GTC REVPAD User manual

     
SAVE SYS X-Y
XYXYXYXY
ABC D
BYPASS
SET
12 3
CLIP COMM BATT FREEZE PEDAL PATCH NORMAL
GTC Sound Innovations REVPAD Manual

II
REVPAD Firmware version: 1.0
Last manual update: 2017-02-10

III
Copyright and Intellectual Property
Copyright and Intellectual Property
Copyright © 2017 GTC Sound Innovations
All rights reserved.
No part of this publication may be reproduced in any form without the written permission of GTC Sound Innovations.
The product can be used to record or duplicate audio without being limited by certain technological copy-protection measures. This
is due to the fact that this product is intended to be used for the purpose of producing original music, and is therefore designed so that
material that does not infringe copyrights belonging to others (for example, your own original works) can be recorded or duplicated
freely.
Do not use this unit for purposes that could infringe on a copyright held by a third party. We assume no responsibility whatsoever with
regard to any infringements of third-party copyrights arising through your use of this unit.

a
Table of Contents
Table of Contents
Copyright and Intellectual Property ....................................................................... III
Welcome to the Creative World of the GTC Sound Innovations REVPAD............................................1
Important Safety Instructions ..............................................................................2
General Battery Safety Instructions .........................................................................4
Battery Replacement Instructions...........................................................................6
EMC and Certicate of Conformity .........................................................................8
Quick Start ..........................................................................................11
The REVPAD Touchpad .................................................................................12
The REVPAD Base Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Take the REVPAD for a Spin..............................................................................16
Exploring Your GTC Sound Innovations REVPAD .............................................................17
Getting to Know the REVPAD Base Unit ....................................................................18
The Back Panel of the REVPAD Base Unit ...................................................................26
Getting to Know the REVPAD Touchpad ....................................................................31
Customizing your REVPAD ..............................................................................35

GTC Sound Innovations REVPAD Manual
b
Creating and Editing Patches .............................................................................36
Modifying a Patch .....................................................................................37
Setting Patch Effect Parameters............................................................................38
Mix / Touch Mix ......................................................................................39
Tempo and Global Tempo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting X-Y Values in Effects..............................................................................41
Saving a New Patch....................................................................................43
Organizing Your Patch List ...............................................................................44
Modes ..............................................................................................45
Patch Setup ..........................................................................................51
Pad Setup ...........................................................................................55
MIDI Setup ..........................................................................................56
Auto Setup...........................................................................................57
External Control of Internal Effects.........................................................................59
System Conguration ..................................................................................61
Device Utilities .......................................................................................61
Pad Settings ..........................................................................................63
Touchpad Control Button Assignment ......................................................................65

c
Table of Contents
MIDI Settings.........................................................................................68
MIDI IN CC Map......................................................................................69
MIDI Control ........................................................................................71
MIDI IN.............................................................................................72
MIDI OUT...........................................................................................74
Specications ........................................................................................79
MIDI Implementation Map ..............................................................................83
Contact & Support ....................................................................................85

1
Welcome to the Creative World of the GTC Sound Innovations REVPAD
Welcome to the Creative World of the GTC Sound Innovations REVPAD
The GTC Sound Innovations REVPAD is a sound effect controller for use with amplied instruments. It includes a sound processing
base unit, which can connect to other equipment or systems. It has a Touchpad, which attaches to the guitar and communicates wire-
lessly with the base unit. The Touchpad attaches to the guitar by an adhesive that does not damage or otherwise affect the surface of
the instrument. The base unit contains algorithms that provide a great number of effects, in addition to analog distortion and overdrive,
and includes the possibility to change effects while playing.
The REVPAD includes multiple Patches (presets) of effect parameters, including analog distortion and overdrive, as well as additional
effects, such as chorus, delays, and virtual faders. It enables the user to manipulate sound effects by swiping or tapping the Touchpad
surface and allows for improvisation and creating new effects on the y. The REVPAD enables smooth cross-fading between effects,
a dynamic kill switch, a virtual whammy bar, volume control, ambient sounds, and control of external gear, such as a favorite pedal.
With the REVPAD the user can manipulate the wah and virtual whammy bar, change volume, apply cross-fading, and create varying
levels of feedback more easily than by using the knobs on the guitar.
The REVPAD supports your creativity to explore the limitless world of sound effects.

GTC Sound Innovations REVPAD Manual
2
Important Safety Instructions
■Read and follow these instructions before operating your REVPAD system.
■Keep these instructions for future reference.
■Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power supply cord or plug is damaged, liquid has been spilled or the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
■The REVPAD does not require preventive maintenance.
■Clean the REVPAD only with a dry cloth. Do not use any chemicals.
■This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. See “EMC and Certicate of Conformity” on page 8 for more information.
Warning! DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.
This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in
just two hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close
securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.

3
Welcome to the Creative World of the GTC Sound Innovations REVPAD
Protecting From the Elements
■The REVPAD is designed for indoor use. Do not operate the system outdoors without proper protection against mist or rain.
■Do not expose the REVPAD to dripping or splashing and ensure that no objects lled with liquids, such as vases, are placed on
the apparatus.
■Unplug the unit during lightning storms and when not intended for use for long periods of time.
Protecting the Power System
■Use only the power adapter supplied with the system.
■Protect the power cord from being walked on or pinched.
■The DC power jack is used to disconnect the REVPAD. Please keep this plug accessible.
■Charge the REVPAD Touchpad frequently; this will increase the lifetime of the battery.
■In long storage periods it is recommended to remove the battery from the REVPAD Touchpad.
■Limit exposure to extremely high noise levels.
■Charge the REVPAD Touchpad with the USB cable supplied with the system. Do not charge the battery using an external charger
at any time.
Note: After connecting the USB wait for a message to appear in the base unit display area before continuing. If this is the rst time you
are using the Touchpad the message will say PAD WAS SUCCESFLLY ASSIGNED. Otherwise the message will say PAD CONNECTED.

GTC Sound Innovations REVPAD Manual
4
General Battery Safety Instructions
Warning! DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.
This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in
just two hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close
securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
■Before using the battery, be sure to read the instructions and observe the precautions printed on its packaging.
■Improper handling a Li-Ion rechargeable battery might cause leakage, heat, smoke, explosion, or re. This could cause
deterioration of performance or failure.
■See “Battery Replacement Instructions” on page 6 before installing or removing the battery from the REVPAD Touchpad.
■All of the following are dangerous.
■Do not leave, charge, or use the battery in a car or similar place where inside temperature might be over 60º C / 140° F.
■Do not leave the battery near a re or a heat source. Do not throw the battery into a re. Do not immerse, throw into, or wet
the battery in water or seawater.
■Do not short circuit positive (+) and negative (-) terminals with a metallic object intentionally.
■Do not pierce the battery with a sharp object such as a needle or screwdriver.
■Do not heat a partial area of the battery with heated objects or solder directly to the battery.
■Do not hit with heavy objects such as a hammer and do not throw or drop the battery on a hard oor.
■Do not disassemble the battery or modify the battery design, including the electric circuit.
■Do not put the battery into a microwave oven, dryer, or high-pressure container.

5
Welcome to the Creative World of the GTC Sound Innovations REVPAD
■If at any time you witness a battery starting to balloon, swell up, smoke, heat, discolor, deform, or if an abnormal condition is
detected during use, charge, or storage:
■If charging, immediately discontinue charging process.
■Immediately disconnect the battery and observe it in a safe place for approximately 15 minutes.
■If at any time leakage or foul odors are detected make sure that there is sufcient distance from re.
■If liquid leaking from the battery gets onto your skin or clothes, immediately wash well with fresh water.
■If liquid leaking from the battery gets into your eyes, do not rub them. Immediately ush them with clean water and seek medical
attention.

GTC Sound Innovations REVPAD Manual
6
Battery Replacement Instructions
The REVPAD is supplied with a Li-Ion rechargeable battery.
The battery does not need to be replaced unless its operating time becomes much shorter than usual.
Warning! DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD.
This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in
just two hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close
securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.

7
Welcome to the Creative World of the GTC Sound Innovations REVPAD
To replace the battery:
1. Remove the REVPAD Touchpad from the guitar.
2. Turn off the Touchpad by clicking the microswitch toward the rounded end.
3. Turn the Touchpad over and use a Phillips screwdriver to release the two
mounting screws. Set them aside.
4. Slide the cover off.
5. Remove the old battery from the holder by pulling it out using your ngers.
Do not use any metal apparatus to pull out the battery, as it might short the
battery leads.
Note: Do not throw the spent battery in your household trash. It should be
handed over to an authorized collection site for recycling waste electrical
and electronic equipment. If recycling is not available in your community
the battery should be disposed of responsibly, according to local codes.
6. Clean the leads of the new battery.
7. Replace the battery into the holder in the correct orientation.
Note: Make sure that you place the battery as is pictured in the illustration.
A battery placed the wrong orientation will short-circuit the battery and may cause it to heat up and possibly explode.
8. Close the cover and secure it in place with the two mounting screws.
9. Connect the USB connection of the Touchpad to the base unit to charge the battery. Wait for PAD CONNECTED to appear in the
base unit display area before using the Touchpad. See “Charging the REVPAD Touchpad” on page 34 for more information.







GTC Sound Innovations REVPAD Manual
8
EMC and Certicate of Conformity
Class B Warnings
The FCC Wants You to Know
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
■Consult the dealer or an experienced radio/TV technician.

9
Welcome to the Creative World of the GTC Sound Innovations REVPAD
RF Exposure Warnings
Mobile Device RF Exposure Statement
Mobile Device denition:
a Mobile: (§2.1091) (b)
A mobile device is dened as a transmitting device designed to be used in other than xed locations and to generally be used in such
a way that a separation distance of at least 20 cm / 8” is normally maintained between the transmitter’s radiating structure(s) and the
body of the user or nearby persons.
Per §2.1091d(d)(4)
In some cases (for example, modular or desktop transmitters), the potential conditions of use of a device may not allow easy clas-
sication of that device as either Mobile or Portable. In these cases, applicants are responsible for determining minimum distances
for compliance for the intended use and installation of the device based on evaluation of either specic absorption rate (SAR), eld
strength, or power density, whichever is most appropriate
RF Exposure
This device is only authorized for use in a mobile application. At least 20 cm / 8” of separation distance between the REVPAD and
the user’s body must be maintained at all times.

GTC Sound Innovations REVPAD Manual
10

11
Quick Start
Quick Start
The REVPAD Touchpad provides a wireless connection to the REVPAD Base Unit so you can switch and control effects with a swipe
or tap of your nger.
Driven by the TouchFx Patented Technology engine, the REVPAD provides guitarists full, simultaneous control of multiple effects pa-
rameters, including their own existing pedal board effects. This enables the player, for the rst time, to actually play effects on the y,
instead of in a standard manner, and combine this naturally with playing the guitar.
Up to eight effects and their parameters can be simultaneously assigned to any axis on the pad and by that to actually perform as
“virtual” faders and switches for any aspect of the signal and its processing. It gives the player full, accurate and super-dynamic control
of the effects with just a simple nger tap, touch or swipe. It also eliminates the need to go to the pedal board to change effects and
the hassle of bending down and tweaking knobs while playing.
Three buttons located on the REVPAD Touchpad can be assigned to operate many great features offered by the REVPAD. They can be
used to switch between Patches, go through different modes, bypass, freeze, MIDI applications and much more.
Before exploring how to customize the REVPAD to t your personal way of playing, let’s see what it can do by itself.

GTC Sound Innovations REVPAD Manual
12
The REVPAD Touchpad
The REVPAD Touchpad provides a wireless connection to the REVPAD Base Unit so you can switch and control effects with a swipe
or a touch of your nger.
Attaching the Touchpad
The REVPAD Touchpad comes with three slim (0.6 mm) hook/loop fastener dots, which stick onto the guitar body in any location,
according to your personal preference. It is easily removed if it needs to be replaced. The Touchpad attaches to the dots rmly enough
to endure even the most vigorous live performance, while remaining easy to remove. The guitar remains clean and undamaged.
Note: The hook/loop fastener dots may leave marks on vintage guitars with nitrocellulose nishes. Check on an inconspicuous spot
before attaching the hook/loop fastener dots.

13
Quick Start
To attach the Touchpad:
1. Turn the Touchpad on by pushing the switch toward the pointed end.
2. The power LED should glow green.
Note: If the power LED glows yellow or red, or does not light up
at all, the battery must be recharged. See “Charging the REVPAD
Touchpad” on page 34 for more information.
3. Remove one side of the adhesive backing of a hook/loop fastener
dot.
4. Press the adhesive rmly in the recessed circle on the inside face of
the Touchpad. Repeat with the second hook/loop fastener dot.
5. Remove the adhesive backing of both hook/loop fastener dots.
6. Attach the Touchpad to your guitar where you can conveniently
touch the Control Buttons and Touchpad.






GTC Sound Innovations REVPAD Manual
14
The REVPAD Base Unit
It’s all about preserving the natural sounds and soul of the guitar. The REVPAD is not generating sounds but processing them, so even
though you can get synth-like sounds it is not a synthesizer, rather a signal-processing unit that preserves the natural sound of the
instrument as well as the natural response to and feel of the guitar player’s ngers.
The REVPAD System offers 200 factory and user presets to build and explore your own sounds.
Building a Patch is easy and intuitive:
■Step 1: Choose any effect you want.
■Step 2: Explore the effect to set parameters.
■Step 3: Push a button to select which one of those parameters you’d like to be controlled by the Touchpad and in which direction:
X+, X-, Y+, Y-.
Repeat those three action steps to all of the other effects you’d like to add to the effect chain and press the save button. That’s all you
need to do to build a fully customized Patch.
