grospol Team Plus HD SP2 R1 User manual

GROSPOL Jędruch Sp.J.
Ostródzka 53
03-289 Warsaw
www.grospol.pl
Team Plus HD SP2 R1/R6 - assembly instructions
List of parts:
- 5 castors
- 1 base
- 1 gas lift
- 1 backrest with headrest
- 1 seat with SP2 mechanism
- 2 R6 armrests (left/right)
- 4 M6x25 screws
- 2 screws M6x20
- 3 M8 washers for backrest assembly
- 4 M8 pads for R1 armrest version
- 3 screws M8x12
- Allen wrench for screws (shape "L")
ASSEMBLY
NOTES!
The chair has been granted the Certificate of Durability, Stability and Safety of Use issued by PUR "Remodex"
Furniture Industry Research and Implementation Facility.
1. Push the castors into the base of the chair. 2. Insert the gas lift into the hole in the chair
base.
3. Screw the armrests using two M6x25
screws and one M6x20 screw for each
armrest. For R1 armrests, we use round
washers in addition to the two external screws
of both armrests M8.
4. Screw the backrest to the mechanism already
in the seat using three M8x20 screws and three
M8 washers.
TEAM PLUS CHAIR OPERATION
A
B
A - Seat height adjustment. Pulling the lever
upwards raises the seat. Releasing the lever
to the initial position will lock the selected
height.
B - Adjusting the backrest angle in relation
to the seat - use the lever (B) to block the
selected backrest angle in relation to the seat
(sliding the lever inwards) or release the
movement of the backrest following the
movement of the user's back (pushing the
lever outwards).
C - Adjustment of armrests (R1/R6) -
R6: while sitting in a chair after pressing the
button on the outside of the armrest, you can
change the height of the forearm support.
R1: armrests, in addition to height adjustment,
have a front-back adjustable overlay and a
possibility to change of position angle.
C
D5. The seat with the backrest and armrests
screwed on is placed on an actuator, which is
already in the base equipped with castors.
F
E
D - Backrest resistance force adjustment - a knob for adjusting the backrest resistance force
during tilting. The force is adjusted to the user's weight.
E - Adjustment of seat depth. Pulling the lever upwards slows down the forward and backward
movement of the seat.
F - Headrest height and headrest tilt adjustment - grasp the headrest with both hands in order to
set the selected up-down or front-back position.
2x M6x25
screws
1x M6x20
screw
M8 washers
for R1 version

An invoice is attached to every GROSPOL
consignment. The invoice is a proof of purchase
and a warranty document in case of a claim. We
can also issue a separate warranty card at the
customer’s request.
WARRANTY CARD
PRODUCT NAME, TYPE: Team Plus HD.....................................................
PURCHASE DATE: ......................................................................................
PURCHASER: ..............................................................................................
Warranty terms and conditions:
1. The warranty period for GROSPOL products is 36 months from the date of purchase. A
complaint will be accepted only if a proof of purchase is presented: receipt, invoice with the
date of purchase. This warranty does NOT have to be signed.
2. In case of defects, the user should send a claim in writing: by fax: [phone] or by
email: [email protected]
3. Product defects revealed after the warranty period are removed free of charge within 14
business days from the day of complaint acceptance.
4. In case when defect removal is impossible or entails excessive costs, the manufacturer
can replace the product with a new one.
5. The warranty does not cover claims concerning:
- normal product wear and tear;
- mechanical damages of the product; defects caused by misuse (see: Rules of
proper product use);
- defects revealed after any modifications and design changes made without
the manufacturer’s consent.
6. In the matters not covered by the warranty, the Civil code, the Act on provision of services
by electronic means and the Act on consumers’ law protection shall apply.
7. For the matters not covered by the warranty, the Civil Code, the Act on provision of
services by electronic means and the Act on consumers’ law protection are valid.
Seller’s stamp and signature
1. Products should be used in compliance with their intended uses.
2. All GROSPOL products are intended to be used in dry and closed rooms.
3. Products should be used and stored away from fire sources.
4. Products should not be exposed to sunlight for a long period as the colours
may fade.
5. Products cannot be exposed to heat sources for a long period (distance from heat
sources not less than 1m).
6. Proper use of GROSPOL products will ensure long and failure-free operation.
7. Please DO NOT DO NOT press against the armrest with the whole body weight
when getting up.
USE
Rules for the proper product use
Chairs are intended to be used by one person at a time. It is prohibited to:
- Occupy the seat by more than one person simultaneously;
- Stand on the seat;
- Use the chair to transport heavy objects;
- Sit on the armrests.
MAINTENANCE, CLEANING
Upholstery
For upholstery cleaning, cleaning agents upholstery available on the market. It is
recommended to try the cleaning agent on the upholstery fragment.
Chromed and varnished components
Cleaning chromed and varnished components is recommended by using cleaning
agents intended for such a prupose without abrasives. Floors wehre
products with chromed and varnished elements stand should not be cleaned with
agents exerting harmful effects on chrome and varnishare located.
Plastic components
For plastic components, the user should use agents for plastic cleaning available on
the market.
NOTICE! Damages caused by incompliance with the mentioned rules are not
covered by the warranty.
