Group Dynamics SD205C User manual
PROFESSIONAL TUMBLE DRYER
11kg
SERVICE MANUAL
549262
Publication date: Aug 2012
www.groupdynamics-laundry.com
www.groupdynamics-laundry.com
2
To avoid injury to persons disconnect power before se rvicing this product. If electrical power is required
for diagnosis or test purposes, disconnect the power immediately after performing the necessary checks.
The information in this service guide is intended for use by individuals possessing skill and experience in
electrical, electronic, and mechanical appliance repair. Any attempt to repair a major appliance may result
in injury to persons and property damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in connection with its use.
If grounding wires, screws, straps, clips, nuts, or washers used to complete a path to ground are
removed for service, they must be returned to their original position and properly fastened.
ESD problems are present everywhere. ESD may damage or weaken the electronic
control assembly. The new control assembly may appear to work well after repair is
finished, but failure may occur at a later date due to ESD stress.
એ
Use an anti-static wrist strap. onnect wrist strap to green ground connection point or unpainted
metal in the appliance.
-OR-
Touch your finger repeatedly to a green ground connection point or unpainted metal
in the appliance.
એ
Before removing the part from its package, touch the anti-static bag to a green ground connection
point or unpainted metal in the appliance.
એ
Avoid touching electronic parts or terminal contacts. Handle electronic control assembly by edges only.
એ
Observe above instructions when repackaging failed electronic control assembly in an anti-static bag.
ᵉ
Do not try to light a match, or cigarette, or turn on
any gas or electrical appliance.
ᵉ
Do not touch any electrical switches. Do not use any
phone in your building.
ᵉ
Clear the room, building or area of all occupants.
ᵉ
Immediately call your gas supplier from a neighborís
phone. Follow the gas supplierís instructions
carefully.
ᵉ
If you cannot reach your gas supplier, call the fire
department.
www.groupdynamics-laundry.com
CONTENTS
3
1. IMPORTANT SAFETY INSTRUCTIONS ............................................................................. 4
2. SPECIFICATIONS ............................................................................................................. 10
3. FEATURES AND BENEFITS ............................................................................................. 12
4. INITIAL STEPS FOR INSTALLING YOUR DRYER............................................................ 13
5. STACK MACHINE INSTALLATION INSTRUCTIONS ........................................................ 19
6. EXHAUST REQUIREMENTS AND MAINTENANCE ......................................................... 28
7. DRYER CYCLE PROCESS ............................................................................................... 32
8. COMPONENT TESTING INFORMATION ......................................................................... 33
9. MOTOR DIAGRAM AND SCHEMATIC .............................................................................. 36
10. CONTROL LAY - OUT ..................................................................................................... 37
11. WIRING DIAGRAM ........................................................................................................... 38
12. DIAGNOSTIC TEST.......................................................................................................... 39
12-1. TEST 1 240V AC ELECTRICAL SUPPLY ............................................................ 40
12-2. TEST 2 THERMISTOR TEST................................................................................ 43
12-3. TEST 3 MOTOR TEST ......................................................................................... 44
12-4. TEST 4 MOISTURE SENSOR............................................................................... 45
12-5. TEST 5 DOOR SWITCH TEST.............................................................................. 46
12-6. TEST 6 HEATER SWITCH TEST - ELECTRIC TYPE........................................... 47
12-7. TEST 7 GAS VALVE TEST - GAS TYPE .............................................................. 48
13. ERROR MODE ................................................................................................................ 49
14. CHANGE GAS SETTING (NATURAL GAS, PROPANE GAS) ........................................ 50
15. DISASSEMBLY INSTRUCTIONS .................................................................................... 52
16. EXPLODED VIEW ........................................................................................................... 60
16-1-1. Control Panel & Plate Assembly - Coin / OPL Type ............................................. 60
16-2-1. Cabinet & Door Assembly - Electric Stack Upper Type ........................................ 61
16-2-2. Cabinet & Door Assembly - Electric Stack Lower Type ........................................ 62
16-3-1. Drum & Motor Assembly: Electric Type ................................................................ 63
www.groupdynamics-laundry.com
4
1IMPORTANT SAFETY INSTRUCTIONS
Your Safety and the safety of others is very important.
You will be killed or seriously injured if you don’t immediately follow instructions.
You can be killed or seriously injured if you don’t follow instructions.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER,
WARNING or CAUTION. These words mean:
READ ALL INSTRUCTIONS BEFORE USE
For your safety, the information in this manual must be followed to minimize the risk of
fire or explosion, electric shock, or to prevent property damage, Injury to persons, or death.
DANGER:
WARNING:
WARING
You may be slightly injured or cause damage to the product if you do not follow
instructions. All safety messages will tell you what the potential hazard is, tell you how to reduce the
chance of injury, and tell you what can happen if the instructions are not followed.
CAUTION:
www.groupdynamics-laundry.com
Never stop a tumble dryer before the end of the drying cycle unless all
items are quickly removed and spread out so that the heat is dissipated.
WARNING:
•The lint trap has to be cleaned frequently, if applicable.
•Lint must not to be allowed to accumulate around the
tumble dryer.
•Adequate ventilation has to be provided to avoid the back
flow of gases into the room from appliances burring other
fuels, including open fires.
•Electric Dryer Max capacity is 10kg
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
BASIC SAFETY PRECAUTIONS
To reduce the risk of fire, electric shock, or injury to persons when using this appliance,
follow basic precautions, including the following:
WARNING:
•Read all instructions before using the dryer.
•Before use, the dryer must be properly installed as
described in this manual.
•Do not place items exposed to cooking oils in your dryer.
Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch fire.
•Do not dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive
substances as they g ive off vapors that could ignite or
explode.
•Do not reach into the dryer if the drum or any other part is
moving.
•Do not repair or replace any part of the dryer or attempt
any servicing unless specifically recommended in this
Service Manual or in published user-repair instructions that
you understand and have the skills to carry out.
•Do not tamper with controls.
•Before the dryer is removed from service or discarded,
remove the door to the drying compartment.
•Do not allow children to play on or in the dryer. Close
supervision of children is necessary when the dryer is used
near children.
•Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product.
•Do not use heat to dry articles containing foam rubber or
similarly textured rubber-like materials.
5
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
•Children should be supervised not to play with the
appliance.
•the tumble dryer is not to be used if industrial chemicals
have been used for cleaning
•Keep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint,
dust, and dirt.
•The interior of the dryer and exhaust vent should be
cleaned periodically by qualified service personnel.
•Do not install or store the dryer where it will be exposed
to the weather.
•Always check the inside of the dryer for foreign objects.
•Clean lint screen before or after each load.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol,petrol,kerosene,spot
removers, turpentine, waxes and wax removers should
be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•Items such as foam rubber(latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
•Fabric softeners, or similar products, should be used
as specified by the fabric softener instructions.
•The final part of a tumble dryer cycle occurs without
heat(cool down cycle) to ensure that the items are left
at a temperature that ensures that the items will not be
damaged.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
www.groupdynamics-laundry.com
6
•Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this appliance or
any other appliances.
•Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
1. Do not try to light a match or cigarette, or turn on
any gas or electrical appliance.
2. Do not touch any electrical switches. Do not use
any phone in your building.
3. Clear the room, building, or area of all occupants.
4. Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions carefully.
5. If you cannot reach your gas supplier, call the fire
department.
READ ALL INSTRUCTIONS BEFORE USE
WHAT TO DO IF YOU SMELL GAS: (Applicable for Gas models)
For your safety, the information in this manual must be followed to minimize the risk of
fire or explosion, electric shock, or to prevent property damage, Injury to persons, or death.
WARNING
Disposal of your old appliance
1.When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
2.All electrical and electronic products should be disposed of separately
from the municipal waste stream via designated collection facilities
appointed by the government or the local authorities.
3.The correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
4.For more detailed information about disposal of your old appliance,
please contact your city office, waste disposal service or the shop
where you purchased the product.
What is not covered.
Service trips to your home to instruct you on the product.
If the product is connected to any voltage other than that shown on the rating plate.
If the fault is caused by accidents, neglects, misuses of Acts of God.
If the fault is caused by reasons except for normal domestic use or use in accordance with the owner's
manual.
If the fault is caused by pests, for example, rats or cockroaches etc..
Noise or vibration that is considered normal,for example, water drain sound, spin sound or warning beeps.
Correcting the installation for example, leveling the product, adjustment of drain.
Normal maintenance recommended by the owner's manual.
Removal of foreign objects/substances from the machine including the pump and inlet hose filter, for
example, grit,nails, bra wires and buttons etc..
Replace fuses in or correct wiring or correct house plumbing.
Correction of unauthorized repairs.
Incidental or consequential damage to personal property caused by possible defects with this appliance.
If this product is used for commercial purposes, it is not warranted.
(Example:Public places such as public bathroom, lodging house, training center, dormitory)
If the product is installed outside the normal service area, any cost of transportation involved in the repair of
the products, or the replacement of a defective part, shall be borne by the owner.
www.groupdynamics-laundry.com
7
To reduce the risk of fire, electric shock, or injury to persons when using this
appliance, follow basic precautions, including the following:
WARNING
READ ALL INSTRUCTIONS BEFORE USE
For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death.
WARNING
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of
malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current. This appliance must
be equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug
must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with
all local codes and ordinances.
Do not use an adapter or extension cord. Do not
remove ground prong. If you don’t have the proper
outlet, consult an electrician.
Do not modify the plug provided with the appliance.
If it will not fit the outlet, have a proper outlet
installed by a qualified electrician.This appliance
must be connected to a grounded metal, permanent
wiring system or an equipment-grounding conductor
must be run with the circuit conductors and
connected to the equipment-grounding terminal or
lead on the appliance.
Electric shock can result if the dryer is not properly
grounded.
Improper connection of the equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to
whether the appliance is properly grounded.
SAFETY INSTRUCTIONS FOR INSTALLATION
•Properly ground dryer to conform with all
governing codes and ordinances. Follow details
in the installation instructions. Electric shock can
result if the dryer is not properly grounded.
•Before use, the dryer must be properly installed
as described in this manual.
Electric shock can result if the dryer is not properly
grounded.
•Install and store the dryer where it will not be
exposed to temperatures below freezing or
exposed to the weather.
•All repairs and servicing must be performed by
an authorized servicer unless specifically
recommended in this Service Manual. Use only
authorized factory parts. Failure to follow this
warning can cause serious injury, fire, electric
shock, or death.
•To reduce the risk of electric shock, do not
install the dryer in humid spaces. Failure to
follow this warning can cause serious injury, fire,
electric shock, or death.
•Connect to a properly rated, protected, and
sized power circuit to avoid electrical overload.
Improper power circuit can melt, creating electric
shock and/or fire hazard.
•Remove all packing items and dispose of all
shipping materials properly. Failure to do so can
result in death, explosion, fire, or burns.
•Place dryer at least 18 in. above the floor for a
garage installation. Failure to do so can result in
death, explosion, fire, or burns.
•Keep all packaging from children. Packaging
material can be dangerous for children. There is
a risk of suffocation.
•Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc. Failure to do
so can result in fire.
•Do not place candles, smoking materials, or
other flammables on to top of the product.
Dripping wax, smoke, or fire can result.
•Remove all protective vinyl film from the
product. Failure to do so can cause product
damage, smoke or fire.
•Means for disconnection with contact
separation at least 3mm is that the means for
disconnection must be incorporated in the fixed
wiring according to the wiring rules.
WARNING
www.groupdynamics-laundry.com
8
READ ALL INSTRUCTIONS BEFORE USE
For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death.
WARNING
SAFETY INSTRUCTIONS FOR INSTALLATION
Exhaust/Ducting:
•Gas dryers MUST be exhausted to the outside.
Failure to follow these instructions can result in fire
or death.
•The dryer exhaust system must be exhausted
to the outside of the dwelling. If the dryer is
not exhausted outdoors, some fine lint and
large amounts of moisture will be expelled into
the laundry area. An accumulation of lint in any
area of the home can create a health and fire
hazard.
•Use only rigid metal or flexible metal 4-inch
(10.2 cm) diameter ductwork inside the dryer
cabinet or for exhausting to the outside. Use of
plastic or other combustible ductwork can
cause a fire. Punctured ductwork can cause a fire
if it collapses or becomes otherwise restricted in
use or during installation.
•Ductwork is not provided with the dryer, and
you should obtain the necessary ductwork
locally. The end cap should have hinged
dampers to prevent backdraft when the dryer
is not in use. Failure to follow these instructions
can result in fire or death.
•Acarpet must not obstruct the openings.
•Exhaust air must not be discharged into a flue
which Is used for exhausting fumes from
appliances burning gas or other fuels.
•The exhaust duct must be 4 inches (10.2 cm) in
diameter with no obstructions. The exhaust
duct should be kept as short as possible. Make
sure to clean any old ducts before installing
your new dryer. Failure to follow these
instructions can result in fire or death.
•Rigid or semi rigid metal ducting is
recommended for use between the dryer and
the wall. In special installations when it is
impossible to make a connection with the
above recommendations, a UL-listed flexible
metal transition duct may be used between the
dryer and wall connection only. The use of this
ducting will affect drying time. Failure to follow
these instructions can result in fire or death.
•DO NOT use sheet metal screws or other
fasteners which extend into the duct that could
catch lint and reduce the efficiency of the
exhaust system. Secure all joints with duct
tape. For complete details, follow the
Installation Instructions. Failure to follow these
instructions can result in fire or death.
•In the appliance enclosure or in the built-in
structure, keep ventilation opening clear of
obstruction.
•For appliances with type Y attachment, if the
supply cord is damaged, it must be replaced
by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
•The new hose-sets supplied with the appliance are
to be used and that old hose-sets should not be
reused
•That the appliance must not be installed behind a
lockable door, a sliding door or a door with a hinge
on the opposite side to that of the tumble dryer, in
such a way that a full opening of the tumble dryer
door is restricted.
www.groupdynamics-laundry.com
9
READ ALL INSTRUCTIONS BEFORE USE
SAVE THESE INSTRUCTIONS
For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death.
WARNING
SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY
To reduce the risk of fire, electric shock, or injury to persons when using this
appliance, follow basic precautions, including the following:
WARNING:
•Do not, under any circumstances, cut or
remove the ground prong from the power cord.
To prevent injury to persons or damage to the
dryer, the electrical power cord must be plugged
into a properly grounded outlet.
•For personal safety, this dryer must be
properly grounded. Failure to do so can result in
electric shock or injury.
•Refer to the installation instructions in this
manual for specific electrical requirements for
your model. Failure to follow these instructions
can create an electric shock hazard and/or a fire
hazard.
•This dryer must be plugged into a properly
grounded outlet. Electric shock can result if
the dryer is not properly grounded. Have the
wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded. Failure to follow these instructions can
create an electric shock hazard and/or a fire
hazard.
•The dryer should always be plugged into its
own individual electrical outlet which has a
voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
•Never unplug your dryer by pulling on the
power cord. Always grip plug firmly and pull
straight out from the outlet. The power cord can
be damaged, resulting in a risk of fire and electric
shock.
•Repair or replace immediately all power cords
that have become frayed or otherwise
damaged. Do not use a cord that shows cracks
or abrasion damage along its length or at
either end. The power cord can melt, creating
electric shock and/or fire hazard.
•When installing or moving the dryer, be careful
not to pinch, crush, or damage the power cord.
This will prevent injury and prevent damage to the
dryer from fire and electric shock.
•To reduce the risk of injury to persons, adhere
to all industry recommended safety
procedures including the use of long sleeved
gloves and safety glasses. Failure to follow all of
the safety warnings in this manual could result in
property damage, injury to persons or death.
www.groupdynamics-laundry.com
10
■Type : Electric Dryer
■Rating : Please refer to the rating label regarding detailed information.
■Single dryer size : 686mm(W) x 764mm(D) x 983mm(H)
■Stack dryer size : 686mm(W) x 764mm(D) x 1954mm(H)
■Electric Dryer Max capacity : 10kg
■Weight : 59,4 kg
❋ Specifications are subject to change by manufacturer.
2SPECIFICATIONS
www.groupdynamics-laundry.com
11
ITEM REMARK
TYPE
POWER SUPPLY
CONTROL TYPE
DRUM CAPACITY
Weight (lbs.) - Net/Gross
No. of Programs
Audible End of Cycle Beeper
Time dry
Reversible Door
Drum
Product (WxHxD)
Packing (WxHxD)
230 V / 50 HZ
Blue white
Painted
Stainless Deco (Hair line)
Chrom
Blue white
Input 540W/Output 250W (2,3A)
5400W (24A) -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Electronic
Gas type:
Gas category:
Gas pressure:
Burner pressure:
Flue class:
Nominal heat input:
Gas rate:
126/144
4
Available
Available
Available
Stainless Steel
686mm(W) x 764mm(D) x 983mm(H)
744mm(W) x 385mm(D) x 1140mm(H)
Color
MATERIAL &
FINISH
ELECTRICITY
CONSUMPTION
Top Plate
Door Trim
Door Frame
C/Panel Color
MOTOR
HEATER
GAS VALVE
Electric
220V~240V
Porcelain : SD205C/SD205H
AC 230V
Gas
10Kg
SD205C
SD205HS
SD205H
-
www.groupdynamics-laundry.com
1. DISPLAY LED
2. CYCLE BUTTON
3. START BUTTON
4. STATUS LED
1 24
3
1 24
3
12
3FEATURES AND BENEFITS
■ COIN / OPL TYPE
- SIDE BY SIDE(SD205C, SD205H)
■ COIN TYPE
- STACK UPPER(SD205HS)
www.groupdynamics-laundry.com
13
4
INITIAL STEPS FOR INSTALLING YOUR DRYER
The following instructions will help guide you through the initial steps of setting up your dryer for use.
Please note that every section of this manual provides important information regarding the preparation and
use of your dryer, and it is important that you review this entire manual before proceeding with any
installation or use. More detailed instructions concerning electrical connections, gas connections, and
exhaust requirements are provided at other parts of this manual.
Choose a location with a solid floor for your dryer.
Place the dryer at least eighteen inches above the
floor for a garage installation. After placing the
dryer in the desired location, please make sure that
it has the required clearances shown below, and
sections on xhaust and Maintenance requirements.
* Most installations require a minimum 5 1/2 in.
(14 cm) clearance behind the dryer for the exhaust
vent with elbow.
38,7°±
(98,3 cm)
27°±
(68,6 cm)
29,96°±
(76,4 cm)
49,8°±
(126,4 cm)
Level the d
the adjusting nuts
If the d
properly and the sensor will not be able to de tect
the dryness level accuratel
Adjust the le
Note
No other fuel-burning appliance shall be installed
in the same
This applies only
in a closet.
WARNING
The applian ces are heavy.
Two or more people a re requi
or installing the appliance.
There is a risk of serious back injury or other injuries.
Note
Those required minimum clearances
are set forth in the picture below. Please also keep the
following instructions in mind when installing in a
closet or recessed area:
Consider allowing additional clearance for
installation and servicing.
Wall, door and floor molding may force additional
clearances.
An additional inch of clearance is recommended to
minimize noise transfer .
Consider space needed for companion appliances.
For closet installations, the picture below shows the
minimum required ventilation openings for the door.
A louvered door with comparable ventilation openings
is also acceptable.
roodtesolCweivediS-tesolC
ryer using the leveling legs and tighten
to hold them in place.
ryer is not level, the clothes will not tumble
y.
veling legs carefully to avoid injury.
closet as the drye r.
to dryers suitable for installation
red when moving
Closet-Front view Stacking Kit view
All four legs should be placed firmly on a solid
and even floor.
STEP 1
Positioning the Dryer.
www.groupdynamics-laundry.com
14
Once in position, adjust the leveling legs of the dryer
until it is level from left to right and from front to
back. The leveling legs must remain firmly on the
floor and the dryer should not rock. The maximum
slope of the dryer from left to right or from front to
back should not exceed 2,5 cm (1 inch . If the dryer
is not level, and if the slope exceeds 2,5 cm (1 inch ,
a load may not tumble properly and internal sensors
may malfunction. Note: Other sections of this
manual also provide important information
concerning the placement of and clearances for your
dryer. Please review this entire manual before
To ensure that the dryer provides optimal drying
performance, it must be level. To minimize
vibration, noise, and unwanted movement, the
floor must be a perfectly level, solid surface.
NOTE: Adjust the leveling feet only as far as
necessary to level the dryer. Extending the
leveling feet more than necessary can cause
the dryer to vibrate.
WARNING
w
Use an adjustable or open ended spanner to
turn the leveling feet. Turn clockwise to raise
the dryer or counter clockwise to lower it
Raise or lower the leveling feet until dryer is
level from side to side and front to back.
Make sure that all 4 leveling feet are in firm
contact with the floor.
All four leveling feet must rest solidl y on the
floo r. Gently push on the top corners of the
dryer to make sure that the dryer does not
rock f rom co rner to co rner.
If you are installing the dryer
pedestal, you must use the leveling feet on the
pedestal to level thedryer. The dryer leveling feet
should be fully retracted.
Leveling Feet
Position the dryer in the final location. Place
a level across the top of the dryer.
on the optional
STEP 2
LEVELING the Dryer.
www.groupdynamics-laundry.com
15
STEP 3
Procedure for Reversing
the Door
The door on your dryer can be installed to open
either to the left or the right. Follow these
procedures to reverse the direction in which your
door opens:
!
Door and latch should be aligned at the center
when closed. Otherwise, the door will not open,
close, or latch properly.
Note
www.groupdynamics-laundry.com
16
In addition to the following warnings, please refer to
manual section on Exhaust Requirements and
Maintenance.
To reduce the risk of fire,
combustion, and gas accumulation, the dryer must be
vented to the outdoors. lease follow the instructions
(and all others in this manual) very carefully.
Do not use plastic or thin foil duct.
Use 4" (10,2 cm) diameter rigid or semi-rigid
metal duct (note: venting materials are not
supplied with the dryer, and you must obtain the
venting materials necessary for proper installation)
osition the dryer so the exhaust duct run is as
short as possible.
The male end of each section of exhaust duct must
point away from the dryer
Use as few elbow joints as possible.
Use duct tape on all duct joints
Insulate ductwork that runs through unheated
areas in order to reduce condensation and lint
build-up on pipe walls; and
WARNING
! " !#$ %"& '## ( )
$* "'" '% * '" ! +& , )
-+'" " '--#'* !+ & * # '## )
"+ ( +"' ' $(.$"#% )
+/0'- +'" + *'+
!
1.
2-1.
f@
@@
@QL@
@RL@
@@
@SL@
@@
@
N
2-2.
! ""#$%%&'
3-1.
() *+ &%,
3-2.
- .
Incorrect installation of the vent and improper
taping of the joints will interfere with correct
dryer and vent function.
Note
facing away from the dryer.
*+ &%, / 0
smaller ends
Vent pipe and fittings must be installed with the
STEP 4 Connecting the Exhaust
and Venting System.
www.groupdynamics-laundry.com
17
electric shock
STEP 5
Connection of Gas Supply
STEP 6
Electrical Plug Connection
www.groupdynamics-laundry.com
18
Prior to the first use of this appliance, use all-
purpose cleaning products or a solution of detergent
and water, with damp clothes to remove from the
inside of the dryer drum/drying compartment any
dust or dirt that may have accumulated the inside of
the dryer. Plug-in your dryer after reviewing the
following parts on your dryer's
Requirements.
Effective dryer operation requires appropriate dryer
airflow. The adequacy of the airflow can be
measured by evaluating the static pressure. tatic
pressure in the exhaust duct can be measured with a
manometer, placed on the exhaust duct
approximately 2 ft. (60,9 cm) from the dryer. tatic
pressure in the exhaust duct should not exceed 0,6
inches (1,5 cm). The dryer should be checked with
the dryer running with no load.
Close the door to the dryer drum/drying
compartment and, after completing all steps in this
manual for proper installation of this dryer, start the
dryer on a heat setting, as described more fully in
the operating instructions that accompany the dryer.
After the dryer starts, the igniter will glow red and
the main burner will ignite.
Close the door to the dryer drum/drying
compartment and, after completing all steps in this
manual for proper installation of this dryer, start the
dryer on a heat setting, as described more fully in
the operating instructions that accompany the dryer.
The exhaust air or the exhaust pipe should be warm
after the dryer has been operating for three minutes.
0,6 inche (1,5 cm)
!
WARNING
" # $ ## "
%% %% # %
&
!
Note
If all air is not purged from the gas line,
the gas igniter may go off before the gas and the
main burner have ignited. If this happens, the
igniter will re-attempt gas ignition after
approximately two minutes.
Electrical
STEP 7
Preparation of the Dryer
STEP 9
Dryer Airflow
STEP 8
Confirming Heat Source
Operation
www.groupdynamics-laundry.com
5
STACK MACHINE INSTALLATION INSTRUCTIONS
19
11
SUITABLE MODEL FOR STACKING
STACK
POSITION
UPPER LOWER
Washer Dryer
Dryer
SUITABLE
MODEL SD205HS SD105CS -
- This machine can be stacked only on the model designated as suitable by LGE.
- Do not stack the washer on the top.
Note
www.groupdynamics-laundry.com
This manual suits for next models
2
Table of contents
Other Group Dynamics Dryer manuals
