GT ALARM GT 800/1 Operating manual

GT 800/1/2/3
USER AND INSTALLATION MANUAL
1

SUMMARY
2
1.0 - INSTALLATION AND CONNECTIONS Page. 3
2.0 - GENERAL CONNECTION DIAGRAM Page. 5
3.0 - DESCRIPTION OF THE PROGRAMMABLE FUNCTIONS Page. 6
3.1 - Self-coding vehicle indicators impulses number Page. 6
3.2 - Switches/Discriminators signals stabilizer Page. 6
3.3 - Memorization of switches/discriminators signals only after actuator signals Page. 6
3.4 - Memorisation of actuator signals of changeable type Page. 6
3.5 -Anti-hijack door signal stabilizer Page. 6
3.6 - Acoustic signal when arming/disarming the alarm system Page. 6
3.7 - Visual signal when arming/disarming the alarm system Page. 6
3.8 - Courtesy light switching on when disarming Page. 6
4.0 - SET FUNCTIONS Page. 6
5.0 - DESCRIPTION OF THEALARM SYSTEM ARMING/DISARMING COMMAND WIRES Page. 8
6.0 - DOORS LOCK/UNLOCK SIGNALS SELF-CODING Page. 8
7.0 - RAPID TEST Page. 9
8.0 - SELF-POWER SUPPLY Page. 10
9.0 - FINAL OPERATIONS Page. 10
10.0 - USER MANUAL Page. 11
10.1 - Alarm system arming/disarming Page. 11
10.2 - Electric windows closing command function Page. 11
10.3 - Protections Page. 11
10.4 - If the alarm sounds ... Page. 11
10.5 - Check status LED Page. 11
10.6 - Emergency disarming with “GT CARD CODE” Page. 12
10.7 - How to isolate additional sensors and ultrasonic sensor
when arming the alarm system Page. 12
10.8 - Anti-hijack function Page. 12
10.9 - Visual signal function when arming/disarming the alarm system Page. 13
10.10 - Acoustic signal function when arming/disarming the alarm system Page. 13
10.11 - Functions check Page. 13
11.0 - COMPLIANCE DECLARATION Page. 13
12.0 - WARRANTY CONDITIONS Page. 14
13.0 - TECHNICAL FEATURES Page. 15

3
1.0 - INSTALLATION AND CONNECTIONS
WARNINGS:
- Place the GT800 alarm in the engine compartment, away from direct sources of water
spray and high tension wiring.
- Solder and isolate all connections.
- Isolate the wires not connected.
- The alarm system should be mounted by a professional installer.
1 - Connect the BROWN wire to O/E vehicle earth.
2 - Connect the RED wire to a permanent 12 volts supply (use the supplied 15 Amp fuse).
3 - ConnectthePINK wireofthe alarm(max.capacity 80mA)to thePINKwire ofanyadditional
sensors/modules (i.e. microwave sensor, electric window module).
4 - Connect theGREEN/BLACKwire ofthe alarmtothe GREEN/BLACKwire ofanyadditional
sensors.
5 - Connect the YELLOW wire to an ignition switched live (+15/54) that remains live even
when the engine is being cranked. Do not connect to the same wire used for the engine
immobilisation.
6 - Connect the ORANGE wires to the left and right hand vehicle indicators.
7-Connect the GREEN wire to the boot and bonnet pin switches, provided that they are
switched earth only.
8 - Connect the GREEN/BROWN wire to the existing doors pin switches, provided that they
are switched earth only.
9 - If you want to activate the ANTI-HIJACK FUNCTION connect the GREEN/BLUE wire to
the original driver’s door pin switch, provided that it is a switched earth only.
10 - Connectthe BLUE/VIOLET wireto the “comfort”command of thevehicles equipped with
negative “comfort” closing function (the signal duration is of about 40 seconds).
11- The WHITE and GREY wires are used for the engine immobilisation on either diesel or
petrolvehicles. Cutthe ignition switchedlive thatfeeds, dependingon thetype of vehicle, the
fuel pump relay, or the solenoid valve (diesel vehicles). Connect one end to the GREY wire
and the other to the WHITE wire.
WARNING:
- On the vehicles equipped with an ignition key transponder immobiliser, it is not
necessary to connect the WHITE and GREY wire of the alarm, therefore these two
wires can be isolated.
12 - The YELLOW/BLACK wire sends a negative intermittent signal when triggered alarm
(max 100mA). It can be used to command the vehicle’s horn relay.
13 -Place the LED/BUTTON on the dashboard (in a visible way) and connect it to the
connectors in the alarm wiring loom.

14 -The RED/BROWN, YELLOW/BROWN, RED/GREY and YELLOW/GREY wires must be
connected to the original vehicle central door locking system as indicated on the vehicles
installation guides supplied by GT, or following the section DESCRIPTION OF THE ALARM
SYSTEM ARMING/DISARMING COMMAND WIRES (Page 8).
15 -Connect the GREEN/YELLOW wire to O/E vehicle earth to carry out the DOORS LOCK/
UNLOCK SIGNALS SELF-CODING procedure and to carry out the RAPID TEST (page 8-9).
16 -Ifyou want toactivate theANTI-HIJACK FUNCTION connect the BLACK/WHITE wire to
the supplied N/O switch, connect the other side of the switch to earth.(refer to GENERAL
CONNECTION DIAGRAM page 5). Mount the button in a position not visible but easily
reachable.
17 -ULTRASONIC SENSOR: Install the two ultrasonic transducers at the top of the “A”
pillars, one to the right and one to the left (see picture) pointing towards a hypothetical point
at the centre of the rear window and ensure that between the ultrasonic transducers and the
rear window there are no objects (i.e. headrest, etc.).
Plugthe ultrasonictranducers inthesuitable alarmconnectors payingattention totheircolours
(refer to GENERAL CONNECTION DIAGRAM page
5). To adjust the sensitivity of the ultrasonic sensor,
turn the adjuster close to the main alarm connector
clockwise to increase and anti clockwise to decrease.
Do not cut or lengthen the ultrasonic transducers
cables.
WARNING:
- When the installation has been completed, reconnect the O/E vehicle earth and
carry out the alarm system SET FUNCTIONS.
RED
ADJUSTMENT
WHITE
4

5
2.0 - GENERAL CONNECTION DIAGRAM
RED - Pos. 10
BLACK - Pos. 17
RED LED - Pos. 10
RED - Pos. 10
BLACK/RED - Pos. 14
= FUSE TO BE
INSERTED
LEGEND:
GREEN/BROWN - Pos. 2
GREEN/BLUE - Pos. 20
BROWN - Pos. 9
ORANGE- Pos. 3
ORANGE - Pos. 4
GREEN/BLACK - Pos. 18
PINK - Pos. 13
GREEN/YELLOW - Pos. 19
POSITIVE OUTPUT
WHEN THE ALARM
IS ARMED
DOORS LOCK/UNLOCK
SIGNALS SELF-CODING
RAPID TEST
YELLOW/BLACK - Pos. 1
INTERMITTENT
NEGATIVE OUTPUT
IN ALARM
(MAX CAPACITY 100mA
TO ADDITIONAL
SENSORS
INDICATORS
YELLOW - Pos. 21
IGNITION
SWITCHED LIVE
+15/54
GREEN - Pos. 7
BONNET/BOOT
PIN SWITCHES
DOORS PIN
SWITCHES
ANTI-HIJACK DOOR
PIN SWITCH
WHITE - Pos. 11
GREY - Pos. 22
ENGINE
IMMOBILISATION
CUT
PETROL PUMP RELAY
EARTH
RED/BROWN - Pos. 15
RED/GREY - Pos. 5
YELLOW/BROWN - Pos. 16
YELLOW/GREY - Pos. 6
BLUE/VIOLET - Pos. 12
LED/BUTTON
A = NOT AVAILABLE IN THE
KIT GT802/3
POSITIVE +12 V
(MAX CAPACITY 15 A)
15A
ULTRASONIC
TRANSDUCRES
RED WHITE
A
COMFORT
NEGATIVE
COMMAND
AMP
A
M
P
BLACK/WHITE - Pos. 8
ANTI-HIJACK
PIN SWITCH
VEHICLE ACTUATORS
SIGNALS
SWITCHES SIGNALS
(DISCRIMINATORS)
LOCK/UNLOCK BUTTON DOOR SAFETY LOCK
CLOSING ACTUATOR INDICATORS
811
1821 20
9 6
16
710
171922
5
15
3
13 12
4
14
12
AMPAMP
RED
WHITE

6
3.0 - DESCRIPTION OF THE PROGRAMMABLE FUNCTIONS
4.0 - SET FUNCTIONS
WARNING:
- The alarm system must be disarmed.
1- Leave bonnet and the driver’s door opened.
2 - Turn the ignition key ON and leave it switched on for the whole procedure.
3 - Press the LED BUTTON until the system will emit a visual signal (indicators) and a long
acoustic signal to indicate that you have entered the SET FUNCTIONS mode. The LED
BUTTON will start flashing to indicate that it is possible to program/modify the alarm system
functions. If within 2 minutes the SET FUNCTIONS isn’t modified, the system will visualize
the SET FUNCTIONS condition and it will show their state in that moment by a flashings
sequence of the LED BUTTON, as indicated in the table below.
3.1 - Self-coding vehicle indicators impulses number.
When you enable this function it is possible to self-code the indicators flashes number to the
alarmsystem whendoors are locking (system arming)and whendoors areunlocking (system
disarming).
3.2 - Switches/Discriminators signals stabilizer.
When you activate this function it is possible to recognize these signals to the alarm system
if they would be of impulsive type (polling).
3.3 - Memorisation of switches/discriminators signals only after actuator signals.
Whenyou enable ordisable this function it ispossible to decideif introducethe conditions for
vehicles with impulse switch after the actuator.
3.4 - Memorisation of actuator signals of changeable type.
Whenyou enable ordisable this function it ispossible to decideif introducethe conditions for
vehicles with changeable actuator impulse switch.
3.5 - Anti-hijack door signal stabilizer.
When you activate this function it is possible to recognize to the alarm system these signals
if they would be of impulsive type (polling).
3.6 - Acoustic signal when arming/disarming the alarm system.
When you activate or deactivate this function it is possible to have the acoustic signal on
arming and disarming. This function is valid for vehicles with flashing indicators when the
original CDL is operated.
3.7 - Visual signal when arming/disarming the alarm system.
When you activate or deactivate this function it is possible to have visual signals on the
vehicles indicators on arming and disarming.
3.8 - Courtesy light switching on when disarming.
Whenyou activateor deactivate this function itis possibleto havethe courtesylight switching
on for 15 seconds when disarming the alarm.

7
LED BUTTON
CONDITION
The DEFAULT
programming are in “bold”
ALARM SYSTEM
FUNCTION
NUMBER OF
PRESSES
OF THE LED
BUTTON
NUMBER OF
LED BUTTON
/LED FLASHES
FOR THE
FUNCTIONS
STATUS CHECK LED OFF LED ON
Self-coding indicators
impulses number 11Disabled Enabled
Switches/Discriminators
signals stabilizer 22Deactivated Activated
Memorisation of
switches/discriminators
signals only after actuator
signals
33Disabled Enabled
Memorisation of actuator
signals of changeable type 44Disabled Enabled
Anti-hijack door signal
stabilizer 55Deactivated Activated
Acoustic signal when
arming/disarming the alarm
system 66Deactivated Activated
Visual signal when
arming/disarming the alarm
system 77Deactivated Activated
Courtesy light switching on
when disarming 88Deactivated Activated
To modify the settings proceed as follows:
1 - Press the LED BUTTON the number of times corresponding to the function you wish to
check or modify. The alarm generates an acoustic signal for each press.
Before showing the function state, the alarm system will generate acoustic signals and the
LED BUTTON will flash. For example: if you wish to check the function state “Acoustic signal
when arming/disarming the alarm system”, you will have to press the LED BUTTON 6 times,
check that it flashes 6 times and the LED BUTTON remains switched on (acoustic signal
activated) or switches off (acoustic signal deactivated).
2 - When the LED BUTTON shows the function state you are checking (the LED BUTTON
switched on or off), it is possible to modify the alarm system function condition by pressing
the same LED BUTTON.
3 - Once the function state has been selected, the LED BUTTON will flash to indicate that the
newcondition has been memorised. Ifthe LEDBUTTON isn’tpressed again, orthe ignitionis
switchedoff within2 minutes,thealarm system comesoutfrom thesetcondition automatically.
4 - At this point, the alarm system will emit a long acoustic signal to confirm you have come
out from the SET FUNCTIONS.
When the alarm system functions have been programmed carry out the DOORS LOCK/
UNLOCK SIGNALS SELF-CODING (page 8).

8
5.0 - DESCRIPTION OF THE ALARM SYSTEM ARMING/DISARMING
COMMAND WIRES
6.0 - DOORS LOCK/UNLOCK SIGNALS SELF-CODING
A - Using the RED/BROWN and RED/GREY wires you can arm and disarm the alarm
using the original vehicle remote, or door key lock.
- RED/BROWN WIRE:Connecttothe vehiclewire thatchanges state whenlocking thedoors.
- RED/GREY WIRE: Connect to the vehicle wire that changes state when unlocking the
doors.
Note: with this connection the YELLOW/BROWN and YELLOW/GREY wires have to be
connected to O/E vehicle earth.
B - Using the RED/BROWN, RED/GREY, YELLOW/BROWN and YELLOW/GREY wires,
the alarm will only arm and disarm using the original vehicle remote. YELLOW/BROWN
and YELLOW/GREY wire connections can be found in the vehicle technical guides
supplied by GT.
- YELLOW/BROWN WIRE:This wire has to be connected to the vehicle’s locking wire which
is only present when the door lock is being operated by the original vehicle remote.
- YELLOW/GREY WIRE: This wire has to be connected to the vehicle’s unlocking wire which
is only present when the door lock is being operated by the original vehicle remote.
WARNING:
- Ensure that the RED/BROWN, the YELLOW/BROWN, the RED/GREY and the YELLOW/
GREY wires are correctly connected (as indicated in the GT vehicle installation guides
or following the DESCRIPTION OF THE ALARM SYSTEM ARMING/DISARMING
COMMAND WIRES section), the ignition key must be in off and the alarm disarmed.
1-Earth the GREEN/YELLOWwire untilthe alarm system will emita longacoustic signal and
the LED BUTTON starts to flash.
2 - During the next 10 seconds disconnect and then reconnect the earth to the GREEN/
YELLOW wire.
Note: after 10 seconds the alarm system will emit 3 visual (indicators)/acoustic signals and
automatically start the RAPID TEST procedure.
3 - At this point the system will emit 6 visual (indicators) /acoustic signals to indicate that it is
in condition to SELF-CODE THE DOORS LOCK (arming) AND UNLOCK (disarming)
SIGNALS; when the LED BUTTON starts flashing you have 2 minutes to carry out the points
4, 5 and 6.
4 - Make sure that all the doors and the boot and bonnet closed.
5 - Lock the vehicle using the original remote control, after a couple of seconds the alarm will
emit 1 visual (indicators)/acoustic signal and the doors will lock.

9
7.0 - RAPID TEST
WARNING:
- Ensure that the alarm is disarmed.
A - Earth the GREEN/YELLOW wire until the alarm system emits a long acoustic signal and
the LED BUTTON starts flashing.
B - After about 10 seconds the alarm system will emit 3 visual (indicators)/acoustic signals
andit willenter automaticallythe RAPID TEST function. Thealarm systemcan beconsidered
correctly installed if:
1 - The PINK wire has a positive signal (+12V) output and the additional sensors/modules
connected to this wire activate.
2- Whenopening oneofthe doors(GREEN/BROWNor GREEN/BLUEwires)and thebonnet/
boot (GREEN wire) you will obtain a visual (indicators)/acoustic signal.
3 - When you activate an additional sensor (GREEN/BLACK wire) you will obtain 2 flashings
of LED BUTTON and a visual signal (indicators).
4 - When you activate the ultrasonic sensor you will obtain a visual signal (indicators).
To test the alarm, remove all possible items that may create movements and ensure that
doors and windows are closed. Introduce your arm through the gap and move it around; the
alarmsystem indicatorswill flash toconfirm correctoperation. Toincrease the sensitivity, turn
the adjuster close to the main alarm connector clockwise (see page 4).
Warning: this procedure is one of the most important correct alarm operation. To check tthe
sensitivity,move your armsacross theoutside of thewindow andthe soft toproof, thisshould
not trigger the alarm. Only the introduction of an object should trigger the alarm.
5 - If you press the ANTI-HIJACK FUNCTION reservation button (BLACK/WHITE wire) you
obtain a visual (indicators)/acoustic signal.
6 - When the ignition key is ON you will obtain an acoustic signal (if an additional GT 843
siren is connected, this will sound for about 1 second).
6 - Unlock the vehicle using the original remote control, after a couple of seconds the alarm
will emit 2 visual signals (indicators), and 3 acoustic signals indicating the end of self coding
and the doors will unlock.
Warning: The procedure can be considered carried out correctly only if the operations are in
compliance with the points 5 and 6. On the contrary wait that the alarm system comes out
automatically from the procedure (the alarm system will emit an acoustic signal).To repeat
the procedure disconnect the positive leave for a few seconds and then reconnect. Start the
procedure again from point 1.
Note: supposing that the self-coding procedure has been completed correctly, but you want
torepeatit, forexampleinthe caseofthealarm commandwiresconnection(i.e. RED/BROWN,
YELLOW/BROWN, RED/GREY AND YELLOW/GREY wires) has to be changed, it is
necessary to repeat the signals self-coding procedure from the point 1, remember to
disconnect the alarm system power supply for some seconds.
If a self-coding procedure hasn’t been correctly carried out the system can only be
disarmed by the “GT CARD CODE” (see the relative section). Once the alarm is
disarmed,proceed with the self-codingbefore using the originalvehicle’sremote control
handset.

10
8.0 - SELF-POWER SUPPLY
9.0 - FINAL OPERATIONS
The GT 800/2 alarm system siren is equipped with a rechargeable “backup” battery which
allows the alarm power supply in case of alarm wires cut.
Thesiren will rechargefollowing adisarmed alarm andwith theignition key switchedon forat
least 16 hours. The protection is operating only when the alarm system is armed.
Ensure that the alarm system loom is installed correctly. Reassemble all the parts and carry
out the final test. Check an alarm trigger with the siren at maximum power. Opening the
bonnet, the boot or one of the doors a signal is sent, which will trigger the alarm system.
The RAPID TEST procedure can be stopped in two ways:
A - After about 2 minutes from the test function activation, the alarm system emits a long
acoustic signal and it comes out automatically if any other sensor has not been activated.
B-Pressingthe door lockingbutton fromthe original vehiclehandset thealarm system emits
a long acoustic signal and it comes out from the function. If the doors locke but the alarm
remains disarmed, you will need to disarm and rearm the alarm using the original remote
control handsets to restore correct sequence.
If the RAPID TEST procedure has been correctly performed (from the points 1 to 6), but
you wish to carry out it again, ensure that the alarm system is disarmed and repeat the
operation from the point A (Earth the GREEN/YELLOW wire).

11
10 .0 - USER MANUAL
10.1 - ALARM SYSTEM ARMING/DISARMING.
Locking the doors using the original remote control handset, the alarm system will arm and
it will generate 1 acoustic signal (if the function is activated you will obtain also a visual signal
supplied by the indicators). Unlocking the doors using the original remote control handset,
thealarm system willdisarm andit will generate2 acousticsignals (if thefunction isactivated
you will obtain also 2 visual signals supplied by the indicators).
If the original handset fails to operate, it is possible to disarm the alarm system carrying
out the EMERGENCY DISARMING WITH THE “GT CARD CODE”.
10.2 - ELECTRIC WINDOWS CLOSING COMMAND FUNCTION
If the vehicle is equipped with “comfort” function, the electric windows will close when arming
the alarm, otherwise to have this function it necessary to use an additional modules.
10.3 - PROTECTIONS.
- Engine immobilisation.
-Boot/bonnet/doors contacts.If aboot, bonnetor doorsare notclosed whenarming, youmay
observe a long visual and acoustic signal on the indicators, or it can be caused by the timer
delay circuir of the courtesy light.
- Volumetric protection of the passenger compartment.
- Power supply wires cut (only when armed).
- The interruption of the positive power supply (RED wire) doesn’t cause the vehicle’s stop
(FAIL SAFE).
10.4 - IF THE ALARM SOUNDS …
Should the siren activate, it will sound for about 28 seconds. A press of the original remote
control handset button will unlock the doors, silence and disarm the alarm. The alarm will
generate 4 acoustic signals instead of the normal 2 (if the function is activated you will obtain
also 4 visual signals supplied by the indicators).
10.5 - CHECK STATUS LED.
Your alarm is equipped with status check flashing LED. In order to verify an alarm trigger,
disarm the alarm, the LED will flash a sequence according to the triggered sensor (see the
table below). Record number of flashes and contact your installer. Note: two or more triggers
ondifferent sensors (i.e.doors andbonnet) willbe signalled inorder bythe LED (i.e. 4 flashes
-pause - 5 flashes - pause - 4 flashes - etc.).
LED FLASHES SENSOR
1Volumetric protection
2Additional sensor
4Doors
5Boot/bonnet
6Ignition key
7Power supply wires cut

10.6 - EMERGENCY DISARMING WITH “GT CARD CODE”.
In case of emergency (i.e. the battery of the original vehicle handset is discharged, etc.) it is
possible to disarm the alarm system using the GT CARD CODE. It is necessary to carry out
the following procedure:
1 - Take the “GT CARD CODE” which you have received at the time of installation.
2- Openthe doorwith theoriginal vehiclekey,the alarmstartssounding forabout 30 seconds.
3 - Enter the vehicle and close the door.
4 - Wait until the alarm stop sounding and keep the LED BUTTON depressed until the alarm
will start to emit a sequence of visual (indicators) /acoustic signals, this to confirm that you
have entered the emergency disarming procedure
Note: this operation must be carried out within 5 seconds from when the sounding of the
alarm,otherwiseit remains armed;ifthealarm startssoundingagain,wait untilitstopssounding
and repeat the operation.
5- Within10 secondsfrom thevisual/acoustic signal,turn theignition keyin ONand OFF, the
LEDBUTTON willilluminate (ifyou don’tcarry outthis procedurethe alarmwill remainarmed;
you must repeat point no.4).
6 - Whenthe LED is illuminated constantly,you have 10 seconds toenter your firstnumber of
your “GT CARD CODE” (i.e. if the first number is 2 press the LED button twice).
7 - After 10 seconds the LED BUTTON will extinguish for 5 seconds.
8 - Once the LED will illuminate constantly, you have 10 seconds to enter the second number
of your “GT CARD CODE” (i.e. if the second number is 3 press the LED button three times).
9 - Proceed as indicated as in points 7 and 8 until you have entered the fourth number of the
code.Ifthe codehasbeeninserted correctly,thealarmwilldisarm;otherwise it willbenecessary
to repeat the procedure from the point no.4.
10.7 - HOW TO ISOLATE ADDITIONAL SENSORS AND ULTRASONIC SENSOR WHEN
ARMING THE ALARM SYSTEM.
Withthe alarm disarmedkeep the LEDBUTTON situated on the dashboarddepressed, until
it starts flashing. Leave the vehicle and arm the alarm. To remove this isolation, disarm and
then rearm the alarm without pressing the LED BUTTON.
10.8 - ANTI-HIJACK FUNCTION.
To activate the ANTI-HIJACK FUNCTION it is necessary that the system is disarmed and the
vehicle ignition key is on:
1 - Toreserve the ANTI-HIJACKFUNCTION, press theANTI-HIJACK BUTTON untilthe LED
BUTTON illuminates.
2 - With a second press of the ANTI-HIJACK FUNCTION BUTTON, the LED BUTTON will
switch off and the function will be disabled.
12

Getronic S.r.l. Via Calcinate, 12 Gavirate, Italia, hereby declares that GT 800/1/2/3 as been
approved under the following European Directives as issued by the European Community:
R&TTE 1999/5/CE (including the directives: 95/54/CE - 95/56/CE - EN 60950)
The manufacturer holds the homologation certificates and the documents required for
compliance evaluation. Chairman of the board
Danilo Restelli
Varese, November the 4th 2003
11.0 - COMPLIANCE DECLARATION
In case of Hijack ...
1 - If theANTI-HIJACK FUNCTION has been reserved, when the driver’s door is opened, the
LED BUTTON will extinguish.
2 - When the door is closed and after approx. 60 seconds the ANTI-HIJACK will activate
(ignition ON or OFF). All input triggers circuits are active (boot, bonnet, doors and ignition).
When the ignition is switched OFF the vehicle will be immobilised and you will not be able to
start the vehicle.
DisarmingANTI-HIJACK
To disarm the ANTI-HIJACK function, it is necessary to carry out the “GT CARD CODE”
EMERGENCY DISARMING (see relative section).
10.9 - VISUAL SIGNAL FUNCTION WHEN ARMING/DISARMING THE ALARM SYSTEM.
Thealarm can flashthe vehiclesindicatorson arming/disarming.Thisfunction canbeactivated
or deactivated by your installer.
10.10 - ACOUSTIC SIGNAL FUNCTION WHEN ARMING/DISARMING THE ALARM
SYSTEM.
Thealarm sirencan “beep”on aming/disarming.This functioncan be activated or deactivated
by your installer.
10.11 - FUNCTIONS CHECK.
It is suggested to check periodically all the functions of your alarm system.
WARNING:
- To activate or deactivate the functions 10.9 and 10.10 you contact your professional
installer.
13

This Certificate should be kept in a safe place and produced for verification should technical
assistance be required. Inability to produce this Certificate may affect your warranty rights.
Warranty period begins from date of purchase and is valid for 24 months.
Should technical assistance be required during the warranty period, you should take your
vehicleand thisCertificate toeither theoriginal installeror thenearest GTAutoAlarm Service
Centre for inspection. Should any part of the security system be found to be defective, and
providing all component parts of the system are of GT Auto Alarmmanufacture,the defective
partwill be replaced or repairedfree ofcharge. Warranty replacement/repair does notinclude
the following items:
1) damage caused in transit/carriage;
2)damage caused by incorrect or poor installation; problems which may be caused by
anomalies in the vehicle’s electrical system or originating from the environment in which the
system is operated.
3)damage causedby carelessness,negligence, misuse orrepair byunauthorised personnel.
Unitsreturned to ourorganisation underthe terms of the warrantywill bereplaced or repaired
within a reasonable time period according to our Company requirements.
Any repair/refurbishment received within the warranty period does not extend or renew the
warranty itself.
Nobodyis authorized tomodify or replace anything inverbal or written format whichalters the
conditions of this warranty.The manufacturer reserves the right to modify or improve the
specification.
The alarm will only be used as a deterrant. Our company cannot accept liability for any
consequential damage or loss to persons or property as a result of purchase of a GT Auto
Alarmsystem.Anycorrespondenceforlitigation purposesshallbereceived at ourheadquarters
in Gavirate (Varese) - Italy.
12.0 - WARRANTY CONDITIONS
INSTALLATION CERTIFICATE
We certify that the alarm system installation has been carried out following the
installation instructions and the information in the owner's guide has been passed over
to the customer.
Warranty coupon
Alarm model:
ALARM MODEL: INSTALLATION DATE: INSTALLED ACCESSORIES:
INSTALLED ACCESSORIES: STAMP AND INSTALLER
SIGNATURE: INSTALLATION DATE:
MAKE AND CAR MODEL: STAMP AND INSTALLER
SIGNATURE:
All GT Auto Alarm lines are homologated according to the European Directives.
14

15
13.0 - TECHNICAL FEATURES
GT800:
- Input voltage 12V ± 4 Vdc
- Current draw (Disarmed alarm) < 10 mA
- Current draw (Armed alarm) < 20 mA
- Positive output when the alarm is armed 80 mA
- Negative intermittent output in alarm 100 mA
- Engine immobilisation relay contact capacity 15 A @ 15 Vdc
- Operating temperature from -40 °C to + 85 °C
- 5 sec. delay time when arming Ignition switched live, boot and
or bonnet, power supply wires cut
- 60 sec. delay time when arming Doors, addtional sensors and
ultrasonic sensor
- Alarm cycle time 28 seconds
- Acoustic power > 110 dB @ 1m
- Sel-power supply (only GT800/2) The alarm is equipped with a
rechargeableNickel-Cadmium battery.
The recharge time approx. 16 hours

16
InstGT800UKRev00.p65
Getronic S.r.l.
Via Calcinate no. 12
21026 Gavirate (VA) Italy
Tel. [phone]
Fax + 39 0332 731162
www.gtalarm.it
