z2186 DRIP TRAY 45 1 X45
2
A5-RG3001 ROLLER ASSY CHROME
16
X45
PS-RG3078 ROLLER ASSY POLY WELDED X45S
A5-RG4565 ROLLER ASY HIGRIP 30S/45S X45SG
32N-Z2178 ELEMENT 120V 30/45 16
2N-Z2194 ELEMENT 230V 30/45 230V ONLY
42A-Z8017 BUSHING IDLER 4
52P-Z8392 IDLER SPROCKET ASSEMBLY 4
62C-1810 WASHER 3/16 BURR STL NP 10
7A5-Z13686 CHAIN GUIDE-16 COUNT 1 X45
82C-Z0498 NUT 10-24 NYLK HEX STL ZP 4
92C-6349 SCREW #8X3/8 B THP STL NP 36
10 2I-Z13659 INNER SEAL-BLACK 16 FRONT ROLLERS
2I-Z13660 INNER SEAL-LIGHT GRAY BACK ROLLERS
11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 32
12 A5-RG4594 ASY,CHN TENSIONER W/SPKT 1X45, X45S, X45SG
A5-RG4596 ASY,CHN TNSR -X45F, X75F X45F, X45SF, X45SGF
13 2P-Z8074 EXTENSION SPRING 1
14 2P-Z13745 #25 ROLLER CHAIN,246TEETH 1
15 A5-Z13672 COVER,END PANEL,SLT,16CT 2X45, X45S, X45SG
A5-Z13675 COVER,END PANEL,FLAT, 16CT X45F, X45SF, X45SGF
16 2P-Z11853 MOTOR SPROCKET 1
17 2C-1506 SCREW 10-32X1/2 RHP STL 4
2C-200121 WASHER #10 SPLIT SS
18
2U-Z11854 MOTOR GEAR, 120V
12U-Z11855 MOTOR GEAR, 230V 230V / 60HZ
A5-Z14583 MOTOR, 240V, 50HZ 230V / 50HZ
19 2K-Y3240 BUSHING HEYCO SR 17-2 1
20 A5-Z13679 COVER,BODY PANEL, X45 1 X45
21 2K-Y8571 BUSHING SNAP 2 1/8 2
22 2A-Z11501 FOOT 1” SOLID RUBBER 4
23 2J-Z14323 INFINITE CTL, 120V 2
2J-Z14324 INFINITE CONTROL, 230V 230V ONLY
25 2M-Z13657 OVERLAY, MODEL X30, X45 1
26 2E-Z1858 SWITCH-LIGHTED 1
27 2R-Z1854 KNOB-CONTROL 2
28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2
2J-Z13655 PILOT LIGHT RECT-RED-230V 230V ONLY
29 A5-Z13687 ELEMENT RETAINER,LWR-16CT 1 X45
30 2C-Z14533 WASHER, SHOULDER IDLER ARM 2
NI 2P-Z0584 TONGS-PLASTIC 9” 1
NI D5-HWP006 CORD ASSEMBLY 14-3 120V 1
2E-Z0512 CORD SET, CONT. EUR 10A 230V ONLY
NI A5-RG4512 WIRE ASSY LONG 2

PARTS LIST October17,2014,Rev.C
VALUE ROLLER GRILL MODEL X50, X50S, X50SG, X50F, X50SF, X50SGF
FigNo. PartNumber Description Quantity Applications
1A5-Z2305 DRIP TRAY 50 1
2
A5-RG7501 ROLLER ASSY CHROME
11
X50, X50F
A5-RG7502 ROLLER ASSY X50S, X50SF
A5-RG5057 ROLLER ASY HIGRIP 50SG/75SG X50SG, X50SGF
32N-Z2179 ELEMENT 120V 50/75 11
2N-Z2193 ELEMENT 230V 50/75 230V ONLY
42A-Z8017 BUSHING IDLER 4
52P-Z8392 IDLER SPROCKET ASSEMBLY 4
62C-1810 WASHER 3/16 BURR STL NP 10
7A5-Z13684 CHAIN GUIDE-11 COUNT 1
82C-Z0498 NUT 10-24 NYLK HEX STL ZP 4
92C-6349 SCREW #8X3/8 B THP STL NP 27
10 2I-Z13659 INNER SEAL-BLACK 12 FRONT ROLLERS
2I-Z13660 INNER SEAL-LIGHT GRAY 10 BACK ROLLERS
11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 22
12 A5-RG30153 ASY,CHN TENSIONER W/SPKT 1
13 2P-Z8074 EXTENSION SPRING 1
14 2P-Z13743 #25 ROLLER CHAIN,188TEETH 1X50, X50S, X50SG
2P-Z13744 #25 ROLLER CHAIN,184TEETH X50F, X50SF, X50SGF
15 A5-Z13666 COVER,END PANEL,SLT,11CT 2X50, X50S, X50SG
A5-Z13669 COVER-END PANEL-FLAT-11CT X50F, X50SF, X50SGF
16 2P-Z11853 MOTOR SPROCKET 1
17 2C-1506 SCREW 10-32X1/2 RHP STL 4
2C-200121 WASHER #10 SPLIT SS
18
2U-Z11854 MOTOR GEAR, 120V
12U-Z11855 MOTOR GEAR, 230V 230V / 60HZ
A5-Z14583 MOTOR, 240V, 50HZ 230V / 50HZ
19 2K-Y3240 BUSHING HEYCO SR 17-2 1
20 A5-Z13679 COVER,BODY PANEL, X50 1
21 2K-Y8571 BUSHING SNAP 2 1/8 2
22 2A-Z11501 FOOT 1” SOLID RUBBER 4
23 2J-Z14323 INFINITE CTL, 120V 2
2J-Z14324 INFINITE CONTROL, 230V 230V ONLY
25 2M-Z13658 OVERLAY, MODEL X50, X75 1
26 2E-Z1858 SWITCH-LIGHTED 1
27 2R-Z1854 KNOB-CONTROL 2
28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2
2J-Z13655 PILOT LIGHT RECT-RED-230V 230V ONLY
29 A5-Z13685 ELEMENT RETAINER,LWR-11CT 1
30 2C-Z14533 WASHER, SHOULDER IDLER ARM 2
NI 2P-Z0584 TONGS-PLASTIC 9” 1
NI D5-HWP006 CORD ASSEMBLY 14-3 120V 1
2E-Z0512 CORD SET, CONT. EUR 10A 230V ONLY
NI A5-RG2006 WIRE ASSEMBLY #5 2

PARTS LIST October17,2014,Rev.C
VALUE ROLLER GRILL MODEL X75, X75S, X75SG, X75F, X75SF, X75SGF
FigNo. PartNumber Description Quantity Applications
1A5-Z2306 DRIP TRAY 75 1
2
A5-RG7501 ROLLER ASSY CHROME
16
X75, X75F
A5-RG5044 ROLLER ASSY 07B 50S/75S X75S, X75SF
A5-RG5057 ROLLER ASY HIGRIP 50SG/75SG X75SG, X75SGF
32N-Z2982 ELEMENT 120V, 105W 16 120V
2N-Z2193 ELEMENT 230V 50/75 230 & 240V
42A-Z8017 BUSHING IDLER 4
52P-Z8392 IDLER SPROCKET ASSEMBLY 4
62C-1810 WASHER 3/16 BURR STL NP 10
7A5-Z13686 CHAIN GUIDE-16 COUNT 1
82C-Z0498 NUT 10-24 NYLK HEX STL ZP 4
92C-6349 SCREW #8X3/8 B THP STL NP 36
10 2I-Z13659 INNER SEAL-BLACK 16 FRONT ROLLERS
2I-Z13660 INNER SEAL-LIGHT GRAY 16 BACK ROLLERS
11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 32
12 A5-RG4594 ASY,CHN TENSIONER W/SPKT 1X75, X75S, X75SG
A5-RG4595 ASY,CHN TNSR -X45F, X75F X75F, X75SF, X75SGF
13 2P-Z8074 EXTENSION SPRING 1
14 2P-Z13745 #25 ROLLER CHAIN,246TEETH 1X75, X75S, X75SG
2P-Z13746 #25 ROLLER CHAIN,242TEETH X75F, X75SF, X75SGF
15 A5-Z13672 COVER,END PANEL,SLT,16CT 2X75, X75S, X75SG
A5-Z13675 COVER,END PANEL-FLAT-16CT X75F, X75SF, X75SGF
16 2P-Z11853 MOTOR SPROCKET 1
17 2C-1506 SCREW 10-32X1/2 RHP STL 4
2C-200121 WASHER #10 SPLIT SS
18 2U-Z11854 MOTOR GEAR-120V/60HZ 1120V
2U-Z11855 MOTOR GEAR, 240V 230 & 240V
19 2K-Y2968 BUSHING STRAIN RELIEF 1120V
2K-Y3240 BUSHING HEYCO SR 17-2 240V
20 A5-Z13683 COVER,BODY PANEL, X75 1
21 2K-Y8571 BUSHING SNAP 2 1/8 2
22 2A-Z11501 FOOT 1” SOLID RUBBER 4
23 2J-Z14323 INFINITE CTL, 120V 2120V
2J-Z14324 INFINITE CTL, 240V 230 & 240V
25 2M-Z13658 OVERLAY, MODEL X50, X75 1
26 2E-Z1858 SWITCH-LIGHTED 1
27 2R-Z1854 KNOB-CONTROL 2
28 2J-Z13654 PILOT LIGHT-RECT, RED 120V 2120V
2J-Z13655 PILOT LIGHT-RECT-RED-230V 230 & 240V
29 A5-Z13687 ELEMENT RETAINER,LWR-16CT 1
30 2C-Z14533 WASHER, SHOULDER IDLER ARM 2
NI 2P-Z0584 TONGS-PLASTIC 9” 1
NI A5-RG2034 CORD SET 240V W/TERMINALS 1
2E-Z0512 CORD SET, CONT. EUR 10A 230V ONLY
NI A1-175122 LEAD IN CORD ASSEM 1
NI A5-RG4512 WIRE ASSY LONG 2

STAR MANUFACTURING INTERNATIONAL INC.
SK2469 Rev A 1/13/2011
All Grill-Max Express 120V & 240V, 60Hz, WIRE DIAGRAM
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
P2
H1
L1
H2 H2
P2
H1
L1
7
7
L2
37
4
7
L2
1
1
2
2
REAR FRONT
F
A A
R
(AS VIEWED FROM REAR OF PANEL)
A1/13/11 UPDATE PILOT LIGHTS AND
INFINITE CONTROLS
STAR MANUFACTURING INTERNATIONAL INC.
SK2528 Rev - 1/13/2011
All Grill-Max Express 230V, 50 & 60Hz, WIRE DIAGRAM
THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC.
NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED.
PILOT
H1
L1
H2 H2
PILOT
H1
L1
7
7
L2
37
4
7
L2
1
1
2
2
REAR FRONT
F
R
(AS VIEWED FROM REAR OF PANEL)
6
6
MARKED "COM".
CONNECT WIRE AT
THIS LOCATION.
MARKED "50 Hz" AND
HAS A GREEN DOT.
CONNECT WIRE FOR
230V -50Hz MODELS
AT THIS LOCATION.
MARKED "60 Hz".
CONNECT WIRE FOR
230V-60Hz MODELS
AT THIS LOCATION.
50 Hz
or
60 Hz
COM

¨
GRILL-MAX EXPRESS
VALUE BUN WARMER: MODEL XBW30, XBW50
SK2474, REV -, 8/19/2010
1
3
8
10
9
4
2
7
5
6

PARTS LIST August12,2011,Rev.B
(AS VIEWED WITH BOTTOM COVER REMOVED.)
ALL XBW MODELS 120V & 230V UNITS
I
0
FOIL ELEMENT
BLACK
WHITE
SWITCH ORIENTATION
(AS VIEWED FROM THE
SIDE OF THE UNIT)
SK2475
WIRE DIAGRAM
¨
GRILL-MAX EXPRESS
VALUE LINE BUN WARMER: MODELS XBW-30 & XBW-50
Fig No Part No Description Qty Applications
1A4-BW3023 ASM-DRAWER, XBW-30 1XBW-30
A4-BW5035 ASM-DRAWER, XBW-50 XBW-50
2 2R-Z13650 SLIDES-DRAWER,500MM,SS 1 ALL
3 A4-Z13699 BRACKET, DRAWER ROLLERS 2 ALL
42M-Z13720 LABEL-DRAWER FRONT,XBW-30 1XBW-30
2M-Z13721 LABEL-DRAWER FRONT,XBW-50 XBW-50
5A4-BW3022 ASM-BODY, XBW-30 1XBW-30
A4-BW5034 ASM-BODY, XBW-50 XBW-50
6 2E-Z0091 SWITCH 1 ALL
7
2N-Z13651 ELEMENT,FOIL-20X21-50W120
1
XBW-30
2N-Z13652 ELEMENT,FOIL-20X33-70W120 XBW-50
2N-Z15047 ELEMENT,FOIL-50W-230V XBW-30-230V
2N-Z15048 ELEMENT,FOIL-70W-230V XBW-50-230V
8A4-Z13695 COVER-LOWER BASE, XBW-30 1 XBW-30
A4-Z13698 COVER-LOWER BASE, XBW-50 1 XBW-50
9 2I-Z13653 FOOT,RUBBER,1 DIA X .5 4 ALL
10 2C-Z6743 SCREW 8-32 X 3/8 FHP SS 10 ALL
NI E2-215085 LEAD CORD ASSEM 1120V
2E-Z0512 CORD SET, CONT EURO 10A 230V
NI 2K-70215 STRAIN RELIEF STR HEYCO 1 ALL
NI 2C-Z12945 WIRE HARNESS 1 ALL

2M-4497-2 6/1312
The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.
FOR ASSISTANCE
Should you need any assistance regarding the Operation or Maintenance of any Star equipment; write, phone, fax or email our Service Department.
In all correspondence mention the Model number and the Serial number of your unit, and the voltage or type of gas you are using.
ALL:
*Pop-Up Toasters
*Butter Dispensers
*Pretzel Merchandisers
(Model 16PD-A Only)
*Pastry Display Cabinets
*Nacho Chip Merchandisers
*Accessories of any kind
*Sneeze Guards
*Pizza Ovens
(Model PO12 Only)
*Heat Lamps
*Pumps-Manual
Visit our Website at: www.star-mfg.com Email: [email protected]
THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL
This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which
the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation
company who delivered the item to you and initiate your claim with same. If this procedure is not followed, it may affect the warranty status of the unit.
LIMITED EQUIPMENT WARRANTY
All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited
to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair
of defects without charge, by the factory authorized service agency or one of its sub-agencies. Models that are considered portable (see below) should be taken
to the closest Star service agency, transportation prepaid.
>Star will not assume any responsibility for loss of revenue.
>On all shipments outside the United States and Canada, see International Warranty.
* The warranty period for the Ultra-Max, Hot Plates, Griddles, Charbroilers is (3) years parts & labor.
* The warranty period for the Star-Max, Charbroilers, Griddles, Hot Plates, Fryers & Finishing Oven is (2) years parts & labor.
*The warranty period for the JetStar six (6) ounce & Super JetStar eight (8) ounce series popcorn machines is two (2) years.
*The warranty period for the Chrome-Max Griddles is ve (5) years on the griddle surface. See detailed warranty provided with unit.
*The warranty period for Teon/Dura-Tec coatings is one year under normal use and reasonable care. This warranty does not apply if damage occurs to
Teon/Dura-Tec coatings from improper cleaning, maintenance, use of metallic utensils, or abrasive cleaners, abrasive pads, product identiers and
point-of-sale attachments, or any other non-food object tha comes in continuous contact with the roller coating. This warranty does not apply to the
“non-stick” properties of such materials.
>This warranty does not apply to "Special Products" but to regular catalog items only. Star's warranty on "Special Products" is six (6) months on parts
and ninety (90) days on labor.
>This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by a Star Authorized Service Center or
the Service Center's sub-agency.
>This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage, wrong gas or operated contrary to the Installation and
Operating instructions.
>This warranty is not valid on Conveyor Ovens unless a "start-up/check-out" has been performed by a Factory Authorized Technician.
PARTS WARRANTY
Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The part only is warranted, the labor to replace the part is NOT warranted.
SERVICES NOT COVERED BY WARRANTY
PORTABLE EQUIPMENT
Star will not honor service bills that include travel time and mileage charges for servicing any products considered "Portable" including items listed below.
These products should be taken to the Service Agency for repair:
1. Travel time and mileage rendered beyond the 50 mile radius limit
2. Mileage and travel time on portable equipment (see below)
3. Labor to replace such items that can be replaced easily during a daily cleaning
routine, ie; removable kettles on fryers, knobs, grease drawers on griddles, etc.
4. Installation of equipment
5. Damages due to improper installation
6. Damages from abuse or misuse
7. Operated contrary to the Operating and Installation Instructions
8. Cleaning of equipment
9. Seasoning of griddle plates
10. Voltage conversions
11. Gas conversions
12. Pilot light adjustment
13. Miscellaneous adjustments
14. Thermostat calibration and by-pass adjustment
15. Resetting of circuit breakers or safety controls or reset buttons
16. Replacement of bulbs
17. Replacement of fuses
18. Repair of damage created during transit, delivery, &
installation OR created by acts of God
* The Model 510FD, 510FF Fryer.
* The Model 526TOA Toaster Oven.
* The Model J4R, 4 oz. Popcorn Machine.
*The Model 518CMA & 526CMA Cheese Melter.
* The Model 12MC & 15MC & 18MCP Hot Food Merchandisers.
* The Model 12NCPW & 15NCPW Nacho Chip/Popcorn Warmer.
* All Hot Dog Equipment except Roller Grills & Drawer Bun Warmers.
* All Nacho Cheese Warmers except Model 11WLA Series Nacho Cheese Warmer.
* All Condiment Dispensers except the Model HPD & SPD Series Dispenser.
* All Specialty Food Warmers except Model 130R, 11RW Series, and 11WSA Series.
* All QCS/RCS Series Toasters except Model QCS3 & RCS3 Series.
* All Fast Steamer Models except Direct Connect Series.

STAR INTERNATIONAL HOLDINGS INC. COMPANY
Star - Holman - Lang - Wells - Bloomeld - Toastmaster
10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
[phone]
www.star-mfg.com
