GSS PSDP 6200 User manual

Assembly Instruction
PSDP 6200

- 2 - PSDP 6200
Contents
1 Safety regulations and notes ........................................................................4
2 General information ....................................................................................5
2.1 Packing contents ............................................................................5
2.2 Meaning of the symbols used ..........................................................5
2.3 Technical data ...............................................................................5
2.4 Description ...................................................................................6
2.5 Software query..............................................................................7
3 Assembly ....................................................................................................8
3.1 Installing the cassette......................................................................8
3.2 EMC regulations ............................................................................9
3.3 Overview of the cassette ..............................................................10
3.4 Connecting the cassette ................................................................10
3.5 Retrofitting a CA module ..............................................................11
4 The control panel at a glance .....................................................................12
4.1 Menu items .................................................................................12
4.2 Control panel ..............................................................................12
5 Programming ............................................................................................13
5.1 Preparation .................................................................................13
5.2 Programming procedure ...............................................................13
5.3 Programming the cassette ............................................................17
Selecting the cassette, displaying the software version ......................17
Selecting the channel strip ............................................................18
Selecting channel strip "A" ......................................................18
Selecting channel strip "B" .......................................................18
Switching the modulator off or on ..................................................19
Adjusting the output levels of the channel strips ...............................19
Switching the modulator off or on .............................................19
Adjusting the output levels of the channel strips ..........................19
Setting the TV standard of the output signal ....................................20
Selecting channel / frequency setting .............................................20
Setting the output channel .............................................................21
Setting the fine-tuning ...................................................................21
Setting the output frequency ..........................................................21
Selecting the Tuner (only channel strip B) ........................................22
Setting the LNB oscillator frequency ...............................................23
Configuring the CA module (only channel strip A) ...........................23
Setting the LNB oscillator frequency ..........................................23

- 3 - PSDP 6200
Configuring the CA module (only channel strip A) ......................23
Setting the input symbol rate .........................................................24
Setting the input frequency / Reception quality ................................24
Setting the input frequency .......................................................25
Reception quality ....................................................................25
Channel selection ........................................................................26
Selecting the TV station sound / Setting the volume level ..................27
Selecting the TV station sound ..................................................27
Setting the volume level ...........................................................27
Setting the audio mode / audio output ...........................................27
Setting the audio mode ...........................................................28
Setting the audio output ...........................................................28
Selecting the picture format ...........................................................28
Switching WSS/teletext off or on ...................................................28
Switching WSS off/on ............................................................29
Switching teletext mode off/on .................................................29
Activating test lines ......................................................................29
Locking the regional window ........................................................29
Subtitle settings............................................................................30
Setting teletext subtitle pages ...................................................31
Setting the teletext standard .....................................................31
DVB subtitle ...........................................................................31
Frame suppression ..................................................................31
Setting the time zone and summer time ...........................................32
Setting time-controlled, alternative channels ....................................33
Switching the timer on and off ..................................................33
Setting the duty cycle ..............................................................33
Setting the days of the week ....................................................33
Setting the LNB oscillator frequency (timer) ................................34
Configuring the CA module (timer; only channel strip A) .............34
Setting the input symbol rate (timer) ..........................................35
Setting the input frequency (timer) .............................................35
Channel selection (timer) .........................................................35
Selecting the TV station sound / Setting the volume level (timer) ...36
Saving settings ............................................................................36
6 Final procedures ........................................................................................ 37
7 Channel and frequency tables ....................................................................38

- 4 - PSDP 6200
1 safety regulations and notes
• Assembly, installation and servicing should be carried out by authorised
electricians.
• Switch off the operating voltage of the system before beginning with assem-
bly or service work or pull out the mains plug.
• Do not perform installation and service work during thunderstorms.
• Install the system so it will not be able to vibrate…
- in a dust-free, dry environment
- in such a manner that it is protected from moisture, fumes, splashing wa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
• Ensure that the head-end station is adequately ventilated. Do not cover the
ventilation slots.
• Beware of short circuits
• No liability is accepted for any damage caused by faulty connections or
inappropriate handling.
• Observe the relevant standards, regulations and guidelines on the installa-
tion and operation of antenna systems.
• The standards EN/DIN EN 50083 and IEC/EN/DIN EN 60728 must be
observed.
• For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
"www.mygss.eu".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 5 - PSDP 6200
2 general information
2.1 PaCking Contents
1 cassette PSDP 6200
2 RF cables
1 Brief assembly instructions 1 Measuring log
2.2 meaning of the symbols used
Important note
—> General note
• Performing works
2.3 teChniCal data
The devices meet the following EU directives:
2011/65/EU, 2014/30/EU, 2014/35/EU
The product fulfils the guidelines and standards for CE labelling (page 39).
Unless otherwise noted all values are specified as "typical".
RF input
Frequency range: ....................................................... 950 … 2150 MHz
Level range: ............................................................ 60 dBμV … 80 dBμV
Input impedance: ............................................................................ 75 Ω
Symbol rate: ................................................................1 … 45 Msymb/s
RF output
Channels: ..................................................... C2 … C69 (incl. S2 … S41)
Frequency range: ........................................ 48.25 MHz … 855.25 MHz
Standard: ......................................................................... CCIR PAL B/G
Output level: ............................................................................. 98 dBμV
Output level attenuation: ............................................................0 … 7 dB
Output impedance: .........................................................................75 Ω
Video interference level: .................................................................57 dB
Video band width: ......................................................... 20 Hz … 5 MHz
Audio interference level: ..............................................................> 50 dB
Audio band width: .........................................................40 Hz … 15 kHz

- 6 - PSDP 6200
Connections
SAT inputs: .............................................................................2 F sockets
RF output: ............................................................................1 IEC socket
Connection strip (10-pin): ..................for supply voltages and control circuits
RS 232 socket: ..................................... serial interface for software update
Conditional access:...............................1 (2 channels can be descrambled)
2.4 desCriPtion
The twin transmodulator cassette is a QPSK-converter, which converts all sta-
tions modulated according to DVB-S and QPSK standard into two PAL-modulat-
ed cable signals. The cassette has two digital SAT IF inputs and one RF output.
It is equipped with two channel strips. Each channel strip consists of a digital
tuner, a digital signal preparation unit and a modulator. The cassette ‘s channel
strips are indicated by "Bx …A" or "Bx …B" in the control unit display.
The channel strip "A" can descramble scrambled channels via a correspond-
ing CA module. Depending on the CA module and the smart card, two chan-
nels can be descrambled simultaneously with one CA module, with the second
one supplied via channel strip "B". Using the integrated time control you can
select alternate channels. The control of the cassette takes place via the control
unit of the head-end station.
Two LEDs provide an indication of the SAT IF input signal quality based on
their colour. Additionally the quality of the transport stream received is dis-
played ("CN…"). If the data of channel strip "A" are used in channel strip "B"
the status LED of channel strip "B" is switched off.
The prepared input signals reach the RF output collector of the head-end sta-
tion via the RF output socket. The common output level of the channel strips can
be set at the RF output collector of the head-end station.
When the head-end station is switched on, the two-line LC display briefly
shows the software version of the control unit. To operate this cassette the
software version of the control unit must be "V 45" or higher. You can find the
current operating software for the control unit and the cassette , the software
"BE-Flash" and the current assembly instructions on the website "www.gss.de".
The cassette is designed for use in the following head-end stations:
PSU 12, PSU 8-16 and PST 19-1.

- 7 - PSDP 6200
2.5 soft ware query
Control unit
If necessary, you can activate the indication of the software version of the
control unit manually:
• Press any two keys on the control unit of the head-end station simultaneously
until the display goes dark and afterwards the software version, e.g. " V 45 "
appears.
Cassette
After activating the cassette the software version of the cassette is displayed
(see page 17).

- 8 - PSDP 6200
3 assembly
3.1 installing the Casset te
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid, for example, mounting the head-end station onto a lift shaft or any
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a cassette unplug the power cable from the
mains power socket.
• Remove the fastening screws 1 of an unoccupied slot from the bracket of
the head-end station.
• Insert the cassette in this slot and push it into the housing.
• Align the cassette and apply slight pressure to connect it to the connections
of the board and the RF bus bar.
• Fasten the cassette with the screws 1.
1
1

- 9 - PSDP 6200
3.2 emC regulations
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
CLASS
KLASSE
The attenuation of shielding of the connection lines must meet the requirements
for "Class A".
When mounting the cassette in a head-end station which is installed in a 19"
cabinet, make sure the connections leading in and out for the 19" cabinet are
made using cable terminals.
• Insert the required number of cable terminals in the openings provided in
the head-end station or in the 19 " cabinet.
—> Cable terminals are not included in the scope of delivery.
Tighten the nut on the cable terminal until the teeth on the lock washer have pen-
etrated the exterior coating and a good connection is made between the housing
and cable terminal.

- 10 - PSDP 6200
3.3 overview of the Casset te
2
1
4
5
3
6
1 Slot for a CA module
2 D-SUB socket "RS 232"
3 Status LED of the channel strip "A"
4 SAT IF input (channel strip "A")
5 Status LED of the channel strip "B"
6 SAT IF input (channel strip "B")
The operating software of the cassette can be updated via the
9-pin D-SUB socket "RS 232" 2 using a PC or notebook and
the software "BE-Flash". You can find the current operating soft-
ware on the website "www.mygss.eu".
—> For PCs with USB connector (without serial interface), we recom-
mend the DeLOCK "USB 2.0 to Serial adapter" (Product No.
61460).
3.4 ConneCting the Casset te
• Connect the SAT IF input 3 (channel strip " A ") and SAT IF input 1 (chan-
nel strip " B ") to the respective outputs of the SAT IF input distributor.
• Connect the head-end station to the mains power supply.

- 11 - PSDP 6200
3.5 retrofitting a Ca module
The cassette is equipped with a common interface. It allows you to connect a
CA module for various scrambling systems and service providers. Scrambled
channels can only be descrambled with a CA module suitable for the scram-
bling system and the corresponding smart card. The smart card contains all
the information for authorisation, descrambling and subscription.
– Check with the distributor or manufacturer of the CA module to be used
to ensure that it is suitable for descrambling several channels.
– The hardware and software of this cassette have been thoroughly prepared
and tested.
– Any changes made by program providers to the structures in the program
data might impair or even prevent this function.
– When working with the CA module, please read the corresponding operat-
ing manual from the respective provider.
• Insert the smart card 1 into the CA module 2 so that the chip 3 on the
smart card faces the thicker side (top) of the CA module.
• Insert the CA module into the guide rails of the CA slot 4 with the top side
of the CA module facing the top side of the cassette.
• Push the CA module without canting into the guide rails of the CA slot 4
and contact it to the common interface.
34 1
2

- 12 - PSDP 6200
4 the Control Panel at a glanCe
4.1 menu items
Program the cassette using the buttons on the control unit of the head-end sta-
tion. The two-line display of the control unit then shows the menus.
The parameters and functions to be set are underlined.
Use the key to select the following main menu items:
– Cassette
– Channel strip
– Modulator / output level
– TV standard
– Channel- / frequency selection
– Output channel / output frequency
– CA module (if available)
– LNB oscillator frequency
– Input symbol rate
– Input frequency
– Channel selection
– TV station sound / Volume
– Audio mode / Audio output
– Picture format / Teletext
– Test lines
– Regional window
– Subtitle
– Time zone and summer time
– Timer settings
– Factory reset
4.2 Control Panel
The key pad on the head-end station is used to scroll through the menus and
menu items one at a time:
scrolls forward through the menus.
select parameters in the menus.
set values, initiate actions.
selects sub-menus.
scrolls backward through the menus.
saves all entries.
BE-Remote V 45
PROFESSIONAL

- 13 - PSDP 6200
5 Programming
5.1 PreParation
• Test the software versions of the head-end station and the cassette and up-
date them if necessary.
The current software versions can be found on the website "www.mygss.eu".
• Connect the test receiver to the RF output or the test output of the head-end
station.
• Set the output channel / output frequency of the cassette (page 20) and adjust
the TV test receiver to this channel / this frequency.
• Switch on the modulator if necessary (page 19).
• Balance the output levels of the channel strips "A" and "B" if the difference
in level is ≥ 1 dB (see chapter "Modulator settings / Adjusting the output
levels of the channel strips", page 19).
5.2 Progra mming ProCedure
Ein / On
BE–Remote
please wait …
V 45
Box 4
V 10
QPSK-PAL
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4A/B
ZDF
QPSK-PAL
S21
Bx 4A/B
on
MODULATOR
Level -3
B
0 … - 7 dB
t > 10 s
on / off
CCIR 5.5 FM … OIRT 6.5/6.3 FM
Bx 4A/B
CCIR
NORM
5.5 FM
Bx 4A /B 01/09 +
ZDF
TV
Bx 4A/B
01/02 deu
AUDIO
- 6 dB
A
Bx 4A/B
10600 MHz
LNB
>
▶
◀/
▶
◀/
Bx 4A/B
txt 150 west
SUBTITLE
Sprachauswahl
Language selection
Bx 4A/B
S21
OUTPUT Bx 4A/B
S21 Fine
OUTPUT
0 - 64 … 63
▶
▶
Bx 4A/B
Channel
OUTPUT
Channel / Freq.
A / B
9750 / 10600
Bx 4A/B
27500
SYMBOL ▶
◀/
22000 / 27500
Bx 4A/B
11953 -1.8
FREQ
CN 12
▶
◀/
▶
◀/
Bx 4A/B
mpeg
AUDIO
DUAL norm
▶
◀/
normal / swap
mpeg … stereo
Bx 4A/B
WSS on
VIDEO
TXT on
▶
◀/
on / off
Bx 4A/B
on
TESTLINES
on / off
Bx 4A/B
dynamic
PIDS
dynamic / fixed
on / off
Bx 4A/B
off
SUBTITLE
100 … n
▶
◀/
west / east
▶
◀/
off / txt / dvb / black
Bx 4A/B
dvb 01 / 02
SUBTITLE
"deu"
▶
◀/
+ 6 … - 26 dB
Box …
………
……
……
+
AB
TIMER
01/02 deu
AUDIO
- 6 dB
▶
◀/
TIMER 01/07+
Das Erste
TV
TIMER
11836 -1.8
FREQ
CN 12
TIMER
10600 MHz
LNB
>
▶
◀/
9750 / 10600
Bx 4A/B
14:20:11 ?
TIME
+ 01 S
▶
◀/
- 12 … + 12
S / –
Bx 4A/B
off
TIMER
Bx 4A/B
on
TIMER
05:00 – 10:00
Bx 4A/B
Days
TIMER
MTWTFSS
on / off
+ 6 … - 26 dB
▶
◀/
▶
◀/
▶
◀/
▶
◀/
TIMER
27500
SYMBOL
22000/ 27500
M
M
BA
Bx 4A/B
black 40 / 10
SUBTITLE
▶
◀/
Bx 4B
Tuner Line B
INPUT
Tuner A / Tuner B
nur Kanalzug B
only channel strip B
nicht bei
Kombination
Kanalzug B mit
Tuner A
not at combination
channel strip B
with tuner A
nur mit CA-Modul / only with CA module
Bx 4A
Tuner B
Bx 4B
*) Die angezeigte Information
ist abhängig vom
verwendeten CA-Modul.
The information displayed
is dependent on the
CA module used.
Bx 4A MENU
Information *)
1/6Bx 4A CA-MENU
▶
Tuner A
▶
▶
◀/
nur mit CA-Modul / only with CA module
nur Kanalzug A / only channel strip A
nur Kanalzug A / only channel strip A
Bx 4A MENU
Information *)
1/6
Bx 4A CA-MENU
▶
▶
◀/
▶
Bx 4A/B
Letterbox
VIDEO
Letterbox /
16:9
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1 shows the enter position
Page 16

- 14 - PSDP 6200
Ein / On
BE–Remote
please wait …
V 45
Box 4
V 10
QPSK-PAL
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4A/B
ZDF
QPSK-PAL
S21
Bx 4A/B
on
MODULATOR
Level -3
B
0 … - 7 dB
t > 10 s
on / off
CCIR 5.5 FM … OIRT 6.5/6.3 FM
Bx 4A/B
CCIR
NORM
5.5 FM
Bx 4A /B 01/09 +
ZDF
TV
Bx 4A/B
01/02 deu
AUDIO
- 6 dB
A
Bx 4A/B
10600 MHz
LNB
>
▶
◀/
▶
◀/
Bx 4A/B
txt 150 west
SUBTITLE
Sprachauswahl
Language selection
Bx 4A/B
S21
OUTPUT Bx 4A/B
S21 Fine
OUTPUT
0 - 64 … 63
▶
▶
Bx 4A/B
Channel
OUTPUT
Channel / Freq.
A / B
9750 / 10600
Bx 4A/B
27500
SYMBOL ▶
◀/
22000 / 27500
Bx 4A/B
11953 -1.8
FREQ
CN 12
▶
◀/
▶
◀/
Bx 4A/B
mpeg
AUDIO
DUAL norm
▶
◀/
normal / swap
mpeg … stereo
Bx 4A/B
WSS on
VIDEO
TXT on
▶
◀/
on / off
Bx 4A/B
on
TESTLINES
on / off
Bx 4A/B
dynamic
PIDS
dynamic / fixed
on / off
Bx 4A/B
off
SUBTITLE
100 … n
▶
◀/
west / east
▶
◀/
off / txt / dvb / black
Bx 4A/B
dvb 01 / 02
SUBTITLE
"deu"
▶
◀/
+ 6 … - 26 dB
Box …
………
……
……
+
AB
TIMER
01/02 deu
AUDIO
- 6 dB
▶
◀/
TIMER 01/07+
Das Erste
TV
TIMER
11836 -1.8
FREQ
CN 12
TIMER
10600 MHz
LNB
>
▶
◀/
9750 / 10600
Bx 4A/B
14:20:11 ?
TIME
+ 01 S
▶
◀/
- 12 … + 12
S / –
Bx 4A/B
off
TIMER
Bx 4A/B
on
TIMER
05:00 – 10:00
Bx 4A/B
Days
TIMER
MTWTFSS
on / off
+ 6 … - 26 dB
▶
◀/
▶
◀/
▶
◀/
▶
◀/
TIMER
27500
SYMBOL
22000/ 27500
M
M
BA
Bx 4A/B
black 40 / 10
SUBTITLE
▶
◀/
Bx 4B
Tuner Line B
INPUT
Tuner A / Tuner B
nur Kanalzug B
only channel strip B
nicht bei
Kombination
Kanalzug B mit
Tuner A
not at combination
channel strip B
with tuner A
nur mit CA-Modul / only with CA module
Bx 4A
Tuner B
Bx 4B
*) Die angezeigte Information
ist abhängig vom
verwendeten CA-Modul.
The information displayed
is dependent on the
CA module used.
Bx 4A MENU
Information *)
1/6Bx 4A CA-MENU
▶
Tuner A
▶
▶
◀/
nur mit CA-Modul / only with CA module
nur Kanalzug A / only channel strip A
nur Kanalzug A / only channel strip A
Bx 4A MENU
Information *)
1/6
Bx 4A CA-MENU
▶
▶
◀/
▶
Bx 4A/B
Letterbox
VIDEO
Letterbox /
16:9
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1 shows the enter position

- 15 - PSDP 6200
Ein / On
BE–Remote
please wait …
V 45
Box 4
V 10
QPSK-PAL
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4A/B
ZDF
QPSK-PAL
S21
Bx 4A/B
on
MODULATOR
Level -3
B
0 … - 7 dB
t > 10 s
on / off
CCIR 5.5 FM … OIRT 6.5/6.3 FM
Bx 4A/B
CCIR
NORM
5.5 FM
Bx 4A /B 01/09 +
ZDF
TV
Bx 4A/B
01/02 deu
AUDIO
- 6 dB
A
Bx 4A/B
10600 MHz
LNB
>
▶
◀/
▶
◀/
Bx 4A/B
txt 150 west
SUBTITLE
Sprachauswahl
Language selection
Bx 4A/B
S21
OUTPUT Bx 4A/B
S21 Fine
OUTPUT
0 - 64 … 63
▶
▶
Bx 4A/B
Channel
OUTPUT
Channel / Freq.
A / B
9750 / 10600
Bx 4A/B
27500
SYMBOL ▶
◀/
22000 / 27500
Bx 4A/B
11953 -1.8
FREQ
CN 12
▶
◀/
▶
◀/
Bx 4A/B
mpeg
AUDIO
DUAL norm
▶
◀/
normal / swap
mpeg … stereo
Bx 4A/B
WSS on
VIDEO
TXT on
▶
◀/
on / off
Bx 4A/B
on
TESTLINES
on / off
Bx 4A/B
dynamic
PIDS
dynamic / fixed
on / off
Bx 4A/B
off
SUBTITLE
100 … n
▶
◀/
west / east
▶
◀/
off / txt / dvb / black
Bx 4A/B
dvb 01 / 02
SUBTITLE
"deu"
▶
◀/
+ 6 … - 26 dB
Box …
………
……
……
+
AB
TIMER
01/02 deu
AUDIO
- 6 dB
▶
◀/
TIMER 01/07+
Das Erste
TV
TIMER
11836 -1.8
FREQ
CN 12
TIMER
10600 MHz
LNB
>
▶
◀/
9750 / 10600
Bx 4A/B
14:20:11 ?
TIME
+ 01 S
▶
◀/
- 12 … + 12
S / –
Bx 4A/B
off
TIMER
Bx 4A/B
on
TIMER
05:00 – 10:00
Bx 4A/B
Days
TIMER
MTWTFSS
on / off
+ 6 … - 26 dB
▶
◀/
▶
◀/
▶
◀/
▶
◀/
TIMER
27500
SYMBOL
22000/ 27500
M
M
BA
Bx 4A/B
black 40 / 10
SUBTITLE
▶
◀/
Bx 4B
Tuner Line B
INPUT
Tuner A / Tuner B
nur Kanalzug B
only channel strip B
nicht bei
Kombination
Kanalzug B mit
Tuner A
not at combination
channel strip B
with tuner A
nur mit CA-Modul / only with CA module
Bx 4A
Tuner B
Bx 4B
*) Die angezeigte Information
ist abhängig vom
verwendeten CA-Modul.
The information displayed
is dependent on the
CA module used.
Bx 4A MENU
Information *)
1/6Bx 4A CA-MENU
▶
Tuner A
▶
▶
◀/
nur mit CA-Modul / only with CA module
nur Kanalzug A / only channel strip A
nur Kanalzug A / only channel strip A
Bx 4A MENU
Information *)
1/6
Bx 4A CA-MENU
▶
▶
◀/
▶
Bx 4A/B
Letterbox
VIDEO
Letterbox /
16:9
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1 shows the enter position

- 16 - PSDP 6200
Ein / On
BE–Remote
please wait …
V 45
Box 4
V 10
QPSK-PAL
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4A/B
ZDF
QPSK-PAL
S21
Bx 4A/B
on
MODULATOR
Level -3
B
0 … - 7 dB
t > 10 s
on / off
CCIR 5.5 FM … OIRT 6.5/6.3 FM
Bx 4A/B
CCIR
NORM
5.5 FM
Bx 4A /B 01/09 +
ZDF
TV
Bx 4A/B
01/02 deu
AUDIO
- 6 dB
A
Bx 4A/B
10600 MHz
LNB
>
▶
◀/
▶
◀/
Bx 4A/B
txt 150 west
SUBTITLE
Sprachauswahl
Language selection
Bx 4A/B
S21
OUTPUT Bx 4A/B
S21 Fine
OUTPUT
0 - 64 … 63
▶
▶
Bx 4A/B
Channel
OUTPUT
Channel / Freq.
A / B
9750 / 10600
Bx 4A/B
27500
SYMBOL ▶
◀/
22000 / 27500
Bx 4A/B
11953 -1.8
FREQ
CN 12
▶
◀/
▶
◀/
Bx 4A/B
mpeg
AUDIO
DUAL norm
▶
◀/
normal / swap
mpeg … stereo
Bx 4A/B
WSS on
VIDEO
TXT on
▶
◀/
on / off
Bx 4A/B
on
TESTLINES
on / off
Bx 4A/B
dynamic
PIDS
dynamic / fixed
on / off
Bx 4A/B
off
SUBTITLE
100 … n
▶
◀/
west / east
▶
◀/
off / txt / dvb / black
Bx 4A/B
dvb 01 / 02
SUBTITLE
"deu"
▶
◀/
+ 6 … - 26 dB
Box …
………
……
……
+
AB
TIMER
01/02 deu
AUDIO
- 6 dB
▶
◀/
TIMER 01/07+
Das Erste
TV
TIMER
11836 -1.8
FREQ
CN 12
TIMER
10600 MHz
LNB
>
▶
◀/
9750 / 10600
Bx 4A/B
14:20:11 ?
TIME
+ 01 S
▶
◀/
- 12 … + 12
S / –
Bx 4A/B
off
TIMER
Bx 4A/B
on
TIMER
05:00 – 10:00
Bx 4A/B
Days
TIMER
MTWTFSS
on / off
+ 6 … - 26 dB
▶
◀/
▶
◀/
▶
◀/
▶
◀/
TIMER
27500
SYMBOL
22000/ 27500
M
M
BA
Bx 4A/B
black 40 / 10
SUBTITLE
▶
◀/
Bx 4B
Tuner Line B
INPUT
Tuner A / Tuner B
nur Kanalzug B
only channel strip B
nicht bei
Kombination
Kanalzug B mit
Tuner A
not at combination
channel strip B
with tuner A
nur mit CA-Modul / only with CA module
Bx 4A
Tuner B
Bx 4B
*) Die angezeigte Information
ist abhängig vom
verwendeten CA-Modul.
The information displayed
is dependent on the
CA module used.
Bx 4A MENU
Information *)
1/6Bx 4A CA-MENU
▶
Tuner A
▶
▶
◀/
nur mit CA-Modul / only with CA module
nur Kanalzug A / only channel strip A
nur Kanalzug A / only channel strip A
Bx 4A MENU
Information *)
1/6
Bx 4A CA-MENU
▶
▶
◀/
▶
Bx 4A/B
Letterbox
VIDEO
Letterbox /
16:9
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1 zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1 shows the enter position
Page 13
Page 13

- 17 - PSDP 6200
5.3 Progra mming the Casset te
—> Pressing the button for longer than 2 seconds cancels the
programming procedure. This takes you back to the program item
"Selecting the cassette" from any menu. Any entries that have not
been saved are reset to the previous settings.
—> Entries in the menus can be saved by pressing the key. You are
taken back to the "Selecting the cassette" menu item.
—> Using the button previous menus can be activated.
• Switch on the head-end station
—> The display shows the software version of the head-end station (e.g.
"V 45").
—> The processor reads the cassettes ‘ data (approx. 10 seconds).
Ein / On
BE–Remote
please wait …
V 45
t > 10 s
seleCting the Cassette, disPl aying the software version
Box 4
V 10
QPSK-PAL
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Box …
………
……
……
+
• Select the cassette you want to program (e.g. Box 4) by repeatedly pressing
the button .
—> The display shows e.g. the menu "Box 4 QPSK-PAL" :
"Box 4" stands for slot 4
" QPSK-PAL " type of cassette
"V 10" software version of the cassette

- 18 - PSDP 6200
seleCting the Channel striP
seleCting Channel striP "a"
• Press the button to select channel strip "A".
Box 4
V 10
QPSK-PAL
– – –
Bx 4A
V 10
QPSK-PAL
S21
—> Button selects the previous cassette.
seleCting Channel striP "b"
Box 4
V 10
QPSK-PAL
– – –
Bx 4A
ZDF
QPSK-PAL
S21
Bx 4B
ARD
QPSK-PAL
S22
Box 5
..............
..............
..............
Box 3
..............
..............
..............
• Press the button to select channel strip "B".
—> The display shows e.g. the menu "Bx 4B QPSK-PAL "
ARD S22
"Bx" stands for cassette (box),
"4" for slot 4,
"B" for channel strip "B"
"QPSK-PAL" Type of cassette
"ARD" Programme name
"S 22" adjusted channel
—> Button selects channel strip "A".
—> Button selects the following cassette.
• Press the button.

- 19 - PSDP 6200
—> The "Switching the modulator off or on", "Adjusting the output levels
of the channel strips" – "MODULATOR" menu is activated.
switChing the modulator off or on
adjusting the outPut levels of the Channel striPs
In this menu, you can switch off and on the modulator and set the RF output
levels of the channel strips "A" and "B" to the same values.
Bx 4A/B
on
MODULATOR
Level -3
switChing the modulator off or on
• By pressing , switch the modulator of the channel strip "off" or "on".
—> In position "off" the menu item "Level" is inactive.
adjusting the outPut levels of the Channel striPs
• Measure and note down the output level of channel strip "A".
• Activate menu item "Selecting the channel strip" using the button
and select channel strip "B".
• Activate the "MODULATOR Level" menu.
• If necessary switch on the modulator.
• Measure and note down the output level of channel strip "B".
• Select the channel strip with the higher RF output level.
• Activate the "MODULATOR" menu and position the cursor under "Level …".
• By pressi ng adjust the higher output level of one channel strip to the low-
er output level of the other channel strip incrementally from "0 " to " –7"dB.
• Activate channel strip "A".
• Press the button.
—> The "Setting the TV standard of the output signal" – "NORM" menu
is activated.

- 20 - PSDP 6200
setting the tv standard of the outPut signal
In this menu you can set the TV standard of the output signal.
Bx 4A/B
CCIR
NORM
5.5 FM
• Press to select the TV standard of the output signal ("CCIR 5.5 FM …
OIRT 6.5/6.3 FM").
• Press the button.
—> The "Selecting channel / frequency setting" – "OUTPUT" menu is
activated.
seleCting Channel / frequenCy setting
In this menu, you can choose the channel or frequen cy setting for the adjust-
ment of the RF output. The channel setting covers the following ranges:
C02-C04 / S02-S10 / C05-C12 / S11-S41 / C21-C69
The frequency setting covers the following range:
48.25 MHz - 855.25 MHz
Bx 4A/B
Channel
OUTPUT
Bx 4A/B
Freq.
OUTPUT
• Use to select channel setting "Channel" or frequency setting "Freq.".
• Press the button.
—> The "Setting the output channel" or "Setting the output frequency" –
"OUTPUT" menu is activated.
