Group Dynamics TS 62 Guide
Service manual and spare parts list
549225
Drying cabinet with 8 kg cloth capacity
www.groupdynamics-laundry.com
22011
Thank you for choosing our drying cabinet. We hope that it will be
of great use for you.
www.groupdynamics-laundry.com
32011
Contents
Specification 4
Dimensions 4
Technical information 5
Main control board 5
Service menu 5
Parameter list 6
Explanation of parameters 7
Error codes 8
Spare parts list 9
Cabinet 9
Top 10
Electrical drawing 11
www.groupdynamics-laundry.com
42011
Dimensions
Specification
200
1870
1200
242
469
1855
1453
640
A
B
A = Electrical connection
B= Exhaust
www.groupdynamics-laundry.com
52011
Technical information
Loading capacity, kg (lb) up to 8 (17,6)
Drying capacity, g/min (oz/min)* 91 (3,2)
Hanging length, m (ft) 16 (52,5)
Drying time, min* 35
Evacuated air, max, m³/h (ft³/h) 340 (12007)
Exhaust Ø, mm (in) 125 (4,92)
Heating effect, kW 6,0
Total effect, kW 6,3
Energy consumption, kWh/kg (kWh/lb)* 0,55 (0,48)
Part No 131025
*Drying of 6 kg (13,2 lb) cotton (dry weight), washed and high-spinned to 53%
residual moisture. The cabinet works another 15 minutes with cool-down after
the textiles are dry.
Main control board
This drying cabinet can be customized by adjusting the main
control board´s parameters. The following pages describe how
to adjust the parameters.
Service menu
Activate the service menu
To enter the service menu; press both left arrow buttons in
about 5 seconds. The LCD-display shows the software version
installed on the control board.
Push the START-button, 5 times continuously, to enter the pa-
rameter list.
Navigate in the service menu
To browse in the parameter list, use the two top buttons.
Change parameter values
Depending on if the present parameter shows temperature,
time or ON/OFF-function, the present value is either shown on
the left or on the right side of the LCD-display. To change the
value, use the arrow buttons.
Leave the service menu
Push the start button.
www.groupdynamics-laundry.com
62011
Parameter list
Parameter Alternative Factory position
LANGUAGE SWE/ENG/FRE/GER/SPA ENG
MODEL TS 62/T 196/TS 92/DC 8 TS 62
RESET YES -
DEGREE UNIT C/F C
MIN TEMP [-- --], 25 -> [MED-5] 40
MED TEMP [MIN + 5] -> [MAX-5] 60
MAX TEMP [MED + 5]-90 80
DEF TEMP MIN/MED/MAX MAX
SHOW DEGREES ON/OFF ON
MAX TIME 1:00-09:59 03:00
DEF TIME 0:00-[MAX TID] 00:40
DELAY START ON/OFF OFF
AUTOPROG OFF, 1-9 2
PR1 TEMP MIN/MED/MAX MAX
PR1 HU STOP 0-995 65
PR2 TEMP MIN/MED/MAX MAX
PR2 HU STOP 0-995 490
HYST TEMP 0-20 10
COOL DOWN 0:00-0:20 00:15
SHOW TEMP+HU ON/OFF OFF
SHOW LOGO ON/OFF ON
SOUND ON/OFF ON
STANDBY ON/OFF ON
LIGHT TIME 0:00-0:30 00:10
PAUSE TIME 0:00-0:30 00:10
COIN ON/OFF OFF
SIGNAL TYPE PLS/N-0 N-O
WORK TIME - [000000] h
TEST LOOP ON/OFF OFF
CLEAR E-CODE YES -
www.groupdynamics-laundry.com
72011
LANGUAGE
The drying cabinet is delivered with English display text as
standard. Choose between Swedish, English, French, German
and Spanish.
MODEL
Choice of product model. Shall always be in position TS 62.
RESET
Resets all parameters to initial factory position.
DEGREE UNIT
Degrees can be displayed in Celsius or Fahrenheit.
MIN TEMP
Setting of minimum temperature level in manual mode. “----“
means that the heating is off. The highest possible degree to be
chosen is affected by parameter MED TEMP.
MED TEMP
Setting of medium temperature level in manual mode. Choice
of temperature level is affected by the value of both MIN and
MAX TEMP.
MAX TEMP
Setting of maximum temperature level in manual mode. Lowest
temperature level to choose is affected by the value of param-
eter MED TEMP.
DEF TEMP
Sets the default temperature when the user enters manual
mode.
SHOW DEGREES
Manual mode shows the chosen temperature in degrees. This
function can be turned off so that only the symbol on the ther-
mometer is shown.
MAX TIME
Setting of time in manual mode. Maximum 9h 59 minutes.
DEF TIME
This parameter controls the time which is default when the user
enters manual mode.
DELAY START
This parameter activates delayed start. If the parameter is set to
”ON” the user is given the choice to delay the programme start
with up to 9h 59min.
AUTOPROG
It is possible to activate up to nine automatic programmes. De-
fault from factory; two pre-programmed choices:
Programme 1 = WARDROBE DRY
Programme 2 = IRON DRY
Each programme has two parameters TEMP and HU STOP.
When AUTOPROG is set in mode “OFF” the automatic pro-
grammes is inactivated. If the user choose automatic mode, the
display shows “INACTIVATED”.
PR# TEMP
Every automatic programme can be adjusted by choosing
temperatures MIN, MED, MAX. The temperature values are the
same as parameters MIN TEMP, MED TEMP and MAX TEMP.
PR# HU STOP
HU STOP affects the automatic drying function. Can be chan-
ged if needed. If the value of HU STOP is decreased, the drying
time is prolonged for the automatic programme.
HYST TEMP
It controls the hysteresis. The drying cabinet is preset to 10ºC.
When the working temperature is attained and the heating ele-
ments are turned off, it will be a delay. When the temperature
hits 10ºC, the heating starts again. Shorter hysteresis increase
the energy consumption.
COOL DOWN
After the heating phase, the cabinet has a period of cool down
to recondition the laundry and lower the temperature within the
cabinet. The time is set to 15 minutes. PLEASE NOTE! Without
a sufficient cool down period, the inner plates of the cabinet
will be very hot.
SHOW TEMP+HU
This parameter is for error searching. If set in mode “ON” the
cabinet will show current temperature and air humidity by re-
spective sensors.
SHOW LOGO
Turns on and off the logo on the top of the LCD-display.
SOUND
This parameter controls if the sound shall be on or off. In mode
“ON” you can hear a distinct “beep-noise” every time the but-
tons are pushed or when a drying period is ended.
STANDBY
In position “ON”, the display background light is automatically
turned off if no button is pushed for two minutes. The display
light is turned on when any button is pushed or if the doors are
opened. In position “OFF” the light is constantly off.
LIGHT TIME
When the doors open, the light inside the cabinet is turned on.
With the parameter LIGHT TIME you set how long the light will
be on, if the doors are left opened. When the time is up, the
lamp is turned off automatically.
PAUSE TIME
If the doors are opened during drying, the drying programme
is paused. Are the doors left opened for a long time, the pro-
gramme will stop. The time is adjustable from 0 – 30 minutes.
will stop the programme as soon as the doors are opened.
PLEASE NOTE! If the parameter is set to 0 minutes, the cabinet
Explanation of parameters
www.groupdynamics-laundry.com
82011
COIN
The cabinet can be connected to a booking system. To acti-
vate the function, set the parameter in position “ON”. To start a
programme, a connection to the control board’s COIN-contact
is needed.
SIGNAL TYPE
This parameter is only visible if COIN is activated. COIN is used
when the cabinet is connected to a booking system. Choose
position depending on which type of signal the booking system
is sending. “PLS” stands for pulse and means that the cabinet
is booked per drying period. One pulse gives one drying period.
“N-O” is chosen when the signal is either on or off. The current
programme will always run until finished even if the signal is
broken during the programme.
WORK TIME
The parameter shows the total amount of hours the cabinet
has been on. It is also memorized if the electricity to the control
board is broken.
TEST LOOP
Start the test programme by changing the parameter to “ON”.
The programme can be used to control the components in the
cabinet. Parts are activated as follows: To go to the next step,
press arrow button. The programme goes automatically to the
next level after 30 seconds.
1. Fans connected to FAN1
2. External fan connected to FAN2 (optional)
3. Heating on
4. All segments on LCD-display are lit and the background
light flashes
5. The temperature sensor shows current temperature
6. The humidity sensor shows current air humidity
CLEAR E-CODE
Is used to erase an e-code in the display, after the problem has
been solved. Press the right arrow button.
Disp Reason Activity
T1 Control board gets no
signal from the tempera-
ture sensor.
Control that the sensor is
connected correctly on
the main control board
and that the cable from
the sensor to the board is
intact.
OH The control board’s elec-
tronically overheat protec-
tion has been activated.
The error code is gener-
ated if the temperature is
risen above 100ºC, twice
within 30 minutes.
Control that the fan mo-
tors are working as they
should. Also control the
temperature sensor and
that the cable from the
board is intact.
HU The control board gets no
signal from the humidity
sensor.
Control that the sensor is
connected correctly on
the main control board
and that the cable from
the sensor to the board is
intact.
Error codes
www.groupdynamics-laundry.com
92011
Spare parts list
Cabinet
No Part No Description
1TS 61084 Door left
2TS 61085 Door right
3TS 61086 Handle
4TS 61099 Service door lower, left
5TS 61096 Service door lower, right
6TS 61081 Lamp/Bulb
770107001 Door switch
8TS 61089 Magnet list
90110151-2 Display control board
10 TS 61090 Cover glass
11 0110152 Keypad
12 011053 Sticker user manual
13 TS 61091 Hanging frame
14 TS 61093 Hanging level 4-arms
15 TS 61092 Hanging level 5-arms
16 TS 61094 Foot
17 TS 61097 Protection plate
Detailed view A
www.groupdynamics-laundry.com
102011
No Part No Description
1TS 61080 Element 2000 W
2E 150020 Fan motor
30110155-2 Temperature sensor
4TS 61026 Over heat protection 120ºC
5504142 Relay LC1-D12P7 230 V
6TS 61082 Disturbance filter
70110154-2 Humidity sensor
8TS 61083 Condenser
90110150-2 Main control board
10 TS 61098 Service door upper
Top
www.groupdynamics-laundry.com
11 2011
Electrical drawing
R1-3
RELAY EXT FAN (OPTION)
HEATING ELEMENT
R1-R3
KF1
KF2
T1 CONDENSATOR 1
CONDENSATOR 2
THERMOSTAT (OPTION)
FAN MOTOR
M2
NTC1
H1
L1
B2
B1
K3
K2
K1
THERMISTOR
HUMIDITY SENSOR
MICRO SWITCH
LIGHT
MICRO SWITCH
RELAY FAN
RELAY HEAT
M1 FAN MOTOR LAMP
15
L1 X1
X2
KK1
13
14
13
14
B2
17
NTC1
+-
16
B1
13
14
H1 1
2
DOOR NTC1
HEATER
MAIN FAN1
CN2
FAN2
K1
34
56
12
2
7
8
I0528105-2
3 400V N 50/60Hz
L3
L2
L1
N
1
N
L1
M1
L1
M2
N
KF1 KF2
K2
1
2
9
18
T1 120 C
2
1
6 5
o
K1 A2
A1
11
10
K3 A1
A2
K2 A1
A2
12
www.groupdynamics-laundry.com
