Grundig PSW 5000 User manual

ǵ
WIRELESS
OUTDOOR
LOUDSPEAKER
PSW 5000

ENGLISH
11
Packing contents
Safety
To ensure that this device provides you with long-term satisfaction and enjoyment, please
observe the following instructions.
This device is designed for the playback of audio signals. Any other use is expressly
prohibited.
Protect the device from rain, moisture (dripping or splashing water), dust and heat. Do not
leave it next to heaters or inside parked cars in the sun.
Do not place any objects containing liquids (for example, vases) on the device. Do not place
any naked flames such as candles on the device.
Never open the device casing under any circumstances. No warranty claims are accepted for
damage caused by incorrect handling.
Thunderstorms are a danger to all electrical devices. Even if the device is switched off, it can
be damaged by a lightning strike to the mains. Always pull out the mains plug during an
electrical storm.
Do not use any cleaning agents, as this may damage the casing. Clean the device with a
clean, moist leather cloth.
Please note when deciding where to put the device that furniture surfaces are covered by
various types of lacquer and plastic, most of which contain chemical additives. These may
cause corrosion to the feet of the device, thus resulting in stains on the surface of the furniture
which can be difficult or impossible to remove.
Environmental note
This product has been made from high-quality parts and materials which can be re-used
and recycled.
Therefore, do not throw the product away with normal household waste at the end of its life.
Take it to a collection point for recycling electrical and electronic devices. This is indicated
by this symbol on the product, in the operating manual and on the packaging.
Please find out about collection points operated by your local authority.
Help protect the environment by recycling used products.
PSW 5000 ______________________________________________________
1PSW 5000 loudspeaker
2Mains adapter for connecting the
loudspeaker
3Wireless module
4Mains adapter for connecting the
wireless module
5Audio cinch cable
6Instruction manual
ENGLISH

12
Operating controls of the wireless module
Channel Switch for setting the transmission channel (1, 2 and 3). Switches
• • • • the transmission off.
3 2 1 Off
DC 9 V ÓSocket for the mains adapter cable.
R Line In L Audio signal inputs for connecting the wireless module to the
hi-fi system with the audio cinch cable supplied.
OVERVIEW ______________________________________________________

ENGLISH
13
Operating controls of the loudspeaker
Controls on the front
ON/OFF ǼSwitches the loudspeaker on and off.
– z+Adjusts the volume of the loudspeaker.
UBS Switches the bass boost (Ultra Bass System) on and off.
LIGHT Switches the lighting in the area of the woofer reflector on and off.
OVERVIEW ______________________________________________________

14
Controls on the bottom
Channel Switch for setting the transmission channel (1, 2 and 3).
1 2 3
DC 9 V ÓSocket for the mains adapter cable.
MP3/AUX IN Socket for connecting an external audio source (e.g. digital music
player) via an audio cable.
Close Open Screw for opening the battery compartment (8 x 1.5 V, LR 20/AM 1/
D size).
OVERVIEW ______________________________________________________
ɧ

ENGLISH
15
Connecting the wireless module
1Insert the plug of the supplied audio cinch cable into the »R Line In L« sockets of the
wireless module.
2Insert the plug of the supplied audio cinch cable into the corresponding output sockets
(R AUDIO OUT L) of the hi-fi system.
3Insert the cable of the mains adapter into the »DC 9 V Ó« socket of the wireless
module.
4Plug the mains adapter into the mains socket.
Caution:
The only way to disconnect the device from the mains supply is to unplug the adapter.
Note:
If your hi-fi system does not have R AUDIO OUT L outputs, you can also connect the
wireless module to the stereo headphones output of the hi-fi using a standard adapter
cable.
Preparing the loudspeaker
Battery operation
1Open the battery compartment on the bottom of the device by unscrewing the two screws
and removing the lid.
2Insert eight batteries (8 x 1.5 V, LR 20/AM 1/D size), observing the polarity marked on
the base of the battery compartment.
Notes:
Remove the batteries when they are flat or when you know that the device will not be
used for a long period of time.
The manufacturer accepts no liability for damage resulting from leaking batteries.
The batteries are switched off during mains operation.
Environmental note:
Batteries, including those which contain no heavy metal, should not be disposed of with
household waste. Please dispose of used batteries in an environmentally responsible
manner. Find out about the legal regulations which apply in your area.
Mains operation
1Insert the cable of the mains adapter in the »DC 9 V Ó« socket of the loudspeaker
(bottom of the device).
2Plug the mains adapter into the mains socket.
Caution:
The only way to disconnect the device from the mains supply is to unplug the mains
adapter.
CONNECTION AND PREPARATION ___________

16
General information
The PSW 5000 system works with a wireless audio receiver integrated in the outdoor loud-
speaker, which enables the reception of the wireless audio signals from the wireless module.
Loudspeaker connection cables are no longer necessary.
The wireless audio transmission range is limited by national and international regulations to
prevent radio interference from neighbouring devices. The wireless audio transmission power
is <10 mW. This guarantees an unhindered reception range of approximately 100 m. This
range is restricted inside buildings, depending on the construction materials used.
Avoid placing the system near metal objects or electrical devices such as cordless telephones
which use radio signals.
Since the audio signals are not transmitted on an exclusive range we cannot guarantee that
this will not cause interference. To avoid interference you can choose between 3 transmission
channels.
In some circumstances, people, walls and other surfaces can reflect radio signals. Reflected
signals can mix with non-reflected signals, thus causing a type of interference known as multi-
path reception. This can lead to noise or a temporary loss of sound. If such interference does
occur, simply position the transmitter or the loudspeaker differently.
Switching on the system
1Switch on the hi-fi system.
Note:
If the audio outputs of your hi-fi system have an adjustable output level, you can adjust
the volume on the hi-fi system. If the audio output levels are fixed, you have to adjust the
volume on the loudspeaker.
2Set the transmission channel (1, 2 or 3) with »Channel 3 2 1 Off« on the wireless
module.
– The operating display of the wireless module (front of the device) lights up.
3Switch on the loudspeaker with »ON/OFF Ǽ«.
– The operating display of the loudspeaker lights up.
4On the loudspeaker, set the same transmission channel (1, 2 or 3) as set on the wireless
module using »Channel 1 2 3« (bottom of the device).
5If necessary, set the required volume on the loudspeaker with »– z+«.
Note:
If signal interference occurs during operation, select another transmission channel which
corresponds on both the wireless module and the loudspeaker.
OPERATION ____________________________________________________

ENGLISH
17
Connecting external audio sources
You can relay the sound of an external audio source (e.g. digital music player) to the loud-
speaker via a standard audio cable.
1Plug the audio cable into the »MP3/AUX IN« socket.
2Plug the audio cable in the corresponding output socket of the external audio source.
Notes:
The loudspeaker must be switched off before connection.
As soon as the connection has been made, the loudspeaker automatically switches to the
external audio source. Signals from the wireless module can no longer be received.
Boosting bass sounds
1To activate the bass boost, press »UBS« on the loudspeaker.
– The LED for bass boost glows.
2To deactivate bass boosting, press »UBS« again.
– The LED for bass boost stops glowing.
Switching the loudspeaker lighting on and off
There are two lamps in the area of the woofer reflector.
1Press »LIGHT« to switch the lighting on and off.
Switching off the system
1Switch off the loudspeaker with »ON/OFF Ǽ«.
– The operating display of the loudspeaker stops glowing.
2On the wireless module, set the »Channel 3 2 1 Off« switch to »Off«.
– The operating display of the wireless module (front of the device) stops glowing.
3Switch off the hi-fi system.
OPERATION ____________________________________________________

18
Troubleshooting
In some circumstances, people, walls and other surfaces can reflect radio signals. This can
lead to noise or a temporary loss of sound. When such a problem occurs, it usually suffices
to reposition the loudspeaker or select a different channel combination on the wireless mod-
ule and the loudspeaker.
If the remedies below are not successful, please consult your specialist dealer.
Technical data
These devices are noise-suppressed according to the applicable EU directives.
These products fulfil the European directives 89/336/EEC, 73/23/EEC and 93/68/EEC.
These devices conform to the safety regulation DIN EN 60065 (VDE 0860) and therefore the
international safety regulation IEC 60065.
Never open the devices. No warranty claims are accepted for damage caused by incorrect
handling.
The type plate is located on the bottom of the devices.
INFORMATION_______________________________________________
Wireless module
Power supply
Mains adapter DC 9 V, 150 mA, 50/60 Hz
RF transmission frequency
863 - 865 Mhz
Dimensions and weight
W x H x D: 40 x 137 x 121 mm
Weight: approx. 0.20 kg
Outdoor loudspeaker
Power supply
Mains operation:
Mains adapter DC 9 V, 2000 mA, 50/60 Hz
Batteries: 8 x 1.5 V, LR 20/AM 1/D-Size
RF reception frequency
863 - 865 MHz
Speakers
Number of loudspeakers: 2
Bass: 150 mm
Treble: 25 mm
Dimensions and weight
W x H x D: 230 x 420 x 210 mm
Weight: approx. 2.40 kg
Technical and design modifications reserved
Fault
The outdoor loudspeaker
does not work.
There is noise interference
on the outdoor loudspeak-
er.
Malfunctions occur.
Possible cause
The transmission channels
do not match.
Interference caused by
another device.
Static electrical charge.
Remedy
Set the switches on the transmitter and the out-
door loudspeaker to the same transmission
channel.
Select a different transmission channel on
the wireless module and the outdoor loud-
speaker.
Reset the player. To do this pull out the mains
adapter plug or remove the batteries. Restore
the power supply after a short time.

Grundig Multimedia B.V.
Atrium, Strawinskylaan 3105 • NL-1077 ZX Amsterdam • http://www.grundig.com
72011 406 5000
