GUSH GP-1812 Q5 User manual

Gush GP-1812 Q5
18*12W 5in1 RGBWAPARCAN
User manual

2
TABLE OF CONTENTS
1. S af ety I nst r uctions ................................................................................ 2
2. Technical Specifications ....................................................................... 4
3. How To Control The Unit ................................................................. 5
4. Trouble shooting .................................................................................. 8
5. Fixture Cleaning .................................................................................. 9
statement
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also can not be responsible for any malfunction & problem owing to
ignore the manual.
1. S af ety I nst r uctions
Please keep this User Guide for future consultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.
 Unpack and check carefully there is no transportation damage before using
the unit.
 Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
 It’s important to ground the yellow/green conductor to earth in order
to avoid electric shock.
 The unit is for indoor use only. Use only in a dry location.
 The unit must be installed in a location with adequate ventilation, at

3
least 50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.
 Disconnect main power before replacement or servicing.
 Make sure there are no flammable materials close to the unit while operating as
it is fire hazard.
 Use safety cable when fixes this unit. DO NOT handle the unit by taking its head
only, but always by taking its base.
 Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the
temperature is higher than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hand during its operation. Turn off the power
and allow about 15 minutes for the unit to cool down before replacing or serving.
 In the event of serious operating problem, stop using the unit
immediately.Never try to repair the unit by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the
nearest authorized technical assistance center. Always use the same type
spare parts.
 DO NOT touch any wire during operation as high voltage might be causing
electric shock.
Warning:
 To prevent or reduce the risk of electrical shock or fire, do not expose the unit to
rain or moisture.
 DO NOT open the unit within five minutes after switching off.
 The housing, the lenses, or the ultraviolet filter must be replaced
if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing

4
or attempt any repairs yourself. In the unlikely event your unit may require
service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket.Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating.
And make sure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people and has no one pass by or under it.
2. Technical Specifications
Light Sources: 18 x 12W 5in1 RGBWA LED
Power Consumption: 216W
Power Voltage: AC 100-240V, 50/60Hz
Beam angle:25°/ 45°
Dimension:240x240x300mm
Packing Dimension: 870x590x340mm(6pcs/ctn)
Net Weight: 2.76Kgs
Gross Weight: 3.5Kgs
Control
DMX Channel: 8 Channel
Control Modes: DMX/auto run/master slave
Construction
Display: Digital panel

5
Data In/Out socket: 3-pin & 5-pin XLR sockets
Protection Rating: IP20
Features
Outstanding color macro effect ,fade and built in programs
Dimmer: 0~100% smooth dimming
The lumen derails like below:
25°
1m
3m
5m
R
lux
500
50
15
G
lux
1360
160
60
B
lux
2760
310
120
W
lux
2470
280
95
A
lux
1160
130
45
RGBWA
lux
6600
760
270
3. How To Control The Unit
Th e D M X512 is w id ely used in intellig ent ligh ti ng con tr ol,with a DMX 512
controller.connect several lights together,dmx in and dmx out,
3 pin XLR connectors : Pin 1: G ND , Pin 2: Nega tive s ign a l (-), Pin 3: P o s itive s i gna l
(+)

6
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
uP To go forward in the selected functions
ENTER To confirm the selected functions
Set DMX Address Code
1 Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter into
2 Show "Set DMX Address DMX Address:001",Press the "UPand DOWN"
keys to amended
3Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not save and
Exit
STAT
R000-R255
manual adjust red color from dark to bright
G000-G255
manual adjust green color from dark to
bright
B000-B255
Manual adjust blue color from dark to
bright

7
W000-W255
manual adjust white color from dark to
bright
A000-A255
manual adjust amber color from dark to
bright
S000-S255
Manual adjust strobe from slow to quick
AUTO
A00-A50
full color gradual change from slow to
quick
A51-A99
full color jump change from slow to quick
SOUND
SOUND
sound control
ADDR
A001-A512
dmx control mode adn set address code
DMX channel´s functions and values (8 DMX channels):
Mode/Channel
Value
Function
1
Red LED :
0-255
Red ( 0-Black , 255-100% Red )
2
Green LED :
0-255
Green ( 0-Black , 255-100% Green )
3
Blue LED :
0-255
Blue ( 0-Black , 255-100% Blue )
4
White LED :
0-255
White ( 0-Black , 255-100% White )
5
Amber LED :
0-255
Amber ( 0-Black , 255-100% Amber )
6
Dimmer intensity:
0-255
Intensity 0 to 100%
7
Shutter, strobe:

8
0-255
Strobe effect slow to fast
8
Rainbow:
0-127
Cross fading colors from slow to fast
28-255
Jumping colors from slow to fast
4. Trouble shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e
s o m e s ugg es tion s fo r eas y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Ch eck th e c onnect ion of p owe r a nd m a in fu se .
2. M eas ure th e m a ins volt a g e on th e m a i n conn e ct o r .
3. Ch eck th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X connectors, ca b l es to see if link
p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nnel, che ck th e a dd r ess
s etti ng s a nd D M X pol a r ity .
3. If you h a ve i nter mittent D M X s ign a l p r oble m s , che ck th e p ins on c onnecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Ch eck if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta g e c a b les th a t
m a y c a us e d a m a g e or in terfer ence to D M X inter face circuit.

9
C . One of the cha nnel s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a ged or the c a b le c onnect ed to th e PCB is
b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition.
5. Fixture Cleaning
Th e clean ing o f inter na l a nd ex ter na l optica l lens es a nd/or m irr ors m u s t b e c a rr ied
ou t p eriodica lly to optimiz e ligh t ou tput . Cle a nin g f r eq uency d e p end s on t h e
environment in w hich t h e f ixture ope r a tes : d a mp , s m oky o r p a r tic ula r ly d ir ty
s urr ounding c a n c a us e g r eat er acc um ula tio n of d irt on th e u nit’ s optics .
 Cle a n with s oft clo th u s ing no r m a l g l a ss clea ni ng fluid .
 A lw a y s d r y th e parts ca r ef ully .
 Cle a n th e ex ter na l optic s a t leas t ev ery 20 days. Cle a n th e in ter na l opti cs a t
lea s t ev ery 30/60 days.
