REFRIGERATOR
USER INSTRUCTIONS
GKN17920FX

Contents
1. Safety and environment
instructions 3
2. Your Refrigerator 10
3Installation 11
3.1 Appropriate installation
location ....................................... 11
3.2 Installing the plastic wedges 11
3.3 Adjusting the feet.................. 11
3.4 Electrical connection............ 12
3.5 Reversing the doors ............. 13
3.6 Reversing the doors ............. 14
4 Preparation 15
4.1 Things to be done for energy
saving.......................................... 15
4.2 Initial use .............................. 16
5 Operating the product 17
5.1 Temperature setting button . 17
5.2 Fast freeze ........................... 17
5.3 Vacation function .................. 18
5.4 Indicator panel...................... 19
5.5 Indicator panel...................... 21
5.6 Ice bucket.............................. 23
(This feature is optional)............ 23
5.7 Egg holder............................. 23
5.8 Fan......................................... 24
5.9 Vegetable bin ........................ 24
(This feature is optional)............ 24
5.10 Zero degree compartment. 24
(This feature is optional)............ 24
5.11 HerbBox/HerbFresh........... 24
5.12 Moving door rack................ 25
5.13 Sliding storage box ............ 25
(This feature is optional)............ 25
5.14 Moisture controlled
vegetable bin............................... 25
(This feature is optional)............ 25
5.15 Automatic ice machine ...... 26
(This feature is optional)............ 26
5.16 Icematic and ice storage
container..................................... 27
5.17 Using the water dispenser. 27
5.18 Filling the water
dispenser's tank......................... 28
5.19 Cleaning the water tank ... 28
5.20 Drip tray .............................. 29
5.21 Freezing fresh food............. 30
5.22 Recommendations for
preserving the frozen food......... 31
5.23 Deep-freeze information.... 31
5.24 Placing the food.................. 31
5.25 Door open warning............. 32
5.26 Illumination lamp ............... 32
6. Maintenance and cleaning 33
6.1 Avoiding bad odours.......... 33
6.2 Protecting the plastic
surfaces ..................................... 34
6.3 Door Glasses ....................... 34
7. Troubleshooting 35

2
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants
and checked under the most meticulous quality control procedures, will
provide you an effective service
For this, we recommend you to carefully read the entire manual of your
product before using it and keep it at hand for future references.
The user manual will help you use the product in a fast and safe way.
Will help you use your appliance in a fast and safe way.
Read the manual before installing and operating your product.
Follow the instructions, especially those for safety.
Keep the manual in an easily accessible place as you may need it later.
Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information
or useful usage tips.
AWarning against
dangerous conditions
for life and property.
BWarning against
electric voltage.
Packaging materials
of the product are
manufactured from
recyclable materials
in accordance with our
National Environment
Regulations.

3
IT
1. Safety and environment
instructions
This section provides the safety
instructions necessary to
prevent the risk of injury and
material damage. Failure to
observe these instructions will
invalidate all types of product
warranty.
Intended use
A
WARNING:
Keep ventilation
openings, in the appliance
enclosure or in the built-
instructure, clear of
obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
1.1. General safety
• This product should not
be used by persons with
physical, sensory and mental
disabilities, without sufficient
knowledge and experience
or by children. The device
can only be used by such
persons under supervision
and instruction of a person
responsible for their safety.
Children should not be
allowed to play with this
device.
• In case of malfunction,
unplug the device.
• After unplugging, wait at
least 5 minutes before
plugging in again.
• Unplug the product when not
in use.
• Do not touch the plug with
wet hands! Do not pull the
cable to plug off, always hold
the plug.
• Do not plug in the refrigerator
if the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be
used for a while, unplug the
product and remove any food
inside.

4
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1)
is open.
1
1
• Do not use steam or steamed
cleaning materials for
cleaning the refrigerator and
melting the ice inside. Steam
may contact the electrified
areas and cause short circuit
or electric shock!
• Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
• In case of malfunction, do not
use the product, as it may
cause electric shock. Contact
the authorised service before
doing anything.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED
type lighting, contact the
authorised service for
replacing or in case of any
problem.
• Do not touch frozen food with
wet hands! It may adhere to
your hands!
• Do not place liquids in bottles
and cans into the freezer
compartment. They may
explode.
• Place liquids in upright
position after tightly closing
the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
• Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
• Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
• Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.

5
IT
1.1.1 HC warning
If the product comprises a
cooling system using R600a gas,
take care to avoid damaging
the cooling system and its pipe
while using and moving the
product. This gas is flammable.
If the cooling system is
damaged, keep the product
away from sources of fire and
ventilate the room immediately.
CThe label on the inner left
side indicates the type of
gas used in the product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet
shall be maximum 90 psi (6.2
bar). If your water pressure
exceeds 80 psi (5.5 bar), use
a pressure limiting valve in
your mains system. If you
do not know how to check
your water pressure, ask for
the help of a professional
plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers if you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for
home use. It is not intended
for commercial use.
• The product should be used
to store food and beverages
only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
• Original spare parts will
be provided for 10 years,
following the product
purchasing date.
1.3. Child safety
• Keep packaging materials
out of children’s reach.
• Do not allow the children to
play with the product.

6
• If the product’s door
comprises a lock, keep the
key out of children’s reach.
1.4. Compliance with WEEE
Directive and Disposing of the
Waste Product
This product complies with
EU WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high
quality parts and
materials which can be
reused and are suitable
for recycling. Do not
dispose of the waste
product with normal domestic and
other wastes at the end of its
service life. Take it to the collection
center for the recycling of
electrical and electronic
equipment. Please consult your
local authorities to learn about
these collection centers.
1.5. Compliance with RoHS
Directive
• This product complies with EU
WEEE Directive (2011/65/EU).
It does not contain harmful and
prohibited materials specified in
the Directive.
1.6. Package information
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.

7
IT
C
* optional:Figures in this user manual are schematic and
may not match the product exactly. If the subject parts are not
included in the product you have purchased, then those parts
are valid for other models.
2. Your Refrigerator
1. Cooler compartment door
shelf
2. Water dispenser filling tank
3. Egg section
4. Water dispenser reservoir
5. Bottle shelf
6. Sliding storage containers
7. Adjustable legs
8. Deep freezer compartment
9. Quick freeze compartment
10. Ice cube tray & Ice bank
11. Vegetable bin
12. Zero degree compartment
13. Interior light
14. Cooler compartment glass shelf
15. Temperature adjustment button
16. Cooler compartment
17. Freezer compartment
*1
*2
*3
*4
*5
*5
*6
*8
*9
77
*11
*12
13
*15
16
17
*14
*10
*4

8
3Installation
3.1 Appropriate installation
location
Contact an Authorized Service for
the installation of the product. In
order to prepare the product for use,
refer the information in the user
manual and ensure that electrical
installation and water installation are
appropriate. If not, call a qualified
electrician and technician to have any
necessary arrangements carried out.
B
WARNING:
Manufacturer shall not be
held liable for damages
that may arise from
procedures carried out by
unauthorized persons.
B
WARNING: Product
must not be plugged
in during installation.
Otherwise, there is the
risk of death or serious
injury!
A
WARNING: If the door
clearance of the room
where the product shall be
place is so tight to prevent
passing of the product,
remove the door of the
room and pass the product
through the door by
turning it to its side; if this
does not work, contact the
authorized service.
• Placetheproductonanevenfloor
surface to prevent jolts.
• Installtheproductatleast30cm
away from heat sources such as
hobs, heater cores and stoves and
at least 5 cm away from electrical
ovens.
• Productmustnotbesubjectedto
direct sun light and kept in humid
places.
• Appropriateairventilationmust
be provided around your product
in order to achieve an efficient
operation. If the product is to be
placed in a recess in the wall, pay
attention to leave at least 5 cm
distance with the ceiling and side
walls.
• Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2 Installing the
plastic wedges
Plastic wedges supplied with the
product are used to create the
distance for the air circulation
between the product and the rear
wall.
1. To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
2. Insert the 2 plastic wedges onto
the rear ventilation cover as
illustrated in the figure.
3.3 Adjusting the feet
If the product stands unbalanced
after installation, adjust the feet
on the front by rotating them to the
right or left.

9
IT
C
Hot Surface Warning!
Side walls of your product
is equipped with refrigerant
pipes to improve the
cooling system. Refrigerant
with high temperatures
may flow through these
areas, resulting in hot
surfaces on the side walls.
This is normal and does
not need any servicing.
Please pay attention while
touching these areas.
3.4 Electrical connection
AWARNING:Do not make
connections via extension
cables or multi-plugs.
BWARNING: Damaged
power cable must
be replaced by the
Authorized Service Agent.
C
If two coolers are to be
installed side by side,
there should be at least
4 cm distance between
them.
• Our company shall not be
liable for any damages that will
arise when the product is used
without grounding and electrical
connection in accordance with
the national regulations.
• Power cable plug must be within
easy reach after installation.
• Connect your refrigerator to
a grounded outlet rated for a
voltage value of 220-240V /50
Hz. Outlet shall have 10 to 16A
fuse.
• Do not extension cords or
cordless multiple outlets
between your product and the
wall outlet.

10
3.5 Reversing the doors
Proceed in numerical order .
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20

11
IT
3.6 Reversing the doors
Proceed in numerical order .
1
17
1
20
11
13 9
2
10
5
3
20
20
8
18
17
19
45 °
180°
(8) (13)
14
6
4
12
16
15

12
4 Preparation
4.1 Things to be done for
energy saving
AConnecting the product to
electronic energy-saving
systems is harmful, as it
may damage the product.
• Do not keep the refrigerator
doors open for long periods.
• Do not place hot food or
beverages into the refrigerator.
• Do not overfill the refrigerator;
blocking the internal air flow
will reduce cooling capacity.
• In order to store the maximum
amount of food into the
cooler compartment of your
refrigerator, you should take
out the upper drawers and
place it onto the glass rack. The
declared energy consumption
of your refrigerator was
determined by taking out the
cooler, ice tray and upper
drawers in a way that will
enable maximum storage. Using
the below drawer when storing
is strongly recommended.
Energy saving function should
be activated for best energy
consumption.
• You should not block the airflow
by putting food in front of the
cooler fan. A space of minimum
3cm must be left in front of the
protective fan wire when placing
food.
• Depending on the product’s
features; defrosting frozen foods
in the cooler compartment
will ensure energy saving and
preserve food quality.
• Food should be stored using
the drawers in the cooler
compartment in order to ensure
energy saving and protect food
in better conditions.
• Food packages should not be
in direct contact with the heat
sensor located in the cooler
compartment. If they are in
contact with the sensor, energy
consumption of the appliance
might increase.
• Make sure the foods are not
in contact with the cooler
compartment temperature
sensor described below.

13
IT
4.2 Initial use
Before using your refrigerator,
make sure the necessary
preparations are made in line with
the instructions in “Safety and
environment instructions” and
“Installation” sections.
• Keep the product running with
no food inside for 6 and do not
open the door, unless absolutely
necessary.
CA sound will be heard
when the compressor is
engaged. It is normal to
hear sound even when the
compressor is inactive,
due to the compressed
liquids and gasses in the
cooling system.
CFront edges of the
product might heat up.
This is normal. These
areas are designed to
warm up in order to
prevent condensation.
CIn some models indicator
panel turns off automatically
5 minutes after the door
closes. It will be reactivated
when the door is open or any
button is pressed.

14
5 Operating the product
5.1 Temperature setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door
and leaving the door open for
long periods,
• Food put into the refrigerator
without cooling down to the
room temperature,
• The location of the refrigerator
in the room (e.g. exposing to
sunlight).
• You may adjust the varying
interior temperature due to
such reasons by using the
setting button.
• The numbers around the control
knob indicate the temperature
values in “°C”.
• If the ambient temperature is
25°C, we recommend you to
use the temperature control
knob of your refrigerator at 4°C.
This value may be increased or
decreased as required in other
ambient temperatures.
5.2 Fast freeze
If large amounts of fresh food
are going to be frozen, adjust the
temperature control knob to
( ) max. 24 hours before putting
the fresh food in the fast freeze
compartment.
It is strongly recommended to
keep the knob at this position at least
24 hours to freeze maximum amount
of fresh food declared as freezing
capacity. Take special care not to mix
frozen food and fresh food.
Remember to turn the temperature
control knob back to its previous
position once food has frozen.

15
IT
5.3 Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
• When the setting operation is
completed, you may press the
temperature control knob and
have it hidden.

16
5.4 Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your
product.
45
76
8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C
Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the
product you have purchased, then those parts are valid for other
models.

17
IT
1. Fridge compartment indicator
Fridge compartment light
is illuminated while the fridge
compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge
compartment temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press
Vacation button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press
compartment selection button to
switch between fridge and freezer
compartments.
7. Freezer compartment indicator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.

18
1. Economy
This symbol is illuminated when
the freezer compartment is set to
-18°C’ye as the most economical
setting value ( ). Economy
indicator is turned off when quick
cooling or quick freeze functions
are selected.
2. Power failure/High
temperature / error warning
indicator
This indicator ( ) illuminates
during power failure, high
temperature failures and error
warnings. During sustained power
failures, the highest temperature
that the freezer compartment
5.5 Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product.
Just press the inscriptions on relevant buttons for function settings.
reaches will flash on the digital
display. After checking the food
located in the freezer compartment
( ) press the alarm off button to
clear the warning.
Please refer to “remedies advised
for troubleshooting” section on
your manual if you observe that
this indicator is illuminated.
3. Energy saving function (display
off)
If the product doors are kept
closed for a long time energy
saving function is automatically
activated and energy saving symbol
is illuminated.When energy saving
C
Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the
product you have purchased, then those parts are valid for other
models.
12
568910
4
11
3
7.1 7.2
