Grindhouse Shift User manual

User Manual

for purchasing the Grindhouse®Shift vaporizer for dry herb, wax, and thick oils.
Read and follow the instructions carefully, and keep them in a safe place for future reference.
We hope you enjoy the quality and performance of your new vaporizer. You must be over 18
years old to purchase and use the Grindhouse Shift. This product should not be used by
children, women who are pregnant or breast feeding, or those with life threatening illnesses
without first consulting a doctor.
The Grindhouse Shift is not a medical device and is not intended to diagnose, cure, treat, or
prevent any disease or other condition. If you have any health problems, consult your doctor
before using. The Grindhouse Shift is not intended to administer medicinal or illegal substances
of any kind. Any illegal use of this device could subject the user to severe fines, penalties and/or
imprisonment under the laws of your jurisdiction. For proper intended use only.
THIS PRODUCT DOES NOT CONTAIN TOBACCO OR CONCENTRATE MATERIALS.
Thank you
1

2
First, attach the Grindhouse®Shift to the included USB Charger, and plug into a handy
USB port. Make sure to not let the unit hang as this can damage the USB connection.
While charging, a "Charging" graphic will appear on the top OLED screen. Unit is fully
charged, approx. 1.5 hours.
Before using the Grindhouse Shift, first, heat the unit a few times empty. This will burn off
any impurities collected during manufacturing.
QUICK START GUIDE

Shift Overview
Power Button
Temp Control +
Temp Control - OLED Display
3

Silicone
Mouthpiece
Screen
Cleaning
Brush
Packing
Tool
USB
Cable
Includes:
Tweezers Quartz
Tank
4

Specifications
WARNING: Always store the Grindhouse®Shift in a dry, shaded place to protect the battery
against the elements.
KEEP OUT OF REACH OF CHILDREN AND/OR UNQUALIFIED PERSONS.
Size :
Battery Capacity
Charging Voltage/Current
Lock/Unlock:
Safety Power Duration:
Battery Low:
Temperature Range :
Charging Time :
50*27.3*81mm
1600mAh
5V/1A
Press 5 times consecutively
240 seconds
Low Battery Symbol is displayed
320°F–430°F
< 2 hours
5

OLED Digital Screen Instruction
Turn On/Off Low Battery Charging Error
Occurred
Auto Shut Off
Count-down
Temperature
Setting
KEY FEATURES
6
True Convection
Vaporizer
25sec Heat Time
Temperature Range
320ºF - 430ºF
Micro USB
Charging
Compact Size
Glass Tube
Mouthpiece

Helpful Tips
1. For best results, fill chamber halfway or slightly more, but do not pack tightly. This
allows for even heat distribution and room to stir your herbal blends if necessary
throughout usage.
2. To maximize efficiency, after each session, allow unit to cool, and then stir herbs
before the next cycle.
3. Be sure to turn off the unit when you are done by pressing the on/off button 5 times
within 2 seconds.
Using the Shift
Once you packed the dry herbs into the heating chamber, press the power button 5
times in rapid succession. The OLED screen will display device's current temperature.
The indicator light glowing within the mouthpiece will be RED when heating. Once the
desired temperature is reached, it will turn to GREEN. Smoke session is now ready!
The Grindhouse®Shift will automatically shut off after 4 minutes. This is the device's
safety duration. To reactive the heating element, simply click the power button 5 times
in rapid succession. 7

How To Load With Dry Herb
1. Push top lip
of mouthpiece
away from unit
2. Load ground
material loosely
3. Snap mouthpiece
back in place
8

How to Clean
1. Push top lip of
mouthpiece away
from unit
2. Remove the spent
material from the
chamber with the stir tool
3. Use the cleaning
brush to remove
and clean debris
9

How To Load Wax & Thick oils
1. Remove
mouthpiece
2. Pull silicone
cap off of the
quartz cup
4. Replace
silicone cap
3. Load wax or
thick oil
5. Place quartz
cup into chamber
6. Re-attach
mouthpiece
10

How To Replace Silicone Mouthpiece Screen
1. Remove mouthpiece
2. Pull silicone screen
off at the tab 3. Replace with new
silicone screen ring
4. Securely press the silicone
screen ring into place
11

Charging Instructions
1. Battery capacity: 1600mAh.
2. Initially charge the Grindhouse®Shift for approx.
1.5 hours. The Battery will stop charging when
the icon is full.
3. When battery level is low, charge battery with
included micro USB cable to either your
computer USB port or compatible wall charger.
Low battery level with be indicated with icon
Low Battery.
4. Do not use the Grindhouse Shift while charging.
Charging Port
12

Important Usage Tips
1. Rapid press Power button 5 times with in 2 seconds to power on/off.
2. Press and hold power button and "-" buttons simultaneously with 2 seconds to change
from Fahrenheit to Celsius degrees or from Celsius to Fahrenheit.
3. Adjust to desired temperature manually using "+" or "-" buttons.
4. Your vaporizer is equipped with a 4 minutes auto shut off time to prevent waste
and over heating.
13

Important Safety Warnings:
Do not expose to extreme temperature or direct sunlight. Do not drop the Grindhouse®Shift or accessories. Do not drop
or submerge in any liquid. Do not modify the electronics in any way. Only charge using Grindhouse brand chargers and
Grindhouse brand accessories. Grindhouse Shift is intended for adults only. Do not sell or provide to minors. Keep all
parts, concentrates, herbs, and liquids away from children and pets. Grindhouse Shift is not a medical device and is not
intended to diagnose, treat, mitigate, cure, or prevent any ailment, disease, or other conditions. Consult a physician
before use, especially if you suffer from heart disease or any other medical condition, or if you are pregnant or breastfeeding.
Failure to follow any of these instructions could result in product damage, property damage, or personal injury.
Limited Warranty:
Grindhouse Shift is guaranteed from manufacturer defects or malfunction from the original date of purchase for a period
of 1 year. This limited warranty protects against manufacturer defects under normal use and does not apply to normal
wear and tear, improper use, and accidental damage from dropping or submerging in liquid, improper cleaning, neglect,
or any other damage that is not a result of defective materials or workmanship. If your Grindhouse Shift qualifies for
servicing, we will repair or replace, at our discretion and expense, any defective parts or materials. Purchaser must
provide a copy of the original dated sales receipt and may be required to provide shipping to return defective parts or
materials. We intend to complete all repairs/replacements within 7 business days, although this timeframe may vary
depending on shipping, replacement part availability, or other related factors. The lawful and proper use of this device is
a condition of sale. Any improper use of the Grindhouse Shift will void the warranty. Warranty is nontransferable.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.
Manufactured by Grindhouse, Asheville, NC 28806
www.grindhousegrinders.com
Designed in USA • Assembled in China
For warranty servicing, contact us at:
