Grundig THARUS 51 User manual

COLOR TELEVISION
THARUS 51
LCD 51-9310 DOLBY
ǵ
ENGLISH
22296-941.0400
;

2
CONTENTS__________________________________________________________________________
3 Scope of delivery, Special Featueres
4 Installation and safety
5 At a glance
The front of the TV set; The connection sockets of the TV set
The remote control (TV mode); The remote control (teletext mode)
8 Connection and preparation
Putting batteries into the remote control
10 Settings
Programming TV channels; Picture and sound settings
11 Easy Dialog System
The »Easy Dialog System« interactive operating instructions
12 Additional functions
Zapp-Function; Alphanumeric channel selection
14 Adjusting the tilt angle
15 Mounting on the wall
17 Customer information
20 Correcting problems yourself

ENGLISH
3
THARUS 51 LCD 51-9310 DOLBY__________________
Scope of delivery
Special Features
51 cm aktiv Matrix TFT-LC-Display;
Interactive operating instructions »Easy Dialog System«;
Megatext level 2.5;
TV-Guide, TeleWeb
Alphanumeric channel position selection;
VGA interface for connecting a progressive image source (e.g. computer with
DVD drive);
GRUNDIG Megalogic:
– Perfect communication with a Megalogic video recorder. No troublesome
programming of channel positions.
– By starting playpack on the video recorder, the video programme position on
the TV set will be automatically selected.
01TV set
02Remote control
032 batteries, 1.5 V–, Mignon (AA)
04Strain relief
05Operating instructions
06Mains cable
07AV adapter
08EURO AV cable
09Wall mount
10 Socket panel
11 Aerial cable
12 Screw set consisting of:
a) 2 plugs 8x50, b) 2 screws 4.5x60
c) 1 screw 3.9x22, d) 4 screws 4.15x16
ǵTharus
ǵ
LCD-TV
TelePilot 150 C
@
123
5
6
7
8
9
10
12
11
4

4
INSTALLATION AND SAFETY_______________________________
Please observe the following information when installing and connecting the TV set:
This set has been designed for the reception and reproduction of picture and
sound signals.
Any other use is explicitly forbidden.
The ideal viewing distance from the screen is 5 times the diagonal width of the
screen.
External light shining on the screen adversely affects picture quality.
The TV set is designated for operation in dry rooms. Should you nevertheless
wish to operate the TV outside, make absolutely sure that it is protected against
moisture (rain, splashing from water). Never expose the TV set to moisture of
any kind.
Do not place the TV set close to the heating or in direct sunlight, as it could
overheat.
Heat buildup can be dangerous and is detrimental to the service life of the
equipment. From time to time, have a technician come to remove deposits from
the inside of the set.
Do not open the TV set under any circumstances. The manufacturer accepts no
liability for damage resulting from unauthorised tampering.
Make sure that the mains cable is not damaged.
The TV set may only be operated using the mains unit supplied.
Electrical storms represent a danger for every type of electrical device. Even if
the set is switched off, it could be damaged by a lightning strike hitting the
mains and/or the aerial lead. Therefore, always disconnect the mains plug and
aerial plug when there is an electrical storm.
When cleaning the screen, use only a soft, damp cloth.
Use clean water only.
ǵTharus
Krieg am Golf
TV R
ǵTharus
ǵTharus
! SERVICE !! SERVICE !! SERVICE !
5 x

ENGLISH
5
AT A GLANCE___________________________________________________________________
The front of the TV set
IO Switches the TV set on/off.
An LED indicates the current operating mode.
Green = Operation.
Yellow = Standby (TV-GUIDE mode, copy mode, Timer mode).
Red = Standby (power saving mode,
timer programmed).
The connection sockets of the TV set
The connection sockets are located on the bottom of the screen.
ʋʋMains cable to the socket.
VGA VGA connection for PC
AUDIO IN Audio signal input for PC
AV 2 AUDIO/VIDEO jack 2 for connecting a video recorder, DVD
WIRELESS player via the accompanying AUDIO/VIDEO adapter or the
wireless transmitter module WT-AV.
AV 1 Euro/AV socket
yyHeadphone socket
Service jack for the authorised dealer (under the cover).
ÉAerial socket
s
VGA AUDIO
IN
AV 2
WIRELESS
AV 1 y
ʋ

6
AT A GLANCE_____________________________________________________________________________
The remote control
ǼǼSwitches the TV set off (standby).
PIP TV picture in teletext mode.
EPicture format switching.
DDisplays the index A-Z.
1 … 0 Channel selection and switching on from standby,
alphanumeric channel selection (see page 13),
entry of teletext page numbers.
ĭĭ
Sound on/off (mute)
iCalls up the »Easy Dialog« menu.
ZZap function (see page 12).
P+, P- Switching on from standby,
step-by-step channel selection, cursor up/down.
ǸǷ Volume, cursor to the left/right.
OK Changes and activates various functions.
TXT Teletext mode/TV mode.
TV-G TV-Guide, info about current programme.
zzCalls up the »PICTURE« menu.
ȄȄClock time and channel position information on/off.
ǷǷStill picture.
FFCalls up the »SOUND« menu.
VCR/SAT/ To operate a GRUNDIG video recorder, satellite receiver,
DVD DVD player press the »»VCR«, »SAT« resp. »DVD« button and
hold it down. Then press the desired button.
Which functions can actually be controlled depends of course of
the equipment of the connected unit. Just try it out.
Tele Pilot 150 C
@

ENGLISH
7
AT A GLANCE_____________________________________________________________________________
The remote control (teletext mode)
1 … 0 Enter the teletext page number
ELetter size
DCall up descriptions of the various functions of the teletext in the
»VT-Settings« menu.
iCall up the »VT-Settings« menu in teletext mode
P+, P- Page Catching.
Select teletext pages from overview pages directly and call up
with »OK«
ǸǷ Select sub-pages.
Set the »subpages« function in the »VT-Settings« menu
to »Ja«
OK Direct call up of the »Stop«, »Present mode« or »Press reveal« fun-
ction (if the corresponding function is switched on in
the »VT-Settings« menu)
TXT Teletext mode ɫTelevision (TV) mode
TV-G Direct selection of the »Press reveal« function
zz (red) Page back
ȄȄ
(green) Page forward
@(yellow) Select next chapter
FF(blue) Select next topic
Notes:
In the »VT-Settings« menu, many possibilities of the teletext can be set. To do
this during in teletext mode, call up the »v« menu with »i«.
Detailed notes can be found in the »Easy Dialog System« interactive operat-
ing instructions.
Tele Pilot 150 C
@

8
CONNECTION AND PREPARATION_______________
Putting batteries into the remote control
1Open the battery compartment by pulling off the cover.
2Insert the batteries (Mignon, e.g. UM 3 or AA, 2x 1.5V) observing correct
polarity.
Note:
If your television does not react to the remote control commands correctly,
then the batteries could be used up. Remove empty batteries. There is no
liability for damage caused by leaking batteries.
Environmental note:
The batteries – even those free of heavy metals – cannot be disposed of in
normal household rubbish. Used batteries must be disposed of in used
battery collection containers in businesses or be taken to public waste
disposal facilities.

ENGLISH
9
CONNECTION AND PREPARATION_______________________________________
Connect aerial, mains cable and AV devices (video
recorder, DVD player, etc.)
1Plug aerial cable to the house aerial into the »É« jack
2Plug included mains cable into the »ʋʋ« jack
3If desired, connect video recorder with supplied EURO AV cable to the
»AV 1 « jack.
4If desired, connect other AV devices (e.g. DVD player, satellite receiver) or
Wireless Transmitter System WT-AV2 with supplied AUDIO/VIDEO adapter
to the »AV 2 WIRELESS« jack.
5Lay the connecting cable in the recesses and fasten the supplied strain relief
with the two screws.
6Insert the supplied socket panel.
When doing this, attach the socket panel at the bottom and flip it up.
Notes:
The connected devices have to be set in the »Installation« menu at the
»Devices« point.
Detailed notes can be found in the »Easy Dialog System« interactive operat-
ing instructions.
Consult page 11 and the following pages to see how to use the Easy Dialog
System.
VGA AUDIO
IN AV 2 WIRELESS
12 V ј
max. 200 mA
AV 1 y
ʋ
VGA AUDIO
IN AV 2 WIRELESS
12 V ј
max. 200 mA
AV 1 y
ʋ

10
SETTINGS______________________________________________________________________________
Programming TV channels
The TV set is equipped with the automatic tuning system “ATS euro plus” which
carries out the channel position assignment for you.
1After switching on the TV set for the first time, select the dialog language with
»P+, P-« and confirm with »OK«.
2Select your country (place of installation) with »P+, P-« then confirm with
»OK«.
– The automatic tuning system is started.
– Depending on the number of channels which can be received, the search
can take one minute and more.
– When the automatic allocation of the channel positions is completed, the
»Easy Dialog tips« menu appears. Via this menu you may learn how to
operate your TV set.
3Select the desired menu item with »P-« then press »OK« to call it up.
4To switch to TV mode, select »TV« with »P+, P-« and confirm with »OK«.
Note:
The TV channels that have been found can be sorted as you wish. TV chan-
nels that were subsequently added can also be set.
Detailed notes can be found in the »Easy Dialog System« interactive operat-
ing instructions.
Picture and sound settings
Call up these settings with the »zz« button (picture) or »FF« button (sound).
Detailed notes can be found in the »Easy Dialog System« interactive operating
instructions.
Menu Language
Select
and confirm Help
Exit
Deutsch
Dansk
Español
Français
English
Italiano
Norsk Slovensky
Nederlands
Português
Svenska
Suomi
âesky
Slovensko
Magyar
Polski
Türkçe
Български

ENGLISH
11
EASY DIALOG SYSTEM_____________________________________________
The »Easy Dialog System«
interactive operating instructions
Your TV set is equipped with the »Easy Dialog System« interactive operating
instructions.
The many possibilities as well as settings and operation of the TV set are dis-
played with this interactive operating instructions by menu tables, user guides
and help functions.
The printed operating instructions are used for the first installation, as well as for
a general overview and are therefore very brief.
This is how the »Easy Dialog System« works
The »Easy Dialog« main menu is the control centre of your TV set.
This menu is the table of contents of the »Easy Dialog Systems«.
It is called up with »i«.
In the index »A bis Z«, you will find an alphabetically ordered description of all
user possibilities and settings.
The individual menu items are directly called up with »1 … 0 « or
one by one with »P+, P- « and confirmed with »OK«.
The user guide in the lower part of the menu table shows you with which buttons
certain functions are called up.
If you want an explanation about the selected function, simply press »D«.
Did you accidentally press the wrong menu item? No problem, switch back
to a menu with »FF«.
Have you made all your settings, or are you finished with “browsing” in the
interactive operating instructions, switch to TV operation with »i«.
Just try it out. You can’t do anything wrong.

12
ADDITIONAL FUNCTIONS______________________________________
Zap function
With this function you may store the current channel position and switch to
another one (zap).
1Use »1 … 0« or »P+, P-« to select the channel position you wish to store in
the zap memory (e.g channel position 7, PRO7) then press »Z« to store it.
On the picture screen appears, for example, »Z 7 PRO7«.
2Using »1 … 0 « or »P+, P- « you now may switch to another channel
position.
3By pressing »Z« you may switch at any time to the stored channel position
(PRO7 in the example) and switch back (zap) to the last viewed channel.
4Press »i« to end the zap function. The on-screen display disappears.
›
Z 7 PRO7

ENGLISH
13
ADDITIONAL FUNCTIONS _______________________________________________________
Alphanumeric channel selection
You may select the channel positions directly by entering the channel name (e.g.
ARD). For this, letters are assigned to the numeric buttons »2 … 0«. Up to four
letters can be assigned.
1Use »2 … 0« to enter the first letter of the channel name (e.g. »2« for the
letter A). A list of all TV channels beginning with the letters »A«, »B«, or »C«
appears on the picture screen.
Every entry of a further letter confines the list of channel names.
2Use »P+, P- « to select the desired channel in the list then press »OK« to
call it up.
Note:
Three methods are possible for selecting a channel position:
1. Letter entry off: The channels are only selected by entering digits.
2. Letter entry on: The channels are only selected by entering alphanumeric
characters.
3. Mix: When entering a digit, the TV set switches automatically to the
corresponding channel position and the channel list for assigning letters is
displayed.
Example: Press »3«. The TV set switches to channel position 3 (e.g. BR3),
in addition a list of the channels beginning with »D«, »E«, or »F« is
displayed.
The channel selection mode is selected in the »Installation« menu under the
»Special functions« menu item. See also the notes in the Easy-Dialog system.

14
ADJUSTING THE TILT ANGLE_______________________________
The tilt angle of the screen can be adjusted either electronically or mechanically.
Electronically adjusting the tilt angle
You can easily adjust the tilt angle electronically.
1Call up the picture menu with »zz«.
2Select the »Tilt angle« line with »P+, P- « (second page).
3Set the desired tilt angle with »Ǹ« or »Ƿ«.
4End setting with »i«.
Mechanically adjusting the tilt angle
If the electronic adjustment of the tilt angle was not sufficient, you can also adjust
it mechanically. Use the two different positions available in the foot of the TV set.
1Remove the foot of the TV set.
Loosen the 2 screws on the bottom of the foot.
2Insert both screws into the holes of the desired position and attach it again to
the TV set.
To page 1
Select
and open Help
Back Exit
2 Comb filter
1 Noise reduction automatisch
3 Flicker-Reduction Reference
4 Tilt angle
automatic

ENGLISH
15
MOUNTING ON THE WALL__________________________________
The supplied wall mount lets you hang the TV set on the wall like a picture.
To do this, use the plug (a) and screws (b) included.
Use the wall mount to mark the fixing points on the wall.
Be sure that the screws extend about 1 cm from the wall.
Install the wall mount
1Loosen the large screw on the rear panel of the TV set. This can be done with
a coin.
2Fix the wall mount on the rear panel of the TV set with this large screw and
secure it with the screw (c).
3Remove the foot of the TV set. Loosen the 4 screws on the bottom of the foot.
4Hang the TV set on the wall.
Using the moveable wall mount
The wall mount included with the TV set is set up for mounting the moveable wall
mount compatible with the VESA standard (e.g. EFW 1005 from Vogel`s). This
wall mount lets you adjust the horizontal and vertical angle of the TV set on the
wall.
1Attach the wall mount to the TV set as described above.
2Fasten the moveable holder to the holder on the TV set.
Warning: To do this, only use the screws (d) that were included with the
TV set. The metric screws supplied with the moveable holder are not suitable.
VGAAUDIO
IN AV2
WIRELESS
12Vј
max.200 mA
AV1
y
ʋ
VGAAUDIO
IN AV2
WIRELESS
12V ј
max.200mA
AV1
y
ʋ

16
MOUNTING ON THE WALL_____________________________________________________
Disassembling the sound module (if desired)
1Remove TV set’s foot
To do this, loosen the two screws on the bot-
tom of the foot
2Loosen the four screws on the sound module
at the rear.
3Remove the sound module by pulling down.
Note:
If the TV set is going to be used without the sound module, the "U” jack must
be connected to the audio input plug of the stereo amplifier or to active spea-
kers.
Whether you use a stereo amplifier or active speakers, be sure this choice is
set in "Audio output” in the audio menu (press »FF«).
Detailed information can be found in the interactive operating instructions
"Easy Dialog System”.
VGA AUDIO
IN
AV 2
WIRELESS
12 V ј
max. 200 mA
AV 1 y
ʋ

ENGLISH
17
CUSTOMER INFORMATION__________________________________
Technical data
Power supply voltage: 220 – 240 V, 50/60 Hz,
(range of adjustment in the mains supply circuit
190 … 264 V)
Power requirement: in operating mode 40 W, in standby mode
Final sound stage: Front 2 x 5 watts music (2 x 3 watts sinus)
Subwoofer 12 watts music (8 watts sinus)
Frequency area: C01 … C99, special channels S01 … S41
Pixel pitch: 0.6375 mm x 0.6375 mm
Viewing angle: 70°/70° hor.; 65°/55° vert.
Contrast ratio: 400:1
Brightness: 400cd/m2
max. liquidation: VGA 640 x 480 (60 Hz)
Hor. Frequency: 31~69 kHz
Vert. Frequency: 56~85 Hz
Virtual Dolby Surround: Under license from Dolby Laboratories Licensing Corporation.
DOLBY and the double-D symbol ijare trademarks of Dolby Laboratories Licensing
Corporation.

18
220
21 119
CUSTOMER INFORMATION__________________________________
Pin assignment for the EURO-AV socket 1
Pin Signal
11 = audio output right
12 = audio input right
13 = audio output left
14 = audio ground
15 = blue ground
16 = audio input left
17 = RGB blue input
18 = switching voltage
19 = green ground
10 = data line (MEGALOGIC)
11 = RGB green input
12 = –
13 = red ground
14 = ground
15 = RGB red input, (S-Video = chroma)
16 = RGB switching voltage
17 = video ground
18 = RGB switching voltage ground
19 = video output
20 = video input (S-Video = luminance)
21 = shielding/ground

ENGLISH
19
CUSTOMER INFORMATION__________________________________
Service hints for the specialized dealer
The TV set may be operated only with the mains calbe set supplied. It prevents
mains interference and is an integral part of the appliance approval. For repla-
cement purposes, please order only the mains cable set with the part number
8290.991-427 from an approved after-sales service.
The product meets the requirements of the following EU guidelines: 73/23/EEC
guideline on electrical equipment for use with certain voltage limits.
89/336/EEC guideline on electromagnetic compatibility.
The appliance complies with the standards: EN 60065, EN 55013, EN 55020

20
CORRECTING PROBLEMS YOURSELF____________
If the remedies below do not lead to a good result, contact an authorised GRUNDIG
dealer.
Please consider that problems can also be caused by external appliances, such as video
recorders and satellite receivers.
Problem Possible cause Remedy
When switching on the TV set for Some of the TV channels have ATS RESET: Turn off your TV set
the first time, the menu for selecting already been set using the main power button
the language not displayed. L+ and press main power and
turn is not displayed button at
the same time and turn TV set
on and off again. Then turn
your TV seton again.
Bright screen(noise or blue) Aerial cable. Aerial cable connected?
but no programme visible. Check aerial system.
Low picture contrast. Incorrect picture settings. Change brightness, contrast, or
colour settings.
Problem is with the broadcaster. Test another channel.
No colour Colour intensity is on minimum. Adjust color upward.
TV standard setting Select proper colour standard.
(if setting possibility is available).
problem is with the broadcaster Test another channel.
Sound unclear Sound setting. Correct sound setting.
Double image, reflection. Channel setting Automatic or manual
channel setting/fine tuning
Aerial Have aerial cable or device
checked
