-40- G0549 24" Cut-Off Saw
G0549 Parts Breakdown






 





























 











































 


G0549 24" Cut-Off Saw -41-
G0549
101 P0549101 FENCE
102 PB75M HEX BOLT M12-1.75 X 35
103 P0549103 TABLE
104 P0549104 RIGHTSIDE DOOR
105 P0549105 HINGE PIN
106 P0549106 BACKSIDE DOOR
107 P0549107 SAFETY LOCK
108 P0549108 SAFETY LOCK HANDLE
109 P0549109 CABINET
110 P0549110 AIR VALVE
113 PS65M PHLP HD SCR M4-.7 X 40
114 PB27M HEX BOLT M12-1.75 X 30
115 P0549115 LIMIT SWITCH
116 P0549116 LIMIT SWITCH PLATE
117 PS06 PHLP HD SCR #10-24 X 3/8
118 P0549118 ELEVATION POINTER
119 PSB28M CAP SCREW M6-1 X 15
120 P0549120 ELEVATION LOCK PLATE
121 P0549121 LOCK KNOB M8-1.25 X 30
122 P0549122 FILTER/LUBRICATE/REGULATE
122-1 P0549122-1 GAUGE
122-2 P0549122-2 OIL CUP
122-3 P0549122-3 WATER CUP
123 PSB02M CAP SCREW M6-1 X 20
124 P0549124 TERMINAL BOX BASE
125 P0549125 TERMINAL BLOCK
126 PS03 PHLP HD SCR #10-24 X 1
127 P0549127 TERMINAL BOX COVER
128 PB51M HEX BOLT M16-2 X 50
129 P0549129 LEFT SIDE DOOR
130 PB118M HEX BOLT M8-1.25 X 45
131 PB47M HEX BOLT M6-1 X 40
132 P0549132 RUBBER PAD
133 P0549133 SPINDLE SUPPORT BRACKET
134 P0549134 PEDAL SWITCH
REF PART # DESCRIPTION
134-1 P0549134-1 PEDAL CONTROLLER
135 PB18M HEX BOLT M6-1 X 15
136 PS38M PHLP HD SCR M4-.7 X 10
137 PB10M HEX BOLT M6-1 X 25
138 P0549138 CONTROL BOX ASSEMBLY
139 P0549139 DUST PORT
140 PSB28M CAP SCREW M6-1 X 15
141 P0549141 SPECIAL BOLT M10-1.5 X 130
142 P0549142 SAFETY GUARD
143 P0549143 ACRYLIC PLATE
144 PB09M HEX BOLT M8-1.25 X 20
145 PB89 HEX BOLT 1/2-12 X 4 1/2
146 PB09M HEX BOLT M8-1.25 X 20
147 P0549147 LIMIT SWITCH
148 P0549148 AIR INLET SWITCH
149 P0549149 AIR E-STOP BUTTON
150 P0549150 MANUAL SWITCH
151 P0549151 POWER SOURCE LIGHT
151-1 P0549151-1 BULB 220V
152 P0549152 SAW START BUTTON
153 P0549153 SAW STOP BUTTON
154 P0549154 PANEL
155 P0549155 SCALE
156 P0549156 ELEVATION POINTER
157 PW06M FLAT WASHER 12MM
158 PLW05M LOCK WASHER 12MM
159 PN04M HEX NUT M4-.7
160 PW01M FLAT WASHER 8MM
161 PN13M HEX NUT M16-2
162 PLW04M LOCK WASHER 8MM
163 PN03M HEX NUT M8-1.25
164 PW03M FLAT WASHER 6MM
165 PN01M HEX NUT M6-1
166 PLW03M LOCK WASHER 6MM
REF PART # DESCRIPTION

-42- G0549 24" Cut-Off Saw
G0549













 







































G0549 24" Cut-Off Saw -43-
G0549
201 P0549201 UPPER SEAT
202 PUCF205 BEARING CASING UCF205
203 PB24 HEX BOLT 3/8-16 X 1 1/4
204 P0549204 ADJUSTABLE AIR VALVE
205 PFH40M FLAT HD SCR M6-1 X 15
206 P0549206 BLADE GUARD
207 P0549207 SAFETY COVER
208 PB118M HEX BOLT M8-1.25 X 45
209 PS65M PHLP HD SCR M6-1 X 10
210 P0549210 UPPER SEAT REAR COVER
211 PB27M HEX BOLT M12-1.75 X 30
212 P0549212 SUPPORT ARM SHAFT
213 P0549213 SQUARE BRACKET
214 PSB14 CAP SCREW 3/8-16 X 1
215 P6206 BALL BEARING 6206ZZ
216 PB53 HEX BOLT 1/2-12 X 1
217 P0549217 FENDER WASHER 1/2
218 P0549218 MAIN CRANK
219 P0549219 GREASE FITTING 1/8 X 45°
REF PART # DESCRIPTION
220 P0549220 SUPPORT CRANK
221 P0549221 UPPER DUST HOOD
222 P0549222 ADJUSTABLE PLATE
223 PB71M HEX BOLT M6-1 X 45
224 P0549224 WING BOLT M6-1 X 12
225 P0549225 RUBBER PLATE
226 PFH03M FLAT HD SCR M6-1 X 40
227 P0549227 BAKELITE INSERT
228 P0549228 GREASE FITTING 1/16 X 90°
229 PSS02M SET SCREW M6-1 X 6
230 P0549230 ADJUSTMENT KNOB 3/4-10
231 PSS16M SET SCREW M8-1.25 X 10
232 PN17 HEX NUT 3/4-10
233 P0549233 STUD 3/4 X 6"
234 PLW04 LOCK WASHER 3/8
235 PLW04M LOCK WASHER 8MM
236 PLW05M LOCK WASHER 12MM
237 PW03M FLAT WASHER 6MM
238 PN01M HEX NUT M6-1
REF PART # DESCRIPTION

-44- G0549 24" Cut-Off Saw
G0549
 












G0549 24" Cut-Off Saw -45-
G0549






























 

 

-46- G0549 24" Cut-Off Saw
G0549
301 P0549301 MAIN CRANK SHAFT
302 PK86M KEY 7 X 8 X 50
303 P0549303 ELEVATION PLATE
304 P0549304 ROD END CLEVIS
305 PN17M HEX NUT M20-1.5
306 P0549306 COUPLING PIN
307 PR09M EXT. RETAINING RING 20MM
308 P0549308 AIR CYLINDER 80 X 300MM
308-1 P0549308-1 AIR CYLINDER SEAL KIT
309 P0549309 SUPPORT FRAME
310 P0549310 COUPLING PIN
311 P0549311 SPLINE PIN 5 X 35MM
REF PART # DESCRIPTION
401 PB33M HEX BOLT M12-1.75 X 50
402 P0549402 BRACKET
403 P6205 BALL BEARING 6205ZZ
404 PN13M HEX NUT M16-2
405 PW08M FLAT WASHER 16MM
406 P0549406 MOTOR MOUNT BAR M12-1.75
407 PN09M HEX NUT M12-1.75
408 P0549408 MOTOR SCREW 3/4-10 X 6
409 P0549409 MOTOR PLATE
410 PB01M HEX BOLT M10-1.5 X 30
411 P0549411 MOTOR 15HP
411-1 P0549411-1 MOTOR FAN COVER
411-2 P0549411-2 MOTOR FAN
411-3 P0549411-3 WIRING BOX
412 PK87M KEY 10 X 8 X 80
413 P0549413 MOTOR PULLEY
414 PSS13M SET SCREW M10-1.5 X 12
415 P0549415 V-BELT MF6500
416 PLW05M LOCK WASHER 12MM
417 PLW06M LOCK WASHER 10MM
418 PW04M FLAT WASHER 10MM
REF PART # DESCRIPTION

G0549 24" Cut-Off Saw -47-
G0549



 





















-48- G0549 24" Cut-Off Saw
G0549




 













  
  











G0549 24" Cut-Off Saw -49-
G0549
501 P0549501 ARBOR WRENCH
502 P0549502 ARBOR NUT 1-12
503 P0549503 BLADE 24 X 1 X 80T X 0.16
504 P0549504 BLADE HUB
505 P0549505 ARBOR FLANGE
506 P0549506 FRONT COVER
507 PSB02M CAP SCREW M6-1 X 20
508 P6207 BALL BEARING 6207ZZ
509 P0549509 SPINDLE HOUSING
510 PSB92M CAP SCREW M12-1.75 X 40
511 P0549511 TAPER PIN 4 X 40MM
512 P0549512 GREASE FITTING 1/4
513 P0549513 LIMIT SWITCH DOG
514 PB07M HEX BOLT M8-1.25 X 25
515 P0549515 SPINDLE SHAFT
516 PK86M KEY 7 X 8 X 50
517 P0549517 LOCKING NUT (LH)
518 P0549518 REAR COVER
519 P0549519 ARBOR PULLEY
520 PSS76M SET SCREW M10-1.5 X 15
521 PLW05M LOCK WASHER 12MM
522 PLW04M LOCK WASHER 8MM
523 PW01M FLAT WASHER 8MM
REF PART # DESCRIPTION
601 P0549601 BRACKET
602 P0549602 LEFT ROLLER CONVEYOR
602A P0549602A RIGHT ROLLER CONVEYOR
603 P0549603 STAND
604 P0549604 ADJUSTMENT FOOT 5/8-11 X 4
605 PB09M HEX BOLT M8-1.25 X 20
606 PW01M FLAT WASHER 8MM
607 PB07M HEX BOLT M8-1.25 X 25
608 P0549608 LOCK HANDLE M8-1.25 X 20
609 P0549609 FLIP STOP
610 P0549610 FIXED STOP
611 P0549611 SQUARE WASHER
612 P0549612 SQUARE RAIL
613 P0549613 SCALE
614 PSB13M CAP SCREW M8-1.25 X 30
615 PLABEL-12 READ MANUAL LABEL
616 PLABEL-11 WEAR SAFETY GLASSES LABEL
617 PLABEL-36 UNPLUG 220V LABEL
618 P0549618 HANDS UNDER GUARD LABEL
619 PLABEL-14 ELECTRICITY LABEL
620 PLABEL-30 KEEP DOOR CLOSED LABEL
621 P0549621 MACHINE ID LABEL
REF PART # DESCRIPTION

-50- G0549 24" Cut-Off Saw
G0549 Electrical Panel Parts
10 2
FR1
NTH-25
10 2
R S T U1 V1 W1 Z1 X1 Y1 1 11
1T1R1
R T R2
7 6
5 5
98R S T5R S T
5 9 8
10 10 10 10
U1 V1 W1 4 Z1 X1 Y1 6 Z1 X1 Y1 7
KM1D
C-25D10
KM1D
C-25D01
KM1S
C-18D01
KT1
H3-30S
FU1 FU2 FU3
FR1
NTH-25
HMM2
HMM4 HMM4 HMM4 HMM4 HMM4 HMM4
CBD10 CBD10 CBD10
HMM2
PE 220V 440V 380V 220V0V 0V
T1R1R22
PE
Transformer
701 702 703 704 705
706
717
707
708 709 710
711 712
713
714
715
716
440V Rewire Kit
5R S T
5
10
U1 V1 W1 4
KM1D
C-25D10
701 P0549701 CONTACTOR KM1M C-25D10
702 P0549702 CONTACTOR KM1D C25D01
703 P0549703 CONTACTOR KM1S C-18D01
704 P0549704 TIMER KT1 H3-30S
705 P0549705 FUSE 5 AMP
706 P0549706 OVERLOAD FR1 NTH-25 SET 22
707 P0549707 TERMINAL STRIP PE X 6
708 P0549708 MODULAR TERMINAL CBD10
709 P0549709 MODULAR TERMINAL HMM4
710 P0549710 MODULAR TERMINAL HMM2
711 P0549711 MODULAR TERMINAL BASE
712 P0549712 TRANSFORMER TC1
713 P0549713 WIRE LOOM & COVER 25 X 230
714 P0549714 WIRE LOOM & COVER 25 X 190
715 P0549715 WIRE LOOM & COVER 25 X 160
716 P0549716 WIRE LOOM & COVER 25 X 130
717 P0549620A 440V REWIRE KIT
REF PART # DESCRIPTION

G0549 24" Cut-Off Saw -51-



















 





















801 P0549801 AIR ELBOW 3/8 MPT X 10MM
802 P0549802 AIR FITTING 1/4 MPT X 10MM
803 P0549803 AIR ELBOW 1/4 MPT X 4MM
804 P0549804 T-FITTING PT 1/4(F) X 1/4(F) X 1/4(F)
805 P0549805 AIR MUFFLER 1/8 MPT
807 P0549807 AIR STOP VALVE 3/8 MPT X 3/8
808 P0549808 AIR COUPLER 3/8 MPT
810 P0549810 TUBE FITTING UNION-T X 4MM
811 P0549811 AIR HOSE 6.5 X 10 X 1800MM (CTF)
812 P0549812 AIR HOSE 2.5 X 4 X 2500MM (CTF)
814 P0549814 LOGICAL VALVE
REF PART # DESCRIPTION
G0549 Air System Parts
