Guild T-Bird S-200 User manual

s-200 t-bird
USER GUIDE

B
C
G
H
I
D
E
F
MODE
1
MODE
2
VOLUME
VOLUME
TONE
TONE
A
A) Mode Selector Switch
Selects between Mode 1 and Mode 2
B) Mode 1 Volume
Master volume control in Mode 1 only
C) Mode 1 Tone
Master tone control in Mode 1 only
D) Low-cut Tone Capacitor On/Off
Engages a tone capacitor into the circuit for a brighter
sound in the up position.
E) Neck Pickup On/Off
Engages the neck pickup in the up position
F) Bridge Pickup On/Off
Engages the bridge pickup in the up position
G) Mode 2 Volume
Master volume control in Mode 2 only
H) Mode 2 Tone
Master tone control in Mode 2 only
I) Output Jack
the controls

mode 1
Mode 1 is selected when the Mode Selector Switch (A) is in the up position,
or toward the strings. This mode engages the neck pickup only, and is
controlled by the small volume and tone knobs closest to the vibrato assembly
(B & C).
Note that in Mode 1, all other controls are bypassed.
B
C
A) Mode Selector Switch
Selects between Mode 1 and Mode 2
B) Mode 1 Volume
Master volume control in Mode 1 only
C) Mode 1 Tone
Master tone control in Mode 1 only
A
MODE
1
MODE
2
Neck Pickup
mode 2
Mode 2 is selected when the Mode Selector Switch (A) is in the down
position, or away from the strings. This mode is much more versatile, adding
the three-switch panel into the circuit to engage each pickup and an optional
low-cut tone capacitor for added tonal options.
When using Mode 2, pickups are engaged at the three-switch panel – the
switch closest to the knobs (F) turns the bridge pickup on or off, the middle
switch (E) turns the neck pickup on or off, and the switch closest to the
headstock (D) turns the low-cut tone capacitor on or off.
The volume and tone of Mode 2 are controlled by the lower, larger “G Shield”
knobs furthest from the vibrato assembly (G & H). Note that in Mode 2, the
volume and tone knobs used for Mode 1 (B & C) are bypassed and do not
function.
A
MODE
1
Neck PickupBridge Pickup
MODE
2
A) Mode Selector Switch
Selects between Mode 1 and Mode 2
G) Mode 2 Volume
Master volume control in Mode 2 only
H) Mode 2 Tone
Master tone control in Mode 2 only
D) Low-cut Tone Capacitor On/Off:
Engages a tone capacitor into the circuit
for a brighter sound in the up position.
E) Neck Pickup On/Off:
Engages the neck pickup in the up
position
F) Bridge Pickup On/Off:
Engages the bridge pickup in the up
position
G
H
DEF

troubleshooting
no sound:
1. Turn volume knobs up
2. Use Mode 1
3. Use Mode 2 and turn on the Neck and/or Bridge
pickup switch
bridge pickup not working:
1. Switch to Mode 2
2. Turn Bridge pickup switch on
3. Turn Mode 2 volume up
low-cut tone not working:
1. Switch to Mode 2
2. Turn on Neck and/or Bridge pickup switch
3. Turn on Tone switch

Guildguitars.com
California USA
Copyright © Guild Guitars 2016
