Grizzly H0625 Instruction Manual

The information contained herein is deemed accurate as of 10/6/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model H0625
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL H0625 OSCILLATING DRILL PRESS
Product Dimensions:
Weight................................................................................................................................................................ 49 lbs.
Length/Width/Height............................................................................................................................... 17 x 9 x 23 in.
Foot Print (Length/Width)...................................................................................................................12-1/4 x 7-3/4 in.
Shipping Dimensions:
Type............................................................................................................................................................. Cardboard
Content............................................................................................................................................................Machine
Weight................................................................................................................................................................ 54 lbs.
Length/Width/Height............................................................................................................................. 14 x 18 x 10 in.
Electrical:
Switch............................................................................................................. Paddle On/Off with Safety Lockout Key
Switch Voltage......................................................................................................................................................110V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge....................................................................................................................................................18 gauge
Minimum Circuit Size........................................................................................................................................ 10 amp
Plug Included.......................................................................................................................................................... Yes
Motors:
Main
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................1/2 HP
Voltage........................................................................................................................................................110V
Prewired......................................................................................................................................................110V
Phase........................................................................................................................................................Single
Amps...............................................................................................................................................................5A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings........................................................................................................Shielded, Permanently Lubricated
Main Specifications:
Construction
Table Construction...................................................................................................Precision Ground Cast Iron
Spindle Housing Construction..............................................................................................................Cast Iron
Column Construction...............................................................................................................Ground Cast Iron
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................Cast Iron
Paint..........................................................................................................................................................Epoxy
Head Information
Head Swivel..........................................................................................................................................360 deg.

The information contained herein is deemed accurate as of 10/6/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2Model H0625
Other Related Information
Base Length.........................................................................................................................................12-1/4 in.
Base Width.............................................................................................................................................7-3/4 in.
Quill Diameter........................................................................................................................................ 1-1/2 in.
No. Of Dust Ports..............................................................................................................................................1
Dust Port Size.............................................................................................................................................. 2 in.
Depth Stop Type.............................................................................................Threaded Rod with Positive Stop
Column Diameter......................................................................................................................................... 2 in.
Spindle Information
Spindle Taper............................................................................................................................................... B16
Spindle Travel........................................................................................................................................1-5/8 in.
Dist From Spindle To Column..............................................................................................................4-5/16 in.
Dist From Spindle To Table..........................................................................................................................8 in.
Dist From Spindle To Base........................................................................................................................ 11 in.
Table Information
Table Length................................................................................................................................................ 7 in.
Table Width..................................................................................................................................................7 in.
Table Thickness........................................................................................................................................3/4 in.
Floor To Table Height...................................................................................................................5-5/16 - 11 in.
Vertical Table Movement................................................................................................ Crank Handle Operate
Table Swing.......................................................................................................................................... 360 deg.
Table Tilt................................................................................................................................................. 90 deg.
Table Swivel Around Center................................................................................................................. 360 deg.
Table Swivel Around Column................................................................................................................360 deg.
Maximum Movement Of Work Table..........................................................................................................10 in.
No. Of T Slots....................................................................................................................................................4
T Slot Width...............................................................................................................................................5/8 in.
T Slot Length..........................................................................................................................................3-7/8 in.
Operation Information
Oscillating Stroke Length.......................................................................................................................... 1/2 in.
Swing..................................................................................................................................................... 8-1/2 in.
Drilling Capacity........................................................................................................................... 1/2 in. in Steel
No Of Spindle Speeds.......................................................................................................................................5
Range Of Spindle Speeds............................................................................620, 1100, 1720, 2340, 3100 RPM
Drill Chuck Type.........................................................................................................................B16 Key Chuck
Drill Chuck Size.........................................................................................................................................1/2 in.
Other Specifications:
Country Of Origin ................................................................................................................................................China
Warranty ............................................................................................................................................................2 Year
Serial Number Location ................................................................................................................Data Label on Head
Assembly Time ...........................................................................................................................................30 minutes
Features:
Oscillating Spindle
Dust Collection Fitting
Sanding Drum Shaft
1/2HP Motor
5 Speeds
1/32" - 1/2" Chuck
Cushioned Grip Quill Handles
