Guillens DELFINO Installation and operating instructions

OPERATION
The spa will automatically begin to operate when electrical power is applied. There is no ON/OFF switch for the
spa system; do NOT apply power without first filling the spa with water.
Thecontrolsystemhasbeendesignedsothatbyconnectingthespatoitsproperlygroundedpowersource,itwill
begin to operate. The Status/Heat LED will light briefly. The pump will activate if the temperature of the water is less
than 65°F.
Control Panel
The Control Panel is easy to use with fingertip control of all the spa functions.
Temperature Control
To increase the temperature, turn the Temperature
Control Knob clockwise to the desired setting. To
reduce the temperature, turn the knob counter clock-
wise.
Function Control Button
PresstheFunctionControl Button onceandthelow
speed pump will operate. Press the button again and
both the low speed pump and spa light will operate.
Press the button a third time and the high speed pump
andspalightwilloperate. Pressthebuttonafourthtime
and the high speed pump will operate without the light.
Push the button again and the system will turn off.
Note: TheDefinoisnotfactoryequippedwithalamp
package.
Filter Cycles
Your spa will automatically filter itself twice a day.
During filtration, the low speed pump will activate. The
firstfiltercyclewillbeginonehourafterthespahasbeen
STATUS/
HEAT
WARM
STATUS/HEAT
INDICATOR
COOL
FUNCTION
CONTROL
BUTTON
OFF
LOW
LOW / LT
HIGH
•••
••••
•••••
•
••
HIGH / LT
TEMPERATURE
CONTROL
KNOB
energized. The second cycle will begin twelve hours
after the start of the first cycle.
Over Heat Protection
In the event the spa should overheat, the Status/
Heat LED will flash and the spa will shut down. If this
situationoccurs,turnoffallpowertothespaandcontact
your dealer or service organization. To reset the spa,
press the Function Control Button.
Flow Switch Detection
Ifthepressureswitchmalfunctions,theStatus/Heat
LED will flash. If this situation occurs, turn off all power
to the spa and contact your dealer or service organiza-
tion.
Open Sensor
If either the high limit or water temperature sensors
malfunction, the Status/Heat LED will flash. If this
situationoccurs,turnoffallpowertothespaandcontact
your dealer or service organization.
ADDENDUM
DELFINO OPERATION AND MAINTENANCE
(OVER)

©1996 Jacuzzi Whirlpool Bath K012000 9/96
MAINTENANCE
Water Level/Drain
The water level in the spa must be maintained at its
normal level. Evaporation and splashing will cause the
water level to drop.
When concentrations of impurities from evaporation,
water quality chemicals, body oils, perfumes, dirty feet,
wind,etc.,accumulateinthespaandcannotbefilteredout,
itisnecessarytodrainyourspaandrefillitwithfreshwater.
Thisshouldbedoneevery2monthsormoreoftendepend-
ing on the amount of use.
To drain the spa, turn all controls to OFF, then turn off
circuit breakers at the main electrical panel. Remove the
plug from the suction plumbing. You may at this time,
choose to install a hose bibb or permanently plumb in a
drain line and valve to a sanitary line. If you have installed
ahosebibb,connectagardenhosetothedrainvalve. Turn
the handle and drain the spa.
Afterdrainingthespa,cleanthespashellandthesuction
strainer and refill the spa with fresh water; then check the
pH level and maintain water quality.
WARNING: Removethesuctionstraineronlyforclean-
ing. Thestrainerisasafetydeviceandmustbeinplace
over the suction fitting to minimize potential hazard of
hair and body entrapment.
If heavy rains raise the spa water level, drain the spa to
its normal level.
A spa cover (available as an option), when in place over
the spa, will help reduce evaporation and control the
amount of debris entering the spa when the spa is not
occupied. In addition, its use will reduce energy
consumption.
Suction Strainer Maintenance
Thesuctionstrainer islocatedinthefootwellareaofthe
spa which can be pulled off easily for access to the suction
strainer. The strainer should be checked at least once a
week for collected debris, such as leaves, hair, etc., and
cleaned as necessary. Remove the center screw with a
Phillips screwdriver and clean the strainer by flushing with
water from a hose.
NORMAL WATER LEVEL
Printed on Recycled Paper Printed in the U.S.A.
WATER LEVEL
MARKER
