Grundig GDH 80 Y User manual

EN
www.grundig.com
DRYER
USER INSTRUCTIONS
GDH 80 Y

2
1 Please read this user manual
first 3
2 Important instructions for
safety and environment 4
2.1 General safety .....................4
2.1.1 Electrical safety..............5
2.1.2 Product safety ................6
2.2 Mounting over a washing
machine ....................................8
2.3 Intended use........................9
2.4 Child safety ......................... 9
2.5 Compliance with the WEEE
regulation and disposing of the
waste product: ........................ 10
2.6 Compliance with RoHS
Directive information .............. 10
2.7 Package information......... 10
2.8 Technical Specifications.... 11
3. Your Dryer 12
3.1 Package Contents ............. 12
4. Installation 13
4.1 Appropriate installation
location.................................... 13
4.2 Removing the transportation
safety assembly ...................... 14
4.3 Under counter installation 14
4.4 Connecting to the drain..... 14
4.5 Adjusting the feet .............. 15
4.6 Electrical connection ........ 15
4.7 Transporation of the dryer 15
4.8 Warnings about sounds .... 16
4.9 Changing the illumination
lamp ........................................ 16
5. Preparation 17
5.1 Laundry suitable for drying in
the dryer.................................. 17
5.2 Laundry not suitable for
drying in the dryer .................. 17
5.3 Preparing laundry for
drying ...................................... 17
5.4 Things to be done for energy
saving ...................................... 17
5.5 Correct load capacity ........ 18
6. Operating the product 17
6.1 Control panel..................... 19
6.2 Screen symbols................. 19
6.3 Preparing the machine ..... 20
6.4 Program selection............. 20
6.5 Program selection and
consumption table .................. 21
6.6 Auxiliary functions ............ 23
6.7 Warning symbols............... 23
6.8 End duration...................... 24
6.9 Starting the program ........ 25
6.10 Child Lock........................25
6.11 Changing the program after
it is started .............................. 25
6.12 Canceling the program ... 26
6.13 Program end ................... 26
7. Maintenance and cleaning 27
7.1 Cleaning Lint Filter / Loading
Door Inner Surface ................. 27
7.2 Cleaning the sensor ......... 28
7.3 Draining the water tank .... 28
7.4 Cleaning the filter drawer 29
7.5 Cleaning the evaporator.... 31
TABLE OF CONTENTS

3
EN
1. Please read this user manual first!
Dear Customer,
Thank you for prefering a Grundig product. We hope that your product
which has been manufactured with high quality and technology will
give you the best results. We advise you to read through this manual
and the other accompanying documentation carefully before using your
product and keep it for future reference. If you transfer the product
to someone else, give its manual as well. Pay attention to all details
and warnings specified in the user manual and follow the instructions
given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and
property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste
or other wastes, discard them to the dedicated collection points
designated by the local authorities.

4
2. Important instructions for safety and
environment
This section contains safety instructions that will help protect
from risk of personal injury or property damage. Failure to follow
these instructions shall void any warranty.
2.1 General safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the ha-
zards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by child-
ren without supervision.
• Children of less than 3 years should be kept away unless
continously supervised.
• Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced with materi-
als such as carpet, wood and tape. This will cause problems
with the dryer.
• Always have the installation and repairing procedures car-
ried out by the Authorized Service. Manufacturer shall not
be held liable for damages that may arise from procedures
carried out by unauthorized persons.
• Never wash the dryer by spraying or pouring water onto it!
There is the risk of electric shock!

5
EN
2.1.1 Electrical safety
AElectrical safety instructions should be followed while
electrical connection is made during the installation.
• Connect the dryer to a grounded outlet protected by a fuse
at the value specified on the type label. Have the grounding
installation performed by a qualified electrician. Our com-
pany shall not be liable for any damages that will arise when
the dryer is used without grounding in accordance with the
local regulations.
• The voltage and allowed fuse protection is stated on the type
label plate.
• The voltage specified on the type label must be equal to your
mains voltage.
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation, main-
tenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by pul-
ling on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to con-
nect the dryer to power supply in order to decrease the risk
of fire and electric shock.
• Power cable plug must be easily accessible after installati-
on.
AThe appliance must not be supplied through an external
switching device, such as a timer,or connected to a circuit
that is regularly switched on and off by utility.
BDamaged mains cable should be changed notifying the
Authorized Service.

6
BIf the dryer is faulty, it must not be operated unless it is
repaired by an authorized service agent! There is the risk
of electric shock!
2.1.2 Product safety
A• Ensure that the air inlet of the dryer is open and it is
well-ventilated.
• Product contains R290 refrigerant.
• R290 is an environment-friendly, but flammable
refrigerant.
• Keep the product away from potential heat sources
that may cause it to ignite.
Points to be taken into consideration for fire hazard:
Below specified laundry or items must not be dried
in the dryer considering fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone, alcohol, fuel oil, ke-
rosene, stain removers, turpentine, paraffin or pa-
raffin removers must be washed in hot water with
plenty of detergent before being dried in the dryer.
For this reason especially the items containing the above
specified stains must be washed very well, to do this use
adequate detergent and choose a high washing
temperature.

7
EN
Below specified laundry or items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with rubber foam (la-
tex foam), shower bonnets, water resistant textiles,
materials with rubber reinforcement and rubber
foam pads.
• Clothing cleaned with industrial chemicals.
Items such as lighter, match, coins, metal parts, needle
etc. may damage the drum set or may lead to functional
problems. Therefore check all the laundry that you will
load into your dryer.
Never stop your dryer before the programme completes.
If you must do this, remove all laundry quickly and lay
them out to dissipate the heat.
Clothes that are washed inadequately may ignite on their
own and even may ignite after drying ends.
• You must provide enough ventilation in order to prevent ga-
ses exiting from devices operating with other types of fuels
including the naked flame from accumulating in the room
due to the back fire effect.
AUnderwear that contains metal reinforcements should
not be dried in the dryer. Dryer may be damaged if metal
reinforcements come loose and break off during drying.
CUse softeners and similar products in accordance with
the instructions of their manufacturers.
CAlways clean the lint filter before or after each loading.
Never operate the dryer without the lint filter installed.
• Never attempt to repair the dryer by yourself. Do not per-
form any repair or replacement procedures on the product
even if you know or have the ability to perform the required
procedure unless it is clearly suggested in the operating ins-

8
tructions or the published service manual. Otherwise, you
will be putting your life and others’ lives in danger.
• There must not be a lockable, sliding or hinged door that
may block the opening of the loading door in the place whe-
re your dryer is to be installed.
• Install your dryer at places suitable for home use.
(Bathroom, closed balcony, garage etc.)
• Make sure that pets do not enter the dryer. Check the inside
of the dryer before operating it.
• Do not lean on the loading door of your dryer when it is
open, otherwise it may fall over.
• The lint must not be allowed to accumulate around the
tumble dryer
2.2 Mounting over a washing machine
• A fixing device should be used between the two machines
when installing the dryer above a washing machine. The
fitting device must be installed by the authorized service
agent.
• Total weight of the washing machine and the dryer -with full
load- when they are placed on top of each other reaches to
approx. 180 kilograms. Place the products on a solid floor
that has sufficient load carrying capacity!
AWashing machine cannot be placed on the dryer. Pay
attention to the above warnings during the installation on
your washing machine.
Installation Table for Washing Machine and Dryer

9
EN
Dryer Depth
Washing Machine Depth
62 cm 60 cm 54 cm < 50 cm
54 cm Can be installed Cannot be installed
60 cm Can be installed Cannot be installed
2.3 Intended use
• Dryer has been designed for domestic use. It is not suitable
for commercial use and it must not be used out of its inten-
ded use.
• Use the dryer only for drying laundry that are marked accor-
dingly.
• The manufacturer waives any responsibility arisen from in-
correct usage or transportation.
• The service life of the dryer that you purchased is 10 years.
During this period, original spare parts will be available to
operate the dryer properly.
2.4 Child safety
• Packaging materials are dangerous for the children. Keep
packaging materials away from children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is operating. Do not
let them tamper with the dryer. Use the child-proof lock in
order to prevent the children to tamper with the dryer.
CChild-proof lock is on the control panel. (See Child lock)
• Keep loading door closed even when the dryer is not in use.

10
2.5 Compliance with the WEEE regulation and disposing of the
waste product
This product complies with EU WEEE Directive (2012/19/
EU). This product bears a classification symbol for waste
electrical and electronic equipment (WEEE).
This product has been manufactured with high quality
parts and materials which can be reused and are suitable
for recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take it to
the collection center for the recycling of electrical and electronic
equipment. Please consult your local authorities to learn about
these collection centers.
• R290 is an flammable refrigerant. Thus, ensure that
the system and the pipes are not harmed during
operation and handling.
• Keep the product away from potential heat sources
that may cause it to ignite in case of damage.
• Do not dispose of the product by putting it in fire.
2.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
2.7 Package information
Packaging materials of the product are manufactured from
recyclable materials in accordance with our National Environment
Regulations. Do not dispose of the packaging materials together
with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.

11
EN
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 65,4 cm
Capacity (max.) 7 kg**
Net weight (± 4 kg) 51 kg
Voltage
See type label***Rated power input
Model code
2.8 Technical Specifications
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** For the location of the type label on the dryer.
CTechnical specifications of the dryer are subject to
specification without notice to improve the quality of the
product.
CFigures in this manual are schematic and may not match
the product exactly.
C
Values stated on markers on the dryer or in the other
published documentation accompanying with the dryer
are obtained in laboratory in accordance with the relevant
standards. Depending on operational and environmental
conditions of the dryer, these values may vary.

12
3. Your Dryer
3.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

13
EN
4. Installation
Before the calling the nearest
Authorized Service for the
installation of the dryer, ensure that
electrical installation and water drain
is appropriate referring to the user’s
manual. If they are not suitable,
contact a qualified electrician and
technician to make necessary
arrangements.
CPreparation of the dryer's
location as well as the
electrical and waste water
installations is under
customer's responsibility.
APrior to installation, visually
check if the dryer has any
defects on it. If the drier
is damaged, do not have
it installed. Damaged
products cause risks for
your safety.
ALet your dryer wait for 12
hours before starting to use
it.
4.1 Appropriate installation
location
• Install the dryer on a stable and
level surface.
• Dryer is heavy. Do not move it by
yourself.
• Operate your dryer in a well
ventilated, dust-free environment.
• The gap between the dryer and
the surface should not be reduced
by the materials such as carpet,
wood and tape.
• Do not cover the ventilation grills
of the dryer.
• There must not be a lockable,
sliding or hinged door that may
block the opening of the loading
door in the place where your
dryer is to be installed.
• Once the dryer is installed, it
should stay at the same place
where its connections have been
made. When installing the dryer,
make sure that its rear wall does
not touch anywhere (tap, socket,
etc.).
• Place the dryer at least 1 cm
away from the edges of other
furniture.
• Your dryer can be operated at
temperatures between +5°C and
+35°C. If the operating conditions
fall outside of this range,
operation of the dryer will be
adversely affected and it can get
damaged.
• The rear surface of the tumble
dryer shall be placed against a
wall.
BDo not place the dryer on
the power cable.
* Ignore following warning if your
product’s system does not contains
R290.
Dryer contains R290
refrigerant.*
R290 is an environment-
friendly, but flammable
refrigerant.*
Ensure that the air inlet of
the dryer is open and it is
well-ventilated.*
Keep potential flame
sources away from the
dryer.*

14
4.2 Removing the transportation
safety assembly
ARemove the transportation
safety assembly before
using the dryer for the first
time.
Open the loading door.
There is a nylon bag inside the drum
that contains a piece of styrofoam.
Hold it from its section marked with
XX XX.
Pull the nylon towards yourself and
remove the transportation safety
assembly.
ACheck that no part of
the transportation safety
assembly remains inside the
drum.
4.3 Under counter installation
This product can be installed under a
counter if the height of the counter is
sufficient.
AWhile using undercounter
dryer, it should never
be operated without
undercounter installation
part. For the appropriate
undercounter installation
part contact the Authorized
Service.
Dryer Depth 60 cm 54 cm
Stock number
of under-bench
installation part 2979700200 2973600200
Leave at least 3 cm of space around
the sides and the rear wall of the
dryer when installing it under a
counter.
CIf installed under a
countertop, drying
durations can extend.
4.4 Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water
tank during the drying cycle. You
should drain accumulated water
after each drying cycle.
You can directly drain accumulated
water through the water drain hose
supplied with the product instead
of periodically draining the water
collected in the water tank.
Connecting the water drain hose
1-2 Pull hose at the behind of the
dryer by hand in order to disconnect
it from where it is connected. Do not
use any tools to remove the hose.
3Connect one end of the drain
hose supplied with the dryer to the
connection point from where you
removed the hose of the product in
previous step.
4Connect the other end of the drain
hose directly to the wastewater drain
or to the washbasin.

15
EN
1
3 4
2
AHose connection should
be made in a safe manner.
Your drain house will be
flooded if the hose comes
out of its housing during
water discharge.
CWater drain hose should
be attached to a height of
maximum 80 cm.
CMake sure that the water
drain hose is not stepped on
and it is not folded between
the drain and the machine.
4.5 Adjusting the feet
In order to ensure that the dryer
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet.
Turn the feet to left or right until the
dryer stands level and firmly.
CNever unscrew the
adjustable feet from their
housings.
4.6 Electrical connection
For specific instructions for
electrical connection required during
installation (see 2.1.1 Electrical
Safety)
4.7 Transporation of the dryer
Unplug the dryer before transporting
it.
Drain all water that has remained in
the dryer.
If direct water drain connection
is made, then remove the hose
connections.
AWe recommend carrying the
dryer in upright position.
If it is not possible to carry
the machine in the upright
position, we recommend
carrying it by tilting towards
the right side when looked
from the front.

16
4.8 Warnings about sounds
CIt is normal to hear a metallic
noise from the compressor
sometimes during operation.
CWater collected during
operation is pumped to water
tank. It is normal to hear
pumping noise during this
process.
4.9 Changing the illumination
lamp
In case an illumination lamp is used
in your laundry dryer
To change the Bulb/LED used for
illumination of your tumble dryer, call
your Authorized Service.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose
of this lamp is to assist the user to
place laundry in the tumble dryer in
a comfortable way. ‘’The lamps used
in this appliance have to withstand
extreme physical conditions such as
vibrations and temperatures above
50 °C.’’

17
EN
5. Preparation
5.1 Laundry suitable for drying in the dryer
• Always obey the instructions given on the garment tags. Dry only the
laundry having a label stating that they are suitable for drying in a dryer
and make sure that you select the appropriate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
5.2 Laundry not suitable for
drying in the dryer
CDelicate embroidered fabrics,
woolen, silk garments,
delicate and valuable fabrics,
airtight items and tulle
curtains are not suitable for
machine drying.
5.3 Preparing laundry for drying
• Laundry may be tangled with
each other after washing.
Separate the laundry items
before placing them into the
dryer.
• Dry garments having metal
accessories such as zippers,
inside out.
• Fasten the zippers, hooks and
buckles and button sheets.
5.4 Things to be done for energy
saving
Following information will help you
use the dryer in an ecological and
energy-efficient manner.
• Spin your laundry at the
highest speed possible when
washing them. Thus, the drying
time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on
their type and thickness. Dry the
same type of laundry together.
For example thin kitchen towels
and table clothes dries earlier
than thick bathroom towels.

18
• Follow the instructions in the
user manual for programme
selection.
• Do not open the loading door of
the machine during drying unless
necessary. If you must certainly
open the loading door, do not to
keep it open for a long time.
• Do not add wet laundry while the
dryer is in operation
• Clean the lint filter before or after
each drying cycle.
• Clean the filter periodically when
there is visible air collection on it
or when the symbol lights up, if
there is a filter drawer cleaning
warning symbol “ ” available.
• Ventilate the room, where the
dryer is located, well during
drying.
5.5 Correct load capacity
Follow the instructions in the
“Programme selection and
consumption table”. Do not load
more than the capacity values stated
in the table.
CIt is not recommended to
load the dryer with laundry
exceeding the level indicated in
the figure. Drying performance
will degrade when the
machine is overloaded.
Furthermore, dryer and the
laundry can get damaged.
Following weights are given as
examples.
Laundry Approximate
weights (g)*
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

19
EN
6 Operating the product
1. Program selection knob
2. Remaining duration indicator
3. On/Off button
4. Start/pause button
5. End duration button
6. Sound warning button
1 2
456
3
6.1 Control panel
6.2 Screen symbols
Volume up
Filter
cleaning
Tank
full
Child-proof
lock Mute Anti
Creasing

20
6.3 Preparing the machine
1. Plug in the machine
2. Place laundry inside the machine.
3. Press the On/Off button.
4. When your machine turns on for
the first time, it turns on with
the declaration (cotton cabinet
dryness) program.
CNOTE
• Pressing the On/Off button
doesn‘t mean the program starts.
• Press the Start / Pause button to
start the program.
6.4 Program selection
1. Determine the appropriate
program from the chart below
containing the drying levels.
2. Select the program you desire
using the Program Selection
knob.
