Grizzly G7943 User manual
G7943
G7944
MODEL G7943/G7944
12 SPEED HEAVY-DUTY
DRILL PRESS
OWNER'S MANUAL
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
4HISMANUALPROVIDESCRITICALSAFETYINSTRUCTIONSONTHEPROPERSETUP
OPERATIONMAINTENANCEANDSERVICEOFTHISMACHINEEQUIPMENT
&AILURETOREADUNDERSTANDANDFOLLOWTHEINSTRUCTIONSGIVENINTHIS
MANUALMAYRESULTINSERIOUSPERSONALINJURYINCLUDINGAMPUTATION
ELECTROCUTIONORDEATH
4HEOWNEROFTHISMACHINEEQUIPMENTISSOLELYRESPONSIBLEFORITS
SAFEUSE4HISRESPONSIBILITYINCLUDESBUTISNOTLIMITEDTOPROPER
INSTALLATIONINASAFEENVIRONMENTPERSONNELTRAININGANDUSAGE
AUTHORIZATIONPROPERINSPECTIONANDMAINTENANCEMANUALAVAILABILITY
ANDCOMPREHENSIONAPPLICATIONOFSAFETYDEVICESBLADECUTTERINTEG
RITYANDTHEUSAGEOFPERSONALPROTECTIVEEQUIPMENT
4HEMANUFACTURERWILLNOTBEHELDLIABLEFORINJURYORPROPERTYDAMAGE
FROMNEGLIGENCEIMPROPERTRAININGMACHINEMODIFICATIONSORMISUSE
3OMEDUSTCREATEDBYPOWERSANDINGSAWINGGRINDINGDRILLINGAND
OTHERCONSTRUCTIONACTIVITIESCONTAINSCHEMICALSKNOWNTOTHE3TATE
OF#ALIFORNIATOCAUSECANCERBIRTHDEFECTSOROTHERREPRODUCTIVE
HARM3OMEEXAMPLESOFTHESECHEMICALSARE
s ,EADFROMLEADBASEDPAINTS
s #RYSTALLINESILICAFROMBRICKSCEMENTANDOTHERMASONRYPRODUCTS
s !RSENICANDCHROMIUMFROMCHEMICALLYTREATEDLUMBER
9OURRISKFROMTHESEEXPOSURESVARIESDEPENDINGONHOWOFTENYOU
DOTHISTYPEOFWORK4OREDUCEYOUREXPOSURETOTHESECHEMICALS
7ORKINAWELLVENTILATEDAREAANDWORKWITHAPPROVEDSAFETYEQUIP
MENTSUCHASTHOSEDUSTMASKSTHATARESPECIALLYDESIGNEDTOFILTER
OUTMICROSCOPICPARTICLES
Table of Contents
INTRODUCTION............................................................................................................................... 3
SECTION 1: SAFETY....................................................................................................................... 9
SECTION 2: CIRCUIT REQUIREMENTS ...................................................................................... 12
SECTION 3: SET UP ...................................................................................................................... 13
SECTION 4: OPERATIONS ........................................................................................................... 25
SECTION 5: ACCESSORIES......................................................................................................... 31
SECTION 6: MAINTENANCE......................................................................................................... 34
SECTION 7: SERVICE ................................................................................................................... 35
SECTION 8: WIRING...................................................................................................................... 40
WARRANTY AND RETURNS ........................................................................................................ 49
Foreword
INTRODUCTION
Contact Info
www.
grizzly.com
The information contained herein is deemed accurate as of 5/25/2009 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G7943
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G7943 12 SPEED HEAVY-DUTY BENCH-TOP DRILL
PRESS
Product Dimensions:
Weight.............................................................................................................................................................. 142 lbs.
Length/Width/Height............................................................................................................................. 24 x 14 x 38 in.
Foot Print (Length/Width)............................................................................................................................. 18 x 11 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 154 lbs.
Length/Width/Height............................................................................................................................. 33 x 20 x 12 in.
Electrical:
Switch...................................................................................................................Toggle On/Off with Safety Lock Tab
Switch Voltage...................................................................................................................................................... 110V
Cord Length...................................................................................................................................................... 8-1/2 ft.
Cord Gauge....................................................................................................................................................16 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................3/4 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................9A
Speed.................................................................................................................................................1720 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction....................................................................................................Cylindrical Ground Steel
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................ Cast Iron
Paint.......................................................................................................................................................... Epoxy
Head Information
Head Swivel.......................................................................................................................................... 360 deg.
G7943 Machine Data Sheet
The information contained herein is deemed accurate as of 5/25/2009 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2Model G7943
Other Related Information
Base Length............................................................................................................................................... 18 in.
Base Width................................................................................................................................................. 11 in.
Quill Diameter........................................................................................................................................2.040 in.
Depth Stop Type.............................................................................................Threaded Rod with Positive Stop
Column Diameter.................................................................................................................................. 3.150 in.
Illumination....................................................................................................................... 110V Socket, Separat
Spindle Information
Spindle Taper.............................................................................................................................................MT#2
Spindle Travel........................................................................................................................................ 3-1/4 in.
Dist From Spindle To Column...................................................................................................................... 7 in.
Dist From Spindle To Table........................................................................................................................16 in.
Dist From Spindle To Base........................................................................................................................ 23 in.
Table Information
Table Length........................................................................................................................................ 11-3/8 in.
Table Width.......................................................................................................................................... 11-3/8 in.
Table Thickness..................................................................................................................................... 1-1/4 in.
Floor To Table Height............................................................................................................... 9-1/2 - 23-1/2 in.
Vertical Table Movement................................................................................................ Crank Handle Operate
Table Swing.......................................................................................................................................... 360 deg.
Table Tilt.......................................................................................................................... Left and Right 90 deg.
Table Swivel Around Center................................................................................................................. 360 deg.
Table Swivel Around Column................................................................................................................360 deg.
Maximum Movement Of Work Table....................................................................................................25-3/4 in.
No. Of T Slots....................................................................................................................................................4
T Slot Width...............................................................................................................................................5/8 in.
T Slot Length..........................................................................................................................................3-7/8 in.
Operation Information
Swing..........................................................................................................................................................14 in.
Drilling Capacity........................................................................................................................... 3/4 in. in Steel
No Of Spindle Speeds.....................................................................................................................................12
Range Of Spindle Speeds..................140, 260, 320, 380, 480, 540, 980, 1160, 1510, 1650, 2180, 3050 RPM
Drill Chuck Type....................................................................................................................... JT33 Key Chuck
Drill Chuck Size......................................................................................................................................... 5/8 in.
Other Specifications:
Country Of Origin ................................................................................................................................................China
Warranty ............................................................................................................................................................ 1 Year
Serial Number Location ................................................................................................................Data Label on Head
Awards .............................................................................. Popular Woodworking Editor's Choice Tool Buying Guide
Assembly Time ........................................................................................................................................... 45 minutes
Features:
Table Has Lock Levers and Coolant Trough
Crank Handle Operated Rack and Pinion Vertical Table Movement
Threaded Depth Stop
Four T-Slots Accommodates 1/2" Clamping Kit
Includes Built-in Light
Table and Base are Cast Iron
3/4HP Motor
1/8" - 5/8" Chuck
Cushioned Grip Quill Handles
The information contained herein is deemed accurate as of 5/25/2009 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G7944
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G7944 12 SPEED HEAVY-DUTY 14" FLOOR DRILL
PRESS
Product Dimensions:
Weight.............................................................................................................................................................. 155 lbs.
Length/Width/Height............................................................................................................................. 24 x 14 x 64 in.
Foot Print (Length/Width)............................................................................................................................. 18 x 11 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 171 lbs.
Length/Width/Height............................................................................................................................. 56 x 20 x 10 in.
Electrical:
Switch.................................................................................................................. Paddle On/Off with Safety Lock Tab
Switch Voltage...................................................................................................................................................... 110V
Cord Length...................................................................................................................................................... 8-1/2 ft.
Cord Gauge....................................................................................................................................................16 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................3/4 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................9A
Speed.................................................................................................................................................1720 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction....................................................................................................Cylindrical Ground Steel
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................ Cast Iron
Paint.......................................................................................................................................................... Epoxy
Head Information
Head Swivel.......................................................................................................................................... 360 deg.
G7944 Machine Data Sheet
The information contained herein is deemed accurate as of 5/25/2009 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 2 OF 2Model G7944
Other Related Information
Base Length............................................................................................................................................... 18 in.
Base Width................................................................................................................................................. 11 in.
Quill Diameter........................................................................................................................................2.040 in.
Depth Stop Type...........................................................................................................................................Hub
Column Diameter.................................................................................................................................. 3.150 in.
Mobile Base..............................................................................................................................................G8683
Illumination....................................................................................................................... 110V Socket, Separat
Spindle Information
Spindle Taper.............................................................................................................................................MT#2
Spindle Travel........................................................................................................................................ 3-1/4 in.
Dist From Spindle To Column...................................................................................................................... 7 in.
Dist From Spindle To Table................................................................................................................. 31-1/2 in.
Dist From Spindle To Base........................................................................................................................ 49 in.
Table Information
Table Length........................................................................................................................................ 11-3/8 in.
Table Width.......................................................................................................................................... 11-3/8 in.
Table Thickness..................................................................................................................................... 1-1/4 in.
Floor To Table Height......................................................................................................................... 20 - 46 in.
Vertical Table Movement................................................................................................ Crank Handle Operate
Table Swing.......................................................................................................................................... 360 deg.
Table Tilt.......................................................................................................................... Left and Right 90 deg.
Table Swivel Around Center................................................................................................................. 360 deg.
Table Swivel Around Column................................................................................................................360 deg.
Maximum Movement Of Work Table..........................................................................................................14 in.
No. Of T Slots....................................................................................................................................................4
T Slot Width...............................................................................................................................................5/8 in.
T Slot Length..........................................................................................................................................3-7/8 in.
Operation Information
Swing..........................................................................................................................................................14 in.
Drilling Capacity........................................................................................................................... 3/4 in. in Steel
No Of Spindle Speeds.....................................................................................................................................12
Range Of Spindle Speeds..................140, 260, 320, 380, 480, 540, 980, 1160, 1510, 1650, 2180, 3050 RPM
Drill Chuck Type....................................................................................................................... JT33 Key Chuck
Drill Chuck Size......................................................................................................................................... 5/8 in.
Other Specifications:
Country Of Origin ................................................................................................................................................China
Warranty ............................................................................................................................................................ 1 Year
Serial Number Location ................................................................................................................Data Label on Head
Awards ...............Popular Woodworking Editor's Choice Tool Buying Guide, American Woodworker Best Buy 2001,
Woodworker's Journal Tools That Endure
Assembly Time ........................................................................................................................................... 45 minutes
Features:
Crank Handle Operated Rack and Pinion Vertical Table Movement
Cushioned Grip Quill Handles
Table Has Lock Levers and Coolant Trough
Includes Built-in Light
Four T-Slots Accommodates 1/2" Clamping Kit
Table and Base are Cast Iron
12 Speeds
3/4HP Motor
Threaded Depth Stop
1/8" - 5/8" Chuck
Identification
Figure 1.
Figure 2.
Figures 1 & 2
1. Light Switch:ON/OFF
2. Power Switch:ON/OFF
3. Belt Tension Lever:
4. Belt Tension Lock:
5. Crank Lever:
6. Small Lock Lever:
7. Large Lock Lever:
8. Torsion Spring:
9. Lash Screw:
10. Depth Stop:
11. Table Tilt Scale:
Headstock
Drift Key
T-Slot
Arbor
Quill
Spindle
4. ALWAYS USE HEARING PROTECTION
WHEN OPERATING MACHINERY.
5. WEAR PROPER APPAREL.
6. NEVER OPERATE MACHINERY WHEN
TIRED, OR UNDER THE INFLUENCE OF
DRUGS OR ALCOHOL.
1. READ THROUGH THE ENTIRE MANUAL
BEFORE STARTING MACHINERY.
2. ALWAYS USE ANSI APPROVED
SAFETY GLASSES WHEN OPERATING
MACHINERY.
3. ALWAYS WEAR AN ANSI APPROVED
RESPIRATOR WHEN OPERATING
MACHINERY THAT PRODUCES DUST.
For Your Own Safety, Read Instruction
Manual Before Operating this Machine
The purpose of safety symbols is to attract your attention to possible hazardous conditions. This
manual uses a series of symbols and signal words which are intended to convey the level of
importance of the safety messages. The progression of symbols is described below. Remember
that safety messages by themselves do not eliminate danger and are not a substitute for proper
accident prevention measures.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury. It may also be used to alert
against unsafe practices.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
This symbol is used to alert the user to useful information about
proper operation of the machine.
NOTICE
Safety Instructions for Machinery
SECTION 1: SAFETY
7. ONLY ALLOW TRAINED AND PROP-
ERLY SUPERVISED PERSONNEL TO
OPERATE MACHINERY.
8. KEEP CHILDREN AND VISITORS AWAY.
9. MAKE WORKSHOP CHILD PROOF.
10. NEVER LEAVE WHEN MACHINE IS
RUNNING. OFF
11. DO NOT USE IN DANGEROUS
ENVIRONMENTS.
12. KEEP WORK AREA CLEAN AND WELL
LIT.
13. USE A GROUNDED EXTENSION CORD
RATED FOR THE MACHINE AMPERAGE.
14.
ALWAYS DISCONNECT FROM POWER
SOURCE BEFORE SERVICING
MACHINERY
15. MAINTAIN MACHINERY WITH CARE.
16. MAKE SURE GUARDS ARE IN PLACE
AND WORK CORRECTLY BEFORE
USING MACHINERY.
Safety Instructions for Machinery
17. REMOVE ADJUSTING KEYS AND
WRENCHES.
ON
18. CHECK FOR DAMAGED PARTS
BEFORE USING MACHINERY.
19. USE RECOMMENDED ACCESSORIES.
20. DO NOT FORCE MACHINERY.
21. SECURE WORKPIECE.
22. DO NOT OVERREACH.
23. MANY MACHINES WILL EJECT
WORKPIECE TOWARD OPERATOR.
24. ALWAYS LOCK MOBILE BASES
(IF USED) BEFORE OPERATING
MACHINERY
25. BE AWARE THAT CERTAIN WOODS
MAY CAUSE AN ALLERGIC REACTION
1. EYE/FACE/HAND PROTECTION.
2. SECURING BIT.
3. CORRECT BIT.
4. ADJUSTING KEYS AND WRENCHES.
ON
5. DRILLING SHEET METAL.
6.S U R F A C E / W O R K P I E C E P R E P A R A T I O N
ON
7. DAMAGED TOOLS.
Safety for Drill Presses
8.DRILL OPERATION
OFF
OFF
9. OPERATING SPEED.
.
10. MAINTENANCE/SPEED CHANGES.
11. MOUNTING WORKPIECES.
12. TABLE LOCK
13. EXPERIENCING DIFFICULTIES.
No list of safety guidelines can be complete.
Every shop environment is different. Always
consider safety first, as it applies to your
individual working conditions. Use this and
other machinery with caution and respect.
Failure to do so could result in serious per-
sonal injury, damage to equipment, or poor
work results.
Like all machines there is danger associated
with this machine. Accidents are frequently
caused by lack of familiarity or failure to pay
attention. Use this machine with respect
and caution to lessen the possibility of
operator injury. If normal safety precautions
are overlooked or ignored, serious personal
injury may occur.
Figure 3.
<gdjcY^c\Egdc\^h
Adc\Zhid[i]ZI]gZZ
Egdc\h
8jggZci
8Vggn^c\Egdc\h <gdjcYZY
DjiaZi
Serious personal injury could occur if you
connect the machine to the power source
before you have completed the set up pro-
cess. DO NOT connect the machine to the
power source until instructed to do so.
110V Operation
Amperage Draw
Circuit Requirements
If you are unsure about
any wiring practices, consult a qualified elec-
trician.
Plug/Receptacle Type
This machine must have a ground prong in
the plug to help ensure that it is grounded.
DO NOT remove ground prong from plug
to fit into a two-pronged outlet! If the plug
will not fit the outlet, have the proper outlet
installed by a qualified electrician.
Extension Cords
SECTION 2: CIRCUIT REQUIREMENTS
Electrocution or fire could
result if this machine is
not grounded correctly or
if your electrical configu-
ration does not comply
with local and state codes.
Ensure compliance by
checking with a qualified
electrician!
please immediately call Customer
Service at (570) 546-9663for advice.
Otherwise, filing a freight claim can be difficult.
Wear safety glasses dur-
ing the entire set up pro-
cess!
This machine presents
serious injury hazards
to untrained users. Read
through this entire manu-
al to become familiar with
the controls and opera-
tions before starting the
machine!
Unpacking
Set Up Safety
SECTION 3: SET UP
The Model G7943/G7944
is a heavy machine. DO
NOT over-exert yourself
while unpacking or mov-
ing your machine—get
assistance.
Description Qty
Items Needed for
Set Up
Inventory
Figure 4.
Figure 4
Description Qty
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Hardware Recognition Chart
Figure 5.
Floor Load
Machine Data Sheet
Working Clearances
Figure 5
Unsupervised children and
visitors inside your shop
could cause serious per-
sonal injury to themselves.
Lock all entrances to the
shop when you are away and
DO NOT allow unsupervised
children or visitors in your
shop at any time!
For opti-
mum performance from your machine, make
sure you clean all moving parts or sliding
contact surfaces that are coated.
Site ConsiderationsClean Up
Gasoline and petroleum
products have low flash
points and could cause
an explosion or fire if
used to clean machinery.
DO NOT use gasoline or
petroleum products to
clean the machinery.
Many of the solvents
commonly used to clean
machinery can be toxic
when inhaled or ingest-
ed. Lack of ventilation
while using these sol-
vents could cause seri-
ous personal health risks
or fire. Take precautions
from this hazard by only
using cleaning solvents
in a well ventilated area.
')
&)
Table Support
Components and Hardware Needed: Qty
To install the table support:
1.
Figure 7
Figure 7.
Figure 6.
Components and Hardware Needed: Qty
To secure the column to the base:
1.
2.
Figure 6
Column and Base
3.
4.
Figure 9
Figure 9.
5.
Figure 10
Note: Do
not over-tighten the setscrew or you may split
the column ring. Also make sure the rack is
seated firmly in the lower ring.
Figure 10.
6.
7.
8.
9.
Figure 11
Figure 11.
2. Figure
8
Figure 8.
