Grundig GSBSPDM4FVX User manual

GSBSPDM4FVX
EN
58 7660 0000/AA
Refrigerator
User Manual

A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal
efficiency from this high quality product which has been manufactured with
state of the art technology. To do this, carefully read this manual and any other
documentation provided before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect
yourself and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to
someone else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause materal damage to the product or ts
surroundngs
Important information or useful tips on operation.
Read the user manual.
Risk of fire / Flammable materials

2 /52EN Refrigerator / User Guide
2
1 Safety Instructions 3
1.1 Purpose of usage...............3
1.2 Safety of children, vulnerable
persons and pets..........................3
1.3 Electrical safety ................4
1.4 Handling Safety.................4
1.5 Installation Safety.............4
1.6 Operational safety.............5
1.7 Maintenance and cleaning
safety.............................................7
1.8 Lighting .............................7
2 Environmental instructions 8
2.1 Compliance with the WEEE
Directive and Disposing of the Waste
Product: .......................................8
2.2 Compliance with RoHS
Directive........................................8
2.3 Package information ..............8
3 Your Refrigerator 9
4 Installation 10
4.1 The right place for installation10
4.2 Attaching the plastic wedges10
4.3 Adjustment of the feet..........11
4.4 Electrical connection............13
4.5 Water connection .................13
4.6 Connecting water hose to the
product........................................14
4.7 Connecting to water mains ..14
4.8. For products using water
carboy .........................................15
4.9 Water filter............................16
4.9.1.Fixing external filter on the
wall (Optional).............................16
4.9.2.Internal filter......................17
5 Preparation 20
5.1 What to do for energy saving20
5.2 First operation ......................21
5 Preparation 21
6 Operating the Product 22
6.1 Turning off the product.........22
6 Operation of the Product 23
6.2 Indicator panel......................23
6.3Deodoriser Module ...............26
6.4 Humidity controlled
crisper(FreSHelf)........................26
(This feature is optional) ............26
6.5 Blue light/VitaminCare
Technology..................................27
6.6Using the water fountain.......28
6.7Filling the water tank of the water
fountain.......................................28
6.8 Cleaning the water tank.......29
6.9 Dairy (cold storage) bin ........30
6.10 Crisper ...............................30
6.11 Ionizer .................................30
6.12 Odour filter .........................30
6.13 Taking ice / water ...............31
6.14 Drip tray .............................32
6.15 Ice-maker ...........................32
6.16 Freezing fresh food.............35
6.17 Recommendations for storing
frozen foods ................................36
6.18 Deep freezer details ...........36
6.19 Placing the food..................37
6.20 Door open alert...................37
6.21 Illumination lamp ............... 37
7 Maintenance and cleaning 38
7.1 Stainless Steel External
Surfaces......................................38
7.2 Cleaning of the Products with
Glass Doors ................................39
7.3 Preventing Odours ............39
7.4 Protecting Plastic Surfaces 39
7 Maintenance and cleaning 39
8 Troubleshooting 40

3 / 52EN
Refrigerator / User Guide
3
EN
PT
1Safety Instructions
• Ths secton ncludes the safety
nstructons necessary to prevent
the rsk of personal njury or materal
damage.
• Our company shall not be held
responsble for damages that may
occur f these nstructons are not
observed.
Installation and repair operations
shall always be performed by
Authorized Service.
Always use genuine spare parts and
accessories.
Original spare parts will be
provided for 10 years, following the
product purchasing date.
Do not repair or replace any part of
the product unless specified expressly in
the user manual.
Do not perform any modifications
on the product.
1.1 Purpose of usage
• This product is not intended for
commercial use and it shall not be
used out of its intended purpose.
This product is intended for operating
interiors, such as households or
similar.
For example;
- In the staff kitchens of the
stores, offices and other working
environments,
- In farm houses,
- In the units of hotels, motels or
other resting facilities that are used by
the customers,
- In hostels, or similar environments,
- In catering services and similar non-
retail applications.
This product shall not be used in open
or enclosed external environments
such as vessels, balconies or terraces.
Exposing the product to rain, snow,
sunlight and wind may cause risk of
fire.
1.2 Safety of children,
vulnerable persons and pets
• Ths product may be used by chldren
aged 8 years and older and persons
wth underdeveloped physcal,
sensory or mental capabltes or
lack of experence and knowledge
f they have been gven supervson
or nstructon concernng use of the
applance n a the product safe way
and the hazards nvolved.
• Chldren between 3 and 8 years are
allowed to put and take out food to/
from the cooler product.
• Electrcal products are dangerous for
chldren and pets. Chldren and pets
must not play wth, clmb on, or enter
the product.
• Cleanng and user mantenance should
not be performed by chldren unless
there s someone overseeng them.
• Keep the packagng materals away
from chldren. Rsk of njury and
suffocaton.
• Before dsposng of old products that
shall not be used any more:
1. Unplug the power cord from the mains
socket.
2. Cut the power cord and remove it from the
appliance together with the plug.
3. Do not remove the racks and drawers from
the product to prevent children from get-
ting inside the appliance.
4. Remove the doors.

4 /52EN Refrigerator / User Guide
4
Safety instructions
5. Store the product so that it shall not be
tipped over.
6. Do not allow children to play with the
scrapped product.
• Do not dispose of the product
by throwing it into fire. Risk of
explosion.
• If there is a lock available in the
product’s door, keep the key out
of children’s reach.
1.3 Electrical safety
• The product shall not be plugged
nto the outlet durng nstallaton,
mantenance, cleanng, repar, and
transportaton operatons.
• If the power the cord s damaged, t
shall be replaced by authorzed servce
only to avod any rsk that may occur.
• Do not tuck the power cord under the
product or to the rear of the product.
Do not put heavy tems on the power
cord. The power cord should not be
bent, crushed, and come nto contact
wth any heat source.
• Do not use an extenson cord, mult-
plug or adaptor to operate your
product.
• Portable mult sockets or portable
power supples may overheat and
cause fre. Thus, do not have a mult-
plug behnd or n the vcnty of the
product.
• The plug shall be easly accessble. If
ths s not possble, a mechansm that
meets the electrcal legslaton and
that dsconnects all termnals from
the mans (fuse, swtch, man swtch,
etc.) shall be avalable on the electrcal
nstallaton.
• Do not touch the plug wth wet hands.
• When unpluggng the applance, don’t
hold the power cord, but the plug.
• When positioning the appliance,
ensure the supply cord is not
trapped or damaged
• Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the appliance.
1.4 Handling Safety
• Ths product s heavy, do not handle t
by yourself.
• Do not hold the product from ts door
whle handlng the product.
• Be careful not to damage the coolng
system and the ppes whle handlng
the product. Do not operate the
product f the ppes are damaged, and
contact an authorzed servce.
1.5 Installation Safety
• Contact the Authorzed Servce for
the product’s nstallaton. To prepare
the product for nstallaton, see the
nformaton n the user gude and make
sure the electrc and water utltes
are as requred. If the nstallaton s
not sutable, call a qualfed electrcan
and plumber to have them make the
necessary arrangements. Otherwse,
electrc shock, fre, ssues wth the
product or njures may occur.
• Check for any damage on the product
before nstallng t. Do not have the
product nstalled f t s damaged.
• Place the product on a level and
hard surface and balance wth the
adjustable legs. Otherwse, the
refrgerator may tp over and cause
njures.
• The product shall be nstalled n a
dry and ventlated envronment.
Do not keep carpets, rugs or smlar

5 / 52EN
Refrigerator / User Guide
5
EN
PT
Safety instructions
floor covers under the product. Ths
may cause rsk of fre as a result of
nadequate ventlaton!
• Do not block or cover ventlaton holes.
Otherwse, power consumpton may
be ncreased and damage to your
product may occur.
• Do not connect the product to supply
systems such as solar power supples.
Otherwse, damage to your product
may occur as a result of the abrupt
voltage fluctuatons!
• The more refrgerant a refrgerator
contans, the bgger ts nstallaton
room shall be. In very small rooms,
a flammable gas-ar mxture may
occur n case of a gas leak n the
coolng system. At least 1 m of
volume s requred for each 8 grams
of refrgerant. The amount of the
refrgerant avalable n your product s
specfed n the Type Label.
• The nstallaton place of the product
shall not be exposed to drect sunlght
and t shall not be n the vcnty of a
heat source such as stoves, radators,
etc.
If you cannot prevent installation of the
product in the vicinity of a heat source,
you shall use a suitable insulation
plate and the minimum distance to
the heat source shall be as specified
below.
- At least 30 cm away from heat
sources such as stoves, heating units
and heaters, etc.,
- And at least 5 cm away from
electric ovens.
• Your product has the protecton
class of I. Plug the product n a
grounded socket that conforms wth
the Voltage, Current and Frequency
values specfed n the type label. The
socket outlet shall be equpped wth a
fuse wth a ratng of 10 A – 16 A. Our
company shall not be responsble for
the damages that shall be ncurred
as a result of operatng the product
wthout ensurng ground and
electrcal connectons made as per
local or natonal regulatons.
• The product’s power cable must
be unplugged durng nstallaton.
Otherwse, rsk of electrc shock and
njury may occur!
• Do not plug the product to loose,
broken, dirty, greasy sockets or
sockets that has come out their
seats or sockets with a risk of water
contact.
• Place the power cord and hoses
(if available) of the product so
that they shall not cause a risk of
tripping over.
• Penetration of humidity to live parts
or to the power cord may cause
short circuit. Thus, do not use the
product in humid environments or
in areas where water may splash
(e.g. garage, laundry room, etc.)
If the refrigerator is wet by water,
unplug it and contact an authorized
service.
• Do not connect your refrigerator
to power saving devices. These
systems are harmful for the
product.
1.6 Operational safety
• Do not use chemical solvents on the
product. These materials contain an
explosion risk.
• In case of a failure of the product,
unplug it and do not operate until it
is repaired by the authorized service.
There is a risk of electric shock!

6 /52EN Refrigerator / User Guide
6
Safety instructions
• Do not place a source of flame (e.g.
candles, cigarettes, etc.) on the product
or in the vicinity of it.
• Do not get on the product. Risk of falling
and injury!
• Do not cause damage to the pipes of the
cooling system using sharp and piercing
tools. The refrigerant that sprays out in
case of puncturing the gas pipes, pipe
extensions or upper surface coatings
may cause irritation of skin and injuries
of the eyes.
• Do not place and operate electric
appliances inside the refrigerators/
deep freezer unless it is advised by the
manufacturer.
• Do not jam any parts of your hands or
your body to the moving parts inside the
product. Be careful to prevent jamming
of your fingers between the refrigerator
and its door. Be careful while opening
or closing the door if there are children
around.
• Do not put ice cream, ice cubes or
frozen food to your mouth as soon as
you take them out of the freezer. Risk of
frostbite!
• Do not touch the nner walls, metal
parts of the freezer or food kept nsde
the refrgerator wth wet hands. Rsk of
frostbte!
• Do not place soda cans or cans and
bottles that contan fluds that may be
frozen to the freezer compartment.
Cans or bottles may explode. Rsk of
njury and materal damage!
• Do not use or place materals
senstve aganst temperature such as
flammable sprays, flammable objects,
dry ce or other chemcal agents n the
vcnty of the refrgerator. Rsk of fre
and exploson!
• Do not store explosve materals such as
aerosol cans wth flammable materals
nsde the product.
• Do not place cans contanng fluds over
the product. Splashng of water on an
electrcal part may cause the rsk of an
electrc shock or a fre.
• Ths product s not ntended for storage
and coolng of medcnes, blood plasma,
laboratory preparatons or smlar
materals and products that are subject
to the Medcal Products Drectve.
• If the product s used aganst ts
ntended purpose, t may cause damage
to or deteroraton of the products kept
nsde.
• If your refrgerator s equpped wth
blue lght, do not look at ths lght wth
optcal devces. Do not stare drectly at
UV LED lght for a long tme. Ultravolet
rays may cause eye stran.
• Do not fll the product wth more food
than ts capacty. Injures or damages
may occur f the contents of the
refrgerator falls when the door s
opened. Smlar problems may occur
when an object s placed over the
product.
• Ensure that you have removed any ce
or water that may have fallen to the
floor to prevent njures.
• Change the locatons of the racks/bottle
racks on the door of your refrgerator
whle the racks are empty only. Danger
of physcal njury!
• Do not place objects that may fall/
tpped over on the product. These
objects may fall whle openng or closng
the door and cause njures and/or
materal damages.
• Do not ht or exert excessve pressure
on glass surfaces. Broken glass may
cause njures and/or materal damages.

7 / 52EN
Refrigerator / User Guide
7
EN
PT
Safety instructions
• The coolng system n your product
contans R600a refrgerant. The
refrgerant type used n the product s
specfed n the the type label. Ths gas
s flammable. Therefore, be careful not
to damage the coolng system and the
ppes whle operatng the product. In
case of damage to the ppes;
- do not touch the product or the
power cord,
- Keep the product away from
potential sources of fire that may cause
the product to catch fire.
- ventilation the area where the
product is placed. Do not use a fan.
- Contact authorized service.
• If the product s damaged and you
observe gas leak, please stay away
from the gas. Gas may cause frostbte
f t contacts your skn.
For Products With Water Fountain /
Ice Maker
• Use only drinking water. Do not fill the
water tank with fruit juice, milk, fizzy
beverages, alcoholic beverages or any
other liquids incompatible for use in the
water fountain. This may cause risk to
your health and safety.
• Do not allow the children to play with
the water dispenser or Ice Maker to
prevent accidents and injuries.
• Do not insert your fingers or other
objects inside the hole of the water
dispenser, ice channel or inside the
container of the Ice Maker. This may
cause injuries or material damages.
1.7 Maintenance and
cleaning safety
• Do not pull by the door handle f you
shall move the product for cleanng
purposes. Handle may cause njures
f t s pulled too hard.
• Do not clean the product by sprayng
or pourng water on the product and
nsde the product. Rsk of electrc
shock and fre.
• Do not use sharp or abrasve tools
to clean the product. Do not use
materals such as household cleanng
agents, detergents, gas, gasolne,
alcohol, wax, etc.
• Use cleanng and mantenance
agents that are not harmful for food
only nsde the product.
• Do not use steam or steamed
cleanng materals for cleanng the
product and thawng the ce nsde t.
Steam contacts the lve areas n your
refrgerator and causes short crcut
or electrc shock!
• Take care to keep water away from
the electronc crcuts or lghtng of
the product.
• Use a clean, dry cloth to wpe the dust
or foregn materal on the tps of the
plugs. Do not use a wet or damp pece
of cloth to clean the plug. Otherwse,
rsk of fre or electrc shock may occur.
1.8 Lighting
(May not be applicable for all
models)
• Contact an authorzed servce when
you shall replace the LED / bulb usng
for lghtng.

8 /52EN Refrigerator / User Guide
8
2 Environmental instructions
2.1 Compliance with the WEEE
Directive and Disposing
of the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).
This symbol indicates that this
product shall not be disposed
with other household wastes at
the end of its service life. Used
device must be returned to
offical collection point for recycling of
electrical and electronic devices. To find
these collection systems please contact
to your local authorities or retailer
where the product was puchased. Each
household performs important role in
recovering and recycling of old
appliance. Appropriate disposal of used
appliance helps prevent potential
negative consequences for the
environment and human health.
2.2 Compliance with
RoHS Directive
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
2.3 Package information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do not
dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.

9 / 52EN
Refrigerator / User Guide
9
EN
PT
3Your Refrigerator
C*Optional: Figures in this user guide are schematic and may not be
exactly match your product. If your product does not comprise the
relevant parts, the information pertains to other models.
May not be available in all models
1. Freezer compartment
2. Cooler compartment
3. Cooler compartment door shelves
4. Egg Holder
5. Bottle shelf
6. Adjustable stands
7. Crispers
8. The dairy (cold storage) bin
9. Bottle shelf
2
1
*3
4
6
7
7
*8
*9
6
*3
*3
5
*10
11
12
12
13
17
*15 *14
*16
*14
10. Glass shelves
11. Fan
12. Frozen food storing compart-
ments
13. Freezer compartment glass
shelf
14. Icematic
15. Ice storage box
16. Ice-maker decorative lid
17. Freezer compartment door shel-
ves

10 /52EN Refrigerator / User Guide
10
4Installation
4.1 The right place for installation
ARead the “Safety
Instructions” section first!
Your product requires adequate air
circulation to function efficiently. If the
product will be placed in an alcove,
remember to leave at least 5 cm
clearance between the product and the
ceiling, rear wall and the side walls.
If the product will be placed in an
alcove, remember to leave at least 5
cm clearance between the product
and the ceiling, rear wall and the side
walls. Check if the rear wall clearance
protection component is present at its
location (if provided with the product).
If the component is not available, or if it
is lost or fallen, position the product so
that at least 5 cm clearance shall be left
between the rear surface of the product
and the wall of the room. The clearance
at the rear is important for efficient
operation of the product.
AWARNING: Do not use extension
or multi sockets in power
connection.
BWARNING: The manufacturer
assumes no responsibility for
any damage caused by the work
carried out by unauthorized
persons.
B
WARNING: The product's
power cable must
be unplugged during
installation. Failure to do
so may result in death or
serious injuries!
A
WARNING: : If the door
span is too narrow for the
product to pass, remove the
door and turn the product
sideways; if this does not
work, contact the authorized
service.
• Place the product on a flat surface to
avoid vibration.
• Place the product at least 30 cm away
from the heater, stove and similar
sources of heat and at least 5 cm away
from electric ovens.
• Do not expose the product to
direct sunlight or keep in damp
environments.
• The product requires adequate air
circulation to function efficiently. If the
product will be placed in an alcove,
remember to leave at least 5 cm
distance between the product and the
ceiling and the walls.
4.2 Attaching the plastic wedges
Use the plastic wedges in the
provided with the product to provide
sufficient space for air circulation
between the product and the wall.
1- To attach the wedges, remove the
screws on the product and use the
screws provided with the wedges.

11 / 52EN
Refrigerator / User Guide
11
EN
PT
Installation
2- Attach 2 plastic wedges on the
ventilation cover as shown in the
figure.
4.3 Adjustment of the feet
If the product is not in balanced
position, adjust the front adjustable
stands by rotating right or left.
Fixing nut
Fixing screw
Sabitleme somunu
Sabitleme vidası

12 /52EN Refrigerator / User Guide
12
Installation
In order to adjust the doors vertically,
•Loosen the fixing nut at the bottom
•Screw adjusting nut (CW/CCW)
according to the position of the door
•Tighten the fixing nut for the final
position
In order to adjust the doors horizontally,
• Loosen the fixing screw at the bottom
• Loosen the fixing bolt on the top
• Screw the adjusting bolt (CW/CCW) on
the side according to the position of
the door
• Tighten the fixing bolt on the top for
the final position
• Tighten the fixing screw at the bottom
fixing nut
adjusting nut
adjusting bolt
fixing bolt
ayar somunu
ayar civatası
sabitleme
civatası
sabitleme somunu

13 / 52EN
Refrigerator / User Guide
13
EN
PT
Installation
4.4 Electrical connection
AWARNING: Do not
use extension or multi
sockets in power
connection.
BWARNING: Damaged
power cable must be
replaced by Authorized
Service.
• Our firm will not assume responsibility
for any damages due to usage without
earthing and power connection in
compliance with national regulations.
• The power cable plug must be easily
accessible after installation.
C
Hot surface warning!
The side walls of your
product are equipped with
cooler pipes to enhance
the cooling system. High
pressure fluid may flow
through these surfaces,
and cause hot surfaces
on the side walls. This
is normal and it does
not require servicing. Be
careful when you contact
these areas.
4.5 Water connection
(Optional)
AWARNING: Unplug the pro-
duct and the water pump (if
available) during connection.
The product’s water mains, filter and
carboy connections must be rendered
by authorizer service. The product
can be connected to a carboy or di-
rectly to the water mains, depending
on the model. To establish the con-
nection, the water hose must first be
connected to the product.
Check to see the following parts are
supplied with your product’s model:
3
1
4
2
*5
1. Connector (1 piece): Used to at-
tach the water hose to the rear of
the product.
2. Hose clip (3 pieces): Used to fix
the water hose on the wall.
3. Water hose (1 piece, 5 meter di-
ameter 1/4 inches): Used for the
water connection.
4. Faucet adapter (1 piece):
Comprises a porous filter, used
for connection to the cold water
mains.

14 /52EN Refrigerator / User Guide
14
Installation
5. Water filter (1 piece *Optional):
Used to connect the mains water
to the product. Water filter is not
required if carboy connection is
available.
4.6 Connecting water hose
to the product
To connect the water hose to the pro-
duct, follow the instructions below.
1. Remove the connector on the hose
nozzle adaptor in the back of the
product and run the hose through
the connector.
2. Push the water hose down tightly
and connect to the hose nozzle
adaptor.
3. Tighten the connector manually to
fix on the hose nozzle adaptor. You
may also tighten the connector
using a pipe wrench or pliers.
4. Connect the other end of the hose
to the water mains (See Section
4.7) or, to use carboy, to the water
pump (See Section 4.8).
4.7 Connecting to water mains
(Optional)
To use the product by connecting to
the cold water mains, a standard 1/2”
valve connector must be installed to
the cold water mains in your home.
If the connector is not available or if
you are unsure, consult a qualified
plumber.
1. Detach the connector (1) from the
faucet adaptor (2).
1
23 1
2
3

15 / 52EN
Refrigerator / User Guide
15
EN
PT
Installation
2. Connect the faucet adaptor to the
water mains valve.
3. Attach the connector around the
water hose.
4. Attach the connector into the fau-
cet adaptor and tighten by hand /
tool.
5. To avoid damaging, shifting or ac-
cidentally disconnecting the hose,
use the clips provided to fix the
water hose appropriately.
AWARNING: After turning
the faucet on, make sure
there is no water leak on eit-
her end of the water hose. In
case of leakage, turn the val-
ve off and tighten all connec-
tions using a pipe wrench or
pliers.
4.8. For products using
water carboy
(Optional)
To use a carboy for the product’s wa-
ter connection, the water pump re-
commended by the authorized service
must be used.
1. Connect one end of the water
hose provided with the pump to
the product (see 4.6) and follow
the instructions below.

16 /52EN Refrigerator / User Guide
16
Installation
2. Connect the other end of the wa-
ter hose to the water pump by
pushing the hose into the pump’s
hose inlet.
4.9.1.Fixing external filter
on the wall (Optional)
AWARNING: Do not fix the
filter on the product.
Check to see the following parts are
supplied with your product’s model:
3. Place and fasten the pump hose
inside the carboy.
4. Once the connection is established,
plug in and start the water pump.
CPlease wait 2-3 minutes af-
ter starting the pump to ac-
hieve the desired efficiency.
CSee also the pump’s user
guide for water connection.
CWhen using carboy, water
filter is not required.
4.9 Water filter
(Optional)
The product may have internal or ex-
ternal filter, depending on the model.
To attach the water filter, follow the
instructions below.
123
4
5
6
1. Connector (1 piece): Used to at-
tach the water hose to the rear of
the product.
2. Faucet adapter (1 piece): Used
for connection to the cold water
mains.
3. Porous filter (1 piece)
4. Hose clip (3 pieces): Used to fix
the water hose on the wall.
5. Filter connecting apparatus (2 pi-
eces): Used to fix the filter on the
wall.
6. Water filter (1 piece): Used to con-
nect the product to the water ma-
ins. Water filter is not necessary
when using carboy connection.
1. Connect the faucet adaptor to the
water mains valve.
2. Determine the location to fix the
external filter. Fix the filter’s con-
necting apparatus (5) on the wall.

17 / 52EN
Refrigerator / User Guide
17
EN
PT
Installation
3. Attach the filter in upright position
on the filter connecting apparatus,
as indicated on the label. (6)
4. Attach the water hose extending
from the top of the filter to the
product’s water connection adap-
tor, (see 4.6.)
After the connection is established, it
should look like the figure below.
4.9.2.Internal filter
The internal filter provided with the
product is not installed upon delivery;
please follow the instructions below
to install the filter.

18 /52EN Refrigerator / User Guide
18
Installation
Water line:
Carboy line:
1. “Ice Off”indicator must be active
while installing the filter. Switch
the ON-OFF indicator using the
“Ice” button on the screen.
2. Remove the vegetable bin to ac-
cess the water filter.
Remove the water filter by-pass cover by
pulling.
