Gsou H100 User manual

USER MANUAL
H100
Bluetooth Speaker

Content
-------------------------------------------------------------1
Preface -------------------------------------------------------------2
Warnings and Cautions---------------------------------------------- 2
FCC Warnings -------------------------------------------------------- 3
Names and Contents of Toxic or Hazardous Substances or Elements-- 4
Standard Accessories ----------------------------------------------- 4
Structure Introduction ----------------------------------------------- 5
Applicable Environment --------------------------------------------- 6
Operation Steps ---------------------------------------------------- 6
Connect Bluetooth -enabled audio device with your speaker-----------8
For iPad/Iphone----------------------------------------------------- 8
For Andriod smart phone and Tablet PC---------------------------------9
For Windows Phone ------------------------------------------------- 10
For Windows PC ---------------------------------------------------- 11
For Mac system----------------------------------------------------- 11
Aux in mode- For non-Bluetooth stereo devices---------------------- 12
Charge your personal battery powered devices----------------------- 13
Specifications------------------------------------------------------- 14
Trouble Shooting---------------------------------------------------- 15
Cleaning------------------------------------------------------------ 16
Limited Warranty---------------------------------------------------- 17
Statement---------------------------------------------------------------- 17
Content
1

Preface
Warnings and Cautions
1、To reduce the risk of fire or elec-tric
shock, be sure the electrical circuits are
not overloaded.
2、To reduce the risk of electronic
shock, Do not plug the adapter with
wet hands.
3、Unplug the power cable if yourdevice
is smoking or abnormal and seek
professional help to your nearest service
centre, Do not detach the device yourself.
4、To reduce the risk of fire or electric
shock, do not expose this product to
rain or moisture. Liquids can cause a
failure and/or a fire hazard.
Please take the time to follow the instructions in this User manual carefully. It
will help you to properly use your new Gsou product and enjoy its features.
Please save this user manual for future reference. If you have any query, please
call our national service hotline: [phone].
2
Thanks for purchasing Gsou Bluetooth speaker!
6、Do not place any naked flame
sources, such as lighted candles, on
or near the apparatus.
5、The power cable and audio cable
can not be twisted or dragged in case of
short circuit.

3
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However,there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit differentfrom that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC RF warning statement: The device has been evaluated to meet general RF
exposure requirement. The device can be used in portable exposure condition
without restriction.
RF Exposure Statement To maintain compliance with FCC's RF Exposure
guidelines, This equipment should be installed and operated with minimum
distance between 20cm the radiator your body: Use only the supplied antenna.
FCC RF warning statement: The device has been evaluated to meet general RF
exposure requirement. The device can be used in portable exposure condition
without restriction.
:
Warnings

USER MANUAL
H100
Bluetooth Spe aker
Standard Accessories
3.5mm Audio cable 1 pc Power adapter 1 unit
User manual 1pc Gsou H100 Bluetooth speaker 1 unit
4
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
(CR(VI))
Polybrominated
Biphenyl (PBB)
Polybrominated
Diphenylether
(PBDE)
Part
Name
PCBs
Metal
Parts
Plastic
Parts
Speakers
Cables
X O O O O O
O O O O O O
O O O O O O
O O O O O O
O O O O O O
Toxic or Hazardous Substances and Elements
O: Indicates that this toxic or hazardous substance contained in all of
the homogeneous materials for this part is below the limit requirement
in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at
least one of the homogeneous materials used for this part is above the
limit requirement in SJ/T 11363-2006.
Names and Contents of Toxic or Hazardous
Substances or Elements

Structure Introduction
+ Plus Increase speaker
volume" "
Power on/ off . Play/Pause" "
（Note: long press for power on/off,
short press for pause or play）
Previous track" "
Next track" "
- Minus Decrease speaker
volume" "
Mode switch/disconnect"MODE”
DC OUT 5V DC IN AUX
DC Out USB port (5V)
DC in jack
Aux in jack(3.5mm)
DC OUT 5V DC IN AUX
（The USB port allow you to charge your
mobile phone, tablet PC ,MP3,MP4 and
other 5V input voltage rechargeable
devices.）
6
1
2
3
4
5
7
7
8
8
9
9
6
(* Mode Switch: Bluetooth mode and aux
in mode switch, Press and hold for 3
seconds to choose audio source from
Bluetooth device or AUX in device.
*Disconnect: Short press for 1 second to
set the speaker to discoverable mode
and allow pairing with another Bluetooth
device.
5
3
4
5
1
2

Applicable Environment
Operation Steps
Gsou H100 is designed for home
and office use. Especially for using
in sitting-room, study, bedroom,
dinning hall.
1.
Plug the DC power cord on the power supply into the DC connector on the
Gsou Bluetooth speaker. Plug the power supply into a live AC(mains)
outlet.(*Please use Gsou standard accessories.)
Connecting to AC Power
DC OUT 5V DC IN AUX
6

3.
Bluetooth mode and Aux in mode. Please make sure your audio cable
is inserted into the AUX in jack properly,if you did not insert the audio
cable,you can not switch into AUX in mode.②Default mode is Bluetooth
source mode when power on the speaker, red light and blue light flash
alternatively before pairing with Bluetooth device. The blue indicator
will remains steadily on after pairing successfully ③The red indicator
remains steadily on after connecting with AUX in source successfully.
④Short press the mode button to disconnect the existing Bluetooth
connection, and allow pairing with another Bluetooth device.
①Press and hold the mode button for 3 seconds to switch between
2. Press and hold the button for 3 seconds to start Gsou Bluetooth
speaker,The default mode is Bluetooth source mode. red light and
blue light flash alternatively every second. Press and hold the button
for 3 seconds. The speaker will power off.(See above image)
Mode indicator Speaker status
Red and blue indicator
flashes alternatively
Blue indicator remains
steadily on
Unconnected to
bluetooth
Connected to Bluetooth
source successfully
Red indicator
remains steadily on
Connected to AUX in
source successfully
Blue indicator flashes
once every second
Pairing mode.
Ready for pairing.
7
Auto power off reminder: Your bluetooth speaker will be power off
automatically if it is in standby mode over 15 minutes.

Connect Bluetooth -enabled audio device with
your speaker
1. For iPad/Iphone
①Go to “settings”.
②Go to “General”settings.
③.Go to “Bluetooth ”
④.Go to “Bluetooth settings’and enable
your Bluetooth on
⑤.Select “Gsou H100”in the list of
Bluetooth devices(Make sure the
speaker is in pairing mode)
⑥.Input password “0000(* ”
if required.
⑦.Blue led indicator will stop flash and
remain steadily on once connected
successfully. Your device is ready
to use.
.
.
four zero)
8
1
2

2.For Andriod smart phone and Tablet PC.
①Go to “settings”.
②Go to “Wireless and Network”
③.Go to “Bluetooth settings”
④.Go to “Bluetooth settings’and enable
your Bluetooth visible
⑤.Select “Gsou H100”in the list of
Bluetooth devices(Make sure the
speaker is in pairing mode)
⑥.Input password“0000(*four zero)”if
required.
⑦.Blue led indicator will stop flash and
remain steadily on once connected
successfully. Your device is ready
to use.
.
.
1
2
9

3. For Windows Phone
①.Go to “settings”.
②.Go to “Bluetooth ”
③.Tap to turn On your Bluetooth
④.Select “Gsou H100”in the list of
Bluetooth devices(Make sure the
speaker is in pairing mode)
⑤. Input password “0000(*four zero)”
if required.
⑥.Blue led indicator will stop flash and
remain steadily on once connected
successfully. Your device is ready
to use.
1
2
10

4. For Windows PC
5.For Mac system
①Open the taskbar icon
②Click on the Bluetooth icon
③Click on “add a device”
④Select “Gsou H100”in the list of Bluetooth devices(Make sure the
speaker is in pairing mode) Input password“0000(*four zero)”if required.
⑤When the device is successfully added, Blue led indicator will stop flash
and remain steadily on once connected successfully. your device is
ready to use.
⑥ Right click the speaker icon in the taskbar
⑦Open the “Playback devices”
⑧Set the “Gsou H100”device as your default device.
①Click on the Bluetooth icon in the taskbar
②Make sure Bluetooth is on
③Go to “set up a Bluetooth device”
④Select “Gsou H100”in the list of Bluetooth devices(Make sure the
speaker is in pairing mode)
⑤Click on “continue”
⑥If the pairing attempt was unsuccessful, Go to “passcode options”
⑦Select “Use a specific passcode”
⑧Input passcode“0000(*four zero)” Then Click on “OK”
⑨Click on “Continue”
⑩Your device is ready to use
11

1Gsou H100 speaker comes with a standard 3.5mm Aux in jack for
connecting with other non-Bluetooth audio device.eg mobile
phones, MP3, MP4 players,PC.tablet PC and etc.
Plug one end of the audio cable to the AUX in jack in the speaker
and the other end connect to audio source.
2.Press and hold the mode button for 3 seconds to switch to Aux in
mode.The red indicator will remain steadily on.
3.Now your device is ready to use.You can control your music by both
your playback device and buttons on the bluetooth speaker.
.
Aux in mode- For non-Bluetooth stereo devices
DC OUT 5 V DC IN AUX
Mobile Phones
Tablet PC
MP3/ MP4 Players
PC
MODE
12
Please take note that the buttons"pre" "next"
will not function properly under AUX in mode.

Charge your personal battery powered devices
Note: The USB cable is not standard
accessory of GsouH100.
DC OUT 5V DC IN AUX
MP3/ MP4 Players
Mobile Phones
Tablet PC
Gsou H100 Speakers comes with an extra USB port for charging your
personal devices.
1. Connect your device to Gsou H100 via USB cable.
2. Make sure the input power is 5V for your device.
DC OUT 5V DC IN AUX
13

Specifications
L:325mm
W:82mm
H:121mm
Channels
Speaker
Woofer
Bluetooth chipset
Bluetooth version
Supported protocol and profile
Working current
Frequency
Effective range
Bluetooth receiver Sensitivity
Sensitivity
S/N
Distortion
Working temperature
Frequency response
DC output
Power adapter
Size :
2.1 Channel
2*3W speaker
5W
CSR BC05
2.0
A2DP,AVRCP,HFE,HFP
Max<1.6 A
2.402-2.480GHz
≤10m or 33 feet
<-82dBm. BER<0.1%
85db
≥75db
≤0.3%
-10℃-55℃
80Hz-10KHz
DC 5V/1.5A
Input 100-240V.50-60Hz 0.6A
L325*W82*H121mm
1400g or about 3.08 pounds
Net Weight:include power
adapter and audio cable0
14

Trouble Shooting
Problem Solution
Speaker will not
turn on
◆Make sure your system is connected to a
working AC(mains)outlet
Paired Bluetooth
device will not
connect
◆
input “0000”four zero.
◆Turn the Gsou H100 speaker off and back on
◆Remove the Gsou H100 speaker from the pairing
list on your Bluetooth device pairing list (consult
the device owner’s manual for assistance).
Then pair the device and the speaker again.
If your device requires a pass code, make sure to
Speaker indicates
a connection, but
it not playing
music
◆
devices nearby and reconnect the device you
want to listen.
◆Turn the Gsou H100 speaker off and back on.
Turn off or disable Bluetooth on all other paired
Can not pair the
Gsou H100 with
my Bluetooth
device
◆
◆Your Bluetooth device maybe out of range-try
to move closer to your speaker
◆Make sure your Bluetooth device supports the
transfer of audio
◆Reset your Bluetooth speaker
Make sure your speaker is discoverable
No audio from a
Bluetooth device
◆
volume is up.
◆Make sure your Bluetooth device is playing
audio and volume is up
◆Your Bluetooth device may be out of range,
move closer and try
◆Turn your Bluetooth speaker off and back on
Make sure your Gsou H100 is not muted and the
15

Problem Solution
Poor sound
quality from a
Bluetooth device
◆Your Bluetooth device may be out of range,
move closer and try again
◆Move your Bluetooth device and /or Gsou H100
speaker from any device that generates
electromagnetic interference, such as another
Bluetooth device, cordless phone, microwave
oven or wireless router.
◆Try to turning off WIFI to improve audio quality
◆Make sure your music file is not poor quality.
◆Turn your Bluetooth speaker off and back on.
No Audio from
AUX source
◆
playing
◆Make sure you speaker is in AUX in mode
◆Make sure the audio cable is correctly inserted
◆Increase the volume level on the device and
speaker
make sure your connected device is on and
Poor sound
quality from AUX
source
◆
◆Make sure the 3.5mm audio cable is fully
inserted into the speaker and device.
◆Make sure your audio source and music file is not
of poor quality
Reduce the volume level on the AUX source
Cleaning
To clean the exterior surface of your speaker, you can wipe it using a soft,
dry cloth.
◆Do not use solvents,chemicals,or sprays.
◆Do not allow liquid to spill or objects to drop into any openings.
16

Limited Warranty
Contacting Customer Service
Statement
Your Gsou H100 bluetooth speaker is covered by a limited warranty.It is
backed by 1 year performance warranty against any manufacturing
defects in material or workmanship from the date of original purchase,
This warranty entitles the purchaser to get the product repaired or
replaced under the following conditions:
◆The warranty applies to the original purchaser,Proof of original
purchase is required
◆The warranty does not cover the damage caused by misuse,abuse or
improper storage.
◆In no event shall Gsou be responsible for any direct,incidental,
consequential or other damages of any kind
For questions about the Gsou H100 Bluetooth speaker, contact your local
Gsou dealer.
To contact Gsou directly,send your E-mail to [e-mail]
Service hotline: [phone]
Toll free 400-0985-400
Website: www.gsoutech.com
17
The Gsou trademark and logo are registered trademarks of Gsou
Technology(Shenzhen)Co.,Ltd All Rights Reserved. All other trademarks,
logos or service marks are the property of their respective owners.

Add:14C,Block A,First World plaza,No.7002 West Hongli Road,
Futian District, Shenzhen, China.
Tel: [phone] Fax: [phone]
E-mail: [email protected] Website: www.gsoutech.com
Gsou Technology(ShenZhen)Co.,LTD
