Gtech CLM001 User manual

OPERATING MANUAL
ORIGINAL INSTRUCTIONS
2016
Cordless Lawn Mower
Model number: CLM001

2
IMPORTANT SAFEGUARDS:
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Do not use in rain or leave outdoors whilst raining.
WARNING: Basic safety precautions should always be observed when
using an electrical appliance to reduce the risk of re, electrical shock or
serious injury.
Personal Safety:
•Only use the mower on grass and
lawns, as described in this manual.
• Keep out of reach of children and
animals at all times.
• Only use in daylight or good articial
light.
• Do not use while there are other
people, especially children, nearby.
• Stay alert, watch what you are
doing and use common sense when
operating the mower.
• Do not use the mower while you are
tired or under the inuence of drugs,
alcohol or medication. This may result
in serious personal injury.
• Always be aware of your
surroundings and stay alert for
possible hazards.
• Use protective personal equipment
such as safety glasses, non-skid
safety shoes, sturdy gloves to reduce
the risk of personal injury.
• Do not operate when barefoot or
wearing open toed shoes.
• Dress appropriately. Do not wear
loose clothing or jewellery and keep
hair, clothing and gloves away from
moving parts.
• Mow across slopes, not up and
down, taking care when changing
direction.
• Always be sure of your footing on
slopes or in slippery conditions.
• Do not use on excessively steep
slopes.
• Take particular care when reversing with
the mower or pulling it towards you.
• Never touch the rotating blade.
• Do not stand in front of the protective
ap when opened.
• Do not open the protective ap while
the motor is running.
• Never operate the mower over gravel,
as this risks icking stones.
• Check the area where the mower is
to be used and remove any objects
that could jam or be thrown by the
mower, such as stones and sticks.
• Avoid operating the mower on wet
grass.
• Check the grass box regularly for any
wear and deformation.
• Do not use the mower without the
grass box or other protective guards
in place.
• Never operate the mower with
damaged guards or without the
guards in place.
• Visually check the cutting tools and
their fasteners for any damage before
each use.
• To prevent imbalance, any damaged
or worn-out parts should be replaced
in sets only.
• When operating the mower ensure
that both hands are correctly
positioned on the handle.

3
• Only start the mower when your feet are
a safe distance from the cutting blade.
• Do not tilt the mower when starting
the motor.
• Do not operate the mower if it is
incomplete or has unauthorised
modications.
• Keep all body parts, especially hands
and feet, away from the blade at all
times.
• Warning, the blade will continue to
move after the motor is switched off.
• Ensure that the blade has fully
stopped and activation key has been
removed before :
- leaving the mower
- clearing a blockage
- adjusting the cutting height
- emptying the grass box
- lifting or carrying the mower
- tilting the mower to move
- checking or cleaning the mower
- carrying out any maintenance
• If the mower vibrates intensively, stop
the motor fully and identify the cause.
• The operator is responsible for
accidents or hazards occurring to
other people at their property.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities
or lack of experience or knowledge.
• Never modify the mower in any way.
Electrical safety:
• Do not operate the mower in
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Mowers create sparks,
which may ignite the dust and fumes.
• Do not use the mower when a
thunderstorm is approaching.
• Avoid body contact with earthed or
grounded surfaces, such as pipes.
There is an increased risk of electric
shock if your body is earthed or
grounded.
• Do not expose the mower to rain or
wet conditions.
• Do not handle the charger or the
mower with wet hands.
• Before charging check the power
supply and charger cables for signs
of damage or ageing.
• Do not expose the mower to
temperatures exceeding 80ºC, or
leave the mower in direct sunlight or
in the hot boot of a car for prolonged
periods.
Battery safety:
• Do not attempt to use the charger
with any other product or to charge
this product with any other charger.
• Do not use the charger in moist or
wet conditions or outdoors.
• Disconnect the cable connectors by
pulling the plug only, never the cable.
• Do not use a damaged charger.
• Never cover the ventilation slots.
• Never open the charger. In case of
defect, contact Gtech.
• This product contains Li-Ion batteries.
Do not incinerate batteries or expose
to high temperatures, as they may
explode.
• Do not charge the battery when the
surrounding air temperature or the
battery pack is below 0°C or above
40°C.
• After heavy use or in high
temperatures the battery may
become warm. Allow the product to
cool for 30 minutes before charging.
• Use only with the battery pack
supplied.

4
• Leaks from battery cells can occur
under extreme conditions. If the liquid
gets on your skin wash immediately
with soap and water. If the liquid
gets into your eyes, ush them
immediately with cold water for a
minimum of 10 minutes and seek
urgent medical attention.
• Protect the battery against excessive
temperatures and re.
• Do not store the battery outside for
prolonged periods of time over the
winter months.
• Do not dispose of the battery pack
into household waste, re or water.
Battery pack should be collected,
recycled or disposed of in an
environmentally friendly manner.
Discharge your battery pack by
operating your Cordless Lawn Mower.
Remove the battery pack from
the housing and cover the battery
pack connections with heavy duty
ventilation tape to prevent a short
circuit and energy discharge. Do not
attempt to open or remove any of the
components.
Service:
• Do not use the mower if the switch
does not turn it on or off. Any power
tool that cannot be controlled by the
switch is dangerous and must be
removed or replaced.
• Before any servicing and cleaning
take out the activation key and
remove the battery.
• Check all visible xing screws and
nuts, especially on the cutter bar, to
ensure they are tightened properly.
• Do not keep the mower in a damp
room.
• Before using the the mower and after
any impact, check for signs of wear
and damage and repair or replace as
necessary.
• Use only genuine replacement parts.
This will ensure that the safety of the
the mower is maintained.
• Do not attempt to repair any
damaged parts on the mower unless
you are qualied to do so.
Intended Use:
• This product is intended for
DOMESTIC USE ONLY.

5
Warning Label Descriptions
Warning/Caution. Remove activation key before ser-
vicing and cleaning.
Beware of servering toes or hands.
Do not put hands or feet near a
rotating blade.
Dangerous voltage.
Read the instruction manual. Keep bystanders at a safe distance
(at least 5m).
Caution: Wait until blades stop
rotating when stopped.
Always keep the lawnmower on the
ground when mowing.
Tilting or lifting the lawnmower may
cause stones to be thrown out.
Do not mow in the rain or leave the
lawnmower outdoors while raining.
Do not dispose of Li-Ion battery
with general household waste.
Grass bin empty. Grass bin full.
L WA
96 dB
Guaranteed Sound Power Level
• Please read this manual carefully. Familiarise yourself thoroughly with the
controls and proper use of this machine. You should know how the machine
works and how to immediately switch it off.
• Never let children use this mower. Never let adults work with this mower if not
properly trained.
• Do not let any persons, especially small children or pets near you while
mowing.
• Take care not to slip or fall while mowing.

8
9
PRODUCT SERIAL NUMBER:
You can nd this on the underside of your product
Thank you for choosing a Gtech Cordless Lawn Mower.
“I started Gtech to create sensible, easy to use products, which do a great job. Your
opinion is important to us. Please take the time to write a review of the Cordless Lawn
Mower at Trustpilot.co.uk.
We will use your feedback to improve our products and services and let other people
know what it’s like to be part of the Gtech family.”
Nick Grey – Inventor, Owner of Gtech
What’s in the box
2
1
3
4
5
6
7
8
9
10
10
11
12 5
6
7
4
3
Grass Box
Filling indicator
Charger
Starter Release Button
Activation Lever
Protective Flap
Cutting Height Adjustment
Handle Adjustment Button
Handle Latch Bar
Activation Key
Battery
State Of Charge Indicator
12
11
6
1
2

Ensure the front edges of the grass box
hook over the points at the back of
the mower.
Swing the handle back into the operating
position. There is no latch to undo.
Assembly
Holding the grass box by the green handle,
attach it to the back of the mower.
Lift the ap at the rear of the mower.
7

8
When in the correct position, the handle
will click into place.
Place the battery in the cradle on top of the
mower, base rst.
Pull the handle upwards until it clicks into
place. The mower will not start unless the
handle is fully extended.
Push the battery until it clicks into place.
Assembly

WARNING: To reduce risk of personal injury, wait for the blade to stop rotating
and remove the activation key before adjusting the cutting height.
1
2
3
4
5
6
Operating the Cordless Lawn Mower
9
When you press the lever to the handle,
the mower will start. When you release the
lever, the mower will stop.
To operate the mower, press and hold the
green saftey button and pull the lever under
the handle.
Adjusting the cutting height
The mower has 6 cutting-height settings
between 30mm and 80mm.
Note that settings 2 and 1 will scalp uneven
lawns and reduce your lawn’s resistance to
wear and drought.
To adjust the height, hold the lever rmly
and move it into the notch required.
When cutting on uneven ground, it is
suggested you test the cutting height on
a small patch of grass, to avoid cutting
too deep and creating bald patches.
30mm
50mm
60mm
70mm
80mm
40mm
For longer grass, uneven
ground and damp grass
For a healthy, level,
hard-wearing lawn
For very
level, ne
leaved lawns

10
The mower will not work without the
activation key, which is a safety feature.
Remove the key before you carry out any
maintenance, clear any grass, carry the
mower or put your hands near the blade.
To remove the key, pinch the top parts
together and pull the key out.
Removing the activation key
Using the Cordless Lawn Mower
Push the mower along at a walking pace
when mowing.
When the lling indicator ap opens it is
time to empty the bin. Note: If the bin over-
lls, the grass chute will clog and the ap
will close again. If the grass chute clogs
remove the battery and ensure the blade
has completely stopped spinning before
clearing the grass from the chute.

11
WARNING: To reduce risk of personal injury, wait for the blade to stop rotating and
remove the activation key before emptying the grass box.
Removing and emptying the grass box
Lift the ap at the rear of the mower and
hold onto the green handle attached to the
grass box.
Empty the grass cuttings from the
grass box.
Whilst still lifting the ap, pull the grass box
towards you to remove it from the mower.

12
WARNING:
Do not store the battery outside for prolonged periods of time over the winter months.
Place the battery onto the charging unit.
Plug in the charger and switch it on.
Charging the battery
To remove the battery push the release
lever in the handle to unlock the battery.
Then remove the battery from the cradle by
the handle.
While charging, the LEDs will progressively
pulse until all four are lit. When the battery
is fully charged the LEDs will turn off and
the charger LED will ash.
This should take up to 5 hours.

13
Collapsing the handle for storage
Stowing the handle
Fold the handle over the body of the
mower.
To release the handle, pull back the handle
latch bar.
To collapse the extended handle, depress
the green button on the mid cross-bar.
Whilst holding the green button down, push
the handle in.

Carrying the Cordless Lawn Mower
State of charge
To nd out how much charge there is in the
battery press the button in the centre of the
state-of-charge display. The number of lit
LEDs shows the charge.
Before carrying the mower, make sure the
activation key is removed to avoid starting
it accidentally. The easiest way to carry the
mower is by the middle carry handle and
the front of the mower.
There is a hand-hold under the front of the
mower.
14
100% -
60%
60% -
30%
30% -
10%
10% -
1%

15
Product Care
To ensure that your Cordless Lawn Mower gives you long and reliable service, carry out
the following maintenance regularly:
• Check for obvious defects such as loose, dislodged, worn or damaged blade, loose
xings, and worn, damaged, or loose parts.
• Check that covers and guards are correctly tted and undamaged.
• Always clean the cutting blade after use and apply a lubricating oil or spray
before storage.
• Before use check the condition of the cutting edges of the blade and that the blade
xings are secure.
• Do not use water, solvents, or polishes to clean the mower. Wipe clean with a dry cloth.
• Do not use abrasive materials to clean the product, and do not immerse it in water.
• Store in a secure, dry place, out of reach of children. Do not expose to moisture.
PLEASE NOTE: If the product needs to be repaired or replaced only use replacement
parts supplied by the manufacturer.
Spare parts can be purchased from Grey Technology Ltd:
tel : [phone] www.gtech.co.uk
Wear protective gloves when handling,cleaning or replacing the blade.
To reduce the risk of injury ensure that activation key is removed when the mower is
not in use, being transported, handled or stored.

16
Troubleshooting
Motor not running 1. Charge battery
2. Check activation key is inserted
3. Check switch operation
4. Check handle is fully extended
Irregular running, machine vibrating
strongly
1. Blade may be defective
2. Blade may be loose
Poor cutting /collection performance 1. Empty/unblock grass box
2. Charge/check battery
3. Cutting height may need adjusting
4. Blade may be blunt
Mower leaves cut grass on lawn 1. Check and clear the grass chute
2. Clean the bin fabric.
Struggling to cut / jamming 1. Push slower
2. Increase cut height
3. Check for a build up of grass
Charger ashing red (slow) Battery too hot. Allow to cool.
Charger ashing red (rapid) Battery fault. Call Gtech.
If this doesn’t solve your problem don’t worry, we will help.
Go to www.gtech.co.uk or call 01905 345 891
GTECH CORDLESS LAWN MOWER TECHNICAL SPECIFICATION
Voltage 36V
Battery capacity 4 Ah Li-Ion
Blade speed 3,700 rpm
Grass box capacity 40 litres
Charge time 5 hours
Cutting Width 430mm
Cutting height adjustment 30mm – 80mm
Protection type IP 21
Measured sound power level Lwa 91.0 dB(A) *K=2.19 dB(A)
Guranteed sound power level Lwa 96 dB(A)
Sound pressure level LPA 80.7 dB(A) *K=3 dB(A)
Vibration 0.53 m/s2 *K=1.5m/s2
Weight 16.95kg
Charger INPUT 100V-240V~50/60 HZ 50W
Charger output voltage 42V DC ---- 1A

17
WARRANTY – TERMS AND CONDITIONS
The warranty on your Cordless Lawnmower is 2 years from date of purchase.
If your Gtech Mower breaks, don’t worry, we’re here to help.
Go to www.gtech.co.uk or call 01905 345 891 for assistance.
WHAT ISN’T COVERED
Gtech does not guarantee the repair or replacement of the product as a result of:
• Normal wear and tear.
• Accidental damage, faults caused by negligent use or care, misuse, neglect, careless
operation or handling of the mower which is not in accordance with the mower
operating manual.
• Use of the mower for anything other than normal domestic garden purpose.
• Use of parts and accessories which are not Gtech genuine components.
• Faulty installation (except where installed by Gtech).
• If it is modied in any way.
• Repairs or alterations carried out by parties other than Gtech or its authorised agents.
• If you are in doubt as to what is covered by your warranty, please call the Gtech
Customer Care Helpline on 01905 345 891.
SUMMARY
• The guarantee becomes effective at the date of purchase (or the date of delivery if this
is later).
• The battery is covered by this guarantee.
• You must provide proof of delivery/purchse before any work can be carried out on
the cordless lawn mower. Without this proof, any work carried out will be chargeable.
Please keep your receipt or delivery note.
• All work will be carried out by Gtech or its authorised agents.
• Any parts that are replaced will become the property of Gtech.
• The repair or replacement of your Cordless Lawn Mower is under guarantee and will not
extend the warranty period.
• The guarantee provides benets which are additional to and do not affect your statutory
rights as a consumer.

18
The symbol indicates that this product is covered by legislation for waste electrical
and electronic products (EN2002/96/EC)
When the product has reached the end of its life please do not dispose of it with general
household waste. Consider the environment and take it to a recognised recycling facility.
The product contains a Li-Ion battery which should not be disposed of with general
household waste. The battery should be disposed of properly with the product at a
recycling facility.
Call your local council, civic amenity site, or recycling centre for information on the
disposal and recycling of electrical products.
Alternatively visit www.recycle-more.co.uk
for advice on recycling and to nd your
nearest recycling facilities.
Environmental and Product Recycling

19
EC Declaration of Conformity
We, manufacturer/importer
Grey Technology Ltd
1&2 Cupola Court
Spetchley
Worcestershire
WR5 1RL
declare that the product
CLM001 Cordless Lawn Mower
complies with the essential health and safety requirements of the following directives:
2006/42/EC - Machinery Directive
2014/35/EC - Low Voltage Directive LVD
2014/30/EC - Electromagnetic Compatibility Directive EMC
2011/65/EU - RoHS Directive
Technical documentation holder:
Grey Technology Ltd, 1&2 Cupola Court, Spetchley, Worcestershire, WR5 1RL
Standards and technical specications referred to:
EN 60335-1: 2012+A11:2014
EN 60335-2-77: 2010
EN 60335-2-29: 2004 /+A2:2010
EN 62233: 2008
EN 55014-1: 2006/+A1:2009/+A2:2011
EN 55014-2: 1997/+A1:2001+A2:2008
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 62321: 2009
2000/14/EC & Annex VI, 2005/88/EC
Measured sound power level Lwa 91.0 dB(A)
*K=2.19 dB(A)
Guaranteed sound power level Lwa 96 dB(A)
Notied body of Noise directive:
TÜV SÜD Industrie Service GmbH
Westendstrasse 199 • 80686 München • Deutschland
Notied Body number: 0036

Grey Technology Limited
Cupola Court, Spetchley, Worcestershire WR5 1RL
email: [email protected]
telephone: [phone]
www.gtech.co.uk
CPN0368
