Guild PGB150G User manual

GUILD
150W 150mm Bench Grinder
Instruction Manual
Important - Please read these instructions fully before operating or maintaining your Guild bench grinder
These instructions contain important information that will help you get the best from your Guild
bench grinder, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
PGB150G
UK/Ireland 0333 3201989
[e-mail]

Customer Helpline 0333 3201989
2
Contents
Safety Information ����������������������������������������������������������������������������������������������������3
In The Box�����������������������������������������������������������������������������������������������������������������7
Accessories ��������������������������������������������������������������������������������������������������������������7
Assembly Instructions ����������������������������������������������������������������������������������������������8
Operating Instructions����������������������������������������������������������������������������������������������9
Maintenance ����������������������������������������������������������������������������������������������������������� 10
Trouble Shooting ����������������������������������������������������������������������������������������������������10
Working Hints For Your Bench Grinder�������������������������������������������������������������������10
Technical Data �������������������������������������������������������������������������������������������������������� 11
Environmental Protection���������������������������������������������������������������������������������������11
Guarantee��������������������������������������������������������������������������������������������������������������� 12
Declaration of Conformity��������������������������������������������������������������������������������������� 13
Plug Replacement (Uk & Ireland Only) �������������������������������������������������������������������14

Customer Helpline 0333 3201989
3
Safety Information
Important - Please read these instructions fully before starting assembly
Warning Symbols
The following warning symbols appear throughout this assembly manual and
indicate the appropriate safety measures you should take when assembling and
operating the bench grinder.
To reduce the risk of injury, Please read the instruction manual
Wear ear protection
Wear eye protection
Wear dust mask
Remove plug from mains before maintenance or if cord is damaged.
Waste electrical products must not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authorities or retailer for recycling advice.

Customer Helpline 0333 3201989
4
Safety Instructions
“WARNING! When using electric tools basic safety precautions should always be
followed to reduce the risk of fire, electric shock and personal injury including the
following.
Read all these instructions before attempting to operate this product and save these
instructions”.
Maintenance and Servicing
Remove the plug before carrying out any adjustment, servicing or maintenance
Safe operation
1 - Keep work area clear
- Cluttered areas and benches invite injuries.
2 - Consider work area environment
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area well lit.
- Do not use tools in the presence of flammable liquids or gases.
3 - Guard against electric shock
- Avoid body contact with earthed or grounded surfaces {e.g. pipes, radiators, ranges,
refrigerators).
4 - Keep other persons away
- Do not let persons, especially children, not involved in the work touch the tool or the
extension cord and keep them away from the work area
5 - Store idle tools
- When not in use, tools should be stored in a dry locked-up place, out of reach of
children.
6 - Do not force the tool
- It will do the job better and safer at the rate for which it was intended.
7 - Use the right tool
- Do not force small tools to do the job of a heavy duty tool.
- Do not use tools for purposes not intended; for example do not use circular saws to
cut tree limbs or logs.
8 - Dress properly
- Do not wear loose clothing or jewellery, they can be caught in moving parts.
- Non-skid footwear is recommended when working outdoors.
- Wear protective hair covering to contain long hair.
9 - Use protective equipment
- Use safety glasses.
- Use face or dust mask if working operations create dust.
10 - Connect dust extraction equipment
- If the tool is provided for the connection of dust extraction and collecting equipment,
ensure these are connected and properly used.
Safety Information
Important - Please read these instructions fully before starting assembly
Original Instruction
Original Instructions

Customer Helpline 0333 3201989
5
11 - Do not abuse the cord
- Never yank the cord to disconnect it from the socket Keep the cord away from heat,
oil and sharp edges.
12 - Secure work
- Where possible use damps or a vice to hold the work. It is safer than using your hand.
13 - Do not overreach
- Keep proper footing and balance at all times.
14 - Maintain tools with care
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by an authorized
service facility.
- Inspect extension cords periodically and replace if damaged.
- Keep handles dry, clean and free from oil and grease.
15 - Disconnect tools
- When not in use, before servicing and when changing accessories such as blades,
bits and cutters, disconnect tools from the power supply.
16 - Remove adjusting keys and wrenches
- Form the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17 - Avoid unintentional starting
- Ensure switch is in “off” position when plugging in
18 - Use outdoor extension leads
- When the tool is used outdoors, use only extension cords intended for outdoor use
and so marked.
19 - Stay alert
- Watch what you are doing, use common sense and do not operate the tool when you
are tired.
20 - Check damaged parts
- Before further use of tool, it should be carefully checked to determine that it will
operate properly and perform its intended function.
- Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
- A guard or other part that is damaged should be properly repaired or replaced by an
authorized service centre unless otherwise indicated in this instruction manual.
- Have defective switches replaced by an authorized service centre.
- Do not use the tool if the switch does not turn it on and off.
21 - Warning
- The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22 - Have your tool repaired by a qualified person
- This electric tool complies with the relevant safety rules. Repairs should only be
carried out by qualified persons using original spare parts, otherwise this may result
in considerable danger to the user.
Safety Information
Important - Please read these instructions fully before starting assembly
Original Instruction

Customer Helpline 0333 3201989
6
Original Instruction
Safety Information
Important - Please read these instructions fully before starting assembly
1. Do not use damaged or misshapen grinding wheels or brushes;
2. Use only grinding wheels recommended by the manufacturer which have a marked
speed equal to or greater than the speed marked on the nameplate of the tool;
3. Adjust the spark arrestor frequently so as to compensate for wear of the wheel, keep
the distance between the spark arrestor and the wheel as small as possible and in any
case not greater than 2 mm;
4. The grinder must be secured to a suitable work surface before use
5. For bench grinders and combined bench grinders equipped with straight-sided
flanges, the recommended values of the thickness T and the diameter of the hole see
the technical data;
6. For combined bench grinders, to always keep the brush assembled on the spindle in
order to limit the risk of contact with the rotating spindle.
7. Always wear eye protection and check that the eye shields on the grinder are properly
adjusted.
8. The adjustment of the spark arrestor shall be made frequently ,so as to compensate
the wear of the wheel, keeping the distance between the guard and the wheel as small
as possible, but in any case not greater than 2 mm.
9. The adjustment of the work rest shall be done gradually so as to compensate the wear
of the wheel, keeping the distance between the work rest and the wheel as small as
possible, but in any case not greater than 2 mm.
Bench Grinder Safety Warnings
23 - If the replacement of the supply cord is necessary, this has to be done by the
manufacturer or his agent in order to avoid a safety hazard.
24 - For tools intended to be connected to a water supply:
- Replacement of the plug or the supply cord shall always be carried out by the
manufacturer of the tool or his service organisation,
- Keep water clear off the electrical parts of the tool and away from persons in the
working area.

Customer Helpline 0333 3201989
7
In The Box
Parts
1
2
3
4
5
6
7
Work Rest
Grinding Wheel
Spark Arrester / Eye Shield Bracket
Eye Shield
Wheel Guard Fixing Screws
Mounting Holes
On/Off Switch
1
7
6
5
432
Accessories
Work rest 2pc
Eye shield 2pc
Grinding disk: Φ150 X 16 X Φ12.7mm left #36 1pc
Grinding disk: Φ150 X 16 X Φ12.7mm right #60 1pc

Customer Helpline 0333 3201989
8
Assembly Instructions
NOTE: Before using the tool, read the instruction book carefully.
1� ASSEMBLY
Before use, the eye shields/spark arresters must be fitted to the grinder.
Remove both eye shields from packaging, position the shields over the two mounting
brackets above the grinding wheels with the flanges of the spark arrester facing away from
you, fix with the screw and washer provided. At this stage do not fully tighten. (SEE FIG A)
The next step is to adjust the eye shields/spark arresters. To do this move the eye shields/
spark arresters so as to obtain a gap as small as possible between the arrester and the
grinder wheel, not greater than 2mm, the screw must now be fully tightened, ( SEE FIG B).
The gap must be maintained as the wheel wears.
2� WORK REST ADJUSTMENT
Take the work rest out of the package, fix on the grinder with the knob and washer provided
as shown in FIG C. The gap between the rests and the wheels should be checked before
use. Measure the gap between the grinding wheel and the rests; this should be as small
as possible not greater than 2 mm, if not, loosen the knobs on each of the rests, set the
correct gap and fully tighten. (SEE FIG D) The gap must be maintained as the wheel wears.
Max 2mm
Max 2mm
A B
C D

Customer Helpline 0333 3201989
9
Operating Instructions
1� OPERATING
Make sure grinder is securely mounted; mounting holes are provided in the base of the
grinder for this purpose, but the screws are not provided. Plug in the mains supply and
push the on/off switch right to the on position. Switch off and unplug the grinder when
not in use.
2� CHANGING GRINDING WHEELS (SEE FIG E)
To change the grinding wheels, first unplug from mains supply then remove the eye
shield brackets, then undo and remove the three screws holding the wheel guard
covers in place. Remove the cover. Undo and remove the two wheels retaining nuts
(a). You may have to hold the wheel and give the spanner a firm tap with a soft headed
hammer to release the nut, take off the large domed washer (b), paper washer (c) and
remove the wheels (d).
NOTE: The nut on the right side of the grinder has a standard right hand thread (turn
counter-clockwise to loosen). The one on the left side has a left hand thread (turn
clockwise to loosen).
Replace in same order, making sure both domed washers face correct direction, check
the paper washer(c and e), if damaged replace with new paper washer. Hold the wheel
and tighten the nut firmly but do not over-tighten.
NOTE: Only replace flanges with original items, these can be supplied through a
authorized dealer.
WARNING: OVERTIGHTENING CAN CRACK A GRINDING WHEEL�
E

Customer Helpline 0333 3201989
10
Trouble Shooting
Working Hints For Your Bench Grinder
Although your new bench grinder is really very simple to operate, if you do experience
problems, check the following:
1� GRINDER WILL NOT START
Check that there is “mains” at the socket; test with an electrical screwdriver or another
electrical appliance; check the connections in the plug; correct and tighten poor
connections; check the fuse; if suspect replace with correct rating.
2� WHEEL WOBBLES OR VIBRATES
Check that the lock-nut is tight. Check that the wheel is correctly located on the shaft and
locating washer. If excessive pressure has been used or the wheel has “caught”, it may be
damaged causing it to vibrate. If there is any evidence that the wheel is damaged, do not
use, remove it and replace with a new wheel. Dispose of old wheels sensibly.
3� WHEEL LEAVES ROUGH FINISH
Too much pressure on the wheel can cause a poor surface finish. If working with aluminium
or similar soft alloy, the wheel will soon become clogged and will not grind effectively.
There are no other users serviceable parts in your bench grinder.
Your bench grinder is useful for sharpening tools, e.g. drills, chisels; refacing tools, e.g.
removing burrs from tool edges; removing material, however this is not a heavy duty tool
and is designed primarily for light home and hobby use.
The two different types of wheel will allow the grinder to meet various needs. Typically,
use the coarse grinding wheel for rough cutting, i.e. removing a larger amount of material.
Use the medium wheel for finishing to leave a smoother surface.
If the grinder is used on soft metals such as aluminium, the wheel will soon clog and will
have to be changed.
At all times, let the grinder do the work, do not force it or apply excessive pressure to the
wheel/cutter.
Try to use the tool rest for supporting and guiding the workpiece. Do not grind using the
side cheeks of the grinding wheel as undue pressure on the side of the wheel could cause
the wheel to shatter.
Maintenance
Remove the plug from the socket before carrying out any adjustment, servicing or maintenance�
If the supply cord is damaged, it shall be replaced by the manufacturer or its service agent or
similarly qualified person in order to avoid a hazard.

Customer Helpline 0333 3201989
11
Technical Data
A weighted sound pressure LpA : 63dB(A)
A weighted sound power LwA : 79dB(A)
KpA & KwA=3.0dB(A)
Wear ear protection when sound pressure is over: 80dB(A)
Voltage 230 V-240V~50 Hz
Power input 150W S2 30min
No load speed 2950/min
Wheel size 1 Φ150 X 16 X Φ12.7mm left #36
Wheel size 2 Φ150 X 16 X Φ12.7mm right #60
Protection class I
Machine weight 4.90kg
Technical Data Table
Noise Information
Environmental Protection
Waste electrical products must not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authorities or retailer for
recycling advice.

Customer Helpline 0333 3201989
12
Guarantee
This product is selected for DOMESTIC USE ONLY and not for business use.
This product is guaranteed against manufacturing defects for a period of 24 months. This
does not cover the product where the fault is due to misuse, abuse, use in contravention of
the instructions, or where the product has been the subject of unauthorised modifications
or alterations, or has been the subject of commercial use. In the event of a problem with
the product within the guarantee period please return it to your nearest store. If the item is
shown to have an inherent defect present at the time of sale, the store will provide you with
a replacement. Your statutory rights remain unaffected.
Issue1 08/2015

Customer Helpline 0333 3201989
13
Declaration of Conformity
This Guild 150W 150mm Bench Grinder model number PGB150G fully complies with
the Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/
EC(before 2016/04/20) and 2014/30/EC(since 2016/04/20), RoHS Directive 2011/65/EU and
the following harmonized EU standards
EN 61029-2-4: 2011
EN 61029-1: 2009/A11:2010
EN 55014-1: 2006 + A1:2009 + A2:2011
EN 55014-2: 1997 + A1:2001 + A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
This declaration is made under the sole responsibility of Argos Ltd, 489/499 Avebury
Boulevard, Milton Keynes, MK9 2NW
Category Technical Manager signed
Issued 20/10/2015

Customer Helpline 0333 3201989
14
Plug Replacement (Uk & Ireland Only)
If you need to replace the fitted plug then follow the instructions below.
IMPORTANT
The wires in the mains lead are colored in accordance with the following code:
Blue = Neutral
Brown = Live
Green/Yellow=Earth
As the colors of the wires in the mains lead of this appliance may not correspond with the
colored markings identifying the terminals in your plug, proceed as follows. The wire which
is colored blue must be connected to the terminal which is marked with N. The wire which
is colored brown must be connected to the terminal which is marked with L. The green/
yellow wire to the earth terminal is marked with E or .
If a 13 AMP (BS 1363/A) Plug is used, a 13 AMP Fuse must be fitted, or if any other type
of plug is used a 13 AMP Fuse must be fitted, either in the Plug or Adaptor, or on the
Distribution Board.
Note: If a moulded plug is fitted and has to be removed take great care in disposing of the
plug and severed cable, it must be destroyed to prevent engaging into a socket.
