Grindmaster AMW 67710 User manual

Item # _______________________________
Project _______________________________
Date _________________________________
Tamper Resistant Coffee Urn - Twin 10 gallon
High Capacity: Two Independent Brewing Systems
High Security: No Exposed Fasteners
Model 67710
Electric
• Will Exceed High Volume Demand Burst, Two
Independent Brewing Systems
Two independent brewing heads brew into the 10 gallon (38L) liners
simultaneously or independently. Brew heads are mounted under
hinged lockable covers.
• Innovative Indicators Eliminate Exterior Parts
Indicator lights replace gauge glasses. Water hot light replaces
thermometer. Completely internal air agitation system for each liner.
• Designed For Safety
Eliminates potential burn hazard with two layers of high density
fiberglass insulated body.
• Flanged Feet
Urn can be fastened to counter top to prevent tipping or movement
• Tamper Resistant
All adjustable controls (timer, thermostats, sprayover flow control), are
inside a lockable control box. Master on/off switch is behind a stainless
steel, lockable panel. Control switches and pilot lights are protected
behind a tamper resistant, one inch thick Lexan® cover plate.
• Longer Average Life
Internal frame is all A.I.S.I. type 304, 18-8 stainless steel.
• Saves Steps In Brewing
Two permanent stainless steel brew baskets, so filter paper is eliminated.
Features:

Coffee Urn - Tamper Resistant
High Security / High Capacity
Coffee Brewing Equipment
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
© Grindmaster Corporation, 1995
PRINTED IN USA
0807 Form # AM-204-03
67710
Productivity, 50°F Inlet 40 gal. per hour
Productivity, 130°F Inlet 80 gal. per hour
Dimensions 40-1/2” W X 22” D X 34-1/4” H, (51” H With Cover Open)
Electrical Options
all models 15 KW
120/240V 1 Phase 3 Wire 63 Amps
120/208V 1 Phase 3 Wire 72 Amps
240V 3 Phase 3 Wire 36 Amps
120/208V 3 Phase 4 Wire 42 Amps
480V 3 Phase 3 Wire 18 Amps
PERMANENT BREW BASKET
(NO FILTERS REQUIRED) BREW START AND STOP BUTTONS
40 1/2”
2 3/4”
INTERNAL ELECTRONIC
LEVEL INDICATOR
SIGNALS TO
OPERATOR WHEN
THERE IS LESS THAN
ONE HALF GALLON
OF COFFEE
REMAINING IN
THE LINER
9 3/4”
34 1/4”
FLANGED FEET WITH
SCREW HOLES TO
FASTEN TO COUNTER
DRAIN
1 1/2”
1 1/2”
HOT WATER COFFEE
COFFEE
3 1/2”
FAUCETS ARE NONREMOVABLE
WITHOUT TOOLS
22”
9 1/4”
23 5/8”
11”
4”
DRAIN
3/8” WATER INLET
ELECTRICAL
INPUT
HINGED NON-REMOVABLE
STAINLESS STEEL ENCLOSURE
INTERNALLY HOUSING (2)
SPRAY- ARMS AND BYPASS
VALVE FOR INDEPENDENT OR
SIMULTANEOUS BREWING TO
EACH LINER - MAY BE PADLOCKED
HEAVY DUTY REINFORCED
CONTROL BOX WHICH
INTERNALLY HOUSES ALL
ELECTRICAL CONTROLS -
ACCESS COVER IS
PADLOCKED
ALL TUBING AND FASTENERS
INTERNAL FOR AUTOMATIC AIR
AGITATION (SYSTEM MIXES
COFFEE TO KEEP BREW FRESH)
