Grundig Dt 3110 User manual

Dt 3110
microcassette
ENGLISH
www.grundig-gbs.com

Dt 3110
FFWD
STOP
START
REW
ProMic 800 FX
ǵ
ǵ
FOOT CONTROLHEADSET FOOT CONTROLHEADSET ac 9V-10V ~
ac 9V-10V ~
ǵ
ǵ

Dt 3110
A
0510
MC-
60
MICROCASSETTE
Made in Japan
TM
EJECT
SPEAKER/EAR POWER
FFWD
ERASE STOP/PLAYREWIND
ERASE COUNTER
123
ǵ
ǵ
FOOT CONTROLHEADSET ac 9V-10V ~
FOOT CONTROLHEADSET ac 9V-10V ~
VOLUME TONE

Dt 3110
Made in Germany
Fabriqué en Allemagne
VW

GB
F
I
NL
E
Index mark 9
Counter 10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Counter reset . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
How to use the Microphone 11
Start, stop, and short rewind using
the slide-switch on the microphone . . . . . . . . . 11
Fast forward and rewind using
the slide-switch on the microphone . . . . . . . . . 11
How to use the 536 Foot Control 12
Starting and stopping using the 536
foot control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fast forward and rewind using the 536
foot control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contents
1
Brief Instructions 3
Microcassette compartment, counter reset . . . . 3
Recording and control functions on the
microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Index mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tape speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fast forward, rewind . . . . . . . . . . . . . . . . . . . . . . 4
Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Preparation 5
Suitable location . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mains unit 682 connection . . . . . . . . . . . . . . . . . 5
Turning the machine on and off . . . . . . . . . . . . . 6
Connecting accessories . . . . . . . . . . . . . . . . . . . 6
Recording Dictations 7
Microphone recording sensitivity . . . . . . . . . . . . 7
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Repeating short text passages . . . . . . . . . . . . . . 8
Tape end and tape end switch-off . . . . . . . . . . . . 8
Conference recording with the microphone . . . . . . . 8

2
Technical Data 16
Mains unit 682 . . . . . . . . . . . . . . . . . . . . . . . . . 16
Desktop dictation and transcription machine Dt 3110 16
Accessories 17
Warranty, Service, Sales 18
The features indicated by Grundig apply only when
using original Grundig accessories.
Defects due to the use of accessories which are not
original Grundig accessories or which do not comply
with the legal regulations or the corresponding
standards lead automatically to the expiration of any
guarantee rights.
Contents
How to use the 541 hand control 13
Starting and stopping using the 541 hand control . . 13
Rewind using the 541 hand control . . . . . . . . . 13
What You should Know 14
Stand-by . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Counting speed . . . . . . . . . . . . . . . . . . . . . . . . . 14
Care and Maintenance 15
Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parts that come into contact with the tape . . . . . 15

3
GB
ǼPress the »POWER« button to turn the
machine on and off.
Microcassette compartment, counter reset
ɟPress the »EJECT« button after stopping
the machine.
The cover will open. The counter resets to
zero.
Insert a microcassette into the cover. Make
sure the open end of the microcassette is
facing forward and the full side is to the
right. Close the compartment by pressing
on the cover until it clicks into place.
Recording and control functions on the
microphone
–
ļTo record: press the »
–
ļ« button.
ŁStart to record: move the slide-switch to
the »ŁSTART« position.
To pause during recording: move the slide-
switch to the »STOP« position.
ĵĵ To end a recording:
move the slide-switch briefly to the
»ĵĵ REW« or »ŁŁ FFWD« position,
then to the »STOP« position.
ĵĵ Short rewind: move the slide-switch to the
»ĵĵ REW« position.
ŁŁ Fast forward: move the slide-switch to the
»ŁŁ FFWD« position.
Index mark
II--- Index mark: briefly press the II--- button
during playback.
Brief Instructions

4
Tape speed
Set the tape speed using the
“1.2 SPEED 2.4” slide-switch on the
right-hand side of the machine.
The same tape speed must be used for recording and
playback.
Playback
ŀ/ yTo playback using the speaker in the
machine: press the »SPEAKER/EAR« but-
ton stet( ё ).
ŀ/ yTo playback using headset accessories:
click the »SPEAKER/EAR« button up (Ծ).
/ıPress the »STOP/PLAY« button to start
playback.
/ıPress the »STOP/PLAY« button again to
stop playback.
On the base of the machine turn the rotary
adjuster »BACKSPACE« to change the
backspace rewind time between 0 and
several seconds.
1.2
1.2
1.2 2.4
2.4
2.4
SPEED
SPEED
SPEED
On the base of the machine turn the rotary
adjuster »SPEED« to change the playback
speed. The rotary adjuster clicks into mid-
position (normal speed).
|Change the volume using the »VOLUME«
adjuster (on the front of the machine).
ɼɦ Change the tone using the »TONE« adju-
ster (on the front of the machine).
Fast forward, rewind
ŁŁ Fast forward: Press the »FFWD« button on
the device.
ĵĵ Rewind: Press the »REWIND« button on
the device.
/ıStop: press the »STOP/PLAY« button.
Erase
Press the »ERASE« button until a beep
sounds and »ERASE« lights up (approxi-
mately 2 s), then in addition...
ĵĵ /ŁŁ Press the »REWIND« button or the
»FFWD« button.
Brief instructions

5
GB
Suitable location
Do not place the machine on a soft surface
(tablecloth, pillow etc.) as this could block the con-
vection vents on the bottom of the unit and result in
overheating.
Do not cover or insert any objects in the convection
vents in the dictation machine's housing. This could
destroy the speaker or electronic components.
Do not subject the unit to direct sunlight for a prolon-
ged period of time or to temperatures over
95°F/35°C.
Furniture is often coated with various types of syn-
thetics and paint that contain chemical additives.
These can corrode the material of the machine base
and leave marks on the surface of the furniture that
may, in rare cases, be very difficult or impossible to
remove.
Mains unit 682 connection
To connect the mains unit with the
machine:
push the connector (telephone type
jack) into the socket at the back of
the machine marked ac 9V ˜.
Connect the plug of mains unit
“682 UC” to a a.c. 110 V -120 V, ˜ 50 Hz -60 Hz
electrical outlet.
Connect the plug of mains unit “682 GB” and “ 682”
to a a.c. 230 V -240 V, ˜ 50 Hz electrical outlet.
ac 9V-10V ~
Warning: The mains unit is designed for use
with the GRUNDIG Dt 3110 only.
Ŀ
!Use the mains unit “682 UC” for the USA
and Canada, the mains unit
“ 682 GB ” for
Great Britain, and “ 682 ” for the rest of
Europe.
Preparation

6
To disconnect the mains unit from
the machine:
depress the catch on the connector
and simultaneously
pull the cord.
Turning the machine on and off
ǼPress the »ǼPOWER« button down to turn
the machine on and off. When on, the power
light will illuminate.
Warning: The dictation machine and the mains
unit are only disconnected from the
supply voltage when the plug has been
removed from the power outlet!
Ŀ
!Always disconnect the power supply unit
during an electrical storm. Do not pull it out
by the cord.
T
CONTROL ac 9V-10V
~
Connecting accessories
Connecting the microphone, foot control, hand con-
trol and headset: see figure at the beginning of this
booklett.
Preparation

7
GB
Microphone recording sensitivity
Select one of the three switch settings
on the microphone:
ıPrivate – INormal – IConference
Recording distance from microphone
(dictation) approximately 10 cm.
The machine adjusts automatically to
the volume of the dictation when recor-
ding.If you speak closely to the micro-
phone, less background noise is recor-
ded.
Recording
Activating the record function
Press the »
–
ļ« button.
The record light on the microphone illu-
minates.
Starting to record
Move the slide-switch to the » ŁSTART«
position.
The tape is running. Your dictation is
now being recorded.
Each new recording automatically era-
ses any previous recordings on that part
of the tape.
Note: A warning tone indicates that the tape
has reached the end.
The recording indicator flashes during
“Recording-pause”.
STOP
START
REW
Recording Dictations

8
Repeating short text passages
Short rewind
Move the slide-switch into the
»ĵĵ REW« position.
– The tape is briefly rewound.
– Then the machine switches back into
playback mode.
Resuming recording
Press the »
–
ļ« button.
Tape end and tape end switch-off
When the counter reaches the position 528 in recor-
ding mode, the machine emits a warning tone.
When using a microcassette MC-60, this counter
position is reached after a recording time of 29 minu-
tes when starting at counter position ”0” and recor-
ding at a speed of 2.4 cm/s (58 minutes at a speed of
1.2 cm/s).
At the tape end the machine switches to stop.
START
REW
Conference recording with the microphone
Recording sensitivity
Select one of the three switch settings:
ıPrivate – INormal – IConference
(recommended setting)
Place the microphone in the middle of
the conference table with the slide-
switch facing upward. Place the micro-
phone on a soft surface to reduce the
amount of background noise recorded.
Then proceed as in “Recording”.
Recording Dictations

9
GB
Parts of the tape that have to be corrected can be
marked with an index mark either during playback or
stop.
Press the left » II---« or right » II---« button
at the required position.
The text passages that are to be
inserted can be recorded at the end of
the dictation; or on the second side of
the microcassette; or on another micro-
cassette (used as a correction tape).
Note: Let the person who will do your typing
know what to do when an index mark is
heard on the tape.
Examples: – insert correction tape
– read enclosed index note
– call back for consultation.
Index mark

10
Operation
The typist receives a microcassette which has been
recorded by the author and is not rewound.
The typist inserts this cassette into the microcassette
compartment. This resets the counter automatically
to ”0”. The typist rewinds the cassette to the begin-
ning. For the playback which follows (typing letters),
there are two possibilities of using the counter.
1. After being rewound, the counter counts up to
»999«. The typist knows at any time that the count
difference to ”999” must still be typed.
2. The typist knows the counter position of the begin-
ning of every letter and of the entire contents of the
cassette from the accompanying note. She resets
the counter to ”0” (opens and closes the cover).
Now she can wind the cassette to the beginning of
any desired letter.
If the microcassette is rewound to the beginning and
the counter is reset, the counting speed is nearly the
same as that of a GRUNDIG portable dictation machine.
Counter reset
When switching the dication machine on and off, the
counter is not automatically reset.
Resetting the counter (machine switched on):
ɟOpen the microcassette compartment with
the »EJECT ɟ« button and close it by hand.
Note: After a power failure the counter is automati-
cally reset. When passing from ”999” to ”0”,
the counting speed changes considerably.
Then it will increase slowly in the same way
as on a GRUNDIG microcassette portable dic-
tation machine.
Counter

11
GB
Start, stop, and short rewind using the
slide-switch on the microphone
Tape is not running:
to start playback move slide-switch to
»ŁSTART«.
Dictations are being played back:
to stop playback move slide-switch to
»STOP« .
Short rewind:
to repeat short text passages move the
slide-switch to »ĵĵ REW«. After a short
rewind the machine switches to
playback.
You can set the length of the short
rewind using the rotary adjuster
»BACKSPACE Iĵĵ« on the base of the
machine.
START
REW
WD
STOP
START
STOP
START
REW
Fast forward and rewind using the slide-
switch on the microphone
Fast forward:
move the slide-switch to » ŁŁ FFWD« –
the tape runs forward.
Short rewind:
move the slide-switch to »ĵĵ REW«.
You can set the length of the short re-
wind using the rotary adjuster
»BACKSPACE Iĵĵ « on the base of the
machine.
Stop:
move the slide-switch to »STOP«.
WD
STOP
START
START
REW
FFWD
How to use the Microphone

12
Switch options:
right pedal = start-backspace
middle pedal = fast forward
left pedal = rewind
Starting and stopping using the
536 foot control
You can use the start pedal (right
pedal) to either lock or scan. Slide
the switch on the bottom of the
machine to the desired position.
Note: The start pedal has a ”start-backspace
function« that automatically triggers a
”short rewind” before continuous playb-
ack. ”Short rewind” is not performed if
the backspace regulator
»Backspace « on the base of
the unit is set to zero “0”.
Lock position:
press pedal = start-backspace
release the pedal and press it again = stop.Scan posi-
tion:
press and hold pedal = start-backspace
release pedal = stop.
Fast forward and rewind using the
536 foot control
Fast forward:
Step on the middle pedal of the foot control.
Rewind:
Step on the left pedal of the foot control.
Stop:
Release the pedal.
Note: The ”Fast forward” function stops automatical-
ly at the end of the tape.
The ”Rewind” function stops automatically at
the beginning of the tape.
How to use the 536 Foot Control

13
GB
Starting and stopping using the 541 hand
control
Instead of a foot control you can use the 541 hand
control for transcription.
Start-Backspace:
Press the right button: the tape begins to run.
Stop:
Press the button again.
Note: The ”start-backspace function”
automatically triggers a ”short rewind”
before starting. ”Short rewind” is not
performed if the backspace regulator
»Backspace « on the base of the
machine is set to zero.
Rewind using the 541 hand control
Rewind:
Press the left button on the hand control.
Stop:
Release the button.
Note: The ”Rewind” function stops automatically at
the beginning of the tape.
How to use the 541 Hand Control

14
Stand-by
If no function is selected within 1 minute, the
machine switches to ”stand-by”. The tape-contac-
ting parts then are released from the tape. The
machine remains operable.
Counting speed
The counting speed changes with the counter
position.
See note in the chapter ”Counter”!
What You should Know

15
GB
Housing
Only clean the machine with a soft cloth suitable for
removing dust. Polish and cleaning agents can dama-
ge the surface. Liquids should not be allowed to
penetrate the inside of the unit.
Parts that come into contact with the tape
You should check regularly within the microcassette
compartment for dust and for dirt caused by tape
usage.
We recommend that you clean these parts with a soft
cotton swab that has been dipped in cleaning alcohol.
Never use metal or hard objects!
ɟOpen the tape compartment and remove the
microcassette.
ŁŁ Press and hold the »FFWD ŁŁ« button and the
ĵĵ »ĵĵ REWIND« button simultaneously:
The capstan shaft spins.
Cleaning parts that come into contact with the
tape:
Rubber pressure roller A
Capstan shaft B
Recording head C
Please contact your dealer if malfunctions occur.
Warning: Repair note
ĿĿ
!Use only original replacement parts.
The power cable may be replaced only by a
Grundig authorised repair service.
C
BA
Care and Maintenance

16
Technical Data
Mains unit 682
Mains voltage for mains unit 682 UC:
a.c. 110 V -120 V (± 10 %), ˜ 50 Hz -60 Hz
Mains voltage for mains units 682 GB and 682:
a.c. 230 V (± 10 %), ˜ 50 Hz
Fuse: thermostatic fuse (primary)
Desktop dictation and transcription
machine 3110
Tape: microcassette
Tracks: 2 tracks, 1-channel, monophonic
Drive system: capstan
Tape speed: 2.38 cm/s; or 1.19 cm/s; can be
adjusted by approximately ±15 %
Rewind time: approximately 90 seconds.
Output power: 200 mW
Frequency Response: 100 -5000 Hz
Speaker: 45 mm Ø dynamic speaker
Recording: with a.c. bias voltage (TNR – tape noise
reduction)
Dimensions: approximately
163 mm x 210 mm x 54 mm
Weight: approximately 690 g
The product name and serial number are located on
the bottom of the machine housing.
The product is in accordance with following
EC-Directives: “89/336/CEE, 73/23/CEE, 93/68/CEE“
Technical data and design subject to change.
