Introduction
For high speed drilling applications, this 3⁄8"
Straight Air Drill delivers a free speed of 18,000
RPM. The in-line design also improves balance
and control. Recommended air pressure is 90 PSI
and average air consumption is 6 CFM. Includes
a 1⁄4" NPT quick connect fitting and chuck key.
Inventory
A. Air Drill ........................................................ 1
B. 1⁄4" NPT Quick Connect Fitting (male) ........ 1
C. Chuck Key .................................................. 1
Lubricating Your New Air Drill
Lubricate your air drill with pneumatic tool oil. If
you do not have a lubricator installed in your air
line, place one drop of pneumatic tool oil into the
air fitting daily, as shown in Figure 2.
3⁄8" STRAIGHT AIR DRILL
18,000 RPM
MODEL H6364
INSTRUCTION SHEET
Figure 1. Model H6364.
Damage to your eyes, lungs, and ears could
result from using this drill without proper
protective gear. Always wear safety glasses,
a respirator, and hearing protection while
drilling.
Figure 2. Lubricating the Model H6364.
Need Help?
If you need help with your new air drill, call our
service department at: (570) 546-9663.
COPYRIGHT © NOVEMBER, 2004 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#TR6754 PRINTED IN CHINA
H6364 Parts Breakdown and List

































Ref # Part # Description
1 H6364001 HOUSING
2 H6364002 VALVE BUSHING
3 H6364003 TRIGGER
4 H6364004 LEVER
5 H6364005 SPRING
6 H6364006 PIN
7 H6364007 PIN
8 H6364008 O-RING
9 H6364009 O-RING
10 H6364010 VALVE STEM
11 H6364011 SPRING
12 H6364012 AIR REGULATOR
13 H6364013 O-RING
14 H6364014 O-RING
15 H6364015 VALVE PLUG
16 H6364016 MUFFLE COVER
17 H6364017 AIR INLET
18 H6364018 BEARING
Ref # Part # Description
19 H6364019 END PLATE
20 H6364020 STEEL
21 H6364021 ROTOR
22 H6364022 ROTOR BLADE
23 H6364023 CYLINDER
24 H6364024 BUSHING
25 H6364025 CYLINDER PLATE
26 H6364026 FRONT PLATE
27 H6364027 PIN
28 H6364028 BEARING
29 H6364029 WORK SPINDLE
30 H6364030 RETAINER
31 H6364031 HOUSING
32 H6364032 CHUCK
33 H6364033 CHUCK SCREW
34 H6362032 1/4” NPT MALE AIR FITTING
35 H6362033 CHUCK KEY
