GTRS S800 User manual

GTRSIntelligentGuitar
Owner'sManual
IntelligentGuitar
www.gtrs.tech
www.gtrs.tech

LAYOUT------------------------------------------------------------------------01
QUICK TOUR-------------------------------------------------------------------02
INSTRUCTIONS-----------------------------------------------------------03-04
GWF-4WIRELESSFOOTSWITCH--------------------------------------------05
CONTENT
www.gtrs.tech

GTRScontrolknob
6.35mmguitarline/headphoneoutput
USBType-Cport
Batterycompartment（ Utilizeneedletoopen
thebatterycompartment）
Lithium-ionbattery(GLP-1)（ Pleaseensurethe
GTRSlogoisplacedasshownwhenplacing
battery）
CostomGu itars
01
02
03
04
05
01
02
03
04
05
01
LAYOUT
www.gtrs.tech

QUICKTOUR
02 www.gtrs.tech
Step1:ConnectyourGTRSguitartoamplifierorheadphones
Step2:RotatetheGTRScontrolknobclockwisetoturntheguitaron.The
knobLEDwillindicateon/offstatus
Step3:PresstheGTRScontrolknobtoswitchbetweendifferentpreset
tones
Step4:RotatetheGTRSknobtoadjusttheoutputvolumeleveltoyour
preference

INSTRUCTIONS
03 www.gtrs.tech
GTRSAPP
TheGTRSAppfunctionsastheeditorsoftwarefortheGTRSguitar.Users
caneasilyselecteffectsandcreatepresetsfortheGTRSsystem,
downloadandsharetonestothecloud,andupdatethefirmwareof
theirGTRSguitar.Severaltoolsforpracticeareincludedintheappas
well.
1.GettheGTRSAPP
DownloadtheGTRSAppfromtheAppStore(iOS)orGooglePlay(Android).
2.Activation
OpentheBluetoothmenuofyoursmartphoneortabletandsearchfor“ GTRS”
toconnectyourguitarviaBluetooth.Afterconnecting,aQRcodescannerwill
displayintheapp.UsetheAPPtoscanthebarcodeonthelastpageofyour
owner'smanual,orthebarcodeonthepackage,tofinishactivationand
registration.TheserialnumberandwarrantyofyourGTRSguitarwill
automaticallyberegisteredaspartoftheactivationprocess.
*Notice:ThisprocedureisonlyforGTRSguitarswhichhavenotyetbeen
activated.Anactivatedguitarwillskipthisprocedure.Pleaseensurethe
GTRSguitarisonandyoursmartphonenetworkconnectionisstableduring
activation.
3.Guide
Clickthe“ ?”iconinthetoprightcorneroftheappscreentoaccessthequick
guide/manualoftheGTRSApp.
GTRScontrol
Presetswitch.YoucanassignthefunctionoftheGTRSknobwhilepressingit
shortly.
Presetswitch.YoucanassignseparatefunctionsandpresetsfromtheGTRSApp
bypressingandholdingdowntheknobforashorttime.
1.PresetMode
Presstoswitchbetweenfourdifferenttonepresets.ThecoloroftheLEDwill
changeinorderofdarkblue,purple,orange,andskyblue.

其他功能
Lowbatteryalert
Toprovidethebestexperienceforusers,theGTRSknobwillblinkslowlywhen
thebatterylevelisgettinglow.PleasechargeyourGTRSbatteryassoonas
possibletomaintainthebatterylifeofyourunit.
Charging
Thelithium-ionbatteryintheGTRSsystemcanbechargedthroughtheType-C
USBportfromthepowersupply.Whilecharging,theGTRSknobLEDwillturnred
nomatterwhichmodeitisin.AgreenLEDindicatesafullcharge.
04 www.gtrs.tech
Tuner
WhentheAPPorwirelessfootswitchisconnected,pressandholdtheGTRSknob
toaccessthetuner.TheGTRSknobLEDwillturnyellow.Presstheknobagainto
exitthetuner.
Charging Chargingcomplete
2.GuitarSimulationMode
Presstoswitchtheguitarsimulationon.ThepurpleLEDindicatestheguitar
simulationisonwhileskyblueindicatestheguitarsimulationisturnedoff.
3.TheguitarwillbegininPresetModebydefault.Youcanassigndefaults
through:GTRSAPP‒Settings‒Global-GTRScontrol.
INSTRUCTIONS

05 www.gtrs.tech
Wirelessfootswitch(purchasedseparately)
ThewirelessfootswitchcanbeusedwithGWF-4forbettercontrolofpresets
duringliveperformance.Pleaseseethewirelessfootswitchmanualformore
information.
Bluetooth
OpentheBluetoothmenuofyoursmartphoneortabletandsearchfor“ GTRS”
toconnectviaBluetooth.UserscanusetheBluetoothfunctiontoplayaudio
tracksfromamobiledevicemixedwiththeGTRSguitarsignalandsendthat
signalthroughthemainoutputoftheGTRSguitar.
LiveStream/DirectRecording
Toprovidethebestexperienceforusers,theGTRSknobwillblinkslowlywhen
thebatterylevelisgettinglow.PleasechargeyourGTRSbatteryassoonas
possibletomaintainthebatterylifeofyourunit.
TraditionalGuitarMode
IfGTRSisoff,orifthebatterylifeislow,theoutputsignaloftheguitarwillswitch
totruebypassandfunctionasatraditionalguitarwould.Onlythevolumeknob,
toneknob,andpickupswitchcanaffectthetoneoftheguitar.Inthismode,the
guitarcannotsupportheadphoneoutput.
GWF-4WIRELESSFOOTSWITCH

www.gtrs.tech
FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
