GSW SPACESAVER Series Product information sheet

July 2017
Residen al Electric
Water Heater
Installa on Instruc ons and
Use & Care Guide
Keep this manual in the pocket on heater for future reference whenever maintenance, adjustment or service is required.
Retain your original receipt as proof of purchase.
DO NOT RETURN THIS UNIT TO THE STORE
Read this manual and the labels on the water heater before you install,
operate, or service it. If you have diffi culty following the direc ons, or
aren’t sure you can safely and properly do any of this work yourself:
• Schedule an appointment with a qualified person to install your water heater.
• Call our Technical Assistance Hotline at 1-888-479-8324 or visit
http:// www.hotwatercanada.ca. We can help you with installation, operations,
troubleshooting, or maintenance. Before you call, write down the model and
serial number from the water heater’s data plate.
Incorrect installa on, opera on, or service can damage the water heater, your house
and other property, and present risks including fi re, scalding, electric shock, and
explosion, causing serious injury or death.
Table of Contents Page
IMPORTANT SAFETY INFORMATION .................................3
GETTING STARTED ............................................................6
INSTALLATION ...................................................................7
TROUBLESHOOTING .......................................................16
MAINTENANCE ...............................................................19
REPAIR PARTS ..........................................................22
WIRE DIAGRAM ..............................................................23
100291161 (REV A)/2000547142

2 • Electric Mini Tank Water Heater
COMPLETED INSTALLATION TYPICAL
MAX
1
2
125°F
Hot Outlet Cold Inlet
Temperature & Pressure
Relief Valve
Discharge Pipe
(DO NOT CAP OR PLUG)
Floor Drain
6” (15.24cm) Max
Drain Pan
Electrical
Service
Ground Electrical
Service
Ground
NOTE: 6 Gallon (22.7 liters) models are hard wired
and do not have a cord. See “Step 8” on page 13 for
instruc ons on making electrical connec ons.

Electric Mini Tank Water Heater • 3
SAFETY
IMPORTANT SAFETY INFORMATION
Important informa on to keep
Fill out this sec on and keep this
manual in the pocket of the water
heater for reference.
Date Purchased:
Model number:
Serial number:
Maintenance performed:* Date:
This is the safety alert symbol. It is used to alert you to
poten al physical injury hazards. Obey all safety messages
that follow this symbol to avoid possible property
damage, serious injury or death. Do not remove any
permanent instruc ons, labels, or the data plate from either the outside
of the water heater or on the inside of the access panels. Keep this manual
near the water heater.
DANGER
Read and follow all safety messages and instruc ons in
this manual.
DANGER indicates hazardous
situa on that, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a hazardous
situa on that, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a hazardous
situa on that, if not avoided, could
result in minor or moderate injury.
NOTICE NOTICE indicates prac ces not
related to physical injury.
*Drain and fl ush tank and remove
and inspect anode rod a er fi rst six
months of opera on and at least
annually therea er. Operate the
Temperature and Pressure Relief Valve
(T&P) annually and inspect T&P valve
every 2-4 years (see the label on the
T&P valve for maintenance schedule).
See the Maintenance sec on for more
informa on about maintaining this
water heater.
This product is certified to comply with a maximum weighted average of
0.25% lead content as required in some areas.

4 • Electric Mini Tank Water Heater
To reduce the risk of property damage, serious injury or death, read and
follow the precau ons below, all labels on
the water heater, and the safety messages
and instruc ons throughout this manual.
RISKS DURING INSTALLATION AND
MAINTENANCE
Electric Shock Risk
Contact with the electrical parts
in the junction box and behind
the access doors can result in
severe injury or death from electrical
shock:
• Locate the water heater’s circuit
breaker and turn it OFF (or remove the
circuits fuses).
• Use a non-contact circuit tester to
confirm that power is off before
working on or near any electrical parts.
• Replace the junction box cover and
access door after servicing.
Lifting Risk
WARNING! The
water heater is heavy.
Follow these
precau ons to reduce
the risk of property damage, injuries from
li ing or impact injuries from dropping the
water heater.
• Use at least two people to lift the water
heater.
• Be sure you both have a good grip
before lifting.
• U se an appliance dolly or hand
truck to move the water heater.
Capacity Empty Filled
6G (22.7 liter) 24 lbs (11kg) 73.5 lbs (33.3kg)
4G (15.1 liter) 17.5 lbs (7.9kg) 49.5 lbs (22.5kg)
2.5G (9.5 liter) 14.5 lbs (6.6kg) 36 lbs (16.3kg)
RISKS DURING OPERATION
Scalding Risk
This water heater can
make water hot enough
to cause severe burns
instantly, resulting in severe injury or
death.
• Feel water before bathing or s howering.
• To reduce the risk of scalding,
install Thermostatic Mixing Valves
(temperature limiting valves) at each
point-of-use. These valves automatically
mix hot and cold water to limit the
temperature at the tap. Mixing valves
are available from your local plumbing
supplier. Follow manufacturer’s
instructions for installation and
adjustment of the valves.
• The thermostat(s) on this water heater
have been factory set to approximately
105°F to reduce the risk of scalding.
Higher temperatures increase the risk
of scalding, but even at 105°F (40.6°C),
hot water can scald. If you choose
a higher temperature, Thermostatic
Mixing Valves located at each point-of-
use are particularly important to help
avoid scalding.
Temperature Time to Produce a
Serious Burn
120°F (49°C) More than 5 minutes
125°F (52°C) 1½ to 2 minutes
130°F (54°C) About 30 seconds
135°F (57°C) About 10 seconds
140°F (60°C) Less than 5 seconds
145°F (63°C) Less than 3 seconds
150°F (66°C) About 1½ seconds
155°F (68°C) About 1 second
For informa on about changing the
factory thermostat se ng(s), refer to the
“Adjus ng Temperature” sec on in this
manual (“Step 11” on page 1514).
Even if you set the water heater
thermostat(s) to a low se ng, higher
temperatures may occur in certain
circumstances:
• In some cases, repeated small draws
of water can cause the hot and cold
water in the tank to “stack” in layers.
If this happens, the water can be as
much as thirty degrees hotter than the
thermostat setting. This temperature
variation is the result of your usage
pattern and is not a malfunction.
• Water temperature will be hotter if
someone adjusted the thermostat(s) to
a higher setting.
• Problems with the thermostat(s), or
other malfunctions may result in higher
than expected water temperatures.
• If the water heater is in a hot
environment, the water in the tank can
become as hot as the surrounding air,
regardless of the thermostat setting.
• If the water supplied to the water
heater is pre-heated (for example, by
a solar system) the temperature in the
tank may be higher than the water
heater’s thermostat setting.
To reduce the risk of unusually hot water
reaching the fi xtures in the house, install
Thermosta c Mixing Valves at each point-
of-use.
If anyone in your home is at par cular
risk of scalding (for example, the elderly,
children, or people with disabili es) or if
there is a local code or state law requiring a
certain water temperature at the hot water
tap, then these precau ons are par cularly
important.
IMPORTANT SAFETY INFORMATION
SAFETY

Electric Mini Tank Water Heater • 5
According to a na onal standard:
American Society of Sanitary Engineering
(ASSE 1070) and most local plumbing codes,
the water heater’s thermostat should not
be used as the sole means to regulate water
temperature and avoid scalds.
Properly adjusted Thermosta c Mixing
Valves installed at each point-of-use allow
you to set the tank temperature to a higher
se ng without increasing risk of scalds.
Higher tank temperatures (140°F/60°C)
also kill bacteria that cause a condi on
known as “smelly water” and can reduce
the levels of bacteria that cause water-
borne diseases.
Water Contamination Risk
Do not use chemicals that could
contaminate the potable water supply. Do
not use piping that has been treated with
chromates, boiler seal, or other chemicals.
Fire Risk
To reduce the risk of a fire
that could destroy your
home and seriously injure
or kill people:
• D o not store things that can burn easily
such as paper or clothes next to the
water heater.
• Be sure the junction box cover and the
access door covers are in place. These
covers keep debris from entering and
potentially being ignited, and help keep
any internal fires from spreading.
• Keep the water heater from becoming
wet. Immediately shut the water heater
off and have it inspected by a qualified
person if you find that the wiring,
thermostat(s) or surrounding insulation
have been exposed to water in any way
(e.g., leaks from plumbing, leaks from
the water heater itself can damage
property and could cause a fire risk). If
the water heater is subjected to flood
conditions or the thermostat(s) have
been submerged in water, the entire
water heater must be replaced.
• For 6 gallon (22.7 liters) models,
make electrical connections properly,
according to the instructions on page
13. Use suitable twist on wire
connectors or other approved means
to make the power connections. Use a
UL listed or CSA approved strain relief.
Connect ground wire to ground screw.
Explosion Risk
High temperatures and
pressures in the water heater
tank can cause an explosion
resulting in property damage, serious
injury or death. A new Temperature and
Pressure (T&P) Relief Valve is included
with your water heater to reduce risk of
explosion by discharging hot water.
Additional temperature and pressure
protective equipment may be required by
local codes.
A nationally recognized testing laboratory
maintains periodic inspection of the
valve production process and certifies
that it meets the requirements for Relief
Valves for Hot Water Supply Systems,
ANSI Z21.22. The T&P Relief Valve’s relief
pressure must not exceed the working
pressure rating of the water heater as
stated on the rating plate.
Maintain the T&P Relief Valve properly.
Follow the maintenance instructions
provided by the manufacturer of the T&P
Relief Valve (label attached to T&P Relief
Valve) and the procedure that starts on
page 21.
An explosion could occur if the T&P Relief
Valve or discharge pipe is blocked. Do
not cap or plug the T&P Relief Valve or
discharge pipe.
Fire and Explosion Risk if Hot Water is Not
Used for Two Weeks or More
C AUTION! Hydrogen gas builds up in
a hot water system when it is not used
for a long period (two weeks or more).
Hydrogen gas is extremely fl ammable. If
the hot water system has not been used
for two weeks or more, open a hot water
faucet for several minutes at the kitchen
sink before using any electrical appliances
connected to the hot water system. Do
not smoke or have an open fl ame or other
igni on source near the faucet while it is
open.
IMPORTANT SAFETY INFORMATION
SAFETY

6 • Electric Mini Tank Water Heater
Figure 1 - Flexible connectors use compression
fittings and do not require soldering.
Figure 2 - Use a non-contact circuit tester to
insure that the power is off before you work on
a circuit.
Figure 3 - Install a Pressure Reducing Valve set
to 50 to 60 psi (345 to 414 kPa).
1Review all of the instruc ons
before you begin work.
If you aren’t sure that you can
safely and properly do this work yourself,
call your local plumbing supplier to
arrange for Professional Installa on (you
may also call a qualifi ed person of your
choice, such as a licensed plumber or
electrician, to have the work done).
Improper installa on can damage the
water heater, your home and other
property, and can present risks of serious
injury or death.
2Check with your local and state
authori es for any local or state
codes that apply to your area. In
the absence of local and state codes, follow
Na onal Fire Protec on Associa on
(NFPA-70) and the current edi ons of the
Na onal Electric Code (NEC) and the
Interna onal Plumbing Code (IPC). The
instruc ons in this manual comply with
na onal codes, but the installer is
responsible for complying with local codes.
3Before you start, be sure you have,
and know how to use, the following
tools and supplies:
• Plumbing tools and supplies
appropriate for the type of water pipes
in your home
• Threaded connectors (Figure 1) for the
cold and hot water pipes
• For homes plumbed with plastic pipe,
use threaded connectors suitable
for the specific type of plastic pipe
used: CPVC and PEX (cross-linked
polyethylene). Do not use PVC pipe.
• For homes with copper pipes, you
may purchase connector kits with
compression fittings that don’t require
soldering (Figure 1). Compression
fittings are easier to install than
soldering copper pipes.
• Teflon® tape or pipe joint compound
approved for potable water
• Tools to make the electrical connections
(for example, screwdrivers, wire
strippers)
• Non-Contact circuit tester to check for
power (Figure 2)
• Water Pressure Gauge (Figure 4)
Recommended Accessories:
• Suitable drain pan (Figure 6 on page
8)
• Automatic leak detection and shut-off
device
• Pressure Reducing Valve (Figure 3 on
page 6)
• Thermal Expansion Tank (Figure 5 on
page 7)
• Point-of-use Thermostatic Mixing Valves
(Figure 7 on page 8)
GETTING STARTED
GETTING STARTED

Electric Mini Tank Water Heater • 7
Completely read all instruc ons before
beginning. If you are not sure if you
can complete the installa on, DO NOT
RETURN THIS UNIT TO THE STORE. Seek
assistance from any of the following
sources:
Schedule an appointment with a qualified
person to install your water heater.
Follow these steps for proper installa on:
Step 1:
✓Verify that your
home is equipped
and up-to-date for
proper opera on
Installing a new water heater is the perfect
 me to examine your home’s plumbing
system and make sure the system is up
to current code standards. There have
likely been plumbing code changes since
the old water heater was installed. We
recommend installing the following
accessories and any other needed changes
to bring your home up to the latest code
requirements.
Use the checklist below and inspect your
home. Install any devices you need to
comply with codes and assure that your
new water heater performs at its best.
Check with your local plumbing offi cial for
more informa on.
✓Water pressure
We recommend checking your
home’s water pressure with a pressure
gauge (Figure 4.) Most codes allow a
maximum incoming water pressure of 80
psi (551.6 kPa). We recommend a working
pressure no higher than 50-60 psi (345-
414 kPa).
HOW: Purchase an inexpensive water
pressure gauge available at your local
plumbing supplier. Connect the Water
Pressure Gauge to an outside faucet and
measure the maximum water pressure
experienced throughout the day (highest
water pressures o en occur at night).
Figure 4 - Use a Water Pressure Gauge to make
sure your home’s water pressure is not too high.
To limit your home’s water pressure: Locate
your home’s Pressure Reducing Valve
(PRV) on the main incoming (cold) water
supply line and adjust the water pressure
control to between 50 & 60 psi (345 &
414 kPa) . If your home does not have a
Pressure Reducing Valve, install a PRV on
the home’s main water supply line and set
it to between 50 & 60 psi (345 & 414 kPa).
Pressure Reducing Valves are available at
your local plumbing supplier.
BACKGROUND: Over the years, many
u li es have increased water supply
pressures so they can serve more homes.
In some homes today, pressures exceed
100 psi (689 kPa). High water pressures
can damage water heaters, causing
premature leaks. If you have replaced
toilet valves, had a water heater leak, or
had to repair appliances connected to the
plumbing system, pay par cular a en on
to your home’s water pressure. When
purchasing a PRV, make sure the PRV has
a built-in bypass.
✓Water pressure
increase caused by
thermal expansion
Verify that you have a properly sized
Thermal Expansion Tank (Figure 5). We
recommend installing an expansion tank
if your home does not have one. Codes
require a properly pressurized, properly
sized Thermal Expansion Tank in almost all
homes. (See photo on inside front cover.)
Figure 5 - A Thermal Expansion Tank helps
protect the home’s plumbing system from
pressure spikes.
INSTALLATION
INSTALLATION

8 • Electric Mini Tank Water Heater
HOW: Connect the Thermal Expansion
Tank (available at your local plumbing
supplier ) to the cold water supply line
near the water heater. The expansion
tank contains a bladder and an air
charge. To work properly, the Thermal
Expansion Tank must be sized according
to the water heater’s tank capacity and
pressurized to match the home’s incoming
water pressure. Refer to the installa on
instruc ons provided with the Thermal
Expansion Tank for installa on details.
BACKGROUND: Water expands when
heated, and the increased volume of
water must have a place to go, or thermal
expansion will cause large increases in
water pressure (despite the use of a
Pressure Reducing Valve on the home’s
main water supply line). The Safe Drinking
Water Act of 1974 requires the use of
backfl ow preventers and check valves to
restrict water from your home reentering
the public water system. Backfl ow
preventers are o en installed in water
meters and may not be readily visible. As
a result, most all plumbing systems today
are now “closed,” and almost all homes
now need a Thermal Expansion Tank.
A Thermal Expansion Tank is a prac cal
and inexpensive way to help avoid
damage to the water heater, washing
machine, dishwasher, ice maker and even
toilet valves. If your toilet occasionally
runs for no apparent reason (usually
briefl y at night), that may be due to
thermal expansion increasing the water
pressure temporarily.
Water pipe and tank leaks
Leaks from plumbing pipes or from the
water heater itself can damage property
and could cause a fi re risk.
• Install an automatic leak detection and
shutoff device (available at your local
plumbing supplier ). These devices can
detect water leaks and can shut off the
water heater’s water supply if a leak
occurs.
• Install a suitable drain pan (available
at your local plumbing supply store )
under the water heater (Figure 6) to
catch condensation or leaks in the
piping connections or tank. Most codes
require, and we recommend, installing
the water heater in a drain pan that is
piped to an adequate drain. The drain
pan must be at least two inches wider
than the diameter of the water heater.
Install the drain pan so the water level
would be limited to a maximum depth
of 1-3/4" (4.4cm).
IMPORTANT: The bottom of the water
heater shall be above the top of the drain
pan. Place heater on a stand inside the
drain pan to achieve this.
MAX
1
2
125°F
Figure 6 - A suitable drain pan piped to an
adequate drain can help protect flooring from
leaks and drips.
✓Water temperature
regula on
Figure 7 - Thermostatic Mixing Valves installed
at each point -of-use can help prevent scalds.
Install Thermosta c Mixing Valves (Figure
7) to regulate the temperature of the
water supplied to each point-of-use
(for example, kitchen sink, bathroom
sink, bath, shower). Consult the valve
manufacturer’s instruc ons or a qualifi ed
person.
WARNING! Even if the water heater
thermostat is set to a rela vely low
temperature, hot water can scald. Install
Thermosta c Mixing Valves at each point-
of-use to reduce the risk of scalding (page
4).
BACKGROUND: A Thermosta c Mixing
Valve, installed at each point-of-use,
mixes hot water from the water heater
with cold water to more precisely
regulate the temperature of hot water
supplied to fi xtures. If you aren’t sure
if your plumbing system is equipped
with properly installed and adjusted
Thermosta c Mixing Valves at each
point where hot water is used, contact a
qualifi ed person for more informa on.
INSTALLATION
INSTALLATION

Electric Mini Tank Water Heater • 9
Step 2:
Verify that the loca on is
appropriate
Placement of water heater is very
important to consider, for the safety and
economical use of the appliance.Before
installing your water heater, ensure that:
1The water heater will be:
• Installed indoors close to the
center of the plumbing
system.
• In a suitable drain pan piped to an
adequate floor drain or external to the
building (Figure 6 on page 8).
• In an area that will not freeze
• In an area that is suitable for installing
the water heater vertically
2The loca on has adequate space
(clearances) for periodic
servicing.
3The selected wall or cabinet must
be capable of suppor ng at least
two  mes the weight of the
water heater when fi lled with water (see
weight table on page 4).
4The water heater must be
installed in a ver cal posi on
with water inlet and outlet
connec ons facing upwards and easily
accesible.
5The loca on is not prone to
physical damage by vehicles,
fl ooding, or other risks.
Vehicle
Stop
Drain
Drain
P
a
n
Figure 8 - In a garage, install a vehicle stop to
avoid water heater damage.
6Avoid loca ons such as a cs,
upper fl oors, or where a leak
might damage the structure or
furnishings. Due to the normal corrosive
ac on of water, the tank will eventually
leak. To minimize property damage from
leaks, inspect and maintain your water
heater in accordance with this manual’s
instruc ons. Install a suitable drain pan
under the water heater piped to an
adequate drain. Inspect the drain pan,
pipes, and surrounding area regularly and
fi x any leaks found. Drain pans are
available at your local plumbing supplier .
Drain pans must have a minimum length
and width of at least 2" (5cm) greater
than the water heater dimensions and
must be piped to an adequate drain. Leaks
are frequently in the plumbing system
itself and not the water heater.
Step 3:
Moun ng - Drywall
(Hollow Wall):
1The selected wall or cabinet must
be capable of suppor ng double
the weight of the unit when
completely full of water (up to
150 lbs./68kg).
2Locate the wall studs in the area
where the unit is to be mounted.
3Cut two sec ons of 1/2" (1.3cm)
plywood or equivalent material
3" (7.6cm) in height. The length
of each sec on should be suffi cient to
span the width of the wall studs (see
Figure 9).
4Use appropriately sized nails or
wood screws to a ach the two
wall supports to the wall as
shown in Figure 9.
5Using the bracket as a template,
mark holes to be drilled on upper
wall support and drill two 13/32”
(1.03cm) holes.
NOTE: The holes MUST be level.
6Insert the hollow wall anchors
into the drilled holes. Place the
wall bracket over the anchors and
screw the two Phillips head screws down
 ght against the bracket.
Studs
Drywall
Plywood
Bracket
Figure 9 - Mounting for Drywall
INSTALLATION
INSTALLATION

10 • Electric Mini Tank Water Heater
Moun ng - Masonry Wall
(Solid Wall):
1The selected wall or cabinet must
be capable of suppor ng double
the weight of the unit when
completely full of water (up to
150 lbs/68kg).
2The installa on area must
provide adequate clearances for
removal of the front panel and
servicing the unit.
3Drill two 13/32" (1.03cm) holes in
the masonry wall.
NOTE: The holes MUST be level
and at least 3-1/2" (8.9cm) deep.
4Insert the masonry wall anchors
into the drilled holes. Place the
wall bracket over the anchors and
screw the two Phillips head screws  ght
against the bracket.
Figure 10 - Mounting Bracket for Masonry Wall.
Moun ng - Floor
1The fl oor selected must be
capable of suppor ng double the
weight of the unit when
completely full of water (up to
150 lbs./68kg).
2Installa on area must provide
adequate clearances for servicing
the unit.
3Place a suitable drain pan under
the unit. The pan must limit the
water to a maximum depth of
2-1/2" (6.35cm) and be 2" (5cm) wider
than the unit. The pan must also be piped
to an adequate drain.
NOTICE: Most codes require se ng the
water heater in a suitable drain pan piped
to an adequate drain. The drain pan
helps avoid property damage which may
occur from condensa on or leaks in the
piping connec ons or tank. The drain pan
must be at least 2" (5cm) wider than the
diameter of the water heater. Install the
drain pan so the water level is limited to a
maximum depth of 2-1/2" (6.35cm).
4Verify that the water heater is
properly set in place. Check that:
• The T&P Relief Valve will not be in
contact with any electrical parts.
• There is adequate space to install the
T&P Relief Valve discharge pipe and
that it can be piped to a separate drain
(and not into the drain pan).
• There is adequate access and space
around the water heater for future
maintenance.
DO NOT CONNECT ELECTRICAL
WIRING UNTIL YOU ARE
INSTRUCTED TO DO SO.
NOTICE: Connec ng electrical power to
the tank before it is completely full of
water (water must run FULL STREAM from
a hot water tap for a full three minutes)
will cause the hea ng element to burn
out.
IMPORTANT: The bottom of the water
heater shall be above the top of the drain
pan. Place heater on a stand inside the
drain pan to achieve this.
MAX
1
2
125°F
Figure 11 - A suitable drain pan piped to an
adequate drain can help protect flooring from
leaks and drips.
Step 4:
Connect the Temperature
and Pressure (T&P) Relief
Valve/Pipe
Most T&P Relief Valves are pre-installed
at the factory. In some cases, they are
shipped in the carton and must be installed
in the opening marked and provided for
this purpose and according to local codes.
WARNING! To avoid serious injury
or death from explosion, install a T&P
Relief Valve according to the following
instruc ons:
1Install the new T&P Relief Valve
that came with your water
heater. Do not reuse an old T&P
Relief Valve. Install a T&P Relief Valve
discharge pipe according to local codes
and the following guidelines:
2The discharge pipe should be at
least 3/4" (1.9cm) inside
diameter and sloped for proper
drainage. Install it to allow complete
drainage of both the T&P Relief Valve and
the discharge pipe.
3The discharge pipe must
withstand 250°F (121°C) without
distor on. Use only copper or
CPVC pipe. Do not use any other type of
pipe, such as PVC, iron, fl exible plas c
pipe, or any type of hose.
Figure 12 - The T&P Relief Valve discharge pipe
must be installed properly and piped to an
adequate drain.
INSTALLATION
INSTALLATION

Electric Mini Tank Water Heater • 11
• Terminate the discharge pipe a
maximum of 6" (15.2cm) above a
fl oor drain or outside the building. Do
not drain the discharge pipe into the
drain pan; instead pipe it separately
to an adequate drain. In cold climates,
terminate the discharge pipe inside
the building to an adequate drain.
Outside drains could freeze and obstruct
the drain line. Protect the drain from
freezing.
Discharge Pipe
6“ (15.2cm)
(no more than)
Figure 13 - The end of the T&P Relief Valve
discharge pipe must stop no more than six
inches above a floor drain or terminate outside
the building.
• Do not place any valve or other
restric on between the tank and T&P
Relief Valve. Do not cap, block, plug, or
insert any valve between the T&P Relief
Valve and the end of the discharge pipe.
Do not insert or install any reducer in
the discharge pipe.
Step 5:
Install shutoff and
tempering valves
1If one is not already installed,
install a manual shutoff valve in
the cold water line that supplies
the water heater. Install the shutoff valve
near the water heater so that it is readily
accessible. Only use valves that are
compa ble with potable water. Use only
full-fl ow ball or gate valves. Other types of
valves may cause excessive restric on to
the water fl ow.
2Install a Thermosta c Mixing
Valve at each point-of-use (for
example, kitchen sink, bathroom
sink, bath, shower). Consult the valve
manufacturer’s instruc ons or a qualifi ed
person.
Figure 14 - Install Thermostatic Mixing Valves at
each point where hot water will be used.
WARNING! Even if the water heater’s
thermostat(s) are set to a rela vely low
temperature, hot water can scald. Install
Thermosta c Mixing Valves at each point-
of-use to reduce the risk of scalding. (page
4.)
3For water heaters that are fed by
a solar water hea ng system (or
any other pre-hea ng system),
always install a Thermosta c Mixing Valve
or other temperature limi ng device in the
inlet water supply line to limit water supply
inlet temperature to 120°F (49°C). Solar
water hea ng systems can supply water
with temperatures exceeding 170°F (77°C)
and may result in water heater
malfunc on.
WARNING! Hot water provided by solar
hea ng systems can cause severe burns
instantly, resul ng in severe injury or
death (page 4).
Step 6:
1Connect the water
supply
Determine the type of water pipes in your
home. Most homes use copper water
pipes, but some use CPVC or cross-linked
polyethylene (PEX). Use fi  ngs appropriate
for the type of pipe in your home. Do not
use iron or PVC pipe – they are not suitable
for potable water.
2Connect the cold water supply
using 1/2" (1.3cm) Na onal Pipe
Thread “NPT” to the cold water
inlet nipple.
For ease of removing the water heater for
service or replacement, connect the water
pipes with a coupling called a union. We
recommend using a dielectric-type union
(available at your local plumbing supply
store). Dielectric unions can help prevent
corrosion caused by  ny electric currents
common in copper water pipes and can
help extend the life of the water heater.
INSTALLATION
INSTALLATION

12 • Electric Mini Tank Water Heater
NOTICE: Most water heater models
contain energy saving heat traps in the
inlet and outlet connec ons. Do not
remove the heat traps.
3Connect the hot water supply
using 1/2" (1.3cm) NPT to the hot
water outlet. Follow the same
connec on guidelines as for the cold water
supply.
4Install insula on (or heat tape) on
the water pipes especially if the
indoor installa on area is subject
to freezing temperatures. Insula ng the
hot water pipes can increase energy
effi ciency.
5Double check to make sure the
hot and cold water pipes are
connected to the correct hot and
cold water fi  ngs on the water heater.
6If needed, install (or adjust) the
home’s Pressure Reducing Valve
to 50-60 psi (345-414 kPa) and
install a Thermal Expansion Tank.
Figure 15 - A Pressure Reducing Valve is
required if your home’s water pressure is above
80 psi (552 kPa).
Figure 16 - The Thermal Expansion Tank should
be pressurized with air, to match the home’s
incoming water pressure.
Step 7:
Verify connec ons and
completely fi ll tank
To remove air from the tank and allow the
tank to fi ll completely with water, follow
these steps:
1Remove the aerator at the nearest
hot water faucet. This allows any
debris in the tank or plumbing
system to be washed out.
2Turn the cold water supply back
on.
3Open a hot water faucet and allow
the water to run un l it fl ows with
a full stream.
4Let the water run full stream for
three full minutes.
5Close the hot water faucet and
replace the aerator.
6Check inlet and outlet connec ons
and water pipes for leaks. Dry all
pipes so that any drips or leaks
will be apparent. Repair any leaks. Almost
all leaks occur at connec ons and are not a
tank leak.
IF YOU HAVE COPPER PIPES:
If your home has copper water pipes, you
can solder the water pipe connec ons
or use compression fi  ngs which don’t
require soldering. Compression fi  ngs
are easier to install than soldering pipe.
Check with local plumbing offi cials to
determine what types of pipe materials
are suitable for your loca on. Do not use
lead-based solder.
NOTICE: Do not solder pipes while
they are a ached to the water heater.
The water heater’s inlet and outlet
connec ons contain non-metallic parts
which could be damaged. The proper way
to connect the water heater to copper
water pipes is as follows:
• Solder a short length of pipe (about a
foot or so) to a threaded adapter using
only 95/5  n-an mony or equivalent
solder. A ach the threaded adapters to
the water heater’s connec ons (using
Tefl on® tape or pipe joint compound).
Connect the home’s water pipes by
soldering, keeping the connec ons at
the water heater cool with wet rags.
INSTALLATION
INSTALLATION

Electric Mini Tank Water Heater • 13
NOTICE: The tank must be completely
empty of air and full of water before
connec ng electrical power to avoid
“Dry Firing.” Dry Firing may result in
the element burning out. This is a
common installa on mistake. A er
you make the water connec ons,
but before you connect the electrical
power, open a hot water faucet and
let the water run full un l all the air is
removed. Let the “hot” water run full
for three minutes or longer before
connec ng any electrical wires.
A Dry Fired hea ng element is an
installa on error and is not covered
under warranty.
If Dry Firing occurs, replace the
hea ng element according to the
instruc ons on page 20.
Step 8: (6 Gal. Models)
Make electrical
connec ons (2.5 & 4
gal./9.5 & 15 liter models
have a power cord, plug
into an outlet)
WARNING! Working on an energized
circuit can result in severe injury or death
from electrical shock.
NOTICE: Do not turn electrical power on
unless you are sure all of the air is out of
the tank and the tank is completely full of
water. If power is applied before the tank
is completely full of water, the element will
burn out (Dry Fire).
1Be sure the electrical power to the
water heater is turned OFF at the
circuit breaker panel (or remove
the circuit’s fuses).
2Using a non-contact circuit tester,
check the wiring to make certain
the power is OFF.
3Check the water heater’s data
plate and ensure that the home’s
voltage, wiring size (ampacity) and
circuit breaker ra ng and type are correct
for this water heater. Refer to the wiring
diagram located on the inside of the water
heater’s bo om compartment for the
correct electrical connec ons. Ensure that
wire sizes, type, and connec ons comply
with all applicable local codes. In the
absence of local codes, follow NFPA-70 and
the current edi on of the Na onal Electric
Code (NEC).
4Remove the cover on the
electrical junc on box on the back
of the water heater.
Figure 17 - The water heater’s electrical
requirements can be determined from the data
plate.
5Install wiring in an approved
conduit (if required by local
codes). Use a UL listed or CSA
approved strain relief to secure the
electrical wiring to the water heater.
6Ensure that the green ground wire
is connected to the ground screw.
Connect yellow and green ground
wire to the supply ground wire. Connect
the supply line and supply neutral to the
water heater line (black wire) and neutral
(white wire). Use suitable wire connectors
or other approved means to make the
power connec ons.
Figure 18 - Connecting the electrical wires.
WARNING! Be sure cover is secured to
reduce the risk of fi re and electric shock.
INSTALLATION
INSTALLATION

14 • Electric Mini Tank Water Heater
Step 9:
Adjus ng the
Temperature
With the installa on steps completed, you
may adjust the water heater’s temperature
se ng if desired.
1Set the thermostat(s) to desired
temperature. The thermostat on
this water heater has been factory
set to approximately 105°F (40.6°C) to
reduce the risk of scald injury. You may
wish to set a higher temperature to
provide more hot water capacity, and to
reduce bacterial growth. Higher tank
temperatures (140°F/60°C) kill bacteria
that cause a condi on known as “smelly
water” and can reduce the levels of
bacteria that cause water-borne diseases.
WARNING! Higher temperatures
increase the risk of scalding, but even at
120°F (49°C), hot water can scald
(page 4).
If you increase the water heater’s
temperature se ng, install Thermosta c
Mixing Valve(s) at each point-of-use to
reduce the risk of scalding.
Figure 19 - Adjust Thermostat Mixing Valves at
each point-of-use to 120°F (49°C) or lower.
To adjust the water heater’s thermostat:
• Turn the water temperature dial
clockwise () to increase the
temperature, or counter clockwise
() to decrease the temperature.
• Check water temperature at several
points of use in your home (for
example, bathtub faucet, shower,
or lavatory sink) and adjust the
Thermosta c Mixing Valves as needed.
If you aren’t sure how to adjust the
Thermosta c Mixing Valve se ngs, or
aren’t sure if you have Thermosta c
Mixing Valves, contact a qualifi ed
person.
WARNING! If you have increased the
temperature se ng and the Thermosta c
Mixing Valves are not set properly (or not
installed) you could scald yourself while
checking the temperature.
INSTALLATION
INSTALLATION

Electric Mini Tank Water Heater • 15
Step 10:
Opera on
The water heater is now ready for normal
opera on. To keep your water heater
working safely and effi ciently and extend
its life, perform maintenance according to
the “Rou ne Maintenance” schedule on
page 19.
Vaca on
To save energy, lower the temperature
se ng on the thermostat(s) if you plan
to be gone for an extended  me. Follow
the instruc ons in Step 9 for adjus ng the
thermostat to a lower temperature se ng
before you leave and to properly raise the
temperature se ng when you return.
C AUTION! Hydrogen gas builds up in
a hot water system when it is not used
for a long period (two weeks or more).
Hydrogen gas is extremely fl ammable. If
the hot water system has not been used
for two weeks or more, open a hot water
faucet for several minutes at the kitchen
sink before using any electrical appliances
connected to the hot water system. Do
not smoke or have an open fl ame or other
igni on source near the faucet while it is
open.
Need Assistance?
Call our Technical Assistance Hotline at 1-888-479-8324.
We can help you with installa on, opera on, troubleshoo ng, or maintenance.
Before you call, write down the model and serial number from the
water heater’s data plate.
INSTALLATION
INSTALLATION

16 • Electric Mini Tank Water Heater
WARNING! Working near an energized
circuit can result in severe injury or death
from electrical shock.
WARNING! When you are fi nished, be
sure all covers are secured to reduce the
risk of fi re and electric shock.
No Hot Water
The most likely reasons for an electric water
heater to produce NO hot water are:
• No electric power—a common problem
with new installations
• Burned out element (Dry Fired)
— a common problem with new
installations
• The water heater’s inlet and outlet
connections are reversed (usually only
in new installations)
• Broken thermostat (or wiring)
• A leak in the hot water side of the
plumbing system that exceeds the water
heater’s heating capacity and makes it
appear that the water heater is producing
little to no hot water
Follow these steps to diagnose and
correct common electrical problems:
1Check the electric power to the
water heater. No hot water is
o en caused by a problem with
the home’s electrical wiring or circuit
breakers. You’ll need a non-contact circuit
tester. For 6 gal. (22.7 liter) water heaters,
follow these guidelines:
• Locate the water heater’s circuit
breaker and turn it off (or remove the
circuit’s fuses).
• Drain the water heater (see “Drain the
Water Heater” section).
• Locate the electrical junction box on
the botton of the water heater and
remove the cover.
• Identify the two power wires. The
power wires are usually black/white or
black/red—the green or copper wire is
the ground wire.
Figure 20 - Use a non-contact circuit tester to
check for electrical power.
• Turn the circuit breaker back on (or
install the fuses) and check the power
on both incoming power wires using a
non-contact circuit tester.
• Turn the power off and replace the
cover on the electrical junction box.
For 2.5 & 4 gal. (9.5 & 15.1 liter) models,
check the water heaters circuit breaker for
a tripped breaker. If it has been tripped,
turn it back on. If the water heater is not
ge ng power, contact a qualifi ed person to
have your home’s wiring or circuit breakers
checked.
2Check the hea ng element. If the
water heater is ge ng electrical
power, check to see if the hea ng
element has burned out. If the element is
burned out, you’ll have no hot water. To
check the element, you’ll need a
mul meter capable of reading resistance.
• For 6 gal. (22.7 liter) models, turn the
power OFF at the circuit breaker or
remove fuses. For models with a power
cord, unplug the unit.
• Drain the water heater (see “Drain the
Water Heater” section).
• Remove the access panel.
• With the electrical power off , remove
the two power wires from the hea ng
element.
Wires are
detached
Figure 21 - Use a multimeter to check the
resistance of the heating element.
3Check the resistance of the
hea ng element using a
mul meter. Measure the
resistance between the two push terminals
on the hea ng element. A good element
will have a resistance ranging between 5
and 25 Ohms. If the resistance is:
Outside this range. Replace the element
(see the Rou ne Maintenance sec on
on page 19 ). On a new water heater,
a burned out hea ng element is almost
always caused by turning the power
on before the tank was completely full
of water (Dry Fire). (See Step 8 in the
Installa on sec on.)
Within this range. Rea ach the power
wires, making sure the wires are in good
condi on and the connec ons are clean
and  ght.
TROUBLESHOOTING
TROUBLESHOOTING

Electric Mini Tank Water Heater • 17
Insuffi cient Hot Water or
Slow Hot Water
Recovery
WARNING! Be sure all covers are secured
to reduce the risk of fi re and electric shock.
WARNING! Because of the increased risk
from scalding, if you set the water heater’s
thermostat(s) higher than 120°F (49°C),
Thermosta c Mixing Valves at each point-of-
use are par cularly important (page 4).
If the hot water is simply not warm enough,
there are several possible causes:
• Faulty Thermostatic Mixing Valve in a faucet
or shower control (check other faucets in
the house for hot water)
• Thermostat set too low
• Water heater’s capacity too small (or usage
too high)
• Reversed plumbing connections or melted
dip tube (usually found soon after new
installation)
• Plumbing leak
• Bad element
• Low supply voltage
Thermosta c Mixing Valves. If the hot water
is simply not warm enough, make sure the
faucet you are checking doesn’t have a
defec ve Thermosta c Mixing Valve. Many
shower controls now have built-in mixing
valves. If these devices fail, they can reduce
the amount of hot water the shower or faucet
delivers even though there is plenty of hot
water in the tank. Always check the water
temperature at several faucets to make sure
the problem is not in a faucet or shower
control.
Thermostats set too low. If the water
temperature is too cool, adjust the thermostat
by turning dial clockwise for a higher
temperature.
Undersized water heater. If your water heater
runs out of hot water too quickly, it may be
too small for your needs. If the water heater is
old, consider replacing it with a larger model. If
the water heater is in good condi on, you may
be able to meet your family’s hot water needs
with the exis ng water heater by installing
Thermosta c Mixing Valves at each point-of-
use and then turning the thermostat(s) to a
higher se ng. See “Step 10:” on page 15.
You can also reduce your home’s hot water
needs by washing clothes in cold water,
installing fl ow restrictors on shower heads,
repairing leaky faucets, and taking other
conserva on steps.
Reversed connec ons. Check the hot and
cold connec ons and make sure your home’s
hot water pipe is connected to the hot
water outlet on the water heater. Usually,
reversed connec ons are found soon a er the
installa on of a new unit.
Plumbing leak. Even a small leak in the hot
water side of the home’s plumbing system
can make it appear that the water heater is
producing li le to no hot water. Locate and
repair the leak.
TROUBLESHOOTING
TROUBLESHOOTING

18 • Electric Mini Tank Water Heater
Temperature Too High
If the water temperature is too hot:
• Install or adjust the Thermostatic
Mixing Valves for each point-of-use (see
manufacturer’s instructions), or
• Adjust the temperature by turning the
dial counter-clockwise.
A nonfunc oning thermostat or a shorted
hea ng element can cause extremely hot
water. If the Temperature and Pressure
Relief Valve (T&P Valve) releases large
amounts of very hot water, it is likely due
to a shorted hea ng element, or more
rarely a nonfunc oning thermostat.
Low Water Pressure
Check both the cold and hot water at a sink
to determine if the lower pressure is only
on the hot water side. If both hot and cold
faucets have low pressure, call your local
water u lity. If the low pressure is only on
the hot water side, the primary causes of
this are:
• Partially closed supply valve. Open the
water heater’s supply valve fully.
Drips from T&P Relief
Valve Discharge Pipe
A small amount of water dripping from
the Temperature and Pressure (T&P)
Relief Valve usually means the home’s
water pressure is too high or you need a
properly sized and pressurized Thermal
Expansion Tank. Refer to Step 1 in the
Installa on sec on of this manual for more
informa on. A large amount of hot water
coming from the T&P discharge pipe may
be due to the tank overhea ng.
WARNING! Do not cap or plug the T&P
relief valve or discharge pipe, and do
not operate the water heater without a
func oning T&P Relief Valve - this could
cause an explosion.
Water pressure too high. High water
pressure can cause the T&P Relief Valve
to drip. Install a Pressure Reducing Valve
(PRV) on the main cold water supply line.
Adjust the PRV to between 50 & 60 psi
(345 & 414 kPa).
Thermal Expansion Tank. Install a Thermal
Expansion Tank. If a Thermal Expansion
Tank is already installed and the T&P Relief
Valve discharge pipe drips, the Thermal
Expansion Tank may be pressurized to the
wrong pressure or the internal bladder
may be defec ve. Refer to the instruc ons
that came with the Thermal Expansion
Tank for more informa on.
Debris. In rare cases, debris can s ck inside
the T&P Relief Valve preven ng the valve
from sea ng fully. In that case, the T&P
Relief Valve discharge pipe will drip. You
may be able to clear debris from the T&P
Relief Valve by manually opera ng the
valve, allowing small quan  es of water to
fl ush out the debris. See the label on the
T&P Relief Valve for instruc ons.
If the water pressure is between 50
& 60 psi (345 & 414 kPa), a Thermal
Expansion Tank is installed and properly
pressurized, and the valve has been cleared
of any debris, and it s ll drips, the valve
may be broken—have a qualifi ed person
replace the T&P relief valve.
Water Odor
Harmless bacteria normally present in tap
water can mul ply in water heaters and
give off a “ro en egg” smell. Although
elimina ng the bacteria that causes
“smelly water” with a Chlorina on system
the only sure treatment is increasing the
water temperature.
In cases where the “ro en egg” smell
is pronounced, you can raise the tank
temperature to “MAX” in order to reduce
bacteria growth in the tank.
WARNING! Because higher
temperatures increase the risk of scalding,
if you set the thermostat(s) higher than
120°F (49°C), Thermosta c Mixing Valves
at each point-of-use are par cularly
important (page 4).
NOTE: To protect the tank, an anode rod
must be installed in the water heater at all
 mes or the warranty is void.
TROUBLESHOOTING
TROUBLESHOOTING

Electric Mini Tank Water Heater • 19
R o u  ne Maintenance
Rou ne maintenance will help your water
heater last longer and work be er. If you
can’t perform these rou ne maintenance
tasks yourself, contact a qualifi ed person.
A er the fi rst six months, drain and fl ush
the water heater and inspect the anode
rod. Depending on the hardness of your
water, repeat this process at least annually,
or more frequently if needed. From
 me to  me, you may need to replace a
hea ng element or a thermostat. All three
maintenance tasks are described below.
Draining and Flushing the
Water Heater
Tap water contains minerals that can
form lime deposits on hea ng elements
or sediment in the bo om of the tank.
The amount of lime deposits or sediment
depends on the hardness of your tap
water. The rate at which sediment builds
up depends on water quality and hardness
in your area, the temperature se ngs, and
other variables. We recommend draining
and fl ushing the water heater a er the
fi rst six months of opera on to determine
the amount of sediment build up. Draining
sediment extends the life of the tank,
hea ng elements, and drain valves.
• In areas with very hard water, remove
and check the heating element
whenever you drain the tank. If you
have heavy lime deposits on heating
element, you will need to replace it
more often.
• Sediment may form large masses that
can prevent the tank from draining. Have
a qualified person use a de-liming agent
suitable for potable water to remove the
sediment buildup.
• In most cases, it is easier and cheaper
to replace lime-encrusted elements
than trying to remove heavy lime
deposits.
To drain and fl ush the tank:
1For 6 gal. (22.7 liter) models,
locate the water heater’s circuit
breaker and turn it OFF (or
remove the circuit’s fuses). For 2.5 & 4 gal.
(9.5 &15.1 liter) models, unplug unit from
wall outlet.
Figure 22 - Circuit Breaker
2Open a hot water faucet and let
the hot water run un l it is cool.
Figure 23 - Water Faucet
WARNING! Be sure the water runs cool
before draining the tank to reduce the risk
of scalding.
3Turn the cold water supply valve
OFF and open a nearby faucet to
relieve pressure inside the tank.
4Remove inlet and outlet
connec ons and siphon water
out.
5Tilt unit over to drain any
remaining water.
NOTICE: DO NOT turn electrical power
back on unless the tank is completely full
of water.
6Remove and inspect the anode
rod.
Figure 24 - Anode Rods from new (top) to
partially depleted (bottom).
Anode Rod. The anode rod is a sacrifi cial
metal rod that helps reduce corrosion and
premature failure (leaks) in the tank. The
anode rod is a consumable item. Inspect
the anode rod a er the fi rst six months of
opera on when you drain and fl ush the tank.
Replace the anode rod if it is substan ally
worn out or depleted. Therea er, inspect
the anode rod annually or more frequently
if needed. If you use a water so ener, your
anode rod will deplete faster than normal.
MAINTENANCE
MAINTENANCE

20 • Electric Mini Tank Water Heater
Inspect the anode rod more frequently,
replacing the anode rod as needed. Obtain a
new anode rod by contac ng our Technical
Assistance Hotline (reference contact
informa on on cover).
NOTE: Anode rods are a consumable item
and are not covered under warranty.
7If the sediment was present when
the tank was drained, fl ush the
tank by opening the cold water
supply valve and le ng the water run un l
no more sediment drains from the tank.
NOTICE: Do not turn power back on un l
the tank is completely full of water. For
complete instruc ons on fi lling the tank,
follow Step 7 in the Installa on sec on.
8Refi ll the tank by opening the cold
water supply valve. Make sure a
hot water faucet is open. Allow
the hot water to run full for at least three
minutes to make sure the tank has all the
air removed and is completely full of water.
Failure to perform this step can cause the
hea ng element to burn out. Once you are
certain the tank is completely full of water,
close the hot water faucet.
9Restore power to the water
heater. It may take two hours for
the tank to heat up.
Replacing the Hea ng Element
WARNING! Working on an energized
circuit can result in severe injury or death
from electrical shock. Turn power off .
Check wires with a non-contact circuit
tester to make sure power is off . When
you are fi nished, be sure all covers are
secured to reduce the risk of fi re and
electric shock.
If you are not comfortable replacing a
hea ng element or thermostat yourself,
have this work done by a qualifi ed person.
To replace the hea ng element, you’ll need
the following tools and supplies:
Figure 25 - Non-Contact Circuit Tester
• Always turn power OFF and check the
power wires with a non-contact circuit
tester before working on the water
heater.
Figure 26 - Heating Element (with gasket)
• Check your water heater’s data plate
for the correct wattage and voltage.
(Refer to page 22 for customer contact
information for replacement parts.)
• A 10mm nut driver.
• Hand dishwashing soap to lubricate the
gasket
• A clean cloth to clean the threaded
opening
• A flat blade and a Phillips screwdriver
Steps for Replacing the Hea ng
Element:
1For the 2.5 & 4 gal. (9.5 & 15.1 liter)
models, unplug unit. For the 6 gal.
(22.7 liter) models, turn the power
OFF at the circuit breaker or remove fuses.
Figure 27 - Circuit Breaker
2Open a hot water faucet and let
the hot water run un l it is cool
then siphon water from tank.
WARNING! Be sure the water runs cool
before draining the tank to reduce the risk
of scalding.
Figure 28 - Non-Contact Circuit Tester
3Open the electrical junc on box
on the bo om of the water
heater. Using a non-contact circuit
tester, check the power wires to make
certain the power is OFF.
Figure 29 - Water Faucet
4Remove the access panel on the
water heater then, with the tank
drained and power off , remove
the power wires from the element.
MAINTENANCE
MAINTENANCE
