Grip Rite GRTS1200 Installation and maintenance instructions

1
OPERATOR’S MANUAL
AND PARTS LIST
MODEL GRTS1200 STAPLER

3
2
TABLE OF CONTENTS
TABLE OF CONTENTS
--------------------------------
2
SPECIFICATIONS
----------------------------------------
3
Fastener Selection Chart
-------------------------
3
SAFETY
-----------------------------------------------------
4
TOOL PARTS
----------------------------------------------
8
PART DESCRIPTIONS
---------------------------------
9
OPERATION
---------------------------------------------
10
Loading Staples
-----------------------------------
10
Adjusting Fastener Drive
-----------------------
11
Clearing Staple Jams
----------------------------
11
Tool Operation
-------------------------------------
12
MAINTENANCE
-----------------------------------------
13
Lubrication
------------------------------------------
13
Cleaning
----------------------------------------------
13
Trigger Check
--------------------------------------
13
PARTS SCHEMATIC
----------------------------------
14
PARTS LIST
----------------------------------------------
15
TROUBLESHOOTING
--------------------------------
16
TOOL CHECKS
-----------------------------------------
17
WARRANTY
----------------------------------------------
18
SPECIFICATIONS
SPECIFICATIONS
MODEL
GRTS1200
FASTENER RANGE
3/4” - 2 ” (19 mm - 50 mm)
FASTENER TYPE
16 Ga. Staples
CROWN SIZE
1” (25 mm) Wide Crown
MAGAZINE CAPACITY
150 STAPLES
MAX AIR PRESSURE
120 psi (8.3 bar)
MIN AIR PRESSURE
70 psi (4.8 bar)
TOOL WEIGHT
4.8 lbs. (2.2 kg)
TOOL LENGTH
14.8” (37.6 cm)
TOOL HEIGHT
10” (25.4 cm)
TOOL WIDTH
3.2” (8.13 cm)
STANDARD TRIGGER
Dual Action (Bump/Trigger Fire)
ACCESSORY TRIGGER
Sequential
AIR INLET
1/4 NPT
AIR CONNECTION
Male Quick Connect Coupler
LUBRICATION
10W Air Tool Oil (Provided)
NOISE CHARACTERISTIC VALUES IN ACCORDANCE WITH ISO 3774, ISO 11201:
A-weighted single-event sound
pressure level at operator’s position
----------------------------------
LpA, 1s = 90 dBA
A-weighted single-event sound power level
-----------------------
LwA, 1s = 102 dBA
A-weighted single-event surface sound
pressure level
----------------------------------------------------------------
LpA, 1s = 89 dBA
VIBRATION CHARACTERISTIC VALUES IN ACCORDANCE WITH ISO 8862-1
Weighted root mean square acceleration
----------------------------
= 2.6 m/s
2
IMPORTANT SAFETY INFORMATION
You must read this entire manual and familiarize yourself with all
safety, operating, and service instructions before loading, handling,
or using your tool. When used correctly, pneumatic fastening
tools provide a lightweight, powerful, and safe means of fastening.
Used improperly, these tools can cause serious injury to you and
those around you.
For best results, use Grip-Rite™collated fasteners.
LEG
BOX
CROWN
WIRE
GALVANIZED
LENGTH
QTY.
SIZE
GA.
STEEL SKU
3/4” (19 mm)
10M
1
16
GRP11
7/8” (22 mm)
10M
1
16
GRP12
1” (25 mm)
10M
1
16
GRP13
1-1/4” (32 mm)
10M
1
16
GRP15
1-1/2” (38 mm)
10M
1
16
GRP17
1-3/4” (45 mm)
10M
1
16
GRP19
2” (51 mm)
10M
1
16
GRP21
FASTENER SELECTION CHART

5
4
SAFETY
SAFETY
SAFETY LABELS
This pneumatic fastening tool includes a warning label to help remind you of
important safety information when operating the tool. The safety label must be
legible at all times, and must be replaced if it becomes worn or damaged.
SYMBOL
DESCRIPTION
READ THE MANUAL
- The manual contains
important safety and operating instructions
that must be followed. All tool users must
read the manual before using the tool.
WEAR SAFETY GLASSES
- Tool operator
and bystanders must wear safety glasses
with side shield that meet ANSI Z87.1
requirements.
RISK OF PERSONAL INJURY
- Failure to
follow all safety and operating instructions,
or misuse of the tool, can result in serious
injury to tool operator and bystanders.
WEAR SAFETY GLASSES
Always wear safety glasses with side shields that meet ANSI
Z87.1 requirements when operating the tool. Make sure all
others in work area wear safety glasses.
WEAR HEARING PROTECTION
Wear hearing protection to protect your hearing from noise.
Prolonged exposure to loud noise can result in hearing loss.
NEVER OPERATE THE TOOL WITH OXYGENOR OTHER
BOTTLED GASES
Oxygen and other reactive or high-pressure bottled gases
can cause the tool to explode. Use clean, dry regulated
compressed air from a properly operating air compressor.
DO NOT EXCEED MAXIMUM RECOMMENDED OPERATING AIR
PRESSURE OF 110 PSI /7.6 Bar.
Exceeding the maximum recommended air pressure can
cause the tool housing to burst, or cause premature failure of
components.
NEVER CONNECT THE TOOL TOAN AIR SUPPLY THAT HAS
THE POTENTIAL TO EXCEED 180 PSI/12.4 Bar.
Using a regulated air supply with a line or tank pressure
greater than 180 psi can cause the tool to burst if the air line
regulator fails suddenly.
USE AN AIR HOSE RATED FOR 180 PSI/12.4 Bar OR
GREATER
Always use air hose rated to handle 180 psi or the maximum
potential pressure of the air supply.
ONLY USE ARELIEVING-TYPE AIR COUPLING IN THE TOOL
AIR INLET OPENING.
Use of a non-relieving air coupling on the tool can trap air
inside the tool housing, and allow the tool to drive a fastener
even after the air hose has been disconnected.
SAFETY INSTRUCTIONS
SAFETY SYMBOLS
These safety symbols provide a visual reminder of basic safety
rules, and the personal injury hazard that may arise if all safety and
operating instructions are not followed. Make sure you understand
the meaning of each of these symbols, and protect yourself and
others by obeying all safety and operating instructions.
120 psi
4.8 bar
70 psi
8.3 bar

7
6
SAFETY
SAFETY
DO NOT ATTEMPT TO OPERATE THE TOOL IF THE TOOL’S
OPERATING CONTROLS HAVE BEEN MODIFIED ORARE NOT
WORKING PROPERLY.
Attempting to use a tool with modified or malfunctioning
trigger or workpiece contact can result in a fastener being
driven unintentionally.
USE CORRECT FASTENERS
Only use the correct fastener for the tool. Using fasteners
with incorrect specifications can jam the tool or cause
serious injuries.
USE THE CORRECT FASTENERS FOR THE APPLICATION.
Using the wrong fasteners can cause the workpiece to split
and allow the fastener to fly free.
KEEP TOOL POINTED IN A SAFE DIRECTION WHEN LOADING
FASTENERS.
Never point the tool at yourself or anyone else when loading
fasteners.
DO NOT LOAD TOOL WITH TRIGGER OR WORKPIECE
CONTACT DEPRESSED.
Depressing the trigger or workpiece contact during loading
can result in an unintentional fastener drive if both devices
are accidentally actuated at the same time.
KEEP FINGER OFF TRIGGER UNTIL TOOL IS IN POSITION TO
DRIVE AFASTENER.
An unexpected bump or sudden contact with your body or that
of a bystander can result in serious injuries.
AVOID DRIVING FASTENERS INTO KNOTS, ON TOP OF
OTHER FASTENERS,AT WORKPIECE EDGES, OR INTO
BRITTLE MATERIALS.
Driving fasteners into extremely hard materials, or driving into
workpiece edges, can cause fasteners to deflect away from
the workpiece. Flying fasteners can cause serious injuries.
SAFETY INSTRUCTIONS
KEEP HANDS AND BODY PARTSAWAY FROMAREA BEING
FASTENED.
Fasteners can deflect and turn as they are being driven into
the workpiece, and penetrate fingers, hands, and other body
parts that may be in the fastening area.
DO NOT OVERREACH OR WORK WHILE ON UNSTABLE
FOOTING
If you lose your balance while fastening, you could drive a
fastener into yourself or a bystander.
DO NOT USE TOOL IF TOOL MALFUNCTIONS OR BEGINS
LEAKINGAIR.
Operating a malfunctioning tool can result in an unexpected
fastener discharge and injury to yourself or others.
DISCONNECT THE TOOL FROM THEAIR SUPPLY TO RE-
LOAD, CLEAR JAMS, OR PERFORM MAINTENANCE.
Never attempt to reload a tool, clear a jam, or perform
maintenance without first disconnecting the air supply.
NEVER LEAVE A LOADED, PRESSURIZED TOOL
UNATTENDED
A loaded, pressurized tool could be picked up or handled by
someone who is unfamiliar with the tool or that has not read
the tool manual.
KEEP TOOLS OUT OF THE REACH OF CHILDREN
Place the tool back in the tool box after use, and store the tool
out of reach.
DO NOT MODIFY TOOL
Modifications can cause a tool to be unsafe and can cause
the tool to operate improperly.
SAFETY INSTRUCTIONS

9
8
DESCRIPTION
PART DESCRIPTIONS
1.
360° Adjustable Air Deflector
- Tool-free adjustment blows exhaust
air away from operator. 12 locking positions for secure settings.
2.
Cushioned Grip
- Cushioned handgrip reduces fatigue and provides
comfortable operation.
3.
Dual Action Trigger (Standard)
- Actuates tool when workpiece
contact is depressed against work surface. Permits contact-trip
(bump fire) or trigger-fire operation.
Sequential Trigger
(Accessory) -
Actuates tool only when correct
trigger operating sequence is followed. Does not allow bump firing.
4
.
Rotating Belt Hook
- Durable tool hook slides on belt. Holds tool
securely and keeps it in reach for greater productivity.
5.
Air Coupling
- Quick-disconnect male coupling allows quick
connection to air hose. Dust cap keeps dirt out when tool is not in
use.
6.
Safety Warning Label
- Provides important safety reminders that
must be followed whenever handling, operating, or servicing the tool.
7.
Top Load Staple Magazine
- Hold fasteners securely, and allows
quick check of staple size and quantity.
8.
Spring-loaded Pusher -
Provides positive fastener feeding in all
tool positions. Latches in loading position for rapid, one-handed
loading. Arrow indicators show when it’s time to reload.
9.
Workpiece Contact
- Spring-loaded contact mechanism prevents
tool from driving a fastener unless tool is pressed down and held
against a work surface.
10.
E-Z Clear Latch
- Clear jammed fasteners from nose without tools.
11.
Adjustable Depth of Drive
- Easy, tool-free depth of drive adjust-
ment allows adjustments to be made for consistent depth control.
12.
Tool Housing
- Magnesium tool housing reduces tool weight.
13
.
Cap
- Seals tool housing.
Metric Hex Wrench
- Included with tool to allow tightening of metric
screws.
Air Tool Oil
- Lightweight oil formulated for use in air tools provides
proper lubrication to o-rings and internal parts.
Safety Goggles
- Provides required eye protection
DESCRIPTION
TOOL PARTS
1
2
3
13
6
11
7
12
10
9
8
5
4

11
10
OPERATION
OPERATION
LOADING FASTENERS
LOADING INSTRUCTIONS
A fastener can be driven unintentionally if the trigger and safety bracket
are activated at the same time. Always disconnect tool from air supply
before loading fasteners, making adjustments, or performing any service
on tool. Keep finger off trigger until ready to drive a fastener.
DANGER
1.
Pull pusher (A) back to latched
position at rear of magazine.
2.
Load staple strips (B) over
magazine track. Slide strips
down so that staple crowns
ride on top rail, then slide
forward toward tool nose.
3.
Pull pusher (A) back and press
release lever (C) to release
latch. Slide pusher forward
against staple strips and
release. DO NOT allow pusher
to snap forward against
staples.
4.
Tool is now loaded and ready
to be connected to an air
supply for operation.
ADJUSTING STAPLE DRIVE
1.
Disconnect tool from air supply
using quick-connect coupling.
2.
Turn adjustment dial forward to
decrease staple drive, or
backward to increase staple
drive, as shown by symbols on
tool.
3.
Connect tool to air supply, and
drive staples to check for
correct depth of drive.
4.
Make depth of drive adjust-
ments as needed to maintain
consistent staple driving.
CLEARING STAPLE JAMS
1.
Disconnect tool from air supply
using quick-connect coupling.
2.
Pull pusher back to latched
position at rear of magazine.
3.
Open E-Z Clear latch and open
door.
4.
Remove jammed fastener.
5.
Close door and secure with
latch.
6.
Release pusher and slide
forward against staple strips.
7.
Connect air supply and check
tool for normal operation.
A
C
B
STAPLE TOO HIGH
TURN DIAL
BACKWARD
STAPLE TOO
DEEP TURN
DIAL
FORWARD
DRIVE
DEEPER
DRIVE
LESS
DEEP

13
12
MAINTENANCE
MAINTENANCE
Your tool will last longer and perform better if periodic maintenance is
performed. Please use the information below to keep your tool operating
in top condition.
Lubrication
Disconnect tool from the air supply and remove all
fasteners. Apply 2 - 3 drops of air tool oil (pro-
vided) in the air inlet two - three times a day. If
the tool will be used outside in the winter, use a
winter grade air tool oil to help keep frost from
forming inside the tool. Do not use other types of
lubricants on this tool, as other lubricants may
contain chemicals harmful to o-rings and other
tool components. Drain compressor tanks and
hoses daily.
Cleaning
Disconnect tool from the air supply and remove all fasteners. Brush tool
off using a parts cleaning brush or clean rag. Check area around trigger
and workpiece contact, and clean as necessary. Pull pusher back to
latched position, and brush out staple entry area of tool nose. Open E-Z
Clear latch and brush out debris. Blow out confined areas around tool nose
using low pressure compressed air.
OPERATION
Trigger Check (Sequential)
Check trigger operation daily to confirm proper sequential operation:
1.
Press the workpiece contact against a safe work surface without
depressing the trigger.
THE TOOL MUST NOT CYCLE.
2.
Hold the tool above a safe work surface and pull the trigger without
depressing the workpiece contact.
THE TOOL MUST NOT CYCLE.
3.
Pull and hold the trigger, and then press the workpiece contact
against a safe work surface.
THE TOOL MUST NOT CYCLE.
4.
With finger off trigger, press the workpiece contact against a safe
work surface. Keep tool pressed against work surface, and pull
trigger.
THE TOOL MUST CYCLE
ONCE
.
5.
The trigger must return to the normal position each time finger
pressure is released.
TOOL OPERATION
CONTACT TRIP (BUMP FIRE) DRIVING METHOD (Standard)
To operate this tool in contact trip mode (bump-firing), remove the sequen-
tial trigger provided on the tool, and install the dual-action trigger provided
with the tool.
1.
Position the nose of the tool over the work surface, near the area
where the first fastener is to be driven.
2.
Squeeze and hold the trigger in the depressed position.
3.
Bump the workpiece contact (safety) against the work surface at
each point where a fastener is to be driven.
4.
Using a bouncing motion, continue moving the tool into position for
each fastener drive.
5.
When fastening is completed, release the trigger.
SEQUENTIAL OPERATION (Optional)
1.
Hold the tool securely using the handgrip. Keep finger off trigger
until tool is in position and you are ready to drive a fastener. NOTE:
Depressing trigger before depressing safety bracket will prevent tool
from actuating.
2.
Position the nose of the tool on the workpiece, placing the nose at
the desired fastener driving position.
3.
Press the tool down firmly against the work surface, fully depressing
the workpiece contact (safety bracket).
4.
Squeeze the trigger once to drive a fastener.
5.
Allow the tool to rebound off the work surface, and release the trigger
to reset the workpiece contact. Tool will not drive another fastener
until trigger is released, and cannot be bump-fired with sequential
trigger installed.
6.
Check fastener for correct depth of drive, and if needed, adjust lower
element tip to obtain desired fastener drive.
7.
If tool adjustments do not provide the desired results, make air
pressure adjustments at the compressor: Increase air pressure to
drive deeper or to drive into harder materials. Reduce air pressure to
reduce drive or to drive into softer materials. For longest tool and
part life, always use the lowest air pressure necessary to drive
fasteners to desired depth.
8.
Position the tool for driving the next fastener, and repeat the above
procedure. Always keep hands and other body parts away from
areas being fastened.

15
14
PARTS LIST
PARTS SCHEMATIC
ITEM
P/N
DESCRIPTION
1
GRTN5910
Hex. Soc. Hd. Bolt
2
GRTN3220
Bushing
3
GRTN3230
Deflector
4
GRTN6080
Hex. Soc. Hd. Bolt
5
GRTN5640
Cap
6
GRTN5180
Metal Shim
7
GRTN5170
Piston Stopper
8
GRTN5150
Spring
9
GRTN3350
O-Ring
10
GRTN2300
O-Ring
11
GRTN5120
Piston, Head Valve
12
GRTN5650
Cap, Gasket
13
GRTN5130
Seal
14
GRTN5950
O-Ring
15
GRTN5670
Cylinder Spacer
16
GRTN2140
O-Ring
17
GRTN5960
O-Ring
18
GRTN5660
Cylinder
19
GRTN5940
O-Ring
20
GRTN5140
O-Ring
21A
GRTN5680
Driver Assembly
22
GRTN5690
Bumper
23
GRTN5700
Driver Guide
24A
GRTN5710
Body Assembly
25
GRTN4430
O-Ring
26
GRTN4450
End Cap - Old Style
27
GRTN2220
O-Ring
28
GRTN2240
O-Ring
29
GRTN630
Valve
30
GRTN2100
O-Ring
31
GRTN2130
O-Ring
32
GRTN2170
O-Ring
33
GRTN640
Valve Plunger
34
GRTN830
Spring
35
GRTN2230
O-Ring
36
GRTN810
Plunger
37
GRTN820
Plunger Cap
38A
GRTN2950
Trigger Assembly-
Bump
39
GRTN2540
Spring Pin
40
GRTN790
Trigger Pin
ITEM
P/N
DESCRIPTION
41
GRTN2210
Grommet
42
GRTN5870
Guide, Contact Trip
43
GRTN5780
Upper Safety Lever
44A
GRTN5820
Adjusting Nut Assembly
45
GRTN5810
Lower Safety
46
GRTN5030
E-Ring
47
GRTN5790
Spring, Safety
48
GRTN5770
Bushing
49
GRTN5800
Safety Cover
50
GRTN6070
Hex. Soc. Hd. Bolt
51
GRTN5740
Nose
52
GRTN5890
Hex. Soc. Hd. Bolt
53
GRTN5720
Driver Guide Cover
54
GRTN6020
Spring Pin
55
GRTN5730
Door
56
GRTN6030
Spring Pin
57A
GRTN5750
Latch Door Assembly
58
GRTN5760
Latch Door, Cover
59
GRTN3990
Hex. Soc. Hd. Bolt
60
GRTN5860
Magazine Cap
61
GRTN5830
Magazine
62
GRTN6060
Hex. Soc. Hd. Bolt
63
GRTN5840
Pusher
64
GRTN3950
Latch
65
GRTN4070
Spring
66
GRTN3960
Spiral Spring
67
GRTN3970
Roller
68
GRTN3980
Roller Pin
69
GRTN5850
Bracket
70
GRTN4060
Spring
71
GRTN6040
Flat Washer
72
GRTN5900
Hex. Soc. Hd. Bolt
73
GRTN3340
Locknut
74
GRTN4080
Trigger Assembly
75
GRTN4480
End Cap
76
GRTN4110
Belt Hook
77
GRTN4140
O-Ring
78
GRTN4120
Spring Plate
79
GRTN4440
C-Ring
80
GRTN4150
Complete Belt Hook Assy
A
GRDAK1700
Driver Assembly Kit
B
GRRBK1700
Rebuild Kit
C
CASES1200
Tool Case
D
MANS1200
Operators Manual

17
16
TROUBLESHOOTING
TOOL TROUBLESHOOTING
Your pneumatic fastening tool has been designed for long life and trouble-
free operation. However, if operating problems arise, please use the
troubleshooting information below to determine how to remedy the prob-
lem.
TROUBLESHOOTING
FASTENER DRIVING PROBLEMS
Always disconnect tool from air supply before performing any service on
tool. Correcting a problem while the tool is pressurized may result in
injury from fastener discharge or tool operation.
DANGER
Tool leaks air.
Check for source of leak, and tighten fittings
and screws as required. Discontinue using
tool if air leaks at trigger area or from cap
exhaust. Contact your dealer.
Tool operates, but no
fastener is driven.
Tool won’t operate -
staple jammed in tool
nose, preventing tool
from operating.
Remove jammed fastener. Check magazine
for incorrect, bent, or loose fasteners, and
discard. Reload using Grip-Rite™staples.
Check nose for jammed fastener. Clear jam
and reload magazine. Check staple strips for
smooth feeding in magazine.
Fasteners do not drive
completely.
AT COMPRESSOR: Increase air pressure.
Do not exceed 120 psi/8.3 bar
Fasteners do not drive
completely when
driving in quick succes-
sion.
Inadequate air flow. Use larger diameter hose.
Use compressor with larger storage tank.
Keep hose lines short. Check air hose for
kinks or other restrictions.
Fasteners drive too
deeply.
AT COMPRESSOR: Reduce air pressure.
(Do not reduce below 70 psi/4.8 bar.)
PROBLEM
CORRECTIVE ACTION
Fasteners do not drive
completely after air
pressure is increased.
Driver blade worn or broken. See dealer for
replacement.
FASTENER DRIVING PROBLEMS
AT TOOL: Turn adjustment dial to increase
staple drive depth. Add 2 - 3 drops of air tool
oil to inlet.
AT TOOL: Turn adjustment dial to decrease
staple drive depth.
TOOL CHECKS
Keep your stapler in top working condition by checking it daily. See your
Grip-Rite™dealer for service if part or operating problems are found. Never
use a malfunctioning tool - it could result in serious injury.
Workpiece Contact & Trigger
Check workpiece contact for proper operation before each use. Workpiece
contact must move freely and return to extended position when lifted from
workpiece. Trigger must operate freely.
Daily Inspection
•
Check for broken, damaged, or excessively worn parts, and repair
or replace as needed.
•
Check for air leaks at trigger, cap, and nose. Disconnect tool from
air supply immediately if leaks are present, and see dealer for
service.
•
Make sure all screws are tightened securely.

19
18
PNEUMATIC TOOL/COMPRESSOR WARRANTY
Pneumatic nailers, staplers & compressors marketed under the
GRIP RITE
TM
brand are warranted to be free from defects in work-
manship & materials (except rubber o-rings, bumpers, seals, driver
blades, dipsticks, & air filters) for a period of one year from the date
of original purchase.
This warranty will not apply when:
•
The original receipt (or copy of the original receipt), showing the
original purchase date, is not provided with tools/compressors sent
in for warranty repair
•
The tool/compressor has been misused, abused or improperly
maintained
•
Alterations have been made to the original tool/compressor
•
Repairs have been attempted/made to the original tool/compressor
by any entity other than a proprietary
GRIP-RITE
®
service/warranty
center or authorized service/warranty center
•
Non-
GRIP-RITE TOOLS
TM
/ GRIP-RITE COMPRESSORS
TM
/
parts
have been used
•
The tool has suffered any physical damage due to the use of non-
GRIP-RITE
®
approved fasteners*
•
Repairs are required due to normal wear & tear
•
The tool/compressor has been inadequately packaged leading to
damage in-transit to the service/warranty center.
*Approved fasteners include the following brands
GRIP-RITE
FAS’NERS
TM
, FAS’NERS UNLIMITED
TM
IN NO EVENT SHALL
PRIMESOURCE
®
BE LIABLE FOR ANY INDI-
RECT, ACCIDENTAL OR CONSEQUENTIAL DAMAGE FROM THE SALE
OR USE OF THESE PRODUCTS. THIS DISCLAIMER APPLIES BOTH
DURING & AFTER THE TERM OF WARRANTY.
THIS IS OUR WARRANTY & IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
(EXCEPTAS MAY BE OTHERWISE PROVIDED BY LAW).
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAYALSO HAVE OTHER RIGHTS, WHICH VARY, FROM STATE TO
STATE.
WARRANTY
WARRANTY
PNEUMATIC TOOL/COMPRESSOR SERVICE INFORMATION
Should any mechanical problems develop during the life of your
equipment the following options are available for service and parts:
•
Call [phone] where you will be routed to the nearest
GRIP-RITE®
distribution center and directed to the nearest
authorized service/warranty center.
•
Logging on to our website at
www.grip-rite.com
where you will
find a list of our authorized service centers.
•
Contact the
GRIP-RITE®
Factory Warranty Center directly at
Phone: [phone] or Fax: [phone]
•
In Canada, Call (
866) 512-1418
STEPS TO TAKE WHEN SHIPPING TOOLS
•
Adequately package the product to avoid damage in-transit (in
the case of pneumatic tools, the original blow mold plastic
carrying case is considered adequate packaging).
•
Provide the original/copy of receipt showing the original purchase
date.
•
Insure your shipment with the shipping company.
PRIMESOURCE®
will not be responsible for any tool/compressor
that is lost or damaged by the shipper on route to the
PRIMESOURCE®
service/warranty center.

20
USE GENUINE GRIP-RITE
®
FASTENERS FOR BEST
PERFORMANCE
MANS1200
06/08
