GSI Group 2000 Series User manual

1
SERIES 2000 BATCH DRYER
1
Automatic Batch
Portable Dryer
Operation
Service
Manual
PNEG-680

2
SERIES 2000 BATCH DRYER

3
SERIES 2000 BATCH DRYER
SafetyAlertSymbols&Decals..........................................................................................4
SafetyAlert Decals............................................................................................................5
SafetyPrecautions:.............................................................................................................6
Dryer Control Panel .....................................................................................................7
Dryer Pre-Start Checks.................................................................................................10
Dryer Start-Up............................................................................................................14
Batch Timer Settings............................................................................................16
Automatic Dryer Service Guide..................................................................................18
Seasonal Inspection and Service..........................................................................19
Lubrication Instructions.......................................................................................19
Suggested Lubricants...........................................................................................20
Fan Motor Removal and Installation.....................................................................21
Heater Parts Removal and Installation.................................................................22
Wiring Diagrams......................................................................................................23
Competitor Computer Board.............................................................................23
Input/Output Board............................................................................................24
Competitor Batch Upper External Wiring........................................................25
Competitor Batch Lower Internal Wiring...........................................................26
Competitor Batch Lower ExternalWiring..........................................................27
Competitor Batch External Wiring....................................................................28
Competitor Batch Lower Back Panel Wiring....................................................29
Trouble Analysis Procedure......................................................................................30
Notes............................................................................................................................35
Warranty.................................................................................................................36
TABLE OF CONTENTS

4
SERIES 2000 BATCH DRYER
Safety Alert Decals
TheGSI Group, Inc. (GSI) principle concern is your
safety and the safety of others associated with grain
handling equipment. This manual was written with
that thought in mind. We want to keep you as a
customer by helping you understand safe operating
proceedures, and how to solve some of the prob-
lems that may be encountered by the dryer operator
or other personnel.
ciated with the equipment or who are in the dryer
area. Avoid any alterations to the equipment. Such
alterations may produce a very dangerous situation,
where serious injury or death may occur.
Safety Alert Symbol
WARNING! BE ALERT!
Personnel operating or working around a
dryer should read this manual. This
manual must be delivered with equipment
to its owner. Failure to read this manual
and its safety instructions is a misuse of
the equipment.
The symbol shown below is used
to call your attention to instruc-
tions concerning your personal
safety. Watch for this symbol; it
points out important safety pre-
cautions. It means "ATTEN-
TION", "WARNING", "CAU-
TION", and "DANGER". Read
the message that follows and be
cautious to the possibility of per-
sonal injury or death.
Safety decals should be read and
understood by all people in and
around the dryer area. If the follow-
ing safety decals are not displayed
on your dryer, or if they are dam-
aged, contact The GSI Group, Inc.
for replacement.
A CAREFUL OPERATOR
IS THE BEST INSURANCE
AGAINST AN ACCIDENT
The GSI Group, Inc. recommends
you contact your local power com-
pany and have a representative sur-
vey your dryer installation, so your
wiringwillbecompatiblewiththeir
system and you will have adequate
power supplied to your unit.
SAFETY ALERT SYMBOLS & DECALS
As owner and/or operator, it is your responsi-
bility to know what requirements, hazards and pre-
cautions exist, and to inform all personnel asso-

5
SERIES 2000 BATCH DRYER
Three decals displayed on all GSI Dryers. Belt drives, chain driven meter rolls and
combustible fuels must be treated with caution.
SAFETY ALERT DECALS

6
SERIES 2000 BATCH DRYER
1. Read and understand the operating manual before trying to operate
the dryer.
2. Never operate the dryer while the guards are removed.
3. Power supply should be OFF for service of electrical compo
nents. Use CAUTION in checking voltage or other procedures re
quiring power to be ON.
4. Check for gas leaks at all gas pipe connections. If any leaks
are detected, do not operate dryer. Shut down and repair be
fore further operation.
5. Never attempt to operate the dryer by jumping or otherwise bypass
ing any safety devices on the unit.
6. Set pressure regulator to avoid excessive gas pressure applied to
burner during ignition and
when burner is in operation. See chart
foroperating procedures. Do not exceed maxi
mumrecommended
drying temperature.
7. Keep the dryer clean. Do not allow fine material to accumulate
in the plenum chamber.
8.
Keep auger drive belts tight enough to prevent slippage.
9. Use CAUTION in working around high speed fans, gas burners,
augersand auxiliary conveyors which STARTAUTOMATICALLY.
10. Donot operateinany areawherecombustible materialwillbe drawn
intothe fan.
11. Beforeattemptingtoremoveandreinstallanypropellor,makecertain
toreadtherecommendedprocedurelistedwithintheservicingsection
of the manual.
12. Be certain that capacities of auxiliary conveyors are matched to
dryer auger capacities.
13. Clean grain is easier to dry. Fine material increases resistance to
airflow and requires removal of extra moisture.
Use Caution in the
Operation of this
Equipment
The design and manufacture of
this dryer is directed toward op-
erator safety. However, the very
nature of a grain dryer having a
gas burner, high voltage electri-
cal equipment and high speed
rotating parts, does present a
hazard to personnel, which can
not be completely safeguarded
against, without interfering with
efficient operation and reason-
able access to components.
Use extreme caution in
workingaround high speed fans,
gas fired heaters, augers and
auxiliary conveyors, which may
start without warning when the
dryer is operating on automatic
control.
READ THESE INSTRUCTIONS
BEFORE OPERATION AND SERVICE
SAVE FOR FUTURE REFERENCE
Continued safe, dependable op-
eration of automatic equipment
depends, to a great degree, upon
the owner. For a safe and de-
pendable drying system, follow
therecommendationswithinthis
manual, and make it a practice
to regularly inspect the opera-
tion of the unit for any develop-
ing problems or unsafe condi-
tions.
Take special note of the
safety precautions listed above
before attempting to operate the
dryer.
KEEP THE DRYER CLEAN
DO NOT ALLOW FINE
MATERIAL TO ACCUMULATE
IN THE PLENUM CHAMBER
OR SURROUNDING THE
OUTSIDE OF THE DRYER
SAFETY PRECAUTIONS

7
SERIES 2000 BATCH DRYER
Moisture Control Thermostat
Dryer Control Panel Featuring
Competitor Series 2000 Control System
This switch turns the power on or off to the mois-
ture control thermostat. The light comes on when
the grain column temperature is below the thermo-
stat set point.
Thecontrolpanelprovideseasyaccesstogaugesandcon-
trols, and the lights by the switches provide a quick refer-
ence for every operating function. The Series 2000 Con-
trolSystem is a computerized control systemthatgives
instant information regarding dryer operation. Moisture Control Switch
DRYER CONTROL PANEL
This electronic thermostat controls the moisture
level of discharged grain by sensing grain column
temperature.

8
SERIES 2000 BATCH DRYER
Control Power Switch
The power to the Series 2000 Control System is turned
on or off with this switch.
Load Auger Switch
The dryer service light is turned on or off here. It also
may be set on auto, which turns the light on while the
dryer is running, and off if a shutdown occurs.
Outside Light
DRYER CONTROL PANEL
The fan is turned on or off with this switch. The
on position operates the fan continuously. The auto
position operates the fan during hi-heat, lo-heat and
cool cycles, but shuts off during unload. The light
will light up whenever the airflow switch is sens-
ing air pressure and the dryer is full of grain.
Fan Switch
Heater Switch
This switch is used to turn the burner on or off. The
auto position operates the burner during the hi and
low heat cycles. The on position will operate the
burner anytime that the fan is running. The light will
light up when the flame sensor detects the flame.
Unload Switch
The unload switch turns the discharge auger on or off.
Note: If the unload auxiliary motor connections
are being utilized in the dryer control panel, this
switch will also control the operation of the auxiliary
equipment.
Dryer Power Start Switch
Dryer Power Stop Switch
This switch stops all dryer functions. If an automatic
dryer shutdown occurs, first determine and correct
the cause of the shutdown. Then, press the dryer
power stop button to reset the dryer before restarting.
Turn the control power switch to on. The monitor will
first light up the entire display, then the screen will
show "GSI" followed by the software version #, then
the plenum temperature. When the plenum tempera-
ture is displayed you can run the dryer.
Turning on the Series 2000
Control System
This switch starts and operates the dryer based on switch
settings. The load, fan, heater, and unload switch must
be either in the Aux or Manual position before the dryer
will start.
Competitor Series 2000
High Heat, Low Heat and Cool Timers
These switches are used to set the cycle times. The current
settings on these three timers is displayed on the screen. To
change the setting of these timers follow these instructions:
1. Press the program timer button unit the carrot
is over the correct timer.
2. Press the increase or decrease button to adjust
the settings.
3. The new time is automatically accepted.
During operation the remaining time on each timer
is displayed on the screen. If the power goes out or if
the dryer is stopped, these times are saved by the con-
troller. When the dryer is restarted the timers will
continue timing down. The timers will return to their
initial settings by pressing the stop button.
In both the auto and manual position the load auger
will operate if the dryer is low on grain and will auto-
matically shut off when the dryer is full. In the auto
position only, the dryer will shut down after a preset
period of time set on the out of grain timer, if grain
flow is interrupted to the dryer. The switch will light
whenever the load auger is operating.
Note: If the load auxiliary motor connections are
being utilized in the dryer control panel, this switch will
also control the operation of the auxiliary equipment.
This is used to select the operation of the fill auger.
The Series 2000 Competitor System controls all timing
functions and safety circuit checks. It is designed to
simplify dryer operation by providing printed
messages and warnings on its liquid crystal dis-
play (LCD).

9
SERIES 2000 BATCH DRYER
The load delay is used to delay the starting of the load
auger when the dryer is unloading to prevent the load
auger from starting and stopping. The unload delay is
used to control the amount of time the unload auger runs
after the dryer is empty to allow for auger cleanout. Both
the load and unload delays are set using the same proce-
dure as the timers.
Setting the Load and Unload Delays
Dryer Safety Circuit
DRYER CONTROL PANEL
Setting the Out of Grain Timer
If the dryer runs out of grain while the load auger switch is in
the auto position, the out of grain timer automatically shuts off
the dryer after the period of time preset on the timer.
Vapor High Temperature
The flame sensor has failed to detect a burner flame
indicating that the burner has failed to light, there is a
problem with the flame sensing circuitry or the dryer is
not getting burner fuel. On these dryers, the flame probe
must physically touch the flame. A probe can be Red
Hot, but this does not mean that flame is sensed.
The temperature high limit located on the fan/burner
housing has opened, indicating an over temperature con-
dition has occurred towards the rear of the fan/heater
housing. This control is set at 200°F and must be manu-
ally reset.
The LP gas vapor temperature sensor located in the gas
pipe train downstream from the vaporizer, has opened
indicating that the vaporizor is running too hot and must
be readjusted. This sensor is set at 200°F and automati-
cally resets itself when cool.
Housing High Temperature
Loss of Flame Warning
The lid on the grain discharge box has opened, indicat-
ing that grain is not being taken away fast enough at the
discharge box.
Grain Discharge Warning
Safety Circuit Shutdown Messages
The Series 2000 Control System continuously checks
all safety circuits on the dryer, and will automatically
shut the dryer down should a problem occur. The
cause of the dryer shutdown will be displayed on the
LCD display. To restart the dryer after a safety shut-
down, first correct the reason for the shutdown, and
then press the dryer power stop button to reset the cir-
cuit. Press the start button.
An over temperature condition has occurred in the left side or
rightside(leftandrightasviewedfrombehindthedryer)grain
columncausingthecontroltoshutdownthedryer.Thiscontrol
is set at 210°F and automatically resets itself when cool.
Fixed Grain High Temperature
"Air" Warning
Plenum High Temperature
An over temperature condition has occurred inside the
dryer plenum. This control is a 300°F limit and auto-
matically resets itself when cool.
Loss of Airflow
The contacts in the air switch have opened due to insuffi-
cient air pressure in the plenum.
The air switch contacts have closed prior to the fan start-
ing, indicating a freewheeling blade or improper setting of
the air switch.
The dryer has run low on grain, and the out of grain
timer has timed out, shutting the dryer down.
Out of Grain
One of the thermal overloads on either the fan, load,
unload or auxiliary motors has opened, indicating an
overcurrent condition. The overloads must be manu-
ally reset.
Motor Overload

10
SERIES 2000 BATCH DRYER
DRYER PRE START CHECKS
Pre Season Inspection
Before the dryer is filled, thoroughly inspect the unit
and check the operation of the dryer.
BEFORE ATTEMPTING TO OPERATE THE
DRYER MAKE SURE ALL SAFETY SHIELDS
ARE IN PLACE, ALL BOTTOM CLEANOUT
AND REAR
ACCESS DOORS ARE CLOSED
AND ALL PERSONNEL ARE CLEAR OF
THE DRYER
Moisture Control Switch-ON
Moisture Control Thermostat-
MAXIMUM TEMPERATURE
Load Switch-OFF
Unload Switch-OFF
Fan Switch-OFF
Burner Switch-OFF
Out of Grain Timer-1 MINUTE
Load Delay-30 SECONDS
Unload Delay-30 SECONDS
High Heat Timer-60 MINUTES
Low Heat Timer-20 MINUTE
Cool Timer-10 MINUTES
Set Control Switches
Electrical Power
Turn on the electrical power supply to the dryer, set
all circuit breakers to on, including the safety dis-
connect handle mounted on front of the dryer's
power panel.
The Maxon safety shut off valve.
Power Start Button
Fuel Check
Push the dryer start button, and all the selector switches
on the control panel will be activated.
Turn the control power switch to on. The light will
light up. If a fault is found, the cause will be displayed
on the LCD. If all safeties are found closed, the dryer
is ready to operate.
Control Power Switch
If using LP gas, make sure the tank has plenty of fuel
and that the tank does not have a regulator mounted
to it. If using natural gas, make sure an adequate sup-
ply is available.
If using LP gas, slowly open the main fuel supply
valve at the tank. If using natural gas turn on the
valve along the supply line. Open the Maxon elec-
tronic shut off valve, if so equipped, or open the
manual shut off valve on the dryer to allow fuel flow
to the dryer. Natural gas and multi-fan dryers are
equipped with a Maxon valve, single fan dryers are
not. Inspect all gas lines and connections for pos-
sible leaks.
Any gas leaks must be
fixed immediately!

11
SERIES 2000 BATCH DRYER
Load Auger
switch to the auto position. The top auger and
wet grain supply auxiliary should run for one
minute, and then the dryer will shut down leaving
the safety shutdown message (out of grain) dis-
played. Press the dryer power stop button to reset
the panel, then press the start button.
With the grain supply shut off, quickly bump the
load auger switch to manual, and see if the load
auger rotates clockwise as viewed from the drive
end, or counterclockwise if the dryer is a front
load model. If the wet grain supply auxiliary is
wired to the dryer it should also rotate in the cor-
rect direction at this time. Turn the load auger
To test fire the burner, turn on the fan switch, the heater switch, then, turn on the fuel supply.
DRYER PRE START CHECKS

12
SERIES 2000 BATCH DRYER
DRYER PRE START CHECKS
stat is turned down the gas pressure should also
show a noticeable drop, indicating that the hi-fire
solenoid is closed and the burner is being sup-
plied with less gas through the low fire control
valve. At this time set the hi-fire and lo-fire pres-
sure settings. Use the pressure regulator for hi-
fire and the ball valve for lo-fire. The thermostat
should cycle between high and low, approximately
4 to 5 times per minute.
Approximate settings should be:
LP Gas Hi-Fire 6-15 lbs.
The dryer fan and heater
controls featuring: 1-pressure
regulator, 2-lo-fire control
valve, 3-high pressure sole-
noid, 4-low pressure solenoid,
5-hi-lo fire thermostat (assem-
bly includes thermometer), 6-
fuel supply line, 7-LP solenoid
or supply ball valve(NG) and 8-
air pressure switch.
Fan Switch
onthree phase models all motors will run backwards.
They can easily be reversed by interchanging two
of the three power supply wires. Reverse the two
outside wires, L1 and L3, and leave the middle one
in the same position.
Note: If the dryer is empty, the burner will not
operate. The fans cannot create enough static pres-
sure to engage the air switch. You will receive a loss
of airflow message.
To check the burner safety function, first make sure
the main gas valve is off. Turn the fan switch on,
and allow the fan to start. Then, turn the heater
switch on. The dryer will shut down after 20 sec-
onds. The safety message, "Loss of flame" will ap-
pear.
Burner Test Fire
Burner Safety
Test fire the burner by starting the fan, and then
turn the burner switch to on. Turn on the fuel sup-
ply, and the burner should ignite after a short purge
delay of approximately 10 seconds. Gas pressure
should be shown on the gauge. At this time adjust
Lo-Fire 2-6 lbs.
Natural Gas Hi-Fire 6-10 lbs.
Lo-Fire 1-3 lbs.
If the burner remains on hi-fire and does not cycle,
increase the regulator setting on the propane mod-
Bump the fan switch and observe the fan rotation.
The fan should run counterclockwise. Sometimes the burner hi-lo fire thermostat to 200°F, causing the burner to operate on hi-fire, as indicated on
the display. Observe the gas pressure on gauge,
and adjust the plenum set point to a minimum set-
ting, causing the burner to cycle into lo-fire, as
indicated on the display. As the burner thermo-
els, or the supply valve on the natural gas models
in order to reach the thermostat setting. If the
burner remains in lo-fire and does not cycle, slightly
decease gas pressure with the lo-fire control valve.
If the gas pressure is decreased too
much, a popping or fluttering sound
will be heard. Also, anytime the high
pressure side is adjusted the low
pressure side needs to be checked.
1
2
3
4
5
6
7
8

13
SERIES 2000 BATCH DRYER DRYER PRE START CHECKS
To check the batch operation, locate the white junc-
tion box in the back of the dryer, under the rear ac-
cess door, and remove the cover exposing the mer-
cury switch. Position the switches on the control
panel as follows:
Load - Manual position, to avoid the out of grain
warning in the auto position
Fan - Auto position
Burner - Auto position
Unload - Auto position
Turn on the control power and wait until the display
settles on the plenum tempature. At this point the
timers may be adjusted. Press the start button. The
load switch should light up indicating the loading
process. If it is not lit check the back of the load
mercury switch to see that it is installed properly.
This mercury switch is shipped to you mounted on
the front of the dryer in a white box with a black
cord going to the junction box with the outside
light attached. This switch must be installed on
the load auger to work.
Go to the back of the dryer and reverse the
mercury switch in the clip so the leads are on the
right side. This simulates the presence of grain.
On the front of the dryer, turn the load mercury
Batch Test Check
heat cycle, then only the lo thermostat
will control the hi-lo burner cycle.
Also, in this cycle the load will dis-
continue to run. At the end of this
cycle the moisture control will hold in
the Lo heat mode if the moisture con-
trol switch is on, and the grain has not
reached the preset temperature. If it is
in the off position then it will proceed
to the cooling cycle. At the end of the
cooling cycle the unload auger should
start.
switch to its original position with the leads com-
ing from the left side of the switch before closing
the box up. Caution: the adjustment of this switch
is critical. Try not to change the angle of the switch!
In case of emergency push the dryer emergency stop
button. The fan, burner and all augers will stop im-
mediately.
To shutdown the dryer, first close the fuel supply
valve at the tank or valve along the fuel line. If
the burner is operating, let the dryer run out of
fuel, and it will shutdown automatically due to
loss of flame. Close the fuel valve at the dryer,
and press the dryer power stop button. Turn off
the safety disconnect handle on the front of the
power box, and turn off the main power to the
dryer. Emergency
Dryer Shutdown
Alldryerfunctions shouldbe checkedbeforeoperation
eachseason.
Return to the back of the dryer and again re-
verse the unload mercury switch, so the leads are
coming from the left side of the switch. This will
tell the dryer all the grain has been emptied and
will start the process at the beginning of the batch
cycle again.
Be sure to return the rear unload mercury
switch 90 degrees counterclockwise to
simulate the dryer being completely full
of grain. At this point, the fan should start
up and the burner should light. During
this time, the hi thermostat should be the
only one controlling the hi-lo cycle of the
burner. When the cycle reaches the lo-

14
SERIES 2000 BATCH DRYER
by the moisture content of the drying grain,
turn the moisture control switch to on.
8. To start the drying operation push the dryer
power start button. The controller will start
all the dryer components in their proper or
der. If any of the selected switches are im
properly positioned for batch drying, the dis-
play will indicate an error and will not allow the
dryer tooperateuntil the position of the switch
is corrected.
9. To shutdown the dryer, close the fuel supply
valve at the fuel tank or fuel source. If the
burner is operating, let the dryer run out
of fuel causing an automatic shutdown due
to a loss of flame. Close the fuel valve at the
dryer, and press the dryer power stop button.
Turn off the dryer's main circuit breaker lo
cated on the front of the power panel. Turn off
the main power supply to the dryer.
10. In case of an emergency press the emergency
stop button. The burner, fan and all augers will
stop immediately.
DRYER START UP
Batch Operation
4. Turn the fan switch to auto. The fan will start,
and the switch will light up when air pressure is
detected.
5. Start the burner by turning the heater switch
to auto. After purging for approximately 10
sec onds the burner will fire, and light above
the heater switch will light up indicating that
the flame sensing circuit is sensing burner
flame.
For information concerning burner adjustment
see the pre start section of this manual.
6. To properly set the correct dry, cool and unload
time for various moisture content grains. See
the charts on page 18 and 19.
1. Turn the control power switch to on.
2. Open the main fuel supply valve on the tank if
using LP gas, or the valve in the fuel supply
line if using natural gas. Turn on the Maxon
electric shut off valve, ifsoequipped, or open
the manual shut off valve to allow fuel flow
to the dryer.
3. The dryer should already be filled with
grain. Turn the load auger switch to auto. In
both the auto and manual position, the grain
level switch will automatically keep the dryer
full of grain. In the auto position the dryer will
shut down after the preset time period on the out of
grain timer, or if the grain flow to the dryer is
interrupted.
7. To control the length of the dry time using
only the HI and LO temperature setting pro
grammed into the system, turn the moisture
control setting to off. To use the automatic mois
ture control so that the dry time is determined,
not only by the dry time setting, but only by
the HI and LO temperature setting, and also

15
SERIES 2000 BATCH DRYER DRYER START UP
Batch Fan & Heater Switch Settings
Fan Setting
Auto
Auto
On
On
Fan Function
Fans stay on during dry and cool
cycle only
Fans stay on during dry and cool
cycle only
Fans are on continuously
Fans are on continuously
Heater Function
Burners stay on during dry timer cycle
only
Burners stay on during dry and cool
Burners are on continuously
Burners shut down at the end of the
dry cycle
At the end of the dry cycle in batch, the fans and heaters will continue running if in the Auto-Auto setting,
until the preset temperature on the moisture control thermostat is reached.
Heater Setting
Auto
On
On
Auto

16
SERIES 2000 BATCH DRYER
DRYER START UP
Batch Timer Settings
Approx.
Dry Time
16 min.
21 min.
26 min.
31.5 min.
37 min.
41.5 min.
47 min.
51 min.
54 min.
58 min.
62 min.
66.5 min.
71.5 min.
76 min.
81 min.
86 min.
91 min.
96 min.
100 min.
Moisture
Removed
2 pts.
3 pts.
4 pts.
5 pts.
6 pts.
7 pts.
8 pts.
9 pts.
10 pts.
11 pts.
12 pts.
13 pts.
14 pts.
15 pts.
16 pts.
17 pts.
18 pts.
19 pts.
20 pts.
Initial
Moisture
17%
18%
19%
20%
21%
22%
23%
24%
25%
26%
27%
28%
29%
30%
31%
32%
33%
34%
35%
Cool
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Low Heat
10 min.
13 min.
16 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
High Heat
6 min.
8 min.
10 min
13.5 min.
19 min.
23.5 min.
29 min.
33 min.
36 min.
40 min.
44 min.
48.5 min.
53.5 min.
58 min.
63 min.
68 min.
73 min.
78 min.
82 min.
Full Heat

17
SERIES 2000 BATCH DRYER DRYER START UP
Batch Timer Settings
Cool
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
18 min.
Low Heat
11 min.
14 min.
18 min.
21 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
22 min.
Approx.
Dry Time
18 min.
24 min.
30 min.
35 min.
40 min.
45 min.
50 min.
55 min.
60 min.
65 min.
70 min.
75 min.
80 min.
85 min.
90 min.
95 min.
100 min.
105 min.
110 min.
Moisture
Removed
2 pts.
3 pts.
4 pts.
5 pts.
6 pts.
7 pts.
8 pts.
9 pts.
10 pts.
11 pts.
12 pts.
13 pts.
14 pts.
15 pts.
16 pts.
17 pts.
18 pts.
19 pts.
20 pts.
Initial
Moisture
17%
18%
19%
20%
21%
22%
23%
24%
25%
26%
27%
28%
29%
30%
31%
32%
33%
34%
35%
High Heat
7 min.
10 min.
12 min.
14 min.
18 min.
23 min.
28 min.
33 min.
38 min.
43 min.
48 min.
53 min.
58 min.
63 min.
68 min.
73 min.
78 min.
83 min.
88 min.
Dry & Cool

18
SERIES 2000 BATCH DRYER
AUTOMATIC DRYER SERVICE GUIDE

19
SERIES 2000 BATCH DRYER SERVICE
Seasonal Inspection and Service
The dryer is made of weather resistant material, and
is designed to require a minimum of service. How-
ever,eachseasonwe recommend the following items
be checked before the unit is used, and any dam-
aged or questionable parts replaced. These checks
will help eliminate possible failures, and assure de-
pendable operation of the equipment.
1. Shut off electrical power. Open power box and
controlbox,and inspectfor moisture,rodentdamage
or accumulated foreign material. Remove any
foreign material present. Inspect and tighten
any loose terminal connections. Replace any
damaged or deteriorated wiring.
2. Check propellor for freedom of rotation and uni
formtip clearance.It shouldalso beinspectedfor dirt
and grain dust, especially inside the hub.Any addi-
tional weight can seriously effect the balance, and
result inharmful vibrations and a short bearing life.
3. Check propellor for free play. Any side play is an
indication of defective motor bearings, which
should bereplaced to preventa complete motor fail
ure. Make sure motor mount bolts are tight.
4. Motor bearings should be lubricated periodically, de
pending on operating conditions. Under normal
usage it is desirable to have the motor cleaned,
Ifthe motor is equipped with an alemite fitting, clean
the tip of the fitting and apply grease gun. Use 1 or
2 full strokes on motors in NEMA 215 frame and
smaller. Use 2 to 3 strokes on NEMA 254 through
NEMA 365 frame. Use 3 to 4 strokes on NEMA
404framesandlarger. On motors having drain plugs,
remove drain plug and operate motor for 20 min-
utes before replacing drain plug. On motors
equipped with slotted head grease screw, remove
screw and apply grease tube to hole. Insert 2 to 3
inch length of grease string into each hole on mo-
tors in NEMA frame and smaller. Insert 3 to 5 inch
length on larger motors. On motors having grease
drain plugs, remove plug and operate motor for 20
minutes before replacing drain plug.
Lube Procedures
* The bearings have been lubricated at the factory, thus no lubrication should be added before start up.
H. P. Range
1/8 to 7 1/2
10 to 40
50 to 150
1/8 to 7 1/2
10 to 40
50 to 150
All
1/8 to 40
50 to 150
Suggested Lube Interval
5 years
3 years
1 year
1 year
3 years
9 months
1 year-beginning of season
6 months
3 months
Lubrication Instructions for Ball Bearing Motors
Suggested Lubrication Intervals*
Hours of Service per Year
5000
Continuous Normal Applications
Seasonal Service (motor is idle for 6
months or more)
Continuous high ambient tempera-
tures, dirty or moist locations, high
vibrations or when shaft end gets hot
checked and bearings repacked by an authorized
service station every two to three seasons. If t he
unit is operated continuously through most of the
year, this service should be performed each
year.
Note: If on site bearing relubrication is to be
performed, see lubrication instructions for ball
bearing motors. To keep motor bearings prop
erly lubricated, and dispel any accumulation of
moisture within the windings, the fan and au-
ger motors should be operated for 15 to 30 min-
utes each month.

20
SERIES 2000 BATCH DRYER
SERVICE
Suggested Lubricants
Insulation Class
A & B
A & B
F & H
Consistency
Medium
Medium
Medium
Type
Polyurea
Polyurea
Polyurea
Grease
Shell Dolium R
Shell Dolium R
Shell Dolium R
Frame Type
215T & Smaller
254 & Larger
All
Note: All of the auger and metering roll bearings are lifetime lubri-
cated and do not require service relubrication.
1. Remove and clean the gas line strainers. Make certain gas valves are
closed and that gas is purged from the system before attempting disas-
sembly.
2. Inspect the collector plate (at the top of the burner casting) and
the burner cup for any accumulation of foreign material. Clean if
required. Foreign material in the burner cup or casting will not
burn out and will impair burner operation.
3. If required, inspect ignitor plug and clean the electrodes. Use an ignition
point file to remove carbon and rust between the electrode surfaces.
Ignitor gap should be about 1/8 inch.
4. Inspect flame sensor for possible damage or poor connections.
Flame sensor wire must be in good condition.
5. Inspect and manually rotate the top auger paddle assembly. The paddle
unit must rotate freely without any indication of sticking or binding.
6. Inspect the top auger and bottom auger drive lines for proper adjust-
ment and condition. Readjust line tension as required.
Note:Alloftheaugerandmeteringrollbearingsarelifetimelubricatedand
do not require service relubrication.
7. Operate dryer clean out le
vers, and checkclean-outhatch
mechanism for proper opera-
tion. With hatch open, in-
spect and remove any
accumulation of dirt, fines
and foreign material from
the bottom auger trough
area.
Note: Do not allow high moisture
material to collect within the
trough area. It may adversely af-
fect metal parts.
8. Inspect entire dryer for loose,
wornor damaged parts. Include
check of auger flighting, me-
tering rolls and other internal
parts. Check that temperature
sensors within air plenum
chamber are secured within
insulated clamps, and do
not chafe on other metal parts.
9. Make sure all dryer guards
and warning decals are se
curely installed.Guardsshould
not interfere withmovingparts.
If guards or warning decals are
missing, contact your dealer
for a free replacement.
10. Test fire the dryer several
weeks ahead of the drying sea
son. Check for possible gas
leaks. See page 15 for burner
test fire.
Remove the Blue Burn Optimizer
Cone and inspect the 1-collector
plate, 2-burner cup, 3-ignitor plug
and electrodes and the 4-flame
sensor on the heater.
1
2
3
4
