Audiovox Platinum Prestige APS-610a User manual

128-6538
1 of 10
Model: APS-610a
Owner’sManual
4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is nec-
essary to fully understand the procedure required to enable your vehicle in such situations.
In addition, the chart on the last page of this manual has a section for the particular features
and options installed in your vehicle as well as the override method selected. Valet Switch
manual override is pre-selected from the factory, however, the system can be config-
ured for "Custom Code" operation. Confirm the override mode selected on the last page of this
manual, and familiarize yourself with the selection on it's operation.
FEATURES:
w2 Four Button Programmable RF Trans-
mitters (capable of accepting 4 transmitters)
wFive Channel Receiver
wCode Hopping Technology
wSelectable Manual Override Mode
wRemotePanicinallmodes
wProtected Valet
wUser Programmable Manual Override
Code
w7 Function LED - Arm / Disarm / Zone 1
/ Zone 2 / Zone 3 / Valet / Arming
wIntrusion Alert with Memory
wAudible Arm / Disarm / Defective Zone /
TamperConfirmation
wInstant Siren Activation
wStarter Disable
wTrue Last Door Arming (hardwire only)
wDefective Zone By-Pass
wHardwire or Voltage Sense Selectable
wActive or Passive Arming Selectable
wProgrammable Auto Lock On / Off
wProgrammable Auto Unlock On / Off
wProgrammableDoorLockPulseDuration1
Second/3.5 Seconds/1 Sec L/Dbl. U/L
wProgrammable Active or Passive Door
Locks
wUserProgrammablePermanentChirpDelete
wOnCommandRFChirpDeletefromTrans-
mitter Or Selectable Through Software
w6 Tone Multi Tone Siren (And or)
wCar Horn Activation for additional alarm
response
wAdditional Negative Trigger Input
wRF Inhibit with ignition on
wParking Light Flasher
wRemote Trunk Release (must have
electronic trunk release)
wRemote Keyless Entry With Optional
Access Guard (must have power door
locks)
wIlluminatedEntry
wPlug In Dual Stage Shock Sensor
OPTIONS:
wRemote Trunk Release (must have electronic trunk release)
wRemote Keyless Entry (must have power door locks)
wMultiple Vehicle Capable
wRemote Starter
wRemote Power Window Roll Up
wRemote Garage Door Interface
wHeadlightIlluminationDuringArming/Disarming,OrBoth

128-6538
2 of 10
Page 2
YOUR "Code Hopping" TRANSMITTERS
The transmitters included with your new security system use the most advanced and
secure form of radio frequency transmission available on any current automotive security
system. Some of today’s sophisticated auto thieves use a device known as a code grabber,
which will receive and store the signal from your keychain transmitter, and re transmit at a
later time to disarm your system.
Your code hopping transmitters will change their signal every time the button is pressed, so
when a thief grabs then retransmits your signal, the alarm system will not respond.
If your transmitter button is pressed more than fifty times while it is out of range of the vehicle
(children playing with your keys), the transmitter will not operate when you return to the
vehicle, and will need to be realigned to the receiver. To do this, simply press the lock button
two times within a one second time period. The system will now respond to that transmitter
each time a button is pressed.
NOTE: Your system has the option of using a siren, the vehicle horn, or both for the sounding
device. Where the siren is referenced below, the horn or both may in fact chirp, or beep.
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and release the Lock button on the keychain transmitter.
þRed dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren and or Horn sounds one chirp.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection. If the siren "chirped"
three times, sometime after arming, the exclusive delayed dome light learn circuit
has been programmed and the system detected a open entry point after the
learned delay expired. Again, closing the hood, trunk, or doors will correct the
problem and you do not need to disarm the system to make the correction. If the
siren/horn did not sound when arming, then the chirps have been turned off, and
youshouldrefertothesectiontitled“ ELIMINATINGTHEARM/DISARMCHIRPS“
in this manual.
oDoors Lock - Optional
oHeadlightIllumination-Optional
SILENT ARMING - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and hold the Lock button on the keychain transmitter for 2 seconds.
þRed dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren will not sound.
If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid
ajar. Simply close the opened entry point to provide full protection.
oDoors Lock - Optional
oHeadlightIllumination-Optional

128-6538
3 of 10
Page 3
ARMING THE SYSTEM - PASSIVE ( AUTOMATIC )
1. Turn off the engine, exit the vehicle, close and lock all doors, hood lid and trunk lid.
þRed dash mounted LED begins to flash rapidly, indicating 30 second passive
arming has begun.
2. Opening any protected entry point during the 30 second passive arming cycle will imme-
diately suspend automatic arming, and the 30 second passive arming cycle will restart
when all doors are closed. At the end of the passive arming cycle;
þRed dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren sounds one chirp
If the siren did not sound when arming, then the chirps have
been turned off and you should refer to the section titled
“ELIMINATINGTHEARM/DISARMCHIRPS “inthis manual.
oDoors Lock - Optional
Door locking during passive arming is a selectable feature. The
alarm can be programmed to allow the doors to lock only when
arming using the keychain transmitter, and they will not
automatically lock during passive arming.
PROTECTION WHILE THE SYSTEM IS ARMED
þOpening any protected door, hood, or trunk lid will cause the alarm to
immediately sound. The alarm will continue to sound for 30 seconds, then stop
and continue to monitor all protected entry points. If the thief left a door opened,
the alarm will sound for six 30 second cycles, remain armed and ignore that
triggered zone.
þWhenever the system is armed, the red dash mounted LED indicator will slowly
flash. This serves as a visual deterrent to the potential thief. The LED is a very
low current bulb, and will not cause the vehicle’s battery to drain, even when
left unattended for extended periods.
þWhenever the system is triggered, the vehicle’s parking lights will flash for the
full 30 second alarm cycle, attracting visual attention to the vehicle.
oOptional - Whenever the system is armed, the vehicle’s starting circuit will be
bypassed. If the thief should choose to ignore the siren, the vehicle can not be
started.
þAny mild impact to the vehicle’s glass will cause the alarm to sound a short
series of warning tones.
þAny strong impact to the vehicle’s glass will cause the alarm to trigger for the
full 30 second alarm cycle.
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock button on the keychain trans-
mitter.
þRed dash mounted LED turns off.
If passive arming was selected during the installation, then the LED will start
flashing rapidly, indicating that the system is re-arming automatically. Open
any door to suspend the automatic arming.

128-6538
4 of 10
Page 4
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was triggered in your
absence. Before turning the key on, examine the LED to identify which zone
was triggered.
þSiren sounds two chirps.
If the siren sounds 4 chirps, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was trig-
gered.
If the siren did not sound when disarming, then the chirps have been turned
off, and you should refer to the section titled " ELIMINATING THE ARM /
DISARMCHIRPS" inthismanual.
oDoors Unlock - Optional
Note: If the optional 2 step door unlock circuit is installed, when the unlock transmitter
button is activated, the drivers door only will unlock, pressing the unlock button a
second time will cause all doors to unlock. If your transmitter has a sperate lock
unlock buttons, pressing the unlock button anytime after the first unlock command
will cause all the vehicle doors to unlock.
oHeadlightIllumination-Optional
SILENT DISARMING
1. As you approach the vehicle, press and hold the Unlock button on the keychain transmitter
for 2 seconds.
þRed dash mounted LED turns off.
If passive arming was selected during the installation, then the LED will start
flashing rapidly, indicating that the system is re arming automatically. Open
any door to suspend the automatic arming.
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was triggered in your
absence. Before turning the key on, examine the LED to identify which zone
was triggered.
þSiren will not sound.
If the siren sounds 4 chirps, then the alarm was triggered in your absence.
Before turning the key on, examine the LED and refer to the INTRUSION
WARNING SIGNALS section of this manual to identify which zone was trig-
gered.
oDoors Unlock - Optional
Note: If the optional 2 step door unlock circuit is installed, when the unlock transmitter
button is activated, the drivers door only will unlock, pressing the unlock button a
second time will cause all doors to unlock. If your transmitter has a separate lock/
unlock buttons, pressing the unlock button anytime after the first unlock com-
mand will cause all the vehicle doors to unlock.
oHeadlightIllumination-Optional
WHILETHESYSTEM IS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security
system, simply press and release any transmitter button other than the disarm button. This

128-6538
5 of 10
Page 5
action will turn off the siren yet leave the vehicle fully armed and protected. This feature is
particularly useful if you are aware of children playing near your vehicle that may accidently
trigger your security system. In this case you can cancel the siren sounding without
disarming your alarm.
INTRUSIONWARNINGSIGNALS
This system will inform you if an intrusion attempt has occurred while you were away from
the vehicle. If an intrusion attempt has occurred, the siren will chirp 4 times and the parking
lights will flash 3 times when disarming the system. Enter the vehicle, and observe the red
dash mounted LED to identify which zone was triggered.
If the LED is flashing one time...pause...one time...pause...etc., then an intrusion
attempt was made to the shock sensor, or an accessory triggering device that
may have been added to the system.
If the LED is flashing two times...pause...two times...pause...etc., then an intrusion
attempt was made to a hood or trunk pin switch that was added to the system, or
to a light activated entry point if the alarm was installed using the voltage sensing
feature.
If the LED is flashing three times...pause...three times...pause...etc., then an intru-
sion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory and will only be
erased when the ignition key is turned on.
VALET SWITCH
The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to
hand your transmitter to parking attendants or garage mechanics. When the system is in
valet mode, all alarm functions are bypassed, however the remote panic feature and remote
door locks will remain operational. To use the valet mode, the system must first be disarmed
either by using your keychain transmitter, or by operating the manual override sequence.
1. From the disarmed condition, turn the ignition key to the on position.
2. Press and hold the valet pushbutton switch until the dash mounted LED, (Light Emitting
Diode) turns on. The LED will remain on as long as the system is in valet mode.
3. To return to normal operation, press and release the push button switch any time the
ignition is on.
NOTE: Always remember to return the system to the NON VALET mode, after servicing, to
ensure that the vehicle remains protected at all times.
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE VALET SWITCH MANUAL OVERRIDE
Your Security System can be disarmed without the use of the keychain transmitter. This is
necessary, since you will need the ability to operate your vehicle if the transmitter is lost or
its battery fails. If your system has been selected for Valet Switch manual override as
indicated on the last page of this manual, to by-pass the alarm system.
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet push button switch.
The alarm system will stop sounding and enter the disarmed mode. You can now start and
operate the vehicle normally.

128-6538
6 of 10
Page 6
Typically this override mode is used only if the transmitter has become inoperative. You may
elect to enter the VALET mode until repair or replacement of the transmitter, after
which, returning the system to the full operation mode is necessary. To do so, see item
3 under the heading VALET SWITCH.
Programming Your Custom Override Code:
Unlike override switches easily found and defeated, this security system allows the con-
sumer to program a personal override code, offering a higher level of security. To take
advantage of this option, programmable feature # 10 must be selected for the Custom Code
Option. Consult your installation center for programming details. The system comes from the
factory with a pre-programmed override code of 11. To change this default override code, do
the following:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence. Turn the ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the
pushbutton switch from 1 up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and releasing the
pushbutton switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
If the new code was accepted, the unit will report back the newly entered code, by flashing
the LED, first indicating the 10ths digit, pause and then the units digit. The unit will report the
new code three times with a one second pause between each code, then the system will
begin arming. If the LED flash pattern reports the previously stored code, the new code was
not entered correctly. Please repeat steps 1 through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0
(Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then
5 seconds during any of the above steps, the unit will revert back to the last
successfully stored code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the
following:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
5. Within 10 seconds, begin to press and release the push button switch to set the tenths
digit.
(As per the example, press and release 5 times to set the tenths digit to 5)

128-6538
7 of 10
Page 7
6. Within 10 seconds of the last press of the pushbutton, turn the ignition switch off then on.
7. Within 10 seconds, begin to press and release the push button switch to set the units
digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern.
You will note the LED flashing five times, pause, and then flash two times, pause. This
pattern will be repeated three times indicating the new code (52) has been accepted and
stored in memory.
NOTE: If after step 8, the LED flashes a code other than what was just entered, this
indicates that the code has not been changed. You will have to repeat steps 1
through 7 above being certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no
digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then
5 seconds during any of the above steps, the unit will revert back to the last
successfully stored code.
MANUALLY OVERRIDING YOUR SYSTEM:
USINGTHE CUSTOM CODEOVERRIDE
Assuming the override code programmed has not been changed, and the default override
code of 11 is in the system's memory.
1) Enter the vehicle and turn the ignition switch to the on position.
Note: The siren will sound.
2) Within 5 seconds, press and release the pushbutton switch 1 time.
3) Within 5 seconds, turn the ignition switch off then on.
4) Within 5 seconds, press and release the pushbutton switch 1 time.
5) Turn the ignition switch off then on and start the vehicle.
NOTE: If you have changed the programmed override code then substitute your new code
tenths for step 2 above, and units for step 5 above.
ELIMINATING THE NORMAL ARM / DISARM CHIRPS
As explained earlier in the manual, you can eliminate the chirps selectively any time you arm
or disarm the system simply by holding the ARM / DISARM button for two seconds. If you find
the normal arming and disarming chirps annoying, they can be turned off permanently,
eliminating the need to hold the ARM / DISARM button for two seconds. To do this,
1. Turn the ignition key on then off.
2. Within 10 seconds, press and release the valet push button switch three times.
3. If the chirps were on before you started, then you will hear 2 chirps indicating they have
been turned off.
If the chirps were off before you started, then you will hear one chirp indicating they have
been turned on.
NOTE: Whenever the chirps are by-passed, the 4 chirp intrusion indicator and 3 chirp

128-6538
8 of 10
Page 8
defective zone indicator will always operate. Since these are important warnings to
you that something has happened, they cannot be eliminated.
REMOTEPANICOPERATION
The ARM or DISARM button on your keychain transmitter also functions as a panic switch for
use in emergency situations. To use remote panic,
1. Press and hold the ARM or DISARM button on the keychain transmitter for 3 or more
seconds. The alarm will immediately sound.
2. To stop the alarm, press and hold the ARM or DISARM button on the transmitter again for 3
seconds. If the button is not pressed, the alarm will automatically stop after 30 seconds.
Also if any transmitter button other than the ARM or DISARM button is pressed and
released, the Panic mode will be turned off immediately. The normal function of this
transmitter button will be suspended during the Panic sounding period.
3. During the panic mode, the Lock and Unlock buttons can be used to lock and unlock the
doors, (if the option is installed), however once the unlock/disarm button is pressed, the
vehicle's starter inhibit device, (where installed) will be disabled allowing the vehicle to
start.
NOTE: While in the Panic mode, pressing and releasing the ARM or DISARM buttons will, if
the option is installed, lock and unlock the doors respectively. While in the panic mode,
anytime the DISARM button is pressed, the panic feature will continue for the allotted
30 seconds, however, the security system will be disarmed allowing the vehicle to
start.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 3 )
This security system has an additional features that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are;
oRemote Trunk Release oRemote Car Starter
oRemote Window Closure oRemote Garage Door Interface
Operation of the optional accessory or accessories, can be controlled by pressing and
holding the programmed button on the keychain transmitter for four seconds, or by pressing
and releasing the programmed button on the transmitter two times in succession. Check
with your installation center for more information on what accessories were installed and
how they are accessed.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 )
This security system has an additional feature that can be connected to a number of differ-
ent optional accessories. Some of the more common uses for this channel are;
oRemote Trunk Release oRemote Car Starter
oRemote Window Closure oRemote Garage Door Interface
To activate the optional accessory, press the programmed button on the keychain transmitter
for up to 8 seconds for continuous output, or press and release for momentary activation.
The optional accessory will immediately engage. Check with your installation center for
more information on the optional accessory that may have been installed and how it is
accessed.

128-6538
9 of 10
ADDITIONAL REMOTE FUNCTION ( CHANNEL 5 )
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are;
oRemote Trunk Release oRemote Car Starter
oRemote Window Closure oRemote Garage Door Interface
To activate the optional accessory, press the programmed button on the keychain transmit-
ter for up to 8 seconds for continuous output, or press and release for momentary activa-
tion. The optional accessory will immediately engage. Check with your installation center for
more information on the optional accessory that may have been installed and how it is
accessed.
IGNITION CONTROLLED LOCK UNLOCK: (Unlock Drivers Only, or Unlock All Doors)
Your security system has a selectable safety feature that allows the vehicle doors to lock
when the ignition switch is turned on, (Providing all doors are closed), and to unlock the
doors when the ignition switch is turned off. In addition, the unlocking of the doors is
further selectable, in a two step unlock configuration, to unlock only the drivers door or all
doors.
Page 9

128-6538
10 of 10
APS 610a
SYSTEMFUNCTIONSAT A GLANCE
DASHLEDINDICATORS
RAPIDFLASHING = PASSIVEARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ONSOLID = VALETMODE
3FLASH...PAUSE = INTRUSIONZONE3
2FLASH...PAUSE = INTRUSIONZONE2
1FLASH...PAUSE = INTRUSIONZONE1
SIRENCHIRP INDICATORS
*1CHIRP = ARM
*2CHIRPS = DISARM
3CHIRPS = ARM/DOOROPENED
4CHIRPS = DISARM/INTRUSION
* These chirps are optional, and can be de-activated.
PARKING LAMP INDICATORS
1 FLASH = ARM
2FLASHES = DISARM
3FLASHES = DISARM/INTRUSION
Your System Has These Features Activated
oStarter Disable
oRemote Keyless Entry
oAuto Lock with ignition key
oAuto Unlock with ignition key
oPassive Arming
oNo Lock in passive mode
oHardwire doors, hood, and trunk
oCustom Code Override
oValet Switch Override
© 2003 Audiovox Electronics Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-6538
