Grindmaster AT-2W User manual

www.grindmaster.com
Decanters, Airpots, Thermal Carafes
AUTO SERIES
BREWERS

Commercial Brewing Systems
2-Warmer, Automatic Brewer
Model AT-2W
Brews up to 75 oz (2.2L) decanters
(Decanters sold separately)
3-Warmer, Automatic Brewer
Model AT-3WR
Brews 75 oz (2.2L) decanters
(Decanters sold separately)
Airpot, Automatic Brewer
Model AT-AP
Brews up to 75 oz (2.2L) airpot
(Airpot sold separately)
Shown with optional gourmet brew basket (p/n 80004)
Thermal carafe, Automatic Brewer
Model AT-TC
Brews into 64 oz (1.9L) thermal carafe
(Thermal carafe sold separately)

Pourover Feature
Brewer is equipped with pourover feature allowing the brewer
to be used in locations without water connections.
Adjustable Brew Basket Rails
Brew basket rails are adjustable to fit all
commercial 64 oz (1.9L) brew baskets.
Hot Water Faucet
Brewer is equipped with hot water faucet,
for hot chocolate, tea, etc. Drawing water
from faucet will not affect brew volume.
Lighted Switches, Water Hot Light
Lighted switches are visible from long distance when
energized. Green water hot light signifies brewer
has reached optimum brewing temperature.
Water Quick Disconnect
Water tank is equipped with an electrical
quick disconnect to allow faster service.
Brewers Brew up to 75 ounce (2.2L) Decanters
Brew volume can be adjusted from 24 oz (0.7L) up to 75 oz. (2.2L).
For Serious Coffee Drinkers

© Grindmaster Corporation, 2007
PRINTED IN USA
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
www.grindmaster.com • email: [e-mail] 0607 Form # BW-275-02
Specification Sheets Available by Model on our Full Line of Auto Series Brewers:
AT-AP AT-3WR AT-2W AT-TC
Volts / Watts / Amps 120V / 1780W / 14.8A 120V / 1700W / 14.2A 120V / 1600W / 13.3A 120V / 1780W / 14.8A
Brew Capacity (max) 75 oz (2.2L) 75 oz (2.2L) 75 oz (2.2L) 75 oz (2.2L)
No. of Warmers 0 3 2 0
Machine Dimensions
(H x W x D)
24” x 8-1/2” x 16-1/2”
(61 cm x 22 cm x 42 cm)
17-3/4” x 15-1/2” x 16-1/2”
(45 cm x 39 cm x 42 cm)
19-1/2” x 8-1/2” x 16-1/2”
(49 cm x 22 cm x 42 cm)
17-3/4” x 8-1/2” x 16-1/2”
(45 cm x 22 cm x 42 cm)
Machine Weight 24 lbs (10.9 kg) 28 lbs (12.7 kg) 24 lbs (10.9 kg) 22 lbs (10 kg)
Ship Dimensions
(H x W x D)
28-3/4” x 12-1/2” x 22-1/2”
(73 cm x 32 cm x 57 cm)
22-3/4” x 19-3/4” x 22-1/2”
(58 cm x 50 cm x 57 cm)
23-1/4” x 12-1/2” x 22-1/2”
(59 cm x 32 cm x 57 cm)
23-1/4” x 12-1/2” x 22-1/2”
(59 cm x 32 cm x 57 cm)
Ship Weight 31 lbs (14.1 kg) 36 lbs (16.4 kg) 29 lbs (13.2 kg) 28 lbs (12.7 kg)
Listings (pending) UL, NSF UL, NSF UL, NSF UL, NSF
Specifications
Specifications are subject to improvement or change without notice.
AT-APE AT-3WRE AT-2WE AT-TCE
Volts / Watts / Amps 230V / 2300W / 10A 230V / 2630W / 11.4A 230V / 2520W / 11A 230V / 2300W / 10A
Brew Capacity (max) 75 oz (2.2L) 75 oz (2.2L) 75 oz (2.2L) 75 oz (2.2L)
No. of Warmers 0 3 2 0
Machine Dimensions
(H x W x D)
24” x 8-1/2” x 16-1/2”
(61 cm x 22 cm x 42 cm)
17-3/4” x 15-1/2” x 16-1/2”
(45 cm x 39 cm x 42 cm)
19-1/2” x 8-1/2” x 16-1/2”
(49 cm x 22 cm x 42 cm)
17-3/4” x 8-1/2” x 16-1/2”
(45 cm x 22 cm x 42 cm)
Machine Weight 24 lbs (10.9 kg) 28 lbs (12.7 kg) 24 lbs (10.9 kg) 22 lbs (10 kg)
Ship Dimensions
(H x W x D)
28-3/4” x 12-1/2” x 22-1/2”
(73 cm x 32 cm x 57 cm)
22-3/4” x 19-3/4” x 22-1/2”
(58 cm x 50 cm x 57 cm)
23-1/4” x 12-1/2” x 22-1/2”
(59 cm x 32 cm x 57 cm)
23-1/4” x 12-1/2” x 22-1/2”
(59 cm x 32 cm x 57 cm)
Ship Weight 31 lbs (14.1 kg) 36 lbs (16.4 kg) 29 lbs (13.2 kg) 28 lbs (12.7 kg)
Listings (pending) CE, NSF CE, NSF CE, NSF CE, NSF
International Specifications
Specifications are subject to improvement or change without notice.
pending pending pending
Model AT-AP/AT-APE
(shown with optional
gourmet brew basket)
Model AT-3WR/AT-3WRE Model AT-2W/AT-2WE Model AT-TC/AT-TCE
